Holstein Housewares HF-09016 User manual

PIE MAKER
MÁQUINA PARA PASTELES
THIS MANUAL IS TO BE USED WITH ALL
ITEMS WITH THE MODEL NUMBER:
HF-09016
ESTE MANUAL DE USUARIO APLICA
PARA TODOS LOS PRODUCTOS CON
EL NÚMERO DE MODELO:
HF-09016
READ THIS MANUAL BEFORE USING THE PRODUCT AND SAVE FOR FUTURE REFERENCE
LEA ESTE MANUAL ANTES DE USAR EL ARTEFACTO Y GUÁRDELO PARA REFERENCIA

2www.holsteinhousewares.com
IMPORTANT SAFEGUARDS
WHEN USING ELECTRICAL APPLIANCES,
BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED TO PREVENT THE
RISK OF FIRE, ELECTRIC SHOCK, BURNS, OR
OTHER INJURIES OR DAMAGES.
1 . Read all instructions before using this appliance.
2 . Always unplug the appliance from the electrical outlet before relocating,
servicing, or cleaning it.
3 . Keep hands and utensils out of the appliance when in use. Do not touch
hot surfaces. CAUTION: Surface becomes hot during use.
4 . Do NOT plug/unplug the appliance into/from the electrical outlet with
your hands wet.
5 . Do NOT operate the appliance if the power cord is cut, damaged, or if
the wires are exposed.
6 . Keep the power cord and appliance AWAY from heated surfaces,
including stovetops, burners or heated ovens.
7 . Do NOT immerse in or expose the base, power cord, or plug to water or
any other liquids. NEVER use this appliance near water or wet surfaces.

3
www.holsteinhousewares.com
8 . To disconnect the appliance from an electrical outlet, pull directly on
the plug; DO NOT pull on the power cord.
9 . Do NOT put any stress on the power cord where it connects to the
appliance, as the power cord could fray and break.
10. Do NOT operate the appliance if it malfunctions, or if it is dropped or
damaged.
11. This appliance has NO user-serviceable parts. Do NOT attempt to
examine or repair this appliance yourself. ONLY qualied and approved
service personnel should perform servicing.
12. This appliance is intended for HOUSEHOLD and INTERIOR USE ONLY
and cannot be used for any other purpose. This item is NOT a toy.
13. Keep the appliance out of the reach of children and pets. This appliance
is NOT intended to be used by children and strict supervision is
necessary when used near children.
14. Do NOT leave the appliance unattended while it is in use.
15. Do NOT use any attachments or accessories that are not recommended
or sold and approved by the manufacturer for this appliance.
16. Always operate the appliance on a dry, at, stable, heat-resistant
surface to avoid accidents.
17. Do NOT move the appliance while it is in use. Always let it cool before
moving.
18. Do NOT let cord hang over the edge of a table or the counter top.
19. Use an oven mitt for safety when opening and closing the lid for safety.

4www.holsteinhousewares.com
WARNING: During the rst few minutes of initial use, you may notice
a little smoke and/or a slight odor. This is normal and should quickly
disappear. It will not recur after appliance has been used a few times.
SAVE THESE INSTRUCTIONS!
ADDITIONAL SAFEGUARDS
DO NOT OPERATE APPLIANCE IF THE
POWER CORD SHOWS ANY DAMAGE OR IF
APPLIANCE WORKS INTERMITTENTLY OR
STOPS WORKING ENTIRELY.
• EXTENSION CORDS
A short power-supply cord is to be provided to reduce the risk resulting
from becoming entangled in or tripping over a longer cord. Longer
detachable power-supply cords or extension cords are available and may
be used if care is exercised in their use. If a longer detachable power-supply
cord or extension cord is used:
1 . The marked electrical rating of the cord set or extension cord should be
at least as great as the electrical rating of the appliance, and
2 . The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it can be tripped over, snagged, or pulled
on unintentionally by children or the user.

5
www.holsteinhousewares.com
• POLARIZED PLUG
This product has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to t into a polarize
outlet only one way. If plug does not t fully into the outlet, reverse the plug.
If it still does not t contact a qualied electrician. Do not attempt to modify
the plug in any way.
HOW TO OPERATE
BEFORE FIRST USE:
1 . Unpack the appliance and all its parts. Remove all packaging materials,
including any stickers or labels.
2 . Read these instructions carefully.
3 . Clean the interior surface of the appliance with a damp cloth. Wipe dry
with a soft cloth immediately. Do not use abrasive cleaning materials.
Wipe down the exterior with a soft dry cloth.
4 . NEVER IMMERSE APPLIANCE OR CORD IN WATER OR ANY OTHER
LIQUID.
5 . Position the appliance on a stable, dry, level, heat-resistant surface near
an electrical outlet.
6 . Unroll the electrical cord.
7 . Operate this appliance on a separate outlet and circuit from other
appliances to avoid overloading the circuit.

6www.holsteinhousewares.com
CAUTION: The surfaces of the appliance get hot. To avoid accidental
burns, scalping or steam being released while cooking, always open
and close the lid using an oven mitt.
FOR HOUSEHOLD USE ONLY
USING THE APPLIANCE:
1 . This appliance is intended ONLY for household use of baking pies.
2 . Prepare pie discs, for the base and the top of the pie, and all pie llings
following the recipe instructions.
3 . Release the safety lock and lift the lid to the open position.
4 . Coat the non-stick surface with a small amount of vegetable oil. This
can be done with a paper towel or with a non-stick cooking oil spray.
Wipe o any excess oil. It is recommended to periodically do this before
using the appliance to maintain the quality of the non-stick coating.
5 . Check and conrm the voltage of the appliance is the same as the outlets.
Then, plug electrical cord carefully on a separate outlet from other
appliances to prevent the circuit from being overloaded.
6 . The red indicator light will turn ON as soon as you connect the
appliance. The green indicator light will turn ON when the appliance
reaches the maximum operating temperature. The appliance is ready
to cook as soon as the green light turns ON. NOTE: The green indicator
light turn ON and OFF, during its use. It does not reect cooking
completion, only temperature cycles from minimum (green light OFF) to
maximum (green light ON)
7 . Place the large disc (4.5”, 11.5 cm) into the pie shape reservoir of the

7
www.holsteinhousewares.com
lower non-stick coated plate. Caution: Use oven mitts. Only touch the
pastry as the pie maker will be very hot.
8 . Pour in your pre-cooked pie lling making sure it does not overow
onto non stick-plate surface. Note: Try to ll enough to make a small
mound, so that the small dough disk that will be placed on top to close
the pie will come in contact with the upper plate and cook thoroughly.
9 . Place a small disc (4”, 10 cm) over the pie lling, and make sure to align
the edges of both pie dough discs on top of the edge crimper as best as
possible.
10. Close the lid and let cook for approximately 7-10 minutes, or until fully
cooked.
11. After the pies are ready, carefully remove them using an oven mitt and
a heat resistant wood or plastic spatula. DO NOT use metal utensils
because they will scratch and damage the non-stick coated surface.
12. If cooking more than one batch in a session, after removing the rst
batch, close the top lid to maintain the heat and then place the next
batch when ready. NOTE: Cooking time may vary between batches. DO
NOT use the item continuously for more than 20 minutes.
13. As soon as you are nished cooking, unplug the appliance and allow it cool
down.
CLEANING
Proper maintenance will ensure years of use of your appliance. Clean the
appliance after every use following these steps. This appliance contains no
user serviceable parts and requires little maintenance.
WARNING: The surfaces of the item will get very hot during use,
unplug the appliance and allow it to cool down before cleaning.

8www.holsteinhousewares.com
1 . Clean the interior and exterior surfaces of the pie maker with a damp
cloth or sponge. Wipe dry with a soft cloth.
2 . To remove dough baked onto the cooking surface, pour a small amount
of cooking oil onto the hardened residue. After 5 minutes, carefully wipe
with a paper towel or dry cloth.
3 . NEVER USE ABRASIVE CLEANERS OR SCOURING PADS TO CLEAN THE
PIE MAKER, AS THOSE MAY DAMAGE THE SURFACES.
CAUTION:
DO NOT IMMERSE THE APPLIANCE, THE POWER CORD OR
THE PLUG INTO WATER OR ANY LIQUIDS.
STORAGE
1 . After following the steps of cleaning and maintenance, collect the
power cord.
2 . Store the appliance in a dry and clean place.
SPECIFICATIONS
Before using the appliance, verify that the domestic supply voltage matches
the specications indicated on the appliance.
120V~60Hz 760W

9
www.holsteinhousewares.com
PARTS LID LATCH
UPPER NON-STICK PLATE
BOTTOM
NON-STICK PLATE
PASTRY CUTTER
SMALL
4” 10 CM
LARGE
4.5” 11.5 CM
EDGE CRIMPER
NON-SLIP BASE

10 www.holsteinhousewares.com
2
STEPS TO MAKE PIES
Cut the do ugh with your cutter
provided.
Let them cool down, serve and enjoy!
Place de large disc on the bottom
plate and pour in your pre-cooked
pie lling.
Place an small disc over the
ingredients. Close the lid and bake.
1
3
22

11
www.holsteinhousewares.com
TIPS
• Always coat the non-stick surface with a small amount of vegetable
oil. This can be done with a paper towel or with a non-stick cooking
oil spray. Wipe o any excess oil. It is recommended to periodically do
this before using the appliance to maintain the quality of the non-stick
coating.
• Let the pies cool before you serve.
• Use any pie crust recipe or a refrigerated pre-made pie crust
• Do not stretch the dough before baking as stretching will cause the
dough to thin out and break during baking.
• Have all ingredients (both pie dough discs and llings) prepared and
ready before baking the rst pie.
• If baking more than 1 batch of pies, allow the pie maker to cool between
batches
• Fill the bottom bottom dough disc generously, enough to make a small
mound so when the small dough disc that is placed on top comes in
contact with the top non-stick plate and cooks thoroughly. Do not over
ll it such that the lling seeps out.
FOR HOUSEHOLD USE ONLY

12 www.holsteinhousewares.com
Ingredients:
• 1 1/4 cups our
• 1/4 teaspoon salt
• 1/2 cup cold butter cut into cubes
• 1/4 cup cold water
Steps:
• In a large bowl, combine the ingredients. Knead until you create a ball.
• Wrap in plastic and refrigerate for 30 min.
• Roll out the dough on a lightly oured surface until ne and cut into
circles with the cutter provided.
Pie
Crust

13
www.holsteinhousewares.com
Ingredients:
• 1 red apple
• 2 tbsp cinnamon
• 2 tbs all spice
• 2 tbs nutmeg
• 2 tbs apple cider
• Pie dough
• 3/4 cup brown sugar
• Use any pie disc recipe or a
refrigerated pre-made pie disc
Apple
Pie
Steps:
• Dice your apples.
• Mix your ingredients together in a large bowl.
• Cut your dough with your pie cutter.
• Place the dough in the maker.
• Fill the dough with your mixture.
• Seal the pie with the dough.
• Bake for 7-10 minutes.
• Serve warm with some ice cream.
• *Makes 2-4 pies

14 www.holsteinhousewares.com
Ingredients:
• 1 can cherry pie lling
• Pie dough
• 8 oz cream cheese
• 1 cup powdered sugar
• 2 eggs
• 1 cup heavy cream
Steps:
• Roll out the dough and cut the dough using your pie cutter.
• Mix your cream cheese and powdered sugar together.
• Then add the eggs and whipping cream.
• Place the dough in the maker.
• Add in the lling half way. Then top with some cherry lling.
• Seal the top of the pie with the dough.
• Bake for 7-10 minutes.
• Serve warm and enjoy!
• *Makes 6-8 pies
Cherry Cream
Pie

15
www.holsteinhousewares.com
Ingredients:
• 1 can pumpking puree
• Pie dough
• 2 eggs
• 1 can of eveporated milk
• Whiped cream
Steps:
• Roll out the dough and cut the dough using your pie cutter.
• Mix the eggs and evaporated milk.
• Place the dough in the maker.
• Add in the lling half way to the mix of eggs and evaporated milk. Pour
the lling into the pie.
• Seal the top of the pie with the dough.
• Bake for 7-10 minutes.
• Serve warm and enjoy!
• *Makes 6-8 pies
Pumpkin
Pie

16 www.holsteinhousewares.com
IMPORTANTES INSTRUCCIONES
DE SEGURIDAD
AL USAR ARTEFACTOS ELÉCTRICOS, SIEMPRE
DEBEN TOMARSE PRECAUCIONES BÁSICAS
DE SEGURIDAD PARA EVITAR EL RIESGO DE
INCENDIO, CHOQUE ELÉCTRICO, QUEMADURAS
U OTRAS LESIONES O DAÑOS.
1 . Lea todas las instrucciones antes de usar este artefacto.
2 . Siempre desenchufe el artefacto del tomacorriente antes de mover o
limpiar.
3 . Mantenga las manos y utensilios fuera del artefacto cuando se utilice.
No toque las supercies calientes. Utilice un guante de cocina y las
asas para abrir y cerrar el artefacto. ATENCIÓN: La supercie se calienta
durante su uso.
4 . NO conectar / desconectar el artefacto del tomacorriente con las
manos mojadas.
5 . NO utilice el artefacto si el cordón eléctrico esta roto, dañado, o si los
cables están expuestos.
6 . Mantenga el cordón eléctrico y el artefacto alejado de supercies
calientes, incluyendo estufas y hornos.
7 . NO sumerja el artefacto, cordón eléctrico o el enchufe en agua u otros
líquidos. NUNCA use este artefacto cerca del agua o supercies mojadas.

17
www.holsteinhousewares.com
8 . Para desconectar el artefacto del tomacorriente, tire directamente del
enchufe, NO tire del cordón eléctrico.
9 . NO ponga presión sobre el cordón eléctrico donde se conecta al
artefacto, ya que el cordón eléctrico podría romperse.
10. NO utilice el artefacto si funciona mal, o si se ha caído o dañado.
11. Este artefacto no tiene piezas que el usuario pueda reparar. No trate de
examinar o reparar este artefacto usted mismo. Sólo personal calicado
y aprobado debe realizar cualquier tipo de servicio.
12. Este artefacto está diseñado sólo para uso doméstico y uso en
interiores y no puede ser utilizado para ningún otro propósito. Este
artefacto no es un juguete.
13. Mantenga el artefacto fuera del alcance de niños y mascotas. Este
artefacto no está destinado a ser utilizado por niños y una estricta
supervisión es necesaria cuando se utiliza cerca de niños.
14. NO deje el artefacto desatendido mientras está en uso.
15. NO utilice ningún accesorio que no este recomendado o vendido y
aprobado por el fabricante de este artefacto.
16. Siempre opere el artefacto en un lugar seco, plano, estable, y resistente
al calor para evitar accidentes.
17. NO se debe mover el artefacto mientras está en uso. Siempre deje que
se enfríe antes de moverlo.
18. NO permita que el cordón eléctrico cuelgue del borde de una mesa o
mostrador.
19. Utilice un guante de cocina al abrir y cerrar la tapa cuando está en uso
para su seguridad y evitar quemaduras.

18 www.holsteinhousewares.com
PRECAUCIÓN: Durante los primeros minutos de uso inicial, usted
puede notar un poco de humo y/o un olor del artefacto. Esto es
normal y desaparecerá. No va a reaparecer después de que el
artefacto se haya utilizado un par de veces.
¡CONSERVE ESTAS INSTRUCCIONES!
INSTRUCCIONES DE SEGURIDAD
ADICIONALES
NO USE EL ARTEFACTO SI EL CORDÓN
ELÉCTRICO MUESTRA CUALQUIER TIPO
DE DAÑO O SI EL ARTEFACTO FUNCIONA
INTERMITENTEMENTE O DEJA DE
FUNCIONAR POR COMPLETO.
• CABLES DE EXTENSIÓN
Se provee un cordón eléctrico corto para reducir el riesgo de enredarse o
tropezar con un cable/cordón largo. Pueden usarse cables de extensión
más largos si se toman las precauciones necesarias en su uso. Si se usa
cable de extensión:
1 . Las características eléctricas del cable de extensión deben ser iguales o
superiores a las del artefacto.

19
www.holsteinhousewares.com
2 . El cable debe colocarse de forma que no cuelgue para evitar que se pueda
tropezar, enredarse o tirar de el accidentalmente (especialmente por niños).
• ENCHUFE POLARIZADO
Este electrodoméstico tiene un enchufe polarizado (una pata del enchufe
es más ancha que la otra). Para reducir el riesgo de descarga eléctrica, este
enchufe está diseñado para entrar de un sólo modo en la toma eléctrica. Si
el enchufe no entra totalmente en la toma de corriente, invierta su posición.
Si aún así no entrase, póngase en contacto con un electricista calicado. No
intente modicar el enchufe de ninguna manera.
FUNCIONAMIENTO
ANTES DEL PRIMER USO:
1 . Desempaque cuidadosamente el artefacto y todas las partes. Retire todo
los materiales de embalaje, incluyendo las pegatinas (las etiquetas).
2 . Lea las instrucciones de uso cuidadosamente.
3 . Limpie las supercies interiores y exteriores del artefacto con un paño
húmedo. Seque con un paño suave de inmediato. No use materiales
abrasivos.
4 . NUNCA SUMERJA ELARTEFACTO O EL CABLE EN AGUA U OTROS LÍQUIDOS.
5 . Coloque el artefacto en un lugar estable, seco, y resistente al calor.
6 . Desenrolle el cordón eléctrico.
7 . Utilice este artefacto en una toma de corriente y separado de otros
aparatos para evitar la sobrecarga del circuito.
PRECAUCIÓN: Las supercies del artefacto se calientan. Siempre abra
y cierre la tapa utilizando un guante de cocina para evitar quemaduras
mientras cocina.

20 www.holsteinhousewares.com
SOLO PARA USO DOMESTICO
INSTRUCCIONES DE USO:
1 . Este artefacto está diseñado sólo para uso doméstico y hornear pasteles.
2 . Prepare la masa de pasteles y su relleno siguiendo las instrucciones de la
receta seleccionada. Nota: Corte los discos de masa para pastel usando
el cortador proveído. Ver instrucciones de cómo usar el cortador.
3 . Suelte el cierre de seguridad y levante la tapa a la posición abierta.
4 . Cubra la supercie antiadherente con una pequeña cantidad de aceite
vegetal. Esto puede hacerse con una toalla de papel o con un spray de
aceite para cocinar. Limpie el exceso de aceite. Se recomienda hacer
periódicamente este paso después de uso para mantener la calidad de
la capa antiadherente.
5 . Verique y conrme que la tensión del artefacto sea la misma que el
circuito de la red domestica. A continuación, conecte el cordón eléctrico
al tomacorriente con cuidado. Asegúrese de que sea un tomacorriente
separado de otros artefactos para evitar que el circuito se sobrecargue.
6 . La luz indicadora roja se encenderá al conectar el artefacto. La luz
indicadora verde se encenderá tan pronto como el artefacto alcance la
temperatura máxima de funcionamiento. El artefacto estará listo para
usar cuando la luz verde se enciende. Nota: La luz indicadora verde se
encenderá y se apagará durante el uso, mas no reeja las condiciones
de cocción de los pasteles, solo los ciclos de temperatura de minimo
(luz verde Apagada) a maximo (luz verde Encendida).
7 . Abra el producto con cuidado de no quemarse, y proceder a colocar los
ingredientes dentro del producto.
8 . Coloque el disco de masa de pastel grande (4.5”, 11.5 cm), sobre la
horma del pastel en la placa de abajo.
