OPERATING MANUAL
for
MORSO manual notching machine
Model NFXL
Hoffmann Machine Company, Inc.
1386 Drexel Road Valdese, NC 28690 USA
Phone: (828) 430 - 4510 Fax: [phone]
e-mail: [e-mail]
www.Hoffmann-USA.com
Toll-free Technical Support: (866) 248 –0100

1
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Contents
Introduction page A-1 Rectifying Faults
Survey page B-1 Methods for Repair page I-1
Work Piece Safety:
Safety Devices page J-1Cutting of work piece on a
circular saw before notching page C-1 Regulations page J-1
Functional Description: Index of Spare Parts
General Description page D-1 Survey page K-1
Machine Description page D-2 Basic Machine page K-2
Table, complete page K-3Description of the Lever
Linkage System page D-3 Knife Block Unit page K-4
Technical Data page E-1 Drive Mechanism page K-5
Assembly Instructions:
General page F-1
Fitting of Table Extensions
and fences page F-1
Operating Instructions:
Before operating page G-1
Adjustment of moveable fence page G-2
Adjustment of Cock-bead Stops page G-3
Adjustment of Centre Stop page G-4
Adjustment of Flip Stops page G-5
Adjustment of Height Stop page G-6
Service References:
Lubrication Instructions page H-1
Cleaning page H-1
Changing of Knives and
Chip Breakers – Adjustment page H-2
Grinding of Knives page H-3
Regulation of Draw Bar page H-4
Adjustment of Springs page H-5
Changing of Spare Parts page H-6
Contents 0-1
Authorized U.S. Importer and Service Center:
Hoffmann Machine Company, Inc.
1386 Drexel Road
Valdese, N.C. 28690
Toll-free: 1 - 866 – 248 – 0100
www.Hoffmann-USA.com

2
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Introduction A-1
We recommend that you read this instruction manual thoroughly before using this machine.
Damage or faults on the machine caused by misuse or incorrect operation are not covered
under our conditions of warranty.
Use of the Instruction Manual:
The reference system of this Instruction Manual described below will help you to quickly find
the information you require (Picture A-1)
(1) Subject Heading
.
(2) Page Index
The letter (A) refers to the description of the section.
The number (1) refers to the page number of that section.
(3) Text
Description of the subject heading.
(4) Illustration
A three dimensional, numbered drawing of the text subject. The numbers in the text
correspond to the number in the drawing.

3
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Survey B-1
Pos. Designation Pos. Designation
1 Frame 14 Draw Bow (not shown)
2 Lever System (not shown) 15 Draw Bar (not shown)
3 Slide frame 16 Springs (not shown)
4 Cross 17 Height Stop
5 Knife block 18 Table Extensions
6 Knives (not shown) 19 Safety Guard
7 Machine Table 20 Centre Stop
8 Fixed Fence 21 Rear Stop
9 Movable Fence 22 Handle
10 Cock-Bead stops 23 Side Knife
11 Sliding Stops 24 Nose Knife
12 Foot Pedal 25 Chip Breaker (not shown)
13 Foot pedal tipper 26 Spring Holder (not shown)

4
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Work Piece C-1
Cutting of work piece on a circular saw before notchin
g
Before the notching of the work piece it must be cut to the correct length on a circular saw.
It is very important that the saw blade is exactly adjusted to 90°to the machine table (see fig.
1). The blade must also be exactly adjusted to 90°to the fence (see fig. 2).
Discrepancies arising from these cuts will result in gaps in the finished joints.
Fi
g
. 1
Fi
g
. 2

5
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Functional Description D-1
General Description
MORSØ-NFX notch cutter is the optimum machine to cut window bars, mullions, and cabinet
face-frames requiring haunch joints.
MORSØ-NFX is a manual foot-operated machine. The operation is easy.
MORSØ-NFX notch cutting machine is provided with 6 sliding longitudinal stops, fixed fences
(1500 mm) on both the right and left side of the machine, moveable fence, nose knives, side
knives, chip-breaker, cock-bead stops, centre stop, safety guard, and waste chute.
With the MORSØ-NFX you achieve a smooth, clean, and exact cut by notching the work
piece in two cuts.
This is done manually on the MORSØ-NFX.
The forward movement of the knife block is infinitely adjustable.
A special lever system makes the operation of the machine very easy. Twin return springs
bring the knife block back to its home position.
The height movement of the knife block (length of stroke) is infinitely adjustable.
The work pieces can be joined without any further finishing.

6
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Functional Description D-2
Picture D-2-1
Machine Description
D
-
2
D
-
2
-
1

7
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Machine Description
PICTURE D-2:
The MORSØ-NFX is constructed as a compact machine with a sturdy frame (1) with built in
lever system (2).
The cutting assembly is situated at the top of the machine.
In the slide frame (3), fitted at the cross (4), the knife block (5) is moved up and down. The
cross (4) runs in the guidings of the table.
The knives (6) fitted on the knife block (5) cut not only the notch but also cope the corners to
complete the joint.
The forward movement of the knife block (5) is made manually.
PICTURE D-2.1
The stile is placed on the table (7) against the fixed fences (8). The setting of the adjustable
fence (9) to the width of the stile is made by pushing this fence (9) towards the fixed fences
(8) until there is a distance of about 5 mm between the stile and the fixed fences (8).
PICTURE D-2:
The cock-bead stops (10) are adjusted to the required cutting depth of the notch.
The adjustment of the sliding longitudinal stops (11) is done by means of a template of the
stile.
MORSØ-NLFX can be fitted with nose knives from 12 to 26 mm.
MORSØ-NSFX can be fitted with nose knives from 6 to 20 mm.
Functional Description D-2

8
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Lever Linkage System
D-3
Functional Description D-3

9
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Description of the Lever Linkage System
The cutting movement is carried out manually. The length of stroke of the knives is adjusted
to max. 160 mm. The cutting takes place by means of a foot operated lever system.
The pedal (12) is pressed down.
The foot pedal lever (13) pulls the draw bow (14), draw bar (15), and the knife block (5)
down.
By relieving the foot pressure from the foot pedal the knife block returns to top position by
means of the two springs (16).
The height stop (17) is adjustable.
Functional Description D-3

10
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Technical Data
E-1
Technical Data E-1

11
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Technical Data
Machine Dimensions (max.): Working Capacity:
Length (a) 3,700 mm Nose Widths (NFXS) 6 – 20 mm
Width (b) 510 mm Nose Widths (NFXL) 12 – 26 mm
Height (c) 1,150 mm Width of Work Piece, max . 205 mm
Weight 100 kg Working Height (max.) 160 mm
Siting Considerations Extensions Table, left and right 1,000 mm
Distance to Wall min.1000 mm Fences, left and right 1,500 mm
Noise/Pollution:
Noise Level silent
Pollution nil/no dust
Technical Data E-1

12
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
In General
F-1
Assembly Instructions F-1

13
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
In General
The machine is delivered ready for use and complete with standard equipment.
Only the table extensions (18) and fences (8) are dismounted during transport.
NOTE before starting up first time:
1. The lever clamp on the arc is loosened (it functions as the rear stop when moving the
knife block backwards).
2. The knife block is moved halfway back, and the waste chute is fitted.
Place the machine 1 m from the wall as stated in D-1. The machine can be fastened to the
floor using parabolts through the two holes in the bottom of the machine frame.
Check each time before starting that all protection devices are correctly fitted.
Fitting the Table Extensions and fences
(the drawing shows the left side, the same procedure is used on the right side).
Before fitting, the ends of the table extension (18) and the table (7) must be cleaned
thoroughly. Special attention must be paid to the pin and screw holes, as the smallest
amount of dirt will prevent the correct alignment.
A
fter cleaning, the table extension is pressed against the table so that the pins placed in the
table extension are inserted in the pin holes in the table. The included bolt is now inserted
into the hole and fastened with a standard spanner.
The fence (8) is fitted on the table extension (location pins are fitted in the table extension). It
is secured with allen screws.
(Extra extension tables and supporting legs can be ordered as accessories).
Assembly Instructions F-1

14
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Before Operating
G-1
Operating Instructions G-1

15
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Before Operating
Before starting the machine the following must be checked and adjusted:
1. Check
a) knives (6)
general condition
sharpness
b) waste
room for waste
c) safety devices
fitting of all safety devices:
safety guard for knives (19)
d) table and table extension
cleanness and undamaged surface
2. Adjustments
a) Moveable fence (9)
(adjustment instructions page G-2)
b) Cock-bead stops (10)
(adjustment instructions page G-3)
c) centre stop (20)
(adjustment instructions page G-4)
d) sliding longitudinal stops (11)
(adjustment instructions page G-5)
e) height stop (17)
(adjustment instructions page G-6)
f) Rear Stop (21)
Operating Instructions G-1

16
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Moveable Fence
G-2
Operating Instructions G-2

17
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Adjustment of moveable fence (9)
The adjustment of the moveable fence (9) to the width of the moulding is made as follows:
1. Place the moulding in the machine against the moveable fence (9).
2. Loosen the screws (a) in the fence (9), and push the fence (9) towards the knife block and
the fixed fence (8) until there is a distance of about 5 mm between the moulding and the
fixed fence (8).
3. Fasten the screws (a) again.
Operating Instructions G-2

18
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Cock-bead stops
G-3
Operating Instructions G-3

19
Instruction Manual
MORSØ Notch Cutting Machine
Model NFX
Adjustment of the cock-bead stops (10)
The cock-bead stops (10) are adjusted as follows:
1. Loosen the Allen screws on the cock-bead stops (10) and move these to rear of the
sliding guide.
2. Using a test piece (a) make a notch cut into the cock-bead. This cut must be the same
depth as the cock-bead. The overall width must be equal to the width of the centre cross-
rail. When you are satisfied the two sizes are equal, we can now position and lock the
cock-bead stops (10).
3. Press the foot-pedal down and hold it in this position. By operating the hand lever, bring
the knife block (5) forward into the previously cut notch. Position the cock-bead stops (10)
against the cock-bead and lock them in place using the Allen screws. When these stops
are fixed in position the knife block (5) can only cut into the cock-bead as far as this
setting. The notch cut depth is then referenced from the face of the cock-bead. The width
of stile can vary without changing this setting.
4. Check the alignment of the two cock-bead stops (10) using a straight edge. By bringing
the knife block (5) forward, check that they are level and true with the fence.
5. Lock the second Allen screws on the cock-bead stops (10).
6. This setting will allow you to make regularly accurate notch cuts in the stiles. These stops
will need no further adjustment unless the size of the cock-bead changes.
Operating Instructions G-3
