Hitachi SS-485P Operating and safety instructions

SS-485P Pan & Tilt
Setup and Installation Manual
September 1997
Software Version
3.5
Distributed By
Hitachi Denshi America Ltd.
150 Crossways Park Drive
Woodbury, NY 11797
516-921-7200
MANUFACTURED By
WESTLAKE TECHNICAL PRODUCTS
ddd
BIG BEAR LAKE, CA 92315
818-481-2590
[e-mail]
Manufactured By
Westlake Technical Products
2821 Erwin Ranch Road
Big Bear City, Ca 92314
818-481-2590
[email protected]

Please Read First!
The Warranty Period provided for all SS485P Pan & Tilts manufactured by
Westlake Technical Products and sold by Hitachi Oenshi has expired!
The last production run
of this product was late in 2002. This makes
the newest
of these units at least Ten (10) years old and the first units
almost twice that old.
There are over 2,350 SS485P Pan & Tilts in service some where in the
world. Not much ever breaks or wears out. Sometimes a belt comes
loose or motor contacts need to be cleaned because of lack of use. This
is usally fixed by just running it back and forth to clean the contacts.
With occasional preventative maintenance, a little oil and cleaning
these units should continue to provide their owners reliable service for
many, many more years.
One thing must be considered -Microcontroller Backup Battery Oepletion:
The OS5000 Microcontroller manufactured by Oallas Semiconductor was
used to control the SS485P. This component is a highly Integrated Circuit
( IC ) which is so reliable we have delivered it in
over Ten Thousand
Industrial, Commercial, and Consumer products which are in use all over
the world. The OS5000 Microcontroller's Application Software, Setup
Parameter, and Preset Location Memory are stored inside the OS5000 and
protected by a Lithium Battery which is inside the Microcontroller itself.
The Rated Battery Life by the manufacturer is Ten (10) Years.
As
of this writing, all SS485P Pan & Tilts are older than Ten (10) Years.
To assure you will not loose any Application Software or Setup
Parameters because of a Depleted Battery the 056000 should be replaced.
If you wish to do this yourself, you can download the instructions, the
application software and even purchase the OS5000 on our web site at:
http://www.westlaketechnical.com/SS485P
If you wish to purchase a new OS5000 with the Application Software
already loaded and tested you can also make this purchase on our web
site. We will include instructions on how to replace the Microcontroller.
You can also send the unit to us for this or any required service work...
Service Parts and Product Service Support can be obtained from:
Westlake Technical Products I westlaketechnical.com
[phone] -
[email protected]
2821 Erwin Ranch Road, PO Box 254, Big Bear City, CA 82314

Table of Contents
SECTION
PAGE
Specifications .. . ................ ... ... ... .. ...... ................................. .. ..... .. ........... 4
Standard Composition .......... . ........ .... .......... ... .. .. ... ..... ... .. .. .... . ........ . .... .. ... .. 4
Acce sories ................... .. ....... . ..... .. ... ....... . ....... .... ... ........ ..... .. .... ..... .... ..
4
Mechanical Drawing .. ......... ... ..... .... ... ..... ...... .... ........... .... .... ... .... .. ............ 4
Connector Identificati on .. . .. . ..... ... .......... . .... ... ...... ... ................................ ....5
B lock Diagram ......... ............. .. ..... .. ... .... ......... ... ... .. .... . ...................... ...... 5
1. Precautions ......... ... ...... .... .. ... ... .... .... .. ... .... ... .. . ... .............. ... . ... ........ ...0
2. Sy ste m Requ ir6ments... ... ... .... ....... ... ... . ...... . ... .. .... .... ..... . ... . ............... . .... 6
3. Power Requirements..... ... ........... ....... .. ..... ... .. ...... .... .. ... .. . ... .. ..... . ........... 6
4. Warra nty... ... .... ................................. ...... ... .. ............... ......... ............ 7
5. Installation
............ . .... ... ... .... .. ..... .... ... .. .... ... .......... ... . ... . ... ........ .... ...... 7
6. Camera Mounting ............. ... .......... .... .... ....... ... ..... .... ..................... . ...... 8
7. Control Mod~s ..... .... .. .. . ..... .. ..... .. .. . ...... ....... ..... ... ..... . ........... ........... . ..... 8
A. Serial. ............... . ... . ... ... .... ......... . ............. ... ... ................ .. ....... ...... 9
B. Switch Contact...... .... ... ........ ...... .. ..... ... . ......................................... 11
8. Required Service .. .. ... .... .... ... .. ............ ... ... .......... ........ . .................. .... ... 11
9. Service Acces ... . ...... . .............................................................. ... ..... .. 12
10. Lens Setup and Control. .. ...... . ............... . ................. .. ............................ 12
Bayonet Len ses ............. . ................ ... .. .. .............. ............ . ............. 12
C-Mouot MEA I PZF Types .............. .. ......... .... .. ..... .. .... .... ..... ... .. . .. ... 13
Fujinon SNPY Types .... ... .. ... ... .. ... ....... .... ...... ................................. 13
Fujinon AMSRll Types .... ....... . ..... .................. .. .............................. 13
11. End Stops and Manual Speed Setup ....... .............. .... ................................. 14
End Stops ............ ...... ... ... .... ..... . ...... ... .................... . .... .... ... .. ....... 15
Manual Motion Speeds.. ...... ... .......... .... .. ........... .... ... ..... . ..... . ........ ... 15
Serial Cgmmand Protoco1..... ... ................................................... . ..... 15
12. Function Setup and Optjons Jumpel!s ........................... ..... .... ......... ........ ...16
13. Serial Communicatjons Commands and Protocol Programming .... . ................... 18
14. Troubleshooting....
............................ .. .... .. .... . ................................ ... 22
Motor te st. ... . ... ...... .. .. ... .. .... . ... .. .... . ...... . ............. '" ........ .............. 22
Factory Presets .................. ... .... ... ............. ...... .. " .......................... 22
Software Version.... ............ ... . ......... . ....................... . ..................... 22
2

Checks .. ...... .... .. ...... ..... ........ .. ......... ... .. . ........ .. ...... .............. . ...... 22
Control Trouble ... ........................ . ...... ....... . ... .......... ........... .. ...... .. 22
PC Control ............ ...... ...... . ...... ..... . ................ .. ............ ... .... ....... 22
15. Lens Control Voltage .... ... .................... . ............................. .. .. ..... .... ... 24
16. Control and Lens Adapter Cable Schematics ................ ..... .......... .. ...... ....... 25
RS-232 Communications Wiring ............. .... .. .. . ... ... ..................... ....... 26
DC-485P to SS-485P Cable Wiring.. ... ...... .... ....... .... . ...... .... ...... . ..... . ... 27
Bayonet Lens Cable Wiring ....... ...... ... .. .......... .. ................ ... ..... ... .. ... 28
Canon PH10X8.5B RGE PZF Lens Wiring ...... .... ........ .... ...... .. ..... .... ..... 29
C-Mount MEA / PZF Lens Wiring ...... . .... .. ....... .. . ............................... 30
Kowa TV Zoom Lens Wiring ...... .... ...... .... .. . .......... . ...... ..... .... ..... ...... 31
Fujinon SNPY 21 Lens Wiring ... ..... ............................ . ....... ... .......... . 32
Fujinon SNPY 41 Lens Wiring.... ... .. ........ ..... ........... .. .... ..... ... ........... 33
Fujinon AMSR11 Lens Wiring ........................... ... ....................... ..... 34
3

SS-485P Sj!ecifications
Input Voltage
Pan Range
Tilt Range
Max. Pan Speed
Max. Tilt Speed
Resolution
Camera Power
Lens Power
Load rating
Environment
Shipping Weight
24 VAC center tapped
180 degrees
±45 degrees
25 degrees / second
30 degtees / seconcl
±7.5 arc minutes
12 VDC lA max.
6 VDC or
12 VDC
11 pounds
Indoor
9 pounds
Suggested DC Power Cable
Manufacturer Type
Alpha CM1898/3C
Belden SJ-19129
Alpha CM189W3C
Belden SJ-19130
Gauge
18
18
16
16
Standard Composition
1 - SS-485P Pan / Tilt
1- CP-l 050 5 pin DIN power connector
I - Setup / control software disc -3.5 inch floppy
1 - Operation manual
1 - Bag of jumpers for Lens Selection
Major Accessories
DC-485P Digital Controller
24APCT -1 24VAC center tapped power supply
24APCT-5 power supply for up to 5 pan / tilt units
PT-SM wall mount for SS-485P
PT-SPM-66 inch pedestal (ceiling) mount for SS-485P
Lens adapter cables
CA485-SNPY 21 for Fujinoo SNPY 21 lenses
CA485-SNPY 41 for Fujinon SNPY 41 lenses
CA485-AMSR for Fujimm AMSR lenses
CA-485-BAY for bayonet mount lenses
Maximum Length
100 feet
100 feet
200 feet
200 feet
DimensIons:
I ~~~~~
M. OU r ~G I
lQA
• ,--
I
4. l-
I
· l.l
I I
1-
Sl)EVEW
8M:XYlEW
,, -....,.,,-
4

SS-48SP Connector and Operation Identifications
08.15 Cafl' ,
~(,
L "
c.:.n1YGl ~~
5 pin DIN Conneclor 2!-V Inw.
Per ..
r
~lJ1tc101
Control Cable:---,
$S48SP Front View
Block Diagram
RS-232 or RS-485
serial control cable~
,--....:...---
-- Camera Power
24APCT-lor
24APCr-5
DC-485P or
PC with software or
AMXor
Crestron
5

1. PRECAUTIONS
Improper connections or settings may cause damage to the SS-485P, the
camera or the lens. Please read the instruction manual before power
is
connected to the unit. Check the positions of the internaljumpers, to make sure
they match yoursystem components. Install the lens selectionjumpers, according
to the type of lens being used. Failure to properly install thejumpers, may cause
damage
to the unit, and void the warranty. To avoid failure, never connect or
disconnect any
of the control or camera power cables with the power on.
Manual Axis Movement
The pan and lilt mechanics should not be moved BY HAND. The unit should only be
operated under power.
If an installer needs to move one of the motion channels, the local
manual control lines can be used
on the DB25 connector, ( see Section 7B ), or the serial
control by PC or selected controller can be used
to position the motion channel.
2. SYSTEM REQUIREMENTS
1. SS485P Pan / Tilt Head
2. Controller ( DC-485P, PC, AMX, Crestron, etc. )
3. Camera
4. Teleconference type lens with potentiometers
5. Power supply (Two types available from Hitachi Denshi )
6. Lens and camera power interface cable ( Several types available from Hitachi Dens hi )
7. System power cable (made by the installer, connector supplied with SS485P)
8. Control Cable ( DB25 connector supplied with SS485P, connector for DC-485P
supplied with the unit. )
9. Auto Iris C-Mount lenses require a separate auto iris cable.
3. POWER REQUIREMENTS
The pan and tilt requires 24V AC which is center tapped. Power to the unit must be
provided with a three wire connection as follows.
Pin 1- Ground -Center Tap
Pin 2 - No Connection
Pin 3 - No Connection
Pin 4 - 12 VAC
Pin 5 - 12 VAC
(24V AC is measured between pins 4 & S.)
2
1 ( So!dercup
vi ew )
CONNECTOR AVAILABLE FROM:
WESTLAKE TECHNICAL PRODUCTS
818-481-2591
[email protected]
6

The solder pins inside the 5 pin DIN power connector supplied with the SS-485P are not Iwge
enough for wire sizes greater than #16. For long wire runs, in excess of 200feet,
it
is
recommended to use larger wires, such as #14 or #12, and splice the large wiFe down to a cable
which is attached to the connector.
Power Supply
A separate 24VAC center tapped power supply (transformer) capable of delivering sufficient
currentfor the system is required. Power is input through a 5 pin DIN connector. See
POWER REQUIREMENl'S, for pr0per wire connections. Two power supplies are available
from IDTACHI, depending on system requiliements. The 24APCT-l will power one SS-
485P,
or the 24APCT-5 which will power 5 SS-485P's. For suitability of power supply with
other system components, contact the local HITACID office.
4. WARRANTY
THE WARRANTY PERIOD FOR ALL SS485 PAN
& TILTS MANUFACTURED
BY
WESTLAKE TECHNICAL PRODUCTS AND SOLD BY HITACHI DENSHI HAS EXPIRED!
SERVICE PARTS AND PRODUCT SERVICE SUPPORT CAN BE OBTAINED FROM:
WESTLAKE TECHNICAL PRODUCTS / WESTLAKETECHNICAL.COM
505 ECHO LANE / BIG BEAR LAKE, CA 92315
[phone] -[email protected]
5. PAN & TILT INSTALLATION
Packing Materials
When possible retain the 0figinal packing b0x in which the unit was delivered from
the factory. This container, and the internal foam inserts have @een designed to
protect the unit during shipping.
Mounting
1. The Pan and Tilt may be installed in a horizontal plane either
righ~
side up or
up side down. When the unit is mounted up side down the m0tion controls can
be swapped by changing jumpers inside the control electronics housing. The unit may
also be mounted on a vertical surface for viewing horizontal surfaces such as
table tops, etc. ( with limited movement
).
2. Mechanical: Four
114
-20 Mounting screw holes are evenly spaced on a 3.5" circle.
Refer
to
the mechanical drawing on page 4.
7

6. CAMERA MOUNTING
The tih table has slots provided to accomm0date the mounting of different camera / lens
combinations in many locations. Slots are provided in the table, and are
1/.1 inch wide to
accommodate a
t.4 -20 screw. It may be easier to mount the camera with the tilt table tilted up or
down which will give more room for your fingers to start the mounting screw.
NOTE: DO NOT A1TEMPT TO MOVE THE TILT TABLE OR PAN AXIS BY
HAND, OR DAMAGE MAY OCCUR.
Use Serial or Switch Contact Motion Control to position the pan and tilt only. The pan and tilt
mechanics should not be moved manually. The unit should only be operated under power.
If an
installer needs to move one
of the motion channels the local manual control lines can be used on
the DB25 connector. See the section on Switch Contact -Manual Motion, ( Section 7B ).
Balance
The balance of the load should be placed such that the load is somewhat balanced in the center of
the travel. Someexperimentation may be required to find the best balance for the lens / camera
combination. Cable weight must be taken into consideration when determining proper balance
of
the load. For proper operation, provide strain relief for the cables, and allow sufficient cable to
permit the full range
of motion required.
Mechanical Height
Some consideration should be made to the overall height of the camera / lens combination. If
absolute height is required to be at a minimum, center the load to achieve the minimum height at
the extremes.
If this results in an unbalanced condition, performance may be affected. The unit
may run at labored speeds during manual movements. When the unit is sent to a preset position,
the motors may run labored but significantly faster.
Maximum Weight
1be actual total weight which the unit will handle varies with where the weight is located.
Generally,
if the center of gravity of the camera and lens is placed at center of the Tilt Table, the
pan and tilt will move large loads up to 11 pounds if the load height is not very tall.
Manual Motion - Performance
1be unit is limited mostly when lifting large loads in the manual motion mode ( not going to a
preset ) from fully down or up. This is caused because the motors are pulse width modulated with
small pulses toause slower motion. When the speed is set to quite slow settings, the motors are
notas capable
of movinglarge loads. If you will be moving a camera / lens load mostly between
a
fuDy down to horizontal position. try mounting the load far back to move the center of gravity
back.
7. CONTROL MODES
8

of operation is used to replace existing equipment, or for special applications.
A. Serial -Motion Control
1. Serial Mode Selection
To select the
"Serial- Control Mode" make the following connection on the OB25
connector on the back
of the motor electronics chassis.
Pin I ( with respect to
ground)
No connection (open) ="Serial Motion Control"
When this pin is left open ( No Connection ), an internal pull up resistor keeps this pin at
+5VDC with respect to ground. This tells the controller you want
to send commands only
on the serial control channel.
When this pin is pulled low to ground the pan and tilt will only respond
to Switch Contact
Motion Control inputs on the DB25.
(See Section 7B ).
SS-485P Motor I Electronics
Chassis
Rear view
Option Connector: For serial
camera control data.
OBIS connector for Lens
control and camera power
OB25 connector for
remote control. RS232,
RS485,
or switch contact
RS485 termination switch
( Termination is "ON" when the'-;;;;~~n-
the left Shown with tennination "OW' )
Serial address switches _------
( Address is selected when the switch is to the
right Shown with address "I" selected. )
2. Wiringconnections for serial control
The followiag coonections to the DB25 connector on the back of the motor /
9

Pin 3 - RxData Receive Data ( from your computer's send line ).
Pin 7 - Ground (from your computer's s rial data ground reference).
b. Two wire RS-485 (0825 connector wiring)
Pin 2 - RS485 Line B ( from your control comput
r)
Pin 3 - RS485 Line A ( from your control oomputer )
3. Serial Line Termination's
8. RS-232 Line Termination
RS-232 is a single device to host serial link whi h do s no\. require individual
line termination.
b. RS-485 Line Termination
RS-485 is a multi drop, ( daisy chain ), serial communication link which mu t b
terminated at each end with a resistor. The Plln and tilt wired on the e nd of th e able
should be terminated. Under the DB25 connector on th e Motor I E le ctro ni cs hassis
is a five position dip switch. The number one ( I ) position on this dip switch is
provided to switch in and out a line termination resistor. Wh en multiple units are
connected
in a daisy chain setup, it is only necessa ry to terminate the la st unit in th "
chain.
4. Serial Address
Under the DB25 connector on the rear of th e Motor I Electronic chassis is a fi ve
position DIP switch. Positions two through liv > are used to select th e ser ial addr ss
that the unit will answer
to. Up to sixteen uddres,es may be chose n.
5. RS-232 & RS-485 Connections
a. Serial RS-232 communication
This is thefactory default setting!
b. Serial RS-485 communications
To select serial RS-485 or to change back to RS -232 onununications you must first
see "Service Access"
in Section 9, for directions to access the interior of the unit,
and then continue below.
6. In order to change between RS-232 and RS-485 serial modes
of operation, it is necessary to
change the interface IC. Having opened the motor I electronics chassis and swinging do\ n
the hinged side panel, you can access most
of the options on the proce sor and power
supply p.c. boards. The two IC Sockets which hold the serial interface fe's are located on
the bottom ( underneath the power supply
board) p.c. board. Just behind the "Serial
Address" select dip switch on the side panel you hould see
twalC sockets which are
labeled along the edge of the p.c. board "RS-232 and RS485". One of the IC sockets will
be empty. depending on the current mode of operation. The following describes which chip
must be plugged into it's socket for the desired protocol:
~~i ~":U2Communica tions· install the 16 Pin MC14S406IC in the 16 pin ocket provided.
. k:<~~ .~IUCorDDIlUDilcatio n.- install the 8 Pin SN7S1768 IC in the 8 pin socket provided.
10

Take care to unplug the IC you are not using and plug it into the foam provided on
top
of
the OB-l 5 connector. A small screw driver or knife blade will help you in removal.
Plugging in the chip which you need requires a little patience. Be sure to put the pin I end.
ofthe
IC which you are inserting. facing inward toward the center of the p.c. board. The IC
has a mark indicating pin I.This completes the interface selection process.
B. Switch Contact -Motion Control
1. Communication Mode Selection
To select the "Switch Contact -Control Mode" make the following connection on the DB25
connector on the back of the motor electronics chassis.
Pin 1 ( with respect to ground) Connected to ground. When this pin is pulled low to ground. the
pan and tilt will only respond to Switch Contact Motion Control inputs on the DB25.
2. Wiring Connections
r The following connections to the DB25 connector on the back of the motor / electronics chas si s apply
to Switch Contact -Motion Control.
I.
Pin 20 -Pan Left
2.
Pin 8 - Pan Right
3.
Pin 21 -Tilt Up
4. Pin 9 - Tilt Down
5. Pin 22 -Zoom In
6. Pin 10 -Zoom Out
7. Pin 23 -Focus Near
8. Pin II -Focus Far
9. Pin 19 -Ground ( Common)
10 . Pin 16 -Iris Open - not used
II . Pin 4 - Iris Close - not used
To cause a motion channel to become active. take anyone of the control lines to ground with
a switch or relay contact.
As long as the motion channel control line is held low ( grounded)
the motion channel will remain active. When the channel reaches it's programmed end stop
the channel
will stop. When the line is released the channel will also stop.
REQUIRED SERVICE
ltepJarMaintenance iarequired for trouble free operation. The unit has oil impregnated
IWrjap and sbould not require oiling for the first year or two depending on use. A light
.• Clail ile oilC8Il be UIeCl the back of the motor bearings and ateach bearing connection.
~ f'W' Ibaft ...... . 1bouI6 alIo have a couple ofdrops of light machine oil yearly.
~ __ ddittIIIIl ptme should be removed from all moving surfaces. A small brush will
fljlglJ.yI dirt. For grease or other type deposits. soap or a suitable
11

9. SERVICE ACCESS
To access the "MotorI Electronics Chassis" for service or to change Option Jumpers the side
panel
on the motorI control chassis must be opened. This is done be removing the three #4-40
screws around the top edge using a Philips screw driver.
CAUTION - DO NOT REMOVE THE TWO SCREWS WHICH
SECURE THE BOTTOM HINGE! ( or it will be necessary to readjust
the door
alignment)
The side panel is hinged and will swing out and down, moving a little more than 90 degrees,
allowing easy access to the interior switches and circuit boards. Once the three screws a
re
removed, if the side panel will not swing down easily, a flat blade screw driver or pocket knife
inserted into the top edge may be used
to help get it started. The chassis is fitted tight so to
reduce vibration, and because the paint
is rough, it may not want to move. There is nothing
inside that should prevent the side panel from swinging out at the top and downward
s.
10. LENS SETUP & CONTROL
To access lens control and option jumpers see "Service Access" in Section 9, and then
continue below.
The following lens selection, control, and options are accessed inside the pan and tilt "Motor /
Electronics Chassis." The unit as shipped from the factory, has
no lens selection jumpers
installed. It is necessary to install the jumpers according
to the type of lens being used. The
lens type selection jumpers are shipped in a separate plastic bag, the selection jumper posts are
located
just behind the Lens / Camera power connector ( OB - 15 ), inside the unit. For access
to the inside
of the unit, see "Service Access" in Section 9. A chart showing the
location
of the jumpers for various type lenses can be found in Section 14. A board layout
showing the location
of the various jumpers can be found on page 16.
Lens Selection
Several Lens / Camera c0mbinations are supported. The following are the lenses which can be
controlled:
1. Bayonet Lenses
Fujinon S14X7.5BMD & S16X6.7BMO Lenses
Canon YHI3X7.5KTS & YH17X7KTSA Lenses
Function Jumper "Func2"
On the top PC board the tens Control Function Enable / Disable control
jumper "Func2" must be moved into the "Enabled" position. This is done by
moving thejumperdown closest to the
PC Board edge.
Lens
Type Selection
lust behind the Lens/Camera Power connector ( DB-IS) is a vertical
row of 12 jumpers. All of thesejumpers must be moved to the left side
12

( away from the DB-IS connector) to control this lens. The label at the
top
of these jumpers is "P3 and P2" which corresponds to "Bayonet and
C-mount lenses".
2. C-Mount Lenses
Rainbow: All "MEAlPZP' ZOOM LENSES
Function
Jumper "Func2"
On the top PC board Lens Control Function Enable / Disable control jumper
"Func2" must be moved into the "On" or "Enabled" position. This is done by
moving the
jumper down closest to the PC Board edge.
Lens Type Selection
Just behind the Lens / Camera Power connector (
DB-IS) is a vertical row of 12
jumpers. All of these jumpers must be moved to the Right side ( closest to the
DB-IS connector) to control this lens. The label at the top of these jumpers is
"P3 ( Left) and P2 ( Right)" which corresponds to "Bayonet and C-mount
lenses".
Fujinon: All SNPY Lenses
Function Jumper "Func2"
Lens Control Function Enable / Disable control jumper "Func2" must be moved
into the
"On" or ''Enabled'' position. This is done by moving the jumper down
closest to the PC Board edge.
Lens Type Selection
Just behind the Lens/Camera Power connector ( DB-15 )
is a vertical row of 12
jumpers. All of these jumpers must be moved to the Right side ( closest to the
OB-15 connector) to control this lens. The label at the top of these jumpers is
"P3 ( Left ) and P2 ( Right)" which corresponds to "Bayonet and C-mount
lenses".
Fujinon: All AMSRll Lenses and D14x7.5BMDD24 lenses
Function Jumper "Func2"
Lens control Function Enable / Disable control jumper "Func2" must be moved
into the
"On" or "Enabled" position. This is done by moving the jumper down
closest to the
PC Board edge.
Lens
Type Selection
Just behind the Lens / Camera Power connector (DB-IS) is a vertical row of 12
jumpers. All of these jumpers must be moved to the Left side ( away from the
OB-l 5 connector) to control this lens. The label at the top of these jumpers is
"P3 ( Left) and P2 ( Right )" which corresponds to "Bayonet and C-mount
lenses". You will notethat this lens is a "c" mount lens with the control
electronics found normally
in a Bayonet lens. For this reason the jumpers are set
as
if it was a Bayonet Lens.
13

11. END STOP AND MANUAL SPEED SETUP
All Motion Channel "End Stops" and "Manual Speeds" for the Pan, Tilt, Zoom, and Focus
functions are adjustable by the user / installer. There are two ways that you can set these
parameters. You can set the "End Stops" and "Manual Speeds" with the "External
Set~p
Dip Switch" located on the Pan and Tilt head front panel, or by the use of the Senal
Command Protocol. The procedures for these two methods are described below:
External Setup Dip Switch -End Stop & Speed Setup
First in order to activate the "External Setup Dip Switch" the "OPTION 3 - External Setup
Dip Switch Enable Jumper" inside the unit must be moved to the "ON" ( enabled)
position. The "Option Jumpers" are accessed inside the
pan and tilt "Motor / Electronics
Chassis". To access these function jumpers see "Service Access" in Section 9, along with
the chart on page
16 , and then continue below.
You should make sure that the "Set/ Run" Dip Switch
on the front panel is set to the
"Run" position prior to placing the Option 3 Jumper "On". This will prevent you from
accidentally setting an end stop or speed when the External Setup Dip Switch
is Enabled.
Option 3 ON = jumper moved closest to edge of PC Board
Option 3 OFF =jumper moved away from the edge of PC Board
Once the Option 3 jumper
is set to "On", the external dip switches can be set according to
the chart above the switches located on the front outside face of the Pan and Tilt chassis.
SS-485P Front Panel
Manual Motion Speed Adjust
Set / Run DIP Switch
DIP Switches
With the "SetI Run" Dip Switch on the front panel set to the "Run" position, select which
function you wish to set from the chart to the left
of the "Set / Run" Dip Switch. The bottom four
dip switches are used to make this selection. Once you have set the bottom four switche to the
function number you want to set, you are ready to set that function. Move the "Set / Run" Dip
Switch to the "Set" position. (The Second Status LED will light up "Green LED". The Pan &
Tilt will have the "Green LED" segment on when ever you are in the "Setup Mode". )
14

End Stops
If you are setting End Stops, the unit will move the motion channel you are setting to the last
end stop position which was set. This will take only a few seconds. The Second Status LED
will light up the "Red LED" segment for about 10 Second s. With both the Green and Red
LED segments on at the same time, the Second Statu s LED will look Amber or Orange in
color. This indication is to show that the software has pa sse d th e la st end S LOP position to the
preset processor routine and that the unit has begun to move to the prior end stop.
After the motion channel stops completely, you can then move to the new desired end stop
position, or a new end stop position may be selected right away. The Second Status LED will
only remain "Orange" for about 10 Seconds. During this time you can move the motion
channel to any position within it's travel at any manual s peed you have se t. h is much easier
(faster)
to move the motion channel while the LED is "Orange", but you can s till move the
channel after the LED has turned to "Green".
The motion channel can be moved anywhere you choo se while the Second Status LED is
"Orange" but you must wait until it returns [0 a "Green" only LED to move the " Set / Run " dip
Switch back to the "Run" Position which will save the new end stop po s ition.
Note: If you move the "Set / Run" Dip Switch back to the "Run" Po s ition before the
Second Status LED is "Grecn", your new end stop will not be se t and the channel will
move to the previous end stop.
Manual Motion Speeds
If you are setting Manual Motion Speeds, you will be adjusting the trim pot which is marked by a
minus ( - ) and a plus ( + ) symbol. You will need a small flat blade sc rew driver for this purpo se .
Select the setup function with the four dip switches and move the "Set / Run" switch to the "Set"
position. The manual motion speed for the selected channel can be increased by turning the trim
pot c.lockwise toward the plus ( +). You can likewise reduce the manual motion speed for the
selected channel by turning the trim pot counter clockwise toward the minus ( - ). There are
currently six ( 6 ) manual speeds supported .. The pot is a ten (10 ) turn pot with slip clutches at
each end. If the pot is fully rotated counter clockwise at least ten (10 ) turns then you should be at
the bottom end ofyour speed selections. To achieve the new desired speed requires some
experimentation. Rotate the pot about one turn and then move tbe "Set / Run" Switch to the
"Run" position. The new speed will only take effect after the switch is moved to the "Run"
position. Move the motion channel to see if the speed has changed and if it is what you desire.
Repeat this sequence until you obtain the desired speed.
Note: The factory defaults can be set for aU End Stops and Manual Motion Speeds by
setting the four ( 4 ) setup function switches to Fourteen (14) and momentarily moving
the "Set / Run" Switch to the "Set" position and then back to the "Run" Position. If you
get lost, sometimes this is quicker than trying to figure out where you are.
Serial Command Protocol· End Stop & Speed Setup
When using Serial Command Protocol the "OPTION_3 - External Setup Dip Switch Enable
Jumper" inside the unit need not be set. See the Serial- Communications Commands & Protocol
section.
15

12. FUNCTION SETUP ANI) OPTIONS JUMPERS
The following lens selection, control, and options are accessed inside the pan and tilt "Motor /
Electronics Chassis". To access function setup and option jumpers see "Service Access"
in
Section 9, and then continue below.
The "Power Supply / Option
PC Board", provides space for "Option Jumpers" and test
connections which are used
to configure the pan and tilt. The following are the general
descriptions for all option jumpers. For the locations
of each set of jumpers, refer to the
PC board layout on the following page, and the description of the option jumpers which follows.
Test H ea d er
pol -
Top PC Board Layout
Front of unit
On Off
r--
I_ -
1-
P'j"""-P8
r
(1 f
P9PIO
~ ~
,....--
-
0
0
0
~p~ ~
I
I ~
Connector slde of board ( rear )
t-
Func 2 - Funcl ion Header
une I
/""
F
I
F
- Die -Mo ti on Direction Header
. Dir j P7= On
Z· Dir P8 = Off
T· Dir
P - Dir
g~: ~ / op~n=H~:d c r
Opt 5 PIO=O ff
Opt 4
Opt 3
Opt 2
Opt I
O pt 0
PW F oc us & Zoo m H ea der
p. '" P4 = Reverse
P+ Focus P6 = Normal
M. /
M+
PW
p. '"
P+ Z oo m
M· /
M+
Bayonet / Lens Header
P3 = Bayonet
C • Mount P2 = C . Mount
16

All of ~e Headers have 3 rows of pins, with th c pti n f th PI H ad'r. A s I 'rion is mad ,
acco.rdmg to the charts shown at the tight when the jump r connc ts th c nl' r row t
outsIde rows .
PI: Test Header ( u ed for production test )
P2! P3: Lens Type Header
See schematics in back of manual for jump I' 'cttin 'S for your I ns typ".
P4 ! P6 : Zoom & Focus Pot & Motor' Heuder
See schematics in back of manual for jump I' sett in gs fo r your I 'ns typ .
P7 ! P8: Motion Direction Options
Label De cription
P _DI R Pan Direction
T_DIR Tilt Direction
Z_DlR Zoom Direction
F
DIR Focus Dir ect ion
CDIR Iris Direction
FUNCI Pan & Tilt Enable
FUNC2 Zoom & Focus Enable
P9! PIO: Options Header
Axis Function Enable! Disuble Header
Fun 'Iion- Ofr Fun lion-n
Normal
Normal
No rmlll
No rm al
(Nol upported)
P&T Disabled
Z&F Di 'abled
R crs'
R " l'S'
Rev rse
Rev r5e
(Not upporlcd
P
&T Enabl"d
Z&F Enabled
Label Description Function-Off Function-On
OPTION_O Manual Motion Ramp Ru mp Disabled Ramp Ena bl ed
( When this option
is on, aLI motion starts al th" slowe I speed and is ramped up I the
selected speed. This allows for exact positioning wh n reating preoet s. )
Label Description Function-Off Function-On
OPTION_I System test enable NormalOp ration All motors
( When this option
is on, all motor channels are dri n for a short tim in b th dir ti ons.
LED's blink and all logic inputs are continuously read and output on the T °t
Pl. This tests all inputs and output channels. )
Label Description Function-Off Function-On
OPTION 2 Prod. test AID enable TestinIY Disabled Testing Enabl 'd
( When this option is on, and OptioQ..l i also on. I/O and motor I ~ t is suspend d and nil
AID channels are continuously read and Olltput on th Te t C nnector Pl. Thil: test all
AID channel inputs.
Label Description Function-Off Function-On
OPTION_3 External dip switch enable etup DA etnp SA
(When this option is on, the external "S tup Dip Swit h" i Enabl d. Thxternal s tup
dip switch is used to set
end stops and manualm lion peeds. This jumper sh uld be et t
off to protect against accidental etup modifi ation' . )
17

Label D· .
escnptlOn Function-Off Function-On
OPTION_4 No pots-disable zf presets Nonnal Presets No Presets
( When this option jumper is on, the zoom and focus software ignores the follow pots on
the zoom and focus ohannels. Presets are disabled but lenses without pots can be used.
Motion control
is normal. )
Description
Unused
Description
Unused
Function-Off
Function-Off
Function-On
Function-On
Label Description Function-Off Function-On
OPTION_7 Set factory defaults EA Defaults Not Set Defaults Set
( When this option is on, each time the unit's power is applied, the factory defaults for end
stops and manual motion speeds are set.
If you wish to have any settings saved which you
make during operation, you must set this option jumper set
to "Off' .)
13. SERIAL COMMUNICATIONS COMMANDS & PROTOCOL
PROGRAMMING
Communication protocol: 9600 Baud No Parity 8 Bits 1 Stop
Bit
The following definitions are taken from the "c" source file which runs in the Pan
and Tilt Micro Controller. If you are writing an application to talk to the Pan and
Tilt, this file contains all the command definitions for communicating with the
units.
A host contmller, such
as a PC or Control Panel, sends only two types of bytes to the pan
and tilt. This limited number ofserial data transmissions
has been developed to optimize
system performance over serial control lines. The "Header Byte" may be sent only once
followed
by several "Function Data Bytes" or sent every time along with trailing data.
1. Header Byte -Address & Function Description
dO -Address AO -\ / 000 -Manual Motion Command
dl- Address Al--\ 16 addresses I 016 -Preset Storage Number
d2 -Address A3 --/00= all I 032 -Preset Recall Number
d3 -Address A4 -/ I 04S -Setllp Functions
d4 -----\ I 064 - Self Test Fl!lnctions
d5 - Function Description Nwmber;::. < 080 -Download Presets from P&T
d6 -----I I 096 -Upload Presets to P&T
d7 - Always set to One ( 1 ) \ 102-
( identifIes byte as Header Byte -Address & Function Description)
l8

/*
#define Header 128
unsigned char HeadecByte;
unsigned char Need Header'
-,
unsigned char function Num'
-,
unsigned char Need Fun Data'
- - ,
unsigned char Joystick;
#define Joystick_Off
#define Joy _Pan_Tilt
A. Function Description Nun
/*d7 header byte identifier */
/* address & function desc */
1* header hvte needed flal! */
/* function description # */
/* function data needed flag
*/
/*joystick priority flag */
/*joystick is disabled */
/*joystick P & T function */
#define S_Fun_Manual
#define S_Fun_Store
#define S_Fun_Recall
#define S_Fun_Setup
#define S_Fun_SelITest
o
16
32
48
64
80
96
/* Manual Motion Command */
/* Preset Storage
Number */
/* Preset Recall Number */
/* Setup Functions */
/*
Self Test Functions */
#define SYun_Download Presets
#define S_Fun_Upload_Presets /* download presets from P & T */
/* upload presets to P & T */
1*
2. Function Data Byte
A. Manual Motion Corhmand ( OOd ) - Range ( 00 - 127 )
dO -Motion Command Number - dO
dl -Motion Command Number - dI
d2 -Motion Command Number -d2
d3 -Motion Command Number -
d3
d4 -Motion Command Number - d4
d5
-Motion Command Number - d5
d6 -Motion Command Number - d6
d7 -Always set to Zero ( 0 ) <-Identifies byte as Function Data */
unsigned char Fun_Data;
1* function data byte
1* fust time thru flag
unsigned char First;
#define S ALL STOP
0
/* all stop
--
/* pan left
#define S_PAN_LRFT
1
#define S_PAN_RlGHT
2
1* pan right
#define STILT_UP
3
1* tilt l!lp
#define S_TILT_DOWN
4 /* tilt down
#defme S.-z;OO~IN
5 /* zoom
in
#defme S.-z;OOM_OUT 6 /* zoom
out
#define SYOCUSflEAR
7 /* focus near
#define
S_FOCUS_FAR
8 /* focus far
#define S_IRIS_OPEN
9 /* iris open
#defme SJRIS_CLOSE
10 /* iris close
*1
*/
*/
*/
*/
*f,
*/
*/
*/
*/
*/
*/
*/
19
