Hollyland SOLIDCOM C1 User manual

QuickGuide
V1.0.0
HOLLYLAND SOLIDCOM C1

Introduction
Thank you for purchasing
The SOLIDCOM C1 includes eight single-sided remote wireless headsets along with
eight rechargeable batteries, a charger, a HUB base with wired headset, and accessories.
It is a full-duplex wireless DECT intercom system engineered to provide clear audio and
all-day wearing comfort in a true-wireless design with no beltpack required. The system
operates in the 1.9GHz band/5GWIFI(5190MHz), providing a reliable transmission range up to 1000ft (350m
radius (LOS.
This Quick Guide will guide you through the installation and use of the equipment.
FULL-DUPLEX WIRELESS INTERCOM SYSTEM

SOLIDCOM C1 Headset Intercom Package
①HUB Base 1 x
②Remote Headset (with blue nameplate) 8 x
④ Charging Case 1 x
⑩High-gain Antennas 4 x
③ 3.5mm HUB Headset (with red nameplate) 1x
⑦ 12V/2A DC Adapter 2 x
⑨ USB Type-A to Type-C Cable 1 x
⑧Over-ear Cushion 9 x
⑪ Storage Case 1 x
⑫ Quick Guide 1 x
⑬ Warranty Card 1 x
Note: The amount of the items listed above depends on the edition.
 Battery 16 x
⑤
① ② ③
⑥⑦⑧
⑨
④
⑥Microphone Cushion 9 x
Packing List
1

Product Interfaces
①HUB Headset Volume Knob
②Display
④LEFT Arrow Key
③UP Arrow Key
HUB Base Interfaces
A
⑤Menu/Confirm Button - Long press to enter the
main menu/press once to confirm
⑥DOWN Arrow Key
⑦RIGHT Arrow Key
⑧Join/Exit Group A Button for the 3.5mm HUB
Headset - The indicator turns off when the HUB
Headset exit Group A’s conversation, and turns
on in orange after joining in
⑨ 3.5mm Headphone Jack

⑩Join/Exit Group B Button for the 3.5mm HUB
Headset - The indicator turns off when the HUB
Headset exit Group B’s conversation, and turns
on in orange after joining in
A
⑫ANNOUNCE Button - Press and hold the button
while making an ANNOUNCE, release the button
when finished
⑭Power Switch
⑬RF Antenna Interface
⑮DC Power Interface
⑯ PGM Audio Input Interface
⑰2-wire Audio Input & Output Interface
⑱ RJ45 Network Port
⑲4-wire Audio Input & Output Interface
(RJ45 network socket)
⑳ UAC Interface
NP-F Battery Bay
① ②③④⑤⑥⑦ ⑧⑨⑩⑪⑫
⑬
⑭⑱⑲
⑳
⑮⑯⑰
⑪USB Interface
V-Mount/G-Mount Battery Plate (Subject to the
actual product you purchased)
2

Product Interfaces
1
3
4
5
6
7
① Power/Connection Indicator
②Microphone
⑨Power Button
③ USB Type-C Interface - For firmware upgrade, and headset pairing
Headset Interfaces
B
⑤Volume + Button
⑥Volume - Button
⑦A Button - Lights up when joined Group A, turns off when exited Group A;
Long press for 5 seconds to pair
⑧B Button - Lights up when joined Group B, turns off when exited Group B
④Battery Compartment
⑩Speaker
B
2
8
9
10
3

Product Interfaces
① Charging Indicator
Orange: Charging in progress
Green: Fully charged
② Charging Contact
Charging Case Interfaces
c
②
③
①
c
③ DC Charging Interface
4

Quick Start Guide
Set Up HUB Base
Install the HUB antennas.
Power Up HUB Base
Connect the 12V/2A DC Adapter to the HUB base. Press the Power Switch to turn on.
Note: The HUB Base can be powered using NP-F battery, V-Mount/G-Mount batter y, or DC power supply.
5

Quick Start Guide
Install Headset Battery
Turn On Headset
Note: The indicator light stops flashing and turns to
static green when the HUB Base and the
Remote Headset(s) are successfully connected.
Mute/Unmute Microphone
Mute/Unmute the headset’s microphone by moving the mic boom up/down.
1.Move the mic boom up to the MUTE position that makes a
CLICK sound, and the HUB Base’s interface displays "MUTE"
corresponding to the headset status.
2.Move the mic boom down to the TALK position that makes a
CLICK sound, and the HUB Base’s interface displays "TALK"
corresponding to the headset status.
TALK
MUTE
Stop-point
Stop-point
The device is now ready for use.
MUTE
TALK
6
Step 1 : Slide the battery compartment
cover lock
Step 2 : Open the cover Step 3 : Place the batteries into the compartment
and cl ose the battery c over
Name plate
Powe r Switch
Powe r up the Headset

①HUB Base configuration - Master/Slave
②HUB Base battery level
HUB Base Main Display Interfaces
③Headset signal strength
④Headset battery level - turns red in low battery
⑤Headset number
⑥Headset status
TALK: Headset is active to hear and talk
MUTE: Headset is muted to hear only
LOST: Headset lost connection with HUB Base
⑦Network connection status
⑧ WiFi status
①
②
③
④⑤
⑥
⑧
⑦
Quick Start Guide
7
Master

Quick Start Guide
Headset Status Indicator
①FLASH GREEN: Headset disconnected
②STAT IC GREEN: Headset connection successful
③FLASH RED: Battery low, please change the battery
Pairing Operation
The HUB Base and Remote Headsets that come in one system package will auto pair up right out of box.
Manual pairing is only required when there is a need for adding or changing headset or HUB base to the
system.
Connect the HUB Base and the Headset with a USB-C Cable.
Pairing requires a USB-C cable.
Connect one end to the USB interface on the HUB Base’s front panel, and the other end to the USB-C
interface of the headset.
The HUB Base screen will display the Select Number interface. Locate the designed headset number with
the arrow keys, and press the round Menu/Confirm Button to complete number setting and pairing.
8

Quick Start Guide
Headset(s) Number Setting via HUB Base
When re-pairing and numbering the headset, be sure to turn on all the headsets to avoid selecting
duplicate numbers, which may lead to connection failure with other headsets.
In case of wrong numbering of a headset, simply connect it to the HUB with the USB cable and operate
the pairing and numbering process again.
Cascade Connections
Multiple intercom systems can be cascaded to expand the number of intercom headsets. The Solidcom C1
HUB Base supports two cascading methods, 4-wire analog and IP digital signal cascading. Generally,
using 4-wire analog mode to cascade is recommended when cascading two intercom systems. If three or
more sets are cascaded, it is recommended to use IP digital signal cascade.
It is recommended to use CAT5e super five network cable and RJ45 crystal head with 568B sequence
standard for cascade connection.
Stan dard N etwork Cable Cabl e Spec Max. L ength
CAT5e
CAT 6e 300 m
Two Systems Cascade via 4-Wire Interface
Use a standard network cable to connect two HUB bases through the 4W interface. The network cable is
generally up to 300 meters long.
300m network cable
9

Quick Start Guide
4 Wire Settings
After connecting the two systems with the network cable, configure each HUB Base’s line sequence by
entering "4 Wire Settings" and selecting "Line sequence switching".
Set the first HUB Base to “Standard mode” and the second HUB Base to “Cross mode”.
Ente r 4 Wire menu, and se lect
Lin e sequence switchin g Set to Standard mode
HUB❶
4 Wire
Sett ings
HUB❷En ter 4 Wire menu, an d select
Lin e sequence switchin g Set to  Cros s mode
4 Wire
Sett ings
10
Two Systems Cascade via IP Network
Use a standard network cable to connect the two systems through the RJ45 network port. Either one of the
two RJ45 network ports on the HUB works.The network cable is generally up to 300 meters long.
300m network cable
HUB Display Interfaces

Quick Start Guide
HUB Settings
After connecting the two systems with the network cable, configure each HUB Base’s basic settings as
Master or Slave device. Generally, the first system is set as Master Device, and the second one as Slave
Device.
In this case, you need to turn OFF the “Obtain IP address automatically” under “Network” settings on both
the HUB Bases.
HUB Display Interfaces
Enter Network menu, and set the
Obtain IP address automatically to OFF
Ente r Master and Slave me nu,
and se lect Master Device 
HUB ❶
Netw ork
Sett ings
HUB❷ En ter Network menu, a nd set the
Obt ain IP address automatically to OFF Enter Master and Slave menu,
and select Slave Device
Netw ork
Sett ings
Tap Sca n to enter. The sc reen wil l
disp lay the Master Device s IP address.
Use th e Arro w Key to locate the IP
address, a nd press C onfirm.
11
Three Systems Cascade via IP Network
Cascade Connection Method
When cascading three systems, it is recommended to use the IP network connection. Set the first system's
HUB to Master Device and the second and third HUBs to Slave Device.
Netw ork cable Netw ork cable

Quick Start Guide
Group Settings
The HUB Base supports A and B grouping settings. You can view the system’s current group setting by
entering the Group menu on the HUB. To operate group settings, connect the computer and the HUB via
the RJ45 interface using the network cable, and enter the Group settings menu. Or download the Solidcom
APP on the mobile phone and connect to the HUB through WiFi to access the Group settings menu.
Check Group Settings on HUB
HUB Di splay Interfaces
Viewing method:
Operate Grouping via Computer
Enter the “Network” menu on the HUB, and select
“Wired network settings” to view the HUB’s default IP
Address, User Name and Password.
Use a network cable to connect the computer and
the HUB via the RJ45 network port. Set the IP
address of the computer as [192.168.218.xxx],
and the default IP address of the HUB as
[192.168.218.10]
Long press the Menu/Confirm Button
to enter the Group settings menu
12

Quick Start Guide
Open the browser on the computer and visit http://192.168.218.10 to enter the configuration page of the
HUB.
A & B Group Buttons on Headset(s)
After entering Group setting on the HUB, the A and B Buttons on the connected headset will light up. The
buttons light status indicates which group the headset has joined. Press the A or B Button on the
headset to Join/Enter the corresponding group.
A and B Button Light Status Status
Ligh t ON
When t he A or B Button lights ON, it indicates the
head set has joined the corresponding group and can
conv erse with the other headset(s) in the same group .
Ligh t OFF When t he A or B Button lights OFF, it indicates the
head set has exited the corresponding group.
AB
AB
13

Parameters
14
Range 350m (1000ft) Line-of-Sight
Frequency Information
Frequency band: 1.9GHz DECT (varies by country and region)
Modulation mode: GFSK
Transmit power:20.79dBm (varies by country and region)
Receiving sensitivity: <-90dBm
Transmission Latency
Battery Capacity 700mAh (2.66Wh) Li-Ion battery
Headset Runtime Remote headset: ≈10h
Charging Time ≈2.5h
Frequency Response
Signal-to-Noise Ratio
Distortion
Microphone Type Electret
Maximum Input
Sound Pressure Level Electret
Output Sound
Pressure Level
HUB Base Netweight ≈1300g (antennas excluded)
Net Weight ≈170g (batteries included)
Temperature Range Working status: 0~+45℃
Storage status: -20~+60℃
Note: The frequency band and transmit power varies by country and region.
＜35ms
150Hz~7kHz
＞55dB
＜1％
Typical 98±3dBSPL(at94dBSPL1kHz)
Frequency band: 5190MHz Modulation mode:OFDM
Transmit power:9.10dBm

15
Hollyland Products User Group
HollylandTech
[email protected]
www.hollyland-tech.com
HollylandTech

16
Statement:
Al l co py r ig ht s be lon g to S he nzh en H ol lyl an d Te ch n ol og y Co , .L TD .
Trademark Statement:
Without the written approval of Shenzhen Hollyland Technology Co,.LTD, no
organization or individual may copy or reproduce part or all of the content of the text
without authorization, and may not disseminate it in any form.
Al l re pr e se nt at ion s, i nf orm at io n, r e co mm en d at io ns i n t hi s do cu m en t
do n ot c on s ti tu te w arr an ti es of a ny k in d, ex pr es s or i m pl ie d.
Note:
Due to product version upgrades or other reasons, this quick guidewill be updated
from time to time. Unless otherwise agreed, this document is provided as a guide for
use only. All representations, information, recommendations in this document do not
constitute warranties of any kind, express or implied.

FCC Requirement
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. This device
complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference.
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy, and if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment.This equipment should be installed and operated
with minimum distance 20cm between the radiator& your body.
