EM18K-1-8EX1900-6 HYDRAULIC EXCAVATOR OPERATOR’S MANUAL

Serial No 001223 and up

Hydraulic Excavator

PRINTED IN JAPAN (E) 2019, 09

1900-6

This book is printed on recycled paper.

EM18K-1-8

PART NO.

Operator’s Manual

URL:http://www.hitachi-c-m.com

INTRODUCTION

Read this manual carefully to learn how to operate and

service your machine correctly. Failure to do so could

result in personal injury and/or machine damage.

This standard specification machine can be operated

under the following conditions without being modified.

Atmospheric Temperature: -20 °C to 50 °C (-4 °F to 122 °F)

Altitude: 0 m to 2000 m (0 ft to 6600 ft)

In case the machine is used under conditions other than

described above, contact your authorized dealer.

This manual should be considered a permanent part of

your machine and should remain with the machine when

you sell it.

This machine is of metric design. Measurements in this

manual are metric. Use only metric hardware and tools as

specified.

• SI Units (International System of Units) are used in

this manual.

For reference MKS system units and English units are

also indicated in parentheses after the SI units.

Example : 24.5 MPa (250 kgf/cm², 3550 psi)

Right-hand and left-hand sides are determined by

facing in the direction of forward travel.

Write product identification numbers in the Machine

Numbers section. Accurately record all the numbers

to help in tracing the machine should it be stolen.

Your dealer also needs these numbers when you order

parts. If this manual is kept on the machine, also file the

identification numbers in a secure place off the machine.

Use only diesel fuel with quality specified in JIS K-2204,

EN-590 or ASTM D-975 which contents 15 ppm or lower

sulfur.

Also use fuel that complies with solid contamination level

of class 18/16/13 of ISO4406-1999 (solid contamination

includes dust). If the fuel specified above is not used,

exhaust gas that exceeds the regulation values may be

discharged, causing serious problem on the engine.

Contact your authorized dealer.

Warranty is provided as a part of Hitachi’s support

program for customers who operate and maintain their

equipment as described in this manual. The warranty is

explained on the warranty certificate which you should

have received from your dealer.

All information, illustrations and specifications in this manual are based on the latest product information available at the

time of publication. The right is reserved to make changes at any time without notice.

This warranty provides you the assurance that Hitachi will

back its products when defects occur within the warranty

period. In some circumstances, Hitachi also provides field

improvements, often without charge to the customer,

even if the product is out of warranty.

Should the equipment be abused or modified to

change its performance beyond the original factory

specifications, the warranty will become void and field

improvements may be denied.

Setting fuel delivery above specifications or otherwise

overpowering machines will result in such action.

Moreover, when replacement parts are required, be sure

to use genuine Hitachi parts. Failure to do so may result in

voiding the warranty and/or denial of field improvements.

The Yellow Pages in this operator’s manual contain

IMPORTANT SAFETY INFORMATION.

Read these pages thoroughly and familiarize yourself

with the safety standards and recommendations set

forth in these yellow pages of the manual.

Follow all safety instructions prior to and while

operating the excavator.

Only qualified, experienced operators officially licensed

(according to local law) should be allowed to operate the

machine.

Moreover, only officially licensed personnel should be

allowed to inspect and service the machine.

Prior to operating this machine, including

communication system, in a country other than a

country of its intended use, it may be necessary to

make modifications to it so that it complies with

the local regulatory standards (including safety

standards) and legal requirements of that particular

country. Please do not export or operate this machine

outside of the country of its intended use until such

compliance has been confirmed.

Please contact Hitachi Construction Machinery Co.,

Ltd. or any of our authorized distributor or dealer if

you have any questions concerning compliance.
