Hitachi SJ300-EL Series User manual

LARGE CAPACITY - SENSORLESS VECTOR SJ300EL SERIES
HIGH PERFORMANCE ELEVATOR DRIVES
Main Features
* Powerful starting torque of 200% at 0.5 Hz and 150% at 0 Hz.
*Conforms with Global standards including UL, c-UL, CE and C-Tick.
*PC-based configuration software and enhanced keypad offering compatibility with communication networks
*P and I gains can be set individually for up to 8 sets of frequencies.
*Supports a battery backup function which provides emergency drive (low speed) from external power supply/battery.
*Ability to switch to open loop vector control in case of encoder failure.
*A load cell analog input representing the weight of the elevator car for trimming torque bias adjustment
allows for extremely smooth operation.
*Easy operation and setup by removable keypad.
*Flexible S-curves for acceleration and deceleration. Each curve portion and linear portion can be configured separately.
PRODUCT
DATA
SHEET
Rated HITACHI Moto
r
Moto
r
Continuous 150% Maximum
Input Model Rated Rated Output Output Current Output Current
V
o
l
tage
N
um
b
er
h
p
kW
C
urrent
(A)
f
or
60
sec
(A)
f
or 5 sec
(A)
SJ300-055LFU-EL 5.0 3.7 24 36 42
SJ300-075LFU-EL 7.5 5.5 32 48 56
SJ300-110LFU-EL 10 7.5 46 69 81
SJ300-150LFU-EL 15 11.0 64 96 112
SJ300-185LFU-EL 20 15.0 70 105 123
SJ300-220LFU-EL 25 18.5 92 138 161
SJ300-300LFU-EL 30 22 115 172 201
SJ300-370LFU-EL 40 30 145 218 254
SJ300-450LFU-EL 50 37 175 262 306
SJ300
-55
0LFU
-
EL
60
4
5
20
7
310
362
SJ300-055HFU-EL 5.0 3.7 12 18 21
SJ300-075HFU-EL 7.5 5.5 16 24 28
SJ300-110HFU-EL 10 7.5 23 35 40
SJ300-150HFU-EL 15 11.0 32 48 56
SJ300-185HFU-EL 20 15.0 38 57 67
SJ300-220HFU-EL 25.0 18.5 48 72 84
SJ300-300LFU-EL 30 22 58 87 102
SJ300-370LFU-EL 40 30 75 113 131
SJ300-450HFU-EL 50 37 90 135 158
SJ300-550HFU-EL 60 45 101 152 177
SJ300
-75
0HFU
-
EL
75 55
149
224
261
Note: 1) All ratings at 60/50 Hz and 8 kHz carrier frequency, and based on a geared elevator application
2) Operation temperature: -10°C (14 °F) to 50 °C (120°F)
I/O Terminals 8 programmable logic inputs 50 Prospect Avenu
e
3 analog input channels (0-10v dc, +/- 10v dc, 4 -20 ma) Tarrytown, NY 10591
5 programmable open-collector logic outputs Tel: [phone]
5
2 analog programmable outputs Fax: [phone]
2
1 programmable NO/NC relay output WWW.Hitachi.us/inverters
Standard RS485/RS422 serial communications interface E-Mail: [email protected]
m
Optional Cards SJ-FB (vector control loop speed sensor)
SJ-DG (4-digit BCD/16-bit binary digital input)
SJ-DN (DeviceNet)
SJ-EN (Ethernet - ModBus TCP)
SJ-LW (LonWorks)
SJ-PB (ProfiBus DP)
400 - 480V, 3 Phase AC 200 - 240V, 3 Phase AC
12/12/2005
