HX-RIO3 Series
Power Module
User Manual
Version 1.01

2
HX-RIO3 Series
REVISION HISTORY
REV.
PAGE
REMARKS
DATE
EDITOR
1.01
New Document
Feb. 2021
(OPR), (PF)

3
HX-RIO3 Series
Table of Contents
1Important Notes.......................................................................................................................5
1.1 Safety Instruction........................................................................................................6
1.1.1 Symbols .....................................................................................................................6
1.1.2 Safety Notes...............................................................................................................6
1.1.3 Certification ................................................................................................................6
2Power Module List ...................................................................................................................7
3Specification ............................................................................................................................8
3.1 RIO3-SHD..................................................................................................................8
3.1.1 Wiring Diagram...........................................................................................................8
3.1.2 LED Indicator..............................................................................................................9
3.1.3 Status LED.................................................................................................................9
3.1.4 Specification.............................................................................................................10
3.1.5 Example................................................................................................................... 11
3.2 RIO3-0VCD..............................................................................................................12
3.2.1 Wiring Diagram.........................................................................................................12
3.2.2 LED Indicator............................................................................................................13
3.2.3 Status LED...............................................................................................................13
3.2.4 Specification.............................................................................................................14
3.2.5 Example...................................................................................................................15
3.3 RIO3-PSD ................................................................................................................16
3.3.1 Wiring Diagram.........................................................................................................16
3.3.2 LED Indicator............................................................................................................17
3.3.3 System / Field Power LED........................................................................................17
3.3.4 Status LED...............................................................................................................17
3.3.5 Specification.............................................................................................................18
3.3.6 Example...................................................................................................................19
3.4 RIO3-24VDC............................................................................................................20
3.4.1 Wiring Diagram.........................................................................................................20
3.4.2 LED Indicator............................................................................................................21
3.4.3 Status LED...............................................................................................................21
3.4.4 Specification.............................................................................................................22

4
HX-RIO3 Series
3.4.5 Example...................................................................................................................23
3.5 RIO3-VDC................................................................................................................24
3.5.1 Wiring Diagram.........................................................................................................24
3.5.2 LED Indicator............................................................................................................25
3.5.3 Status LED...............................................................................................................25
3.5.4 Specification.............................................................................................................26
3.5.5 Example...................................................................................................................27
3.6 RIO3-PS...................................................................................................................28
3.6.1 Wiring Diagram.........................................................................................................28
3.6.2 LED Indicator............................................................................................................29
3.6.3 Status LED...............................................................................................................29
3.6.4 Specification.............................................................................................................30
3.6.5 Example...................................................................................................................31
4Environment Specification......................................................................................................32
5Dimension..............................................................................................................................33
5.1 10-Pts. Spring Type..................................................................................................33
6Mounting................................................................................................................................34
6.1 I/O Inserting and Removing Devices.........................................................................34
6.2 RTB (Removable Terminal Block).............................................................................35
7G-Bus Pin Description............................................................................................................36
8Troubleshooting.....................................................................................................................37
9APPENDIX ............................................................................................................................38
9.1 Product List ..............................................................................................................38
9.2 Glossary...................................................................................................................39

5
HX-RIO3 Series
1 Important Notes
Solid state equipment has operational characteristics differing from those of electromechanical equipment.
Safety Guidelines for the Application, Installation and Maintenance of Solid-State Controls describes some
important differences between solid state equipment and hard-wired electromechanical devices.
Because of this difference, and because of the wide variety of uses for solid state equipment, all persons
responsible for applying this equipment must satisfy themselves that each intended application of this
equipment is acceptable.
In no event will HITACHI be responsible or liable for indirect or consequential damages resulting from the use
or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many
variables and requirements associated with any installation, HITACHI cannot assume responsibility or liability
for actual use based on the examples and diagrams.
Warning!
✓If you don’t follow the directions, it could cause a personal injury, damage to the equipment or
explosion.
✓Do not assemble the products and wire with power applied to the system. Else it may cause an electric
arc, which can result into unexpected and potentially dangerous action by field devices. Arching is
explosion risk in hazardous locations. Be sure that the area is non-hazardous or remove system power
appropriately before assembling or wiring the modules.
✓Do not touch any terminal blocks or IO modules when system is running. Else it may cause the unit to an
electric shock or malfunction.
✓Keep away from the strange metallic materials not related to the unit and wiring works should be
controlled by the electric expert engineer. Else it may cause the unit to a fire, electric shock or
malfunction.
Caution!
✓If you disobey the instructions, there may be possibility of personal injury, damage to equipment
or explosion. Please follow below Instructions.
✓Check the rated voltage and terminal array before wiring. Avoid the circumstances over 50℃of
temperature. Avoid placing it directly in the sunlight.
✓Avoid the place under circumstances over 85% of humidity.
✓Do not place Modules nearby inflammable material. Else it may cause a fire.
✓Do not permit any vibration approaching it directly.
✓Go through module specification carefully, ensure inputs, output connections are made with the
specifications. Use standard cables for wiring.
✓Use Product under pollution degree 2 environment.

6
HX-RIO3 Series
1.1 Safety Instruction
1.1.1 Symbols
1.1.2 Safety Notes
The modules are equipped with electronic components that may be destroyed by
electrostatic discharge. When handling the modules, ensure that the environment (persons,
workplace and packing) is well grounded. Avoid touching conductive components, G-Bus
Pin.
1.1.3 Certification
UL Listed Industrial Control Equipment, certified for U.S.
See UL File UL196687
CE Certificate
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
Reach, RoHS (EU, CHINA), EAC
Identifies information about practices or circumstances that can cause an explosion in a
hazardous environment, which may lead to personal injury or death property damage, or
economic loss.
Identifies information that is critical for successful application and understanding of the
product.
Identifies information about practices or circumstances that can lead to personal injury,
property damage, or economic loss.
Attentions help you to identity a hazard, avoid a hazard, and recognize the consequences.

7
HX-RIO3 Series
2 Power Module List
RIO3-Number
Description
ID (hex)
RIO3-SHD
Potential Distributor, 8 CHs, Shield, 10 RTB, ID Type
7408
RIO3-0VCD
Potential Distributor, 8 CHs, 0Vdc, 10 RTB, ID Type
7508
RIO3-PSD
Expansion Power, System/Field Power, Input 24Vdc, Output 5Vdc, 1A,
10 RTB, ID Type
7511
RIO3-24VDC
Potential Distributor, 10 CHs, 24Vdc, 10 RTB, ID Type
7518
RIO3-VDC
Potential Distributor, 5 CHs, 24Vdc / 5 CHs, 0Vdc, 10 RTB, ID Type
7588
RIO3-PS
Field Power Distribution 5~48 (Vdc), 120~240 (Vac) ID Type
7641

8
HX-RIO3 Series
3 Specification
3.1 RIO3-SHD
3.1.1 Wiring Diagram
Pin No.
Signal Description
Signal Description
Pin No.
0
Shield
Shield
1
2
Shield
Shield
3
4
Shield
Shield
5
6
Shield
Shield
7
8
Field Power, 24V
Field Power, 24G
9

9
HX-RIO3 Series
3.1.2 LED Indicator
3.1.3 Status LED
Status
LED
To indicate
Normal signal.
Green
The unit is operating in normal condition.
(After normal initialization of G-Bus communication,
this LED maintains ON status.)
Absence of
Off
Network adapter is not connected to this module.
network adapter
LED No.
LED Function / Description
LED Color
Status
Internal Bus Status
Green

10
HX-RIO3 Series
3.1.4 Specification
Items
Specification
Technical Data
UL Field Power
Supply voltage: 24Vdc nominal, Class 2
Field Power Voltage
24Vdc nominal
Field Power Contacts Current
Max. 10A
Operating Temperature
-40℃~ 50℃: Max. 10A
50℃~ 70℃: Max. 7A
Indicator
1 Green Internal Bus Status
General Specification
System Power Dissipation
Max. 30mA @ 5Vdc
Wiring
I/O Cable Max. 2.0mm2(AWG 14)
Torque
0.8Nm (7 lb-in)
Weight
58g
Module Size
12mm x 99mm x 70mm
Environment Condition
Refer to ‘4. Environment Specification’

11
HX-RIO3 Series
3.1.5 Example
RIO3-SHD Shield

12
HX-RIO3 Series
3.2 RIO3-0VCD
3.2.1 Wiring Diagram
Pin No.
Signal Description
Signal Description
Pin No.
0
0VDC/L2
0VDC/L2
1
2
0VDC/L2
0VDC/L2
3
4
0VDC/L2
0VDC/L2
5
6
0VDC/L2
0VDC/L2
7
8
0VDC/L2
0VDC/L2
9

13
HX-RIO3 Series
3.2.2 LED Indicator
3.2.3 Status LED
Status
LED
To indicate
Normal signal.
Green
The unit is operating in normal condition.
(After normal initialization of G-Bus communication,
this LED maintains ON status.)
Absence of
Off
Network adapter is not connected to this module.
network adapter
LED No.
LED Function / Description
LED Color
Status
Internal Bus Status
Green

14
HX-RIO3 Series
3.2.4 Specification
Items
Specification
Technical Data
UL Field Power
Supply voltage: 24Vdc nominal, Class 2
Field Power Voltage
24Vdc nominal
Field Power Contacts Current
Max. 10A
Operating Temperature
-40℃~ 50℃: Max. 10A
50℃~ 70℃: Max. 7A
Indicator
1 Green Internal Bus Status
General Specification
System Power Dissipation
Max. 30mA @ 5Vdc
Wiring
I/O Cable Max. 2.0mm2(AWG 14)
Torque
0.8Nm (7 lb-in)
Weight
70g Max.
Module Size
12mm x 99mm x 70mm
Environment Condition
Refer to ‘4. Environment Specification’

15
HX-RIO3 Series
3.2.5 Example
RIO3-0VCD Common 0Vdc

16
HX-RIO3 Series
3.3 RIO3-PSD
3.3.1 Wiring Diagram
Pin No.
Signal Description
Signal Description
Pin No.
0
System Power, 24V
System Power, Ground
1
2
System Power, 24V
System Power, Ground
3
4
Frame Ground
Frame Ground
5
6
Field Power, Ground
Field Power, Ground
7
8
Field Power, 24V
Field Power, 24V
9

17
HX-RIO3 Series
3.3.2 LED Indicator
3.3.3 System / Field Power LED
Status
LED
To indicate
On Signal
Green
Normal Operation
No Signal
Off
Not Supplied 24Vdc System / Field power
3.3.4 Status LED
Status
LED
To indicate
Normal signal.
Green
The unit is operating in normal condition.
(After normal initialization of G-Bus communication,
this LED maintains ON status.)
Absence of data
size.
Flashing green
Although this module is connected normally,
there are not input/output data for communication.
Absence of
Network adapter
Off
Network adapter is not connected to this module.
LED No.
LED Function / Description
LED Color
System Power
System Power
Green
Field Power
Field Power
Green
Status
Internal Bus Status
Green

18
HX-RIO3 Series
3.3.5 Specification
Items: RIO3-PSD
Input Specification
System Input Voltage range
15Vdc to 30Vdc
System Power Input Voltage
24Vdc nominal
Indicators
1 Green System Power status, 1 Green Field Power status, 1 Green G-Bus status
UL Field Power
Supply voltage: 24Vdc nominal, Class 2
Field Power Input Voltage
24Vdc (±20%) nominal
Field Power Contacts
Current
Max. 10A
Operating Temperature
-40℃~ 50℃: Max. 10A
50℃~ 70℃: Max. 7A
G-Bus Output Voltage
Max. 5Vdc, 1A *
General Specification
System Power Dissipation
Max. 20mA @ 24Vdc
Wring
I/O Cable Max. 2.0mm2(AWG 14)
Torque
0.8Nm (7 lb-in)
Weight
59g
Module size
12mm x 99mm x 70mm
* Operating temperature
-40 ~ 70℃temperature range specification can be guaranteed under the following conditions.
> Current for I/O modules: 0.4 A below.
> Otherwise, temperature specification can be guaranteed with -40 ~ 60℃.

19
HX-RIO3 Series
3.3.6 Example
RIO3-PSD Provides the additional Power.

20
HX-RIO3 Series
3.4 RIO3-24VDC
3.4.1 Wiring Diagram
Pin No.
Signal Description
Signal Description
Pin No.
0
24VDC/L1
24VDC/L1
1
2
24VDC/L1
24VDC/L1
3
4
24VDC/L1
24VDC/L1
5
6
24VDC/L1
24VDC/L1
7
8
24VDC/L1
24VDC/L1
9
