Hitachi CM 7MRU Manual

•Cutting slits in concrete, cement, bricks or tiles. Slits can then be chipped with a separate tool to form grooves
for laying plumbing piping or trunking cable.
[ NEW FEATURES ]
Sturdy and highly-attractive aluminum die-cast
dust cover.
Largest cutting width in the class.
* In addition to the features above, the Models CM
7MR, CM 7MRU and CM 7MC have features (selling
points) common to base Models G 23SR, G 23SRU
and G 23SC3, respectively.
The Models CM 7MR, CM 7MRU and CM 7MC are new wall chasers developed based on disc grinder
Models G 23SR, G 23SRU and G 23SC3, respectively, and have main bodies common to those base models.
Consequently, these new wall chasers also have main features common to the base models. Moreover, the
Models CM 7MR, CM 7MRU and CM 7MC are each equipped with a dust collection cover (for the diamond
wheels).
PRODUCT NAME
Hitachi Wall Chaser
Models 180 mm (7”) CM 7MR
CM 7MRU
CM 7MC
MARKETING OBJECTIVE
APPLICATIONS
SELLING POINTS
International Sales Division
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR
IMPROVEMENT.
LIST Nos.
CM 7MR : E721
CM 7MRU : E722
CM 7MC : E723
Jun. 2009
C

REMARK:
For more information about HANDLING INSTRUCTIONS, visit our website at:
http://www.hitachi-koki.com/manual_view_export/
Throughout this TECHNICAL DATA AND SERVICE MANUAL, a symbol(s) is(are) used in the place of
company name(s) and model name(s) of our competitor(s). The symbol(s) utilized here is(are) as follows:
Competitors
Symbols Utilized Company Name Model Name
B BOSCH GNF65A

CONTENTS
Page
SELLING POINT DESCRIPTIONS ----------------------------------------------------------------------------------------- 1
SPECIFICATIONS -------------------------------------------------------------------------------------------------------------- 2
1. Specifications--------------------------------------------------------------------------------------------------------------------------------- 2
COMPARISON WITH SIMILAR PRODUCT------------------------------------------------------------------------------ 3
1. Comparison of Specifications ------------------------------------------------------------------------------------------------------- 3
PRECAUTIONS ON SALES PROMOTION ------------------------------------------------------------------------------ 4
1. Safety Instructions ------------------------------------------------------------------------------------------------------------------------ 4
REPAIR GUIDE------------------------------------------------------------------------------------------------------------------ 5
1. Precautions on Disassembly and Reassembly ----------------------------------------------------------- 5
STANDARD REPAIR TIME (UNIT) SCHEDULES---------------------------------------------------------------------- 7
Assembly Diagrams for CM 7MR
Assembly Diagrams for CM 7MRU
Assembly Diagrams for CM 7MC

-1-
㩷㩷㩷㩷㩷
In addition to the following features, the Models CM 7MR, CM 7MRU and CM 7MC have features (selling
points) common to base Models G 23SR, G 23SRU and G 23SC3, respectively. Refer to the TECHNICAL
DATA AND SERVICE MANUAL of each base model for details of the selling points.
Sturdy and highly-attractive aluminum die-cast dust cover
The dust cover is made of aluminum die-casting. It is
both sturdy and highly attractive. (B's dust cover is made
of steel sheet (2.0-mm thick).)
Largest cutting width in the class
The maximum cutting width is 5 mm larger than that
of B. This is the largest cutting width for this class of
wall chaser.
Maker HITACHI
Model
CM 7MR,
CM 7MRU,
CM 7MC
B
Max cutting
width (W)
45 mm
(1-49/64”)
40 mm
(1-37/64”)
SELLING POINT DESCRIPTIONS
㩷㩷㩷㩷㩷
W
Diamond wheel
Dust collection cover

-2-
1. Specifications
Model CM 7MR CM 7MRU CM 7MU
Base Model G 23SR G 23MRU G 23MC
Max. cutting depth 35 mm (1-3/8”)
Max. cutting width 45 mm (1-49/64”)
External
dia. 180 mm (7”)
Thickness 1.5 to 2.0 mm (1/16” to 5/64”) (Thickness of installation part)
Diamond
wheel
size
Internal dia. 22.2 mm (7/8”)
Power source AC single phase 50 or 60 Hz
Voltage and power
input
No-load speed 6,600/min.
Type of motor AC single phase commutator motor
Enclosure
Housing (black) (CM 7MC: green)
Handle, tail cover (green) (CM 7MC: black)
Gear cover, packing gland ---------------------------- Aluminum alloy die-casting
Type of switch Trigger switch
Net*7.9 kg (17.4lbs.) 8.8 kg (19.5 lbs.)
Weight Gross 10.0 kg (22.1 lbs.) 10.9 kg (24.1 lbs.)
Type of packing Carton box
Standard accessories Side handle -----------------1
Wrench -----------------------1
Optional accessories
Diamond wheel (For concrete and masonry work)
· Segment type (Code No. 305459, 307009)
· Wave-shape type (Code No. 305460)
*: Net weight excludes the cord and diamond wheel.
SPECIFICATIONS
Voltage
(V)
Current
(A)
Power
input
(W)
110 19.0 2,000
230 9.2 2,000
Voltage
(V)
Current
(A)
Power
input
(W)
230 9.2 2,000
Voltage
(V)
Current
(A)
Power
input
(W)
110 20.9 2,300
230 10.5 2,300
---- Polyamide resin with glass fiber

-3-
1. Comparison of Specifications
(Superior specifications: )
Maker HITACHI
Model name CM 7MR CM 7MRU CM 7MU B
Cutter dia. 180 mm (7”) 230 mm (9”)
Power input 2,000 W 2,300 W 2,400 W
No-load rotation speed 6,600/min. 5,000/min.
No-load peripheral speed 62 m/s (203 ft/s) 60 m/s (196 ft/s)
No-load sound pressure level 94 dB (A) 97 dB(A)
Max. cutting depth 35 mm (1-3/8”) 65 mm (2-9/16”)
Max. cutting width 45 mm (1-49/64”) 40 mm (1-37/64”)
Width of base (Roller) 110 mm
(4-21/64”)
140 mm
(5-33/64”)
Overall length 571 mm
(22-31/64”)
580 mm
(22-53/64”)
600 mm
(23-5/8”)
Weight 7.9 kg (17.4 lbs.) 8.8 kg (19.5 lbs.) 8.4 kg (18.5 lbs.)
*: Weight excludes the cord and diamond wheel.
COMPARISON WITH SIMILAR PRODUCT

-4-
1. Safety Instructions
In the interest of promoting the safest and most efficient use of the Models CM 7MR, CM 7MRU and
CM 7MC Wall Chasers by all of our customers, it is very important when concluding a sale that the
salesperson carefully ensure that the buyer seriously recognizes the importance of the Handling
Instructions, and fully understands the precautions listed on the Nameplate.
A. Handling instructions
Although every effort is made in each step of design, manufacture, and inspection to provide protection
against safety hazards, the dangers inherent in using any electric power tool cannot be completely
eliminated. Accordingly, the Handling Instructions list general precautions and suggestions on the use of
electric power tools, and specific precautions and suggestions on the use of the Wall Chasers in order to
enhance the safe and efficient use of the tools by the customer.
Salespersons must be thoroughly familiar with the contents of the Handling Instructions in order to offer
appropriate guidance to customers during sales promotion activities.
B. Caution on name plate
Each tool is provided with a namplate that shows the following basic safety precautions on using the tool.
C. Precautions on usage
Never press the pushing button while the diamond wheel is rotating.
Note that pressing the pushing button during diamond wheel rotation will immediately stop the spindle.
In such case, there is a danger that the M14 bolt for diamond wheel fixation may become loose, resulting in
the diamond wheel unexpectedly flying off and possibly causing serious injury.
PRECAUTIONS ON SALES PROMOTION

-5-
㩷㩷㩷㩷㩷
Diamond wheel
Diamond wheel
Dust
Dust
A
Before attempting disassembly or reassembly, always be sure to turn off the switch and disconnect the plug
from the power source outlet.
1. Precautions on Disassembly and Reassembly
The [Bold] numbers in the descriptions below correspond to item numbers in the Parts Lists and exploded
view assembly diagrams for the Models CM 7MR, CM 7MRU and CM 7MC.
The main bodies of the Models CM 7MR, CM 7MRU and CM 7MC are common to those of base Models G
23SR, G 23SRU and G 23SC3, respectively. Therefore, only the disassembly and reassembly procedures
of the newly designed dust collection cover unit are described below.
Dust Cover Ass’y [90] (Model CM 7MR) [91] (Model CM 7MRU) [88] (Model CM 7MC)
The [Bold] numbers and circled numbers in the descriptions below correspond to item numbers in the
Parts List and exploded view assembly diagram of the Model CM 7MR. (The dust cover ass'y is common to
that of the Models CM 7MRU and CM 7MC.)
(1) Turn the Knob Bolt [66] and
remove it together with the
Lock Washer [67].
(2) Raise the dust guard in arrow
direction "A."
(3) Pull out the Rubber Grommet
[74]. Loosen and remove the
M14 Bolt [75] with the attached
Wrench 22-mm [501]. At this
time, remove the Blade
Washer [78], eight Blade
Spacers (5) [79], Blade Spacer
(3) [71], and the two diamond
wheels from the Drive Shaft
[80].
(4) Loosen the two Bolts M4 [13]
with the attached Wrench 22-
mm [501] and then remove it
together with the two Nylon
Washers D14 [14].
(5) Loosen the Hex. Socket HD.
Bolt M6 x 25 [82] and then
remove the Dust Cover Ass'y
[90] from the Packing Gland [2].
(6) Remove the four Shaft Caps [69] from the two Roller Shafts [65] with pliers. Remove the six Rollers [63],
three Roller Spacers (30) [64] and Roller Spacer (20) [81] together from Dust Covers (A) and (B) [77]
[87].
(7) Loosen the Hex. Socket HD. Bolt M5 x 12 [85] and then remove the Vacuum Coupling [89].
(8) Loosen the two Hex. Socket HD. Bolts M4 x 20 [86] and Hex. Socket HD. Bolts M4 x 12 [70]. Remove
Dust Guard (B) [88] from Dust Guard (A) [76] together with the Square Nut M8 [68].
(9) Remove the Side Handle For M14 [52] from Handle Arm (B) [53].
(10) Loosen the Bolt M12 [61] and Handle Plug [56]. Remove Handle Arm (B) [53], Handle Arm (A) [54],
Nylon Washer D12 [55], Handle Ratchet [59], Bolt Washer D12 [60] and Nylon Nut M12 [73] together
from Dust Cover (B) [87].
REPAIR GUIDE
Disassembl
y

-6-
(11) Loosen the four Hex. Socket HD. Bolts M4 x 20 [86] and then remove Dust Cover (B) [87] from Dust
Cover (A) [77].
(12) Loosen the four Hex. Socket HD. Bolts M5 x 12 [58]. Remove the Gear Box Bracket [57] from Dust
Cover (B) [87] and then remove the Gear Box Cramp [83].
Perform reassembly by reversing the order of the disassembly procedure.
Refer to the TECHNICAL DATA AND SERVICE MANUAL for each base model—G 23SR (List No. E273),
G 23SRU (List No. E274) and G 23SC3 (List No. E254)—for precautions on disassembly and reassembly,
lubrication points, types and amounts of lubricant, tightening torque, and the wiring diagrams.
Reassembl
y

-7-
MODEL Variable
Fixed 10 20 30 40 50 60
Work Flow
CM 7MR
CM 7MRU
CM 7MC
General assembly
Dust Cover
Ass’y
Handle (B)
Cord Armor
Gear Cover
Ass’y
Seal Plate
Handle (A)
Switch
Cord
Pinion
Seal Washer
Felt Packing
Ball Bearing
(6301VV)
Rubber Ring (B)
Bearing
Cover (A)
Armature
Dust Seal
Ball Bearing
(6000VV)
Bearing
Bushing
Gear
Housing Ass’y
Stator Ass’y
Bearing
Cover (B)
Ball Bearing
(6302VV)
Felt Packing
(B)
Packing Gland
Spindle
STANDARD REPAIR TIME (UNIT) SCHEDULES

Model CM 7MR
WALL CHASER
LIST NO. E721
(E1)
2009㨯6㨯22
22% TU01684
ᒻޓޓޓฬ ࿑ޓޓޓ⇟
ዤޓᐲ
CM7MR
䎵䏈䏙䎑䎔
1
2
3
4
5
6
7
8
10
11 13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
29
30
31
32
33
34
35
36
37
38
47
48
39
40
41
42
43 44
45
46
49
50
51
52
53
54
55
56
84
57
58
73
59
60
61
63
64
65
66
67
68 69
70
78
72
79
85
86
82
74
75
77
81
87
89
27
9
14
13
63
63
63
69
69
69
63
63
65
80
501
12
88
64
83
76
71
64
62
53 70
90
74
83
73
76 77
89
81
45
46
91

PART
S
CM 7MR
DESCRIPTION REMARKS
1 994-192 HEX. SOCKET HD. BOLT (W/FLANGE) M5 X 16 4
2 320-227 PACKING GLAND 1
3 320-228 SEAL PLATE 1
4 320-234 SPINDLE 1
5 990-852 FELT PACKING (B) 1
6 630-2VV BALL BEARING 6302VVCMPS2L 1
7 320-229 BEARING COVER (B) 1
8 GEAR 1
9 939-542 RETAINING RING FOR D12 SHAFT (10 PCS.) 1
10 323-209 TAPPING SCREW (W/FLANGE) D5 X 35 (BLACK) 4
11 984-509 SEAL LOCK HEX. SOCKET HD. BOLT M5 X 14 2
12 320-217 GEAR COVER ASS'Y 1 INCLUD. 15, 16, 25, 26, 91
13 331-050 BOLT M14 2
14 331-045 NYLON WASHER D14 2
15 320-219 SPRING 1
16 306-888 PUSHING BUTTON 1
17 320-226 SPECIAL NUT M10 1
18 PINION 1
19 320-221 SEAL WASHER 1
20 320-222 FELT PACKING 1
21 630-1VV BALL BEARING 6301VVCMPS2L 1
22 994-208 RUBBER RING (B) 1
23 320-220 BEARING COVER (A) 1
24 949-236 MACHINE SCREW M5 X 10 (10 PCS.) 2
25 306-890 LOCK PIN 1
26 320-218 O-RING 1
27 330-032 GEAR AND PINION SET 1 INCLUD. 8, 18
*28 360-762C ARMATURE 110V 1
*28 360-762E ARMATURE 220V-240V 1
29 320-215 FAN GUIDE 1
30 961-501 HEX. HD. TAPPING SCREW D5 X 60 2
*31 340-664C STATOR ASS'Y 110V 1 INCLUD. 32
*31 340-664E STATOR ASS'Y 220V-230V 1 INCLUD. 32
32 958-032 BRUSH TERMINAL 2
33 320-216 DUST SEAL 1
34 600-0VV BALL BEARING 6000VVCMPS2L 1
35 321-536 BEARING BUSHING 1
36 325-640 HOUSING ASS'Y 1 INCLUD. 42
37 NAME PLATE 1
38 938-477 HEX. SOCKET SET SCREW M5 X 8 2
39 HITACHI LABEL (A) 1
40 940-540 BRUSH CAP 2
*41 999-044 CARBON BRUSH (1 PAIR) 2
*41 999-074 CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) 1 FOR EUROPE, AUT
*41 999-044 CARBON BRUSH (1 PAIR) 1 FOR EUROPE, AUT
42 980-487 BRUSH HOLDER 2
43 325-641 HANDLE (B) 1
44 320-238 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK 1
*45 984-750 TAPPING SCREW (W/FLANGE) D4 X 16 2
*45 984-750 TAPPING SCREW (W/FLANGE) D4 X 16 1 FOR GBR (110V)
- 2 - 06 - 09
*ALTERNATIVE PARTS
ITEM
NO. NO. USED
CODE NO.

PART
S
CM 7MR
DESCRIPTION REMARKS
*46 960-266 CORD CLIP 1
*46 331-336 CORD CLIP 1 FOR GBR (110V)
47 325-642 HANDLE (A) 1
48 305-812 TAPPING SCREW (W/FLANGE) D4 X 16 (BLACK) 4
49 981-373 TUBE (D) 2 FOR CORD
*50 940-778 CORD ARMOR D10.7 1
*50 331-335 CORD ARMOR D11.2 1 FOR GBR (110V)
*51 500-247Z CORD 1 (CORD ARMOR D10.7)
*51 500-450Z CORD 1 (CORD ARMOR D10.7) FOR GBR (230V)
*51 500-482Z CORD 1 (CORD ARMOR D11.2) FOR GBR (110V)
52 937-981 SIDE HANDLE FOR M14 1
53 331-027 HANDLE ARM (B) 1
54 331-058 HANDLE ARM (A) 1
55 331-053 NYLON WASHER D12 1
56 331-037 HANDLE PLUG 1
57 331-026 GEAR BOX BRACKET 1
58 331-048 HEX. SOCKET HD. BOLT M5 X 12 4
59 331-059 HANDLE RATCHET 1
60 331-043 BOLT WASHER D12 1
61 331-044 BOLT M12 1
62 HITACHI LABEL (C) 1
63 331-028 ROLLER 6
64 331-031 ROLLER SPACER (30) 3
65 331-029 ROLLER SHAFT 2
66 331-052 KNOB BOLT 1
67 331-062 LOCK WASHER 1
68 331-040 SQUARE NUT M8 1
69 331-041 SHAFT CAP 4
70 331-046 HEX. SOCKET HD. BOLT M4 X 12 1
71 331-032 BLADE SPACER (3) 1
72 937-907Z WHEEL WASHER (A) 1
73 331-042 NYLOCK NUT M12 1
74 331-038 RUBBER GROMMET 1
75 331-050 BOLT M14 1
76 331-056 DUST GUARD (A) 1
77 331-054 DUST COVER (A) 1
78 331-034 BLADE WASHER 1
79 331-033 BLADE SPACER (5) 8
80 331-035 DRIVE SHAFT 1
81 331-030 ROLLER SPACER (20) 1
82 331-049 HEX. SOCKET HD. BOLT M6 X 25 1
83 331-060 GEAR BOX CLAMP 1
84 331-051 NYLOCK NUT M5 4
85 331-048 HEX. SOCKET HD. BOLT M5 X 12 1
86 331-047 HEX. SOCKET HD. BOLT M4 X 20 6
87 331-055 DUST COVER (B) 1
88 331-057 DUST GUARD (B) 1
89 331-061 VACUUM COUPLING 1
90 331-025 DUST COVER ASS'Y 1 INCLUD. 53-70, 73, 74, 76, 77, 81, 83-89
91 937-033 FELT WASHER 1
06 - 09 - 3 -
*ALTERNATIVE PARTS
NO.
USED
CODE NO.
ITEM
NO.

CM 7MR
DESCRIPTION REMARKS
501 331-036 WRENCH 22MM 1
- 4 - Printed in Japan 06 - 09
(090622N)
*ALTERNATIVE PARTS
NO.
USED
CODE NO.
ITEM
NO.
STANDARD ACCESSORIES

Model CM 7MRU
WALL CHASER
LIST NO. E722
(E1)
2009㨯6㨯22
22% TU01686
ᒻޓޓޓฬ ࿑ޓޓޓ⇟
ዤޓᐲ
CM7MRU
䎵䏈䏙䎑䎔䎵䏈䏙䎑䎔
1
2
3
4
5
6
7
8
10
11 13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
29
30
31
32
33
34
35
36
37
38
47
46
39
40
41
42
43
44
45 49
48
50
51
52
27
9
14
13
501
12
63
53
54
55
56
57
85
58
59
74
60
61
62
64
65
66
67
68
69 70
79
73
80
86
87
83
75
76
78
82
88
90
64
64
64
70
70
70
64
64
66
81
89
65
84
77
72
65
71
54 71
91
75
84
74
77 78
90
82
92

PART
S
CM 7MRU
DESCRIPTION REMARKS
1 994-192 HEX. SOCKET HD. BOLT (W/FLANGE) M5 X 16 4
2 320-227 PACKING GLAND 1
3 320-228 SEAL PLATE 1
4 320-234 SPINDLE 1
5 990-852 FELT PACKING (B) 1
6 630-2VV BALL BEARING 6302VVCMPS2L 1
7 320-229 BEARING COVER (B) 1
8 GEAR 1
9 939-542 RETAINING RING FOR D12 SHAFT (10 PCS.) 1
10 323-209 TAPPING SCREW (W/FLANGE) D5 X 35 (BLACK) 4
11 984-509 SEAL LOCK HEX. SOCKET HD. BOLT M5 X 14 2
12 320-217 GEAR COVER ASS'Y 1 INCLUD. 15, 16, 25, 26, 92
13 331-050 BOLT M14 2
14 331-045 NYLON WASHER D14 2
15 320-219 SPRING 1
16 306-888 PUSHING BUTTON 1
17 320-226 SPECIAL NUT M10 1
18 PINION 1
19 320-221 SEAL WASHER 1
20 320-222 FELT PACKING 1
21 630-1VV BALL BEARING 6301VVCMPS2L 1
22 994-208 RUBBER RING (B) 1
23 320-220 BEARING COVER (A) 1
24 949-236 MACHINE SCREW M5 X 10 (10 PCS.) 2
25 306-890 LOCK PIN 1
26 320-218 O-RING 1
27 330-032 GEAR AND PINION SET 1 INCLUD. 8, 18
28 360-762E ARMATURE 220V-240V 1
29 320-215 FAN GUIDE 1
30 961-501 HEX. HD. TAPPING SCREW D5 X 60 2
31 340-664E STATOR ASS'Y 220V-230V 1 INCLUD. 32
32 958-032 BRUSH TERMINAL 2
33 320-216 DUST SEAL 1
34 600-0VV BALL BEARING 6000VVCMPS2L 1
35 321-536 BEARING BUSHING 1
36 325-640 HOUSING ASS'Y 1 INCLUD. 42
37 NAME PLATE 1
38 938-477 HEX. SOCKET SET SCREW M5 X 8 2
39 HITACHI LABEL (A) 1
40 940-540 BRUSH CAP 2
*41 999-044 CARBON BRUSH (1 PAIR) 1
*41 999-074 CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) 1
42 980-487 BRUSH HOLDER 2
43 320-236 RESISTOR 1
44 325-641 HANDLE (B) 1
*45 320-235 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK 1
*45 320-371 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK 1 FOR HOL
46 325-642 HANDLE (A) 1
47 305-812 TAPPING SCREW (W/FLANGE) D4 X 16 (BLACK) 4
48 960-266 CORD CLIP 1
- 2 - 06 - 09
*ALTERNATIVE PARTS
ITEM
NO. NO. USED
CODE NO.

PART
S
CM 7MRU
DESCRIPTION REMARKS
49 984-750 TAPPING SCREW (W/FLANGE) D4 X 16 2
50 981-373 TUBE (D) 2 FOR CORD
51 940-778 CORD ARMOR D10.7 1
52 500-247Z CORD 1 (CORD ARMOR D10.7)
53 937-981 SIDE HANDLE FOR M14 1
54 331-027 HANDLE ARM (B) 1
55 331-058 HANDLE ARM (A) 1
56 331-053 NYLON WASHER D12 1
57 331-037 HANDLE PLUG 1
58 331-026 GEAR BOX BRACKET 1
59 331-048 HEX. SOCKET HD. BOLT M5 X 12 4
60 331-059 HANDLE RATCHET 1
61 331-043 BOLT WASHER D12 1
62 331-044 BOLT M12 1
63 HITACHI LABEL 1
64 331-028 ROLLER 6
65 331-031 ROLLER SPACER (30) 3
66 331-029 ROLLER SHAFT 2
67 331-052 KNOB BOLT 1
68 331-062 LOCK WASHER 1
69 331-040 SQUARE NUT M8 1
70 331-041 SHAFT CAP 4
71 331-046 HEX. SOCKET HD. BOLT M4 X 12 1
72 331-032 BLADE SPACER (3) 1
73 937-907Z WHEEL WASHER (A) 1
74 331-042 NYLOCK NUT M12 1
75 331-038 RUBBER GROMMET 1
76 331-050 BOLT M14 1
77 331-056 DUST GUARD (A) 1
78 331-054 DUST COVER (A) 1
79 331-034 BLADE WASHER 1
80 331-033 BLADE SPACER (5) 8
81 331-035 DRIVE SHAFT 1
82 331-030 ROLLER SPACER(20) 1
83 331-049 HEX. SOCKET HD. BOLT M6 X 25 1
84 331-060 GEAR BOX CLAMP 1
85 331-051 NYLOCK NUT M5 4
86 331-048 HEX. SOCKET HD. BOLT M5 X 12 1
87 331-047 HEX. SOCKET HD. BOLT M4 X 20 6
88 331-055 DUST COVER (B) 1
89 331-057 DUST GUARD (B) 1
90 331-061 VACUUM COUPLING 1
91 331-025 DUST COVER ASS'Y 1 INCLUD. 54-71, 74, 75, 77, 78, 82, 84-90
92 937-033 FELT WASHER 1
06 - 09 - 3 -
*ALTERNATIVE PARTS
NO.
USED
CODE NO.
ITEM
NO.

CM 7MRU
DESCRIPTION REMARKS
501 331-036 WRENCH 22MM 1
- 4 - Printed in Japan 06 - 09
(090622N)
*ALTERNATIVE PARTS
NO.
USED
CODE NO.
ITEM
NO.
STANDARD ACCESSORIES

Model CM 7MC
WALL CHASER
LIST NO. E723
(E1)
2009㨯8㨯5
22% TU01685
ᒻޓޓޓฬ ࿑ޓޓޓ⇟
ዤޓᐲ
CM7MC
䎵䏈䏙䎑䎔
46
1
2
3
4
5
6
7
8
10
11 13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
31
29
30
35
38
39
35
27
9
14
13
67
501
12
32
33
34
35
36
37
40
41
34
35
42
42
36
43
44
46
47
48
49
60
50
51
52
53
54
82
55
56
71
57
58
59
61
62
63
64
65
66 67
68
76
70
77
83
84
80
72
73
75
79
85
87
61
61
61
67
67
67
61
61
63
78
86
62
81
74
69
62
51 68
88
72
81
71
74 75
87
79
45
89
45

PART
S
CM 7MC
DESCRIPTION REMARKS
1 994-192 HEX. SOCKET HD. BOLT (W/FLANGE) M5 X 16 4
2 320-227 PACKING GLAND 1
3 320-228 SEAL PLATE 1
4 320-234 SPINDLE 1
5 990-852 FELT PACKING (B) 1
6 630-2DD BALL BEARING 6302DDCMPS2L 1
7 320-229 BEARING COVER (B) 1
8 GEAR 1
9 939-542 RETAINING RING FOR D12 SHAFT (10 PCS.) 1
10 323-209 TAPPING SCREW (W/FLANGE) D5 X 35 (BLACK) 4
11 984-509 SEAL LOCK HEX. SOCKET HD. BOLT M5 X 14 2
12 320-217 GEAR COVER ASS'Y 1 INCLUD. 15, 16, 25, 26 ,89
13 331-050 BOLT M14 2
14 331-045 NYLON WASHER D14 2
15 320-219 SPRING 1
16 306-888 PUSHING BUTTON 1
17 320-226 SPECIAL NUT M10 1
18 PINION 1
19 320-221 SEAL WASHER 1
20 320-222 FELT PACKING 1
21 630-1DD BALL BEARING 6301DDCMPS2L 1
22 994-208 RUBBER RING (B) 1
23 320-220 BEARING COVER (A) 1
24 949-236 MACHINE SCREW M5 X 10 (10 PCS.) 2
25 306-890 LOCK PIN 1
26 320-218 O-RING 1
27 330-032 GEAR AND PINION SET 1 INCLUD. 8, 18
*28 360-594U ARMATURE ASS'Y 110V-120V 1 INCLUD. 20, 21, 38, 39
*28 360-594E ARMATURE 220V-230V 1
29 984-271 HEX. HD. TAPPING SCREW D5 X 75 2
*30 340-546C STATOR 110V-120V 1
*30 340-546E STATOR 220V-230V 1
31 320-215 FAN GUIDE 1
32 321-535 HOUSING ASS'Y 1 INCLUD. 40
33 NAME PLATE 1
34 320-232 BRUSH COVER 2
35 305-812 TAPPING SCREW (W/FLANGE) D4 X 16 (BLACK) 6
*36 999-089 CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) 1
*36 999-061 CARBON BRUSH 7 X 17 X 22.5 (1 PAIR) 1
*36 999-061 CARBON BRUSH 7 X 17 X 22.5 (1 PAIR) 2 FOR GBR
37 320-230 HANDLE (A) 1
38 320-216 DUST SEAL 1
39 600-0VV BALL BEARING 6000VVCMPS2L 1
40 321-536 BEARING BUSHING 1
41 HITACHI LABEL (A) 1
42 322-323 BRUSH HOLDER SET 2
43 320-231 HANDLE (B) 1
44 320-238 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK 1
*45 984-750 TAPPING SCREW (W/FLANGE) D4 X 16 2
*45 984-750 TAPPING SCREW (W/FLANGE) D4 X 16 1 FOR GBR (110V)
- 2 - 08 - 09
*ALTERNATIVE PARTS
ITEM
NO. NO. USED
CODE NO.
