CP-SX8350 LCD Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
Accessories and Lenses
Supplied
Accessories
Remote control, power cord, computer
cable, one standard SL702 lens, lens
cover, user's manual, security label,
application CD, adapter cover
Optional
Accessories
USBWL11N USB wireless adapter,
TB-1 wireless USB tablet
Optional Lenses 4 optional lenses are available: FL701,
ML703, LL704, UL705
Replacement Parts
Lamp CPWX8255LAMP (DT01291)
Remote Control HL02801
Filter MU06642
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution SXGA+ 1400 x 1050
White Light Output 5,000 ANSI lumens
Color Light Output 5,000 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 and 16:9 / 16:10 compatible
Contrast Ratio 3000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
1.2 - 1.8 : 1
(with standard lens)
Lens & Operation
Lens x1.5 with motorized zoom, focus and lens shift
Lamp Wattage 330W UHP
Expected Lamp Life* Approximately 2,500 hours (standard mode)
3,000 hours (Eco mode)
Expected Filter Life** Approximately 15,000 hours
Speaker Output 16W (8W x 2)
Acoustic Noise Level 37 dB (31 dB in Eco mode)
Keystone H: +/- 15º and V: +/- 35º
Compatibility
Computer VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+,
UXGA (compressed), MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
Computer signal TMDS Clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 2 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 BNC x 5
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video RCA jack x 3
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port / 10 base-T / 100 base-TX
Network LAN Wireless IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less, wireless adapter, TB-1)
Type B x 1 (USB display or mouse control)
Wired Remote Control 3.8 mm stereo mini jack
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 480W
Operating Temperature 32ºF - 95ºF (0ºC - 35ºC)
Dimensions (W x D x H) 19.6" x 15.6" x 5.3" (without lens)
Weight 19.0 lbs
Approvals UL 60950-1 / cUL FCC Part 15 subpart B class A
Warranty 3 year limited parts and labor
Installation
Series
Projection Throw Chart
Screen Size 4:3 Throw Distance
Diagonal Width Min Max
30 24 29 44
60 48 58 87
80 64 77 115
100 80 96 144
150 120 143 216
200 160 191 287
250 200 238 359
300 240 285 430
Throw Ratio: 1.2 - 1.8 : 1 (distance : width)
Screen size and throw distance are measured in inches
with standard lens SL702.
Projection Lens Chart
Lens Inches Meters
SL702 96 - 144 2.4 - 3.7
FL701 66 1.7
ML703 121 - 241 3.1 - 6.1
LL704 229 - 389 5.8 - 9.9
UL705
390 - 662 9.9 - 16.8
Projection distances measured in inches and meters with standard lens
and optional lenses when projecting onto a 100" diagonal screen.
