HireTech HT7 User manual

SPECIFICATION
This machine is suitable for use in sanding into the edge of areas not
accessible to a drum sander and for small floor areas
Power Supply: Electric Motor 240v.
Sending Disc: 7" Diameter
Noise: 100 dBa at 1m (3’3”)
Motor: Continuous heavy duty AC self-cooling
4 Brush
IMPORTANT
PLEASE READ CAREFULLY
This machine is hired under terms & conditions of the Hire Contract.
No liability will be accepted for any damage caused to persons or
property through failure to observe operating and safety instructions.
A charge will be made for any damage caused to the machine
through misuse or failure to comply with operating instructions.
Hirers are also reminded that they are liable for the replacement cost
of any machine & accessories, lost or stolen.
BE SECURITY WISE - DO NOT TAKE ANY CHANCES
E&J HIRE
Tel: [phone]
Mobile: [phone]
Online catalogue: www.ejhire.co.uk
EDGING SANDER
Model HT7 – 240V
CHECK THAT MACHINE SWITCHED OFF BEFORE PLUGGING IN
SAFETY NOTES
¾We strongly recommend using a residual current device with this
machine.
¾DO NOT expose machine to rain, or allow any contact with moisture. It
must be operated and stored in a dry environment.
¾CHECK that the operating voltage is correct before plugging in and that
any extension cables you supply / use, are in good condition / sufficient
rating.
¾DO NOT carry the machine by, pull on, or stress the power cable.
¾NEVER ALLOW children or anyone uninstructed to operate the machine.
KEEP ALL CHILDREN & PETS AWAY FROM MACHINE AND WORK
AREA.
¾ALWAYS SWITCH OFF and remove plug from socket before fitting
sanding discs, or cleaning etc.,
¾RECOMMENDED SAFETY WEAR facemask & ear defenders.
¾NEVER try to operate machine unless a sanding disc is fitted or continue
using with a damaged / worn disc.
¾STOP MACHINE IMMEDIATELY any damage to sanding disc or
machine is suspected.
¾ALWAYS renew dust bag before it is full:
Accumulations of mixtures of wood dust, previous finishes &
chemicals are liable to spontaneous combustion.
¾NEVER empty contents of bag into an open fire or incinerator as
explosive.
BE extremely careful that you do not sand over the power cables. If
suspected power cable damage, SWITCH OFF AND UNPLUG before
inspecting.
IF A FAULT develops; do not attempt any to repair.
Contact E&J HIRE Tel: [phone]

ATTACHMENT OF ABRASIVE DISC
1. Ensure that the operating switch is “OFF” and the plug is disconnected from
mains supply.
2. Turn the machine over so that it is standing on its head (fig. i) to give access
to the underside.
3. Remove the disc attachment bolt (anti-clockwise) with the key provided, and
remove used disc. (Fig. 1).
4. Centre replacement disc on backing pad, replace bolt and tighten firmly. (Do
not have more than one disc on machine at any time.)
5. Spin disc by hand and check that it is correctly centred.
OPERATION
1. Tilt the machine back on its castors and switch "ON" (Fig. 2).
2. Lower the machine so that the disc is in contact with the floor and keep
moving the machine back and forth with a SLOW SWEEPING movement.
The disc guard (Fig. 2) may be "ROLLED" along the skirting board to enable
the sanding action to be taken to the edge of the floor area.
3. Keep the machine in motion at all times when the disc is in contact with the
work surface. DO NOT press down; the weight of the machine is sufficient to
give a score-free finish.
OPERATING HINTS
1. Use the machine slowly and steadily; follow along the wood grain wherever
possible.
2. During sanding operations it is advisable to close the doors and cover any
gaps around the door. Open the windows. Wear a dust mask.
3. Never leave the machine stationary with the disc revolving on the work
surface. This will cause gouging of the surface and so spoil the finish.
4. Best results are obtained when using the machine by kneeling down on one
knee, which will give positive control and avoid backache.
