HOMEDEPOT WF188268AAA User manual

ASSEMBLY MANUAL
ROUND SOFA SET
WF188268AAA; WF188270AAA; WF188271AAA
WF188268CAA; WF188270CAA; WF188271CAA
AE
B
C
D
F
G
D
MM
NN
I
J
J
K
L
O
H
P
Q
Notice:
1. 50% Tighten before fixing all screws, Allen wrench is
recommended instead of an electric drill.
2. Place the item on a flat ground to adjust and make sure
it remains stable.
3. Tighten up all screws with tools gradually.
4. If the screws are not aligned with holes during assembly,
please loosen all the other screws to 50% and continue
the assembly process.
5. If the item is not stable, please loosen all the screws,
adjust it on a flat ground and tighten up all screws again.
6. Note : If one or some screws are fully tightened during
assembly, chances are the others will not be aligned with
holes. In addition, all the holes are designed to be relatively
larger to provide more space for the adjustment of the screws.
Round Table (1 pc)
Back Frame A (2pcs) Seat Frame B (2pcs) Front Frame C (2pcs)
Side Frame D (4pcs)
A B C
D E F
Back Frame E (2pcs) Seat Frame F (2pcs)
Front Table Frame (1pc)
Behind Table Frame (1pc)
Side Table Frame (2pcs)
Table Top Frame (1pc)
Front Frame G (2pcs)
G H I
JK L
Part List & Hardware
M
Seat Cushion (4pcs)
N
Back Pillow (4pcs)
O
Table Glass (1pc)
Allen key (1pc)
Part List & Hardware
P
Round Table Glass (1pc) Pillow (2pcs)
Q1
Bolt M6x40mm (18 pcs)
2
Bolt M6x35mm (14 pcs)
4
Bolt M6x20mm (8 pcs)
5
Connecting part (4 pcs)
Bolt M6x30mm (28 pcs)
3
6
STEP1
Connect Back Frame A (A) & Seat Frame B (B) with Bolt (1)
Connect part from STEP 1 & Side Frame D (D) with Bolt (3)
STEP 2
3
D
3
3
1
1
A
B
1
3
STEP 3
Connect part from STEP 2 & Front Frame C (C) with Bolt (3)
STEP 4
Connect back Frame E (E) & Seat Frame F (F) with Bolt (1)
C
3
3
F
E
1
1
1
3
STEP 5
Connect part from STEP 4 & Side Frame D (D) with Bolt (3)
STEP 6
Connect part from STEP 5 & Front Frame G (G) with Bolt (3)
D
3
3
3
G
3
3
3
3
4
5
4
STEP 7
Connect part from STEP 3 & STEP 6 with Bolt (1), Connecting part (5) & Bolt (4)
STEP 8
Put on Seat Cushion (M) & Back Pillow (N), Pillow (Q) to complete round sofa
1
1
1
M
Q
N
M
4
4
5
N
STEP 9
Connect Table Top Frame (I) & Behind Table
Frame (K) with Bolt (2)
STEP 10
Connect part from STEP 9 & Table Side Frame (J)
with Bolt (2)
STEP 11
Connect part from STEP 10 & Front Table
Frame (L) with Bolt (2)
STEP 12
Put on Table Glass (O) to complete the table
2
2
I
KJ
J
O
2
2
22
2
2
2
2
2
2
2
L
STEP 13
Put Round Table Glass (P) on Round Table (H) to complete
H
P

This manual suits for next models
