Description
Item No.
:
LATTICEBACK CHAIR
: C-390
ASSEMBLY INSTRUCTIONS

ITEM
NO
.
: C
-
390
ISSUED AUG 8, 2012
Printed in Vietnam
- 2 -
BEFORE ASSEM
B
LY
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws, bolts until completely assembled.
-Keep all hardware parts out of reach of children.
PA
RT
LIST
When unpacking, please carefully not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following parts:
NO
Description
Q
ty
Sketch
NO
Description
Q
ty
Sketch
A Back 1 B Seat frame 1
C Seat 1 D Front leg
(L-R) 2
E Side
stretcher 2
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM
NO
.
: C
-
390
ISSUED AUG 8, 2012
Printed in Vietnam
- 3 -
HARDWARE LIST
When unpacking, please carefully not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Q
ty
Sketc
h
NO
Description
Q
ty
Sketch
1
Short bolt
( M6x40mm)
3 2
Medium bolt
(M6x60mm)
4
3
Long bolt
(M6 x 80mm)
4 4
Wood screw
(M4 x 35mm)
8
5
Lock Washer
(6.5 x11mm)
11 6
Flat Washer
(6.5 x19mm)
11
7
Allen Key
(K4)
1
STEP 1
Attach seat frame (B) to back (A) by using bolts (3) and (1), and washers (5) and (6) .Tighten with
Allen key (7) as shown below.
Note: DO NOT tighten any of the bolts, until the chair is assembled, then put on a flat level surface to
make sure the chair is level and then tighten the bolts.

ITEM
NO
.
: C
-
390
ISSUED AUG 8, 2012
Printed in Vietnam
- 4 -
STEP 2
Attach front legs (D) to the seat frame (B) with bolts (2), and washers (5) and (6). Tighten with Allen
key (7).
Place side stretchers (E) between front and back legs. Attach stretchers with the screws (4) as shown
below. Tighten with a screwdriver.
STEP 3
Attach the seat (C) to top of the seat frame (B) with screws (4) as shown below. Tighten with a
screwdriver.
