Hisense MR6DE Instruction manual

Bar code

RSAG2.025.8717SS English
QUICK START MANUAL

1. Declaration............................................................................... 1
2. Introduction.............................................................................. 4
2.1 Package Contents............................................... 4
2.2 Products View..................................................... 5
2.3 Remote Control................................................... 7
2.4 Low Blue Light Mode........................................... 9
3. Installation Guide .................................................................. 10
3.1 Wall Mount Kit Specifications (VESA) ................10
3.2 Installing the OPS (Optional) ..............................11
4. Making Connections ............................................................. 13
5. Getting Started....................................................................... 18
5.1 Power On/Off.....................................................18
5.2 Five-finger menu................................................19
5.3 Sidebar .............................................................20
6. Serial Protocol ....................................................................... 21
7. Appendix ................................................................................ 23
7.1 Specification......................................................23
7.2 Other Information...............................................26
7.3 Certification and Compliance..............................28
7.4 EU Declaration of conformity (DOC) ...................30
8. Troubleshooting .................................................................... 36
Contents

1MR6DE User Manual
Declaration
Any content and service accessed through this device, while only intended for individual non-
commercial use, shall be the property of the applicable third party and subject to protection by
regulations and laws on copyright, patent, trademark and other intellectual property rights. No
part of such content and service may be modified, duplicated, published, uploaded, distributed,
translated, marketed, or used to make and distribute products derived from it without the prior
permission of the content owner or service provider.
You acknowledge and agree explicitly that you will solely bear the risk associated with the use of
this device, and further you will solely bear any risk related to satisfactory quality, performance
and accuracy for any content and service accessed through this device. To the maximum extent
permitted by applicable law, this device and any third party’s content and service is provided as it is
without any guarantee, express or implied.
Manufacturer hereby declare explicitly that Manufacturer shall not be held liable for any guarantee
and conditions, express or implied, related to this device and any content and service, including
but not limited to warranty on marketability, satisfactory quality, fitness for a particular purpose,
accuracy, quiet use and non-violation of any third party’s rights; to the maximum extent permitted
by applicable law, Manufacturer gives no guarantee on the accuracy, validity, timeliness, legitimacy
and completeness of any content or service provided through this device, or the fitness of such
device, content or service for your particular requirement, or the protection from interruption and
error during operation of such device, content or service; to the maximum extent permitted by
applicable law, in any case, including fault or neglect, Manufacturer shall not be held liable for
legal actions or indemnity obligation arising from any consequence as a result of or related to any
information loaded in this device or use of such device, content or service by you or any third party
.
Any content and service provided as it is together with this device shall be the property of the
applicable third party, therefore Manufacturer gives no declaration or warranty on modification,
suspension, cancellation, termination or abortion thereof, and shall not be held liable for legal
actions or indemnity obligation arising thereof.
Manufacturer reserves the rights to restrict the use or access of certain content or service. As
the content and service are transmitted through third party’s network and transmission facilities,
Manufacturer undertakes no customer service thereof or the obligation for such customer service.
ɋStatementɌ
The pictures and instructions in this user manual are for reference only, and may be different
from the actual product. Please subject to the actual product. (This statement is throughout
this User Manual)
Declaration
1. Declaration

2 MR6DE User Manual
Disposal of Used Electrical & Electronic Equipment
Packaging and electrical goods should be recycled appropriately, and not treated as
household waste. Please dispose of this equipment at your applicable collection point
for the recycling of electrical & electronic equipment waste. By ensuring the correct
disposal of this product, you will help prevent potentially hazardous to the environment
and to human health, which could otherwise be caused by unsuitable waste handling
of this product. The recycling of materials will help conserve natural resources.
Please do not therefore dispose of your old electrical and electronic equipment with
your household waste. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or the
shop where you purchased the product.
Class I product: This symbol indicates that it requires a safety connection of protective
earthing (ground).
Important Safety Precautions
Water and Moisture
Avoid dripping or splashing of liquids onto the product. Objects filled with liquids, such as vases,
should not be placed on the product.
Object and Liquid Entry
Never push objects of any kind into this device through openings as they may touch dangerous
voltage points or short-out parts that could result in fire or electric shock. Never spill liquid of any
kind on or into the device.
Safeguards
The device set may fall, causing serious personal injury or death.To prevent
injury, this device set must be securely attached to thewall in accordance
with the installation instructions.
Warning!
Stability Hazard
Environmental conditions
Operating temperature: 0°C~40°C
Operating humidity: 10%~80%RH
Atmospheric pressure: 86kPa~106kPa
Declaration

3MR6DE User Manual
Heat
The product should be situated away from heat sources such as radiators, heat registers, stoves,
or other products (including amplifiers) that produce heat.
Fire
The product should be situated away from naked flame sources such as lighted candle.
Wall
Precautions for Installation
As shown in the figure below, leave a ventilation space around the device.
Please leave this space
around the device.
When mounted on the wall:
Do not install the device as shown below.
Hinder air circulation
Insufficient ventilation will overheat the device and may
cause damage to the device and even fire.
Start Guide
Declaration
Incorrect replacement of the battery may lead to the risk, including the replacement of
another similar or the same type. Do not expose batteries to heat such as sun or fire or
something like that.
The device should not be exposed to dripping and spraying and it cannot be placed under
objects filled with liquids.
MAIN plug on the power cord is used as the disconnect device, the disconnect deviceand
socket-outlet shall be easily accessible.
Apparatus with CLASS I construction shall be connected to a MAINS socket outlet with a
protective earthing connection.

4MR6DE User Manual
Introduction
Stylus × 2 Remote Control
Battery × 2
Wireless Cast (Optional)
User Manual of the Device Wall Mount Bracket (Optional)
Wall Mount Bracket
Accessories bag (Optional)
User Manual of Wireless
Cast × 1 (Optional)
Power Cord (It depends on the
models, regions, or countries.)
NOTE
7KHDFFHVVRULHVPD\EHGLႇHUHQWIURPWKHOLVWDERYHGXHWRGLႇHUHQWPRGHOVFRXQWULHV / regions, please refer to
the actual accessory bag.
2. Introduction
2.1 Package Contents
MR6DE or MR6DE-E × 1

5 MR6DE User Manual
Introduction
2.2 Products View
2.2.1 Front Panel | Control Panel
Number Item Description
1 NFC When the mobile phone touches the device, it can achieve screen sharing
through mobile phone NFC function.
2 USB
It is a USB interface, which can be used as the media playback interface
of the device and the USB interface of embedded OPS module. It is also
the USB used to syncronize the USB-A dongle.
3HDMI
IN
The front HDMI interface allows digital audio and video signals to be
transmitted using a single cable without compression. HDMI supports multi-
channel digital audio, and can be connected to external devices with HDMI
port, such as computer host, set-top box, Blu-ray player, A/V device, etc.
4 Type-C
,WLVDIXOOIHDWXUHG7\SH&LQWHUIDFHZKLFKVXSSRUWVDXGLRYLGHRDQG¿OH
transmission. Support 65W PD quick charge and support the following
VSHFL¿FDWLRQV9$9$9$9$9$
5Standby
button
:KHQWKHGHYLFHLVRQVKRUWSUHVVWKHEXWWRQWRWXUQRႇWKHVFUHHQORQJ
press the button to go into standby mode.
:KHQWKHVFUHHQLVRႇSUHVVWKHEXWWRQWRRSHQWKHVFUHHQDQGZKHQ
the device is on standby, press the button to start.
The indicator light displays the state of power on or standby:
:KHQWKHGHYLFHLVRQWKHOLJKWLVEOXH.
:KHQVWDQGE\WKHOLJKWLVUHG
:KHQWKHGHYLFHZLWK236PRGXOHLVWXUQHGRQWKHOLJKWLVJUHHQ
:KHQ05'(GRHVQRWFRQQHFW236:3'TXLFNFKDUJHLVVXSSRUWHGZKHQ05'(FRQQHFWV236
65W PD quick charge is not supported. When 75MR6DE and 86MR6DE connect OPS, 65W PD quick charge is
supported.
Type-C
DC5V 1A(MAX)
USB
USB Type-C
HDMI IN
DC5V 1A(MAX)
12 3 4 5
MR6DE: MR6DE-E:
USBUSB Type-CType-C
DC5V 1A(MAX)DC5V1A(MAX)

6MR6DE User Manual
Introduction
2.2.2 Rear Panel | I/O Panel
1
2
4
5
6
2
3
LANTOUCH
USB
DC 5V 1A(MAX)
HDMI OUT
LINE OUT HDMI IN 2
HDMI IN 1(eARC)
Number Port Description
1 LINE OUT Audio out to Headphones
2 HDMI IN HDMI signal input, connect to PC with HDMI output port, set-
top box, or other video device
3 HDMI OUT HDMI signal output, connect to an external device with HDMI
input port
4 LAN Standard RJ45 Internet connection interface
5 TOUCH Touch signal output to external PC
6 USB 3.0 Connect USB devices such as hard disks, keyboard, mouse,
etc
7 RS232-1/RS232-2 Serial interface, used for mutual transfer of data between
devices
8DIGITAL AUDIO
OUT
Connect to power amplifier via coaxial port, then connect
SRZHUDPSOL¿HUWRVSHDNHU
9 LINE IN Input of audio signal
8 9
DIGITAL
AUDIO OUT LINE IN
RS232-1 RS232-2
RS232-1 RS232-2
7

7MR6DE User Manual
Introduction
2.3 Remote Control
Number Description
1Power
Enter/exit standby
2Souce
Switching signal source
3Ÿ
Ÿ
Move focus up/down
Ÿ
/
Ÿ
Move focus left/right
4Back
Back to previous menu
5Volume down (-)
6Mute
Activate/exit mute state
7Setting
Open the Settings menu
8Blank
6ZLWFK2Q2ႇVFUHHQ
9OK
&RQ¿UPRSHUDWLRQ
10 Freeze
Once click: Keep the current screen
(When in the wireless screen
transfer state)
11 Home
Enter home page
12 Volume up (+)
1
2
3
4
5
7
10
11
12
6
8
9

8 MR6DE User Manual
Introduction
Battery replacement method
1. Disconnect the battery cover from the remote control at the battery cover buckle and open the
battery cover.
2. Insert two AAA 1.5V alkaline batteries. Note that the positive (+) and negative (-) terminals of
the batteries must match the positive (+) and negative (-) terminals in the battery case.
3. Close the battery cover from top to bottom until it is fully aligned with the remote control.
Precautions
1. If the remote control is not working properly, is unstable, or can’t control the device, please
replace the batteries.
2. If you do not use the remote control for a long time or the battery is exhausted, remove the
battery. (Waste batteries pollute the environment and must be handled properly.)
3. In order to achieve the best remote control effect, please point the black launch window on the
back of the remote control at the indicator light of the device.
4. Discard batteries in a designated disposal area. Do not throw them into a fire.
5. Remove old batteries immediately to prevent them from leaking into the battery compartment.
6. Battery chemicals can cause a rash. If the batteries leak, clean the battery compartment with
a cloth. If chemicals touch your skin then wash it immediately.
7. Do not mix old and new batteries.
8. Do not mix alkaline, standard (carbon-zinc) or rechargeable (NiCd, NiMH, etc.) batteries.
9. Do not continue using the remote if it gets warm or hot.
10. If any of these issues occur, call our Support Center immediately on the support website.
Effective range
1. Remote control distance: The distance from the front of the remote control is valid within 8m.
2. Remote control angle: With the remote control receiving window of the device as the apex,
the angle in horizontal direction at the distance of 6m is at least ±30°, and the angle in vertical
direction is at least ±15°.

9MR6DE User Manual
Introduction
2.4 Low Blue Light Mode
The low blue light mode reduces the risk of blue light to the human body by reducing harmful blue
light.
How to enter low blue light mode?
The homepage-> "Setting"-> "Image"-> “Eye protection mode"-> open.
[Description]
The machine can meet the requirements for low blue light certification only if the eye protection
mode is turned on in the factory default state.
Proper rest and exercise has proven to be effective in reducing eye fatigue.
To relieve eye fatigue and protect your health, we recommend:
-Taking breaking frequently during viewing the screen
-Increasing outdoor activities
-Overlooking distant objects
-Doing eye exercises
-The optimal viewing distance is 3 times the vertical height of the display screen

10 MR6DE User Manual
Installation Guide
3.1 Wall Mount Kit Specifications (VESA)
3. Installation Guide
B
A
NOTE
Do not use screws that are longer than the standard dimension, as they may cause damage to
the inside of the display.
Model VESA Spec. (A × B) Standard Screw (C × D) Quantity
65MR6DE 600 × 400mm M8 × 25 4
75MR6DE 600 × 600mm M8 × 25 4
86MR6DE 1000 × 600mm M8 × 25 4
D
C

11 MR6DE User Manual
Installation Guide
3.2 Installing the OPS (Optional)
Before installing and operating OPS, it is required to carefully read the instructions that come with
OPS computer and this instruction manual.
Installation Sequence
1. The touch screen is set to the "off" state, and the indicator light is off.
2. The operator wears anti-static gloves and takes out OPS computer.
3. Assembly steps for OPS computer:
(1) This product is compatible with OPS-C Plus interface computer, and assembly instructions are
as follows:
Note: Different models of touch screen and computer brackets have different shapes, but the
assembly method is the same.
Touch
Screen
(back side)
OPS-C Plus
computer
Computer bracket OPS-C Plus plug-in terminal
Connecting screws for computer bracket and
computer
Two M3x6 black screws
1
Assembly diagram of
OPS computer
2
ķis located at the computer bracket and the connecting screw of computer, which can be matched
withĸ .
ĸ It is the hanging nose, where OPS-C Plus computer is assembled with fastening screws.
There are a total of two hanging noses, which are placed in OPS-C Plus computer package as an
accessory and there is need to assemble them on OPS-C Plus computer in advance.
Before assembling the computer, please check the shape of OPS-C Plus plug-in terminal, which
should meet the requirements in the following Figure:

12 MR6DE User Manual
Installation Guide
B
A
|A-B|PP
Instructions for OPS terminal assembly
tolerances
(2) Instructions for assembly routes:
a. Place the touch screen vertically or place the touch screen face-down stably, and make sure
there is enough room for operation around the computer bracket on the back of screen.
b. Remove M3x6 screw reserved at ķfor standby application.
c. Insert OPS-C Plus computer into the computer bracket along the route as shown in the
Figure until ĸand ķare in close contact.
d. Apply spare screws M3x6 to fasten the computer (some computer models come with screws
WKDWFDQEHXVHGGLUHFWO\WLJKWHQLQJWRUTXH1P01P
(3) The pattern after assembly is as follows:
Computer bracket
Touch Screen
(back side)
OPS-C Plus computer
Schematic diagram after the
assembly of OPS-C Plus computer
(4) Precautions after assembly:
a. After the computer is installed, ĸand ķshould be closely fitted (same on the left and right
sides).
b. Screws are firmly and securely fastened. The computer doesn't shake.
4. After the above steps are completed, screen can be switched on. After startup, OPS computer
is started, and the operating system interface is performed to confirm that there is no abnormality.
The first startup is completed.

13 MR6DE User Manual
Making Connections
Connect to external audio device
Digital audio output: connect to power amplifier via coaxial port, then connect power amplifer to
speaker.
Device port &RQQHFWSRZHUDPSOL¿HUWRVSHDNHU
3RZHUDPSOL¿HU Speaker
Coaxial port
Connect to HDMI output
Connect the HDMI output connector of the device to the HDMI input port of an external device.
NOTE
When using it as a screen monitor, carefully read precautions for still image of the device.
VCR/Screen monitor
HDMI
HDMI in
Device port
HDMI OUT
Connect to HDMI input
Connect the HDMI input connector of the device to the HDMI output port of an external device.
NOTE
The supported signal formats of the HDMI port refer to Specifications.
It is recommended that HDMI2.0 4K HD wire should be used. The wire length should be less
than 10m. When using other non-standard wires, malfunctions caused by signal transmission
problems attributable to the wire quality problem may occur.
Set-top box/player/PC/DVD
HDMI
HDMI out
Device port
HDMI IN
4. Making Connections
Connect to TOUCH interface device
It is the touch screen interface used for an external PC as touch host. In the HDMI channel, the
device is used as a touch unit by default
When connecting, USB cables not longer than 1 meter should be used to connect with the
external PC.
Device port
TOUCH
USB
PC

14 MR6DE User Manual
Making Connections
Setting of the touch and audio & video return transmission function
When you need to use an external PC as the touch host, audio & video host and signal source
host, setting can be achieved by the following two methods.
Method 1. Connect the main screen and PC with one full-functional Type-C wire and switch the
signal source to Type-C channel.
Method 2. Use one Touch-USB (one end is type-B male connector, and the other end is type-A
male connector) connecting wire and one HDMI signal wire for connection. Touch-USB wire
connects the Touch port on the main screen side and the USB port of the PC. HDMI signal wire
connects the HDMI port of the main screen and the PC, and the signal source is switched into
the corresponding HDMI channel.
After setting, the external PC can be operated via the touch screen. The external PC can also
invoke the camera and microphone of the main screen.
NOTE
It is recommended that full-functional Type-C wire certified by USB-IF Association should
be used. The wire length should be less than 2m. When using other non-standard wires,
malfunctions caused by signal transmission problems attributable to the wire quality problem
may occur.
Connect to a USB interface device
The total current of all the USB output ports of the device when connected to external devices
at the same time mustn’t exceed 3000mA, or else the device failure caused by overcurrent isn’t
covered by the warranty.
NOTE
This device is connected to wireless keyboard and mouse devices. If there is any insensitivity
phenomenon during use, you can try to change the wireless receiver to another USB port, or
use a USB extension cord to connect the wireless receiver in order to enhance the receiving
range.
External device
Device port
USB
DC 5V 1A(MAX)
LINE OUT Connect Headphone for audio out of the screen.
NOTE
Please make sure that the headphones you plug in is without microphone function, or it may not
be supported.
Headphones (not included) ATTENTION
Excessive sound pressure from
earphones and headphones can
cause hearing loss.
LINE OUT
Device port

15 MR6DE User Manual
Making Connections
Enter the Settings menu and select the Network item.
WIFI
The device can receive network signals directly through a Wireless router
The available wireless network list is automatically displayed when WIFI is selected.
Select an available network, enter the password, and tap Connect. If the selected network is
not encrypted, you can connect directly.
If the network you want to connect to is not displayed in the list, tap Refresh to display more
networks. If the network you want is still not displayed after this operation, tap Add Network and
enter the network name manually, select the corresponding encryption method according to
router settings, enter the password, and tap Confirm.
Ethernet
(WKHUQHWDXWR
The device automatically obtains an IP address and connects to the network. If failure, repeat
the operation again or choose Ethernet:manual.
(WKHUQHWPDQXDO
Manually enter the IP Address, Subnet Mask, DNS Server and Gateway.
Wireless router
Network port Network port
in the wall
Device port
Router
Network port output Network port input Network port
in the wall
Connect to a network
Connect to the OPS interface device
OPS (Open Pluggable Specification) is the interface specification developed by INTEL which
is applicable to embedded computer module products. With this interface, the screen can be
connected to the device in compliance with OPS interface specification, which is short for OPS
module. You can buy the module and conduct secoondary development in accordance with
your requirements.
This product can provide the OPS module with 18V±0.5V (4.74A MAX) power supply.
NOTE
After installing OPS module, when the signal source is in computer channel, device touch
screen regards OPS as the touch unit by default. After TOUCH is connected with an external
computer, the external computer is used as the touch unit. At this time, the signal source should
be switched to the channel of the external computer for using the touch functionality.

16 MR6DE User Manual
Making Connections
You should purchase the OPS module which is applicable to the size of the device OPS. The
size of OPS refers to the following figure:
[Instructions]
After installing the OPS module, when the signal source adopts the computer channel, the
touch screen of the complete machine uses OPS as the touch host by default. After Touch
connects the external computer, the external computer serves as the touch host, and the signal
source should be switched to the display channel of the external computer for touch.
To guarantee stable operation of the complete machine and the OPS module, please purchase
the right type of OPS module. Otherwise, the OPS module cannot work normally because the
failure to adapt structures and software.
Switching on/off the OPS
After inserting OPS to the device, you turn on the device, change the signal source to enter
OPS and stays on the OPS syetem interface. When you turn off the device, you should use the
standby button to go into standby mode, the OPS module is switched off, and then you shut off
the device.

17 MR6DE User Manual
Making Connections
Connect to RS232 port
This machine contains two Internet access-type RS232 ports, i.e. RS232-1 and RS232-2.
Development should apply the adapter cable for conversion from Internet access to DB9 female
head. Secondary development should be performed according to the user’s protocol to realize
serial port control of this machine.
TX/RX wire sequence inside RS232-1 port and RS232-2 port of this machine is different. The
requirements for sequence of the connecting wire for conversion from Internet access to DB9 is
shown in the following table:
RS232-1
Internet access end P1 Connecting wire DB9 female head P2
Pin3-GND - Pin5-GND
Pin5-TX - Pin2-RXD
Pin8-RX - Pin3-TXD
RS232-2
Internet access end P1 Connecting wire DB9 female head P2
Pin3-GND - Pin5-GND
Pin5-RX - Pin3-TXD
Pin8-TX - Pin2-RXD
Device port
34
PC
1
1
