HOMCOM A90-254 Installation guide

ASSEMBLY & INSTRUCTION MANUAL
INaoa008V01_UK
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
A90-254

Introduction
Thank you for purchasing the Exercise Bike. Please read this user manual carefully and keep it
in a safe place for future reference. If you need any assistance, please contact our support team
with your product model number and Amazon order number.
Included
1 x Handlebar
1 x Handlebar post
1 x Handlebar cover
1 x Bike seat
1 x Saddle tube
1 x Seat post
1 x Electronic display
2 x Stabilizing foot
1 x Main frame
2 x Pedal
1 x Assembly kit
1 x User manual
Product Specification
Spinning Exercise Bike
36KGS/40KGS
180KGS
6cm
15cm

Important Safeguards
1.People with knee injuries should not use the product; People with heart disease and high
blood pressure should not use the product for long.
2.For using, place the product on a flat surface and tighten all screws.
3.The handlebar and bike seat can be adjusted according your own need.
4.The inertia of the moving flywheel is relatively large, so be careful when you have to stop
movements immediately.
5.Please do not use the product in a humid environment (like a bathroom), otherwise this would
lead to safety hazards easily.
6.Supervision is necessary if users are children or the handicapped.
7.Please stop using the product if it does not work normally.
Questions & Answers
Product Diagram
01. Electronic display
02. Soft pad
03. Bike seat
04. Seat adjustment knob (forward and backward)
05. Seat height adjustment
06. Pedal
07. Stabilizing foot
08. Flywheel
09. Brake pad
10.Handlebar adjustment knob
11.Brake knob
12.Bottle holder
13.Transport wheel

Product Assembly
Step1
Install the front stabilizing foot (2) and the rear stabilizing foot (3) on the main frame (1), then
tighten with 2 M10*45 carriage bolts (59), 2 M10 flat washers (34), and 2 M10 cap nuts (60).

Step 2
Install the pedal (R) (19) and the pedal (L) (20) on the crank arm (R) (21) and crank arm (L)
(22) respectively. Note: "L" stands for "left" and "R" stands for "right".
Step 3
Install the bike seat (10) on the seat post (8). Then install the seat post (8) on the saddle tube
(5) and stabilize with the adjustment knob (17).

Step 4
Install the saddle tube (5) on the main frame (1), and stabilize with the adjustment knob (17).
Step 5
Install the handlebar (11) on the handlebar post (12), and stabilize with 4 M8*15 inner
hexagonal screws (69), 4 M8 flat washers (48), and 4 M8 anti-loose nuts (70).
Install the upper handlebar cover (13) on the handle bar (11) and install the lower handlebar
cover (14) on the handlebar post (12), and stabilize with 4 self-tapping screws (68).

Step 6
Install the handlebar (12) on the main frame (1), and stabilize with the adjustment knob (17).
Control Panel

1. SCAN:Press the "MODE" button to select the function to "TIME", at which time the "SCAN" words
appear on the left of the monitor and monitor will rotate through all the 6functions:time, speed,
distance, odometer, calorieand pulse. Each display will be hold 6 seconds. In the process of cyclic
display of Each function, press "MODE" button once to make the "SCAN" appear disappear in any
function mode to display this function.If you want to return to "SCAN" again, press the "MODE" button
to select the function to "TIME".In "SCAN" mode, the "SCAN" word on theleft of the monitor flashes
continuously.
2. TIME: Display thetime from exercise start to end.
3. SPEED: Display current speed.
4. DISTANCE: Display thedistancesfrom exercise start to end.
5. ODOMETER: Monitor will display the total accumulated distance, after the battery is reinstalled, the
value will return to zero.
6. CALORIES: Display thecalories burnedfrom exercise start to end.
7. PULSE: Measure the user's heart rate.Press the button to switch to the pulse function, and hold the two
heartbeat sensors in both hands to measure the heart rate ( If the computer has wireless heartbeat
function, please wear the wireless heartbeat chest belt before measuring the pulserate.).
Remark: During the process of pulse measurement, because of the contact jamming, the measurement
value may be higher than the virtual pulse rate during the first 2~3 seconds, then will return to normal
level. The measurement value can not be regarded as the basis of medical treatment.
