Homelegance 9819TP User manual

Assembly Instruction
POWER DOUBLE RECLINING LOVE SEAT
ITEM NO.: 9819TP/CE-2PWH
NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting or cracking
the wood.
COMPONENT LIST (CHAIR)
NO. DRAWING QTY DESCRIPTION
A1 PC
SEAT WITH POWER
HEADREST WIRE &
ADJUSTABLE ARM
QP-AI-P022-RAYMOUR-007-2
B1 PC
LSF BACK REST
HARDWARE LIST
NO. DRAWING QTY DESCRIPTION
1
2
3
1 PC
1 PC PLUG WITH
WIRE
ADAPTOR
Y-CABLE
1 PC
1/3
C 1 PC
RSF BACK REST

STEP#1
Align the female brackets at the back rest onto the male brackets at the seat, insert back rest to the seat then push to
the end and make sure it is fixed in position securely. Connecting the wire from back rest to seat for power headrest.
STEP#2
QP-AI-P022-RAYMOUR-007-2
STEP#3
Velcro
2/3
A
B
C
Back Rest
Installation
3
12
Press
(Headrest Raise)
Rear button
Headrest
Press to adjust headrest height
Press
(Seat Recline)
Front button
Seat
Press to recline/ close the seat
Press
(Headrest Raise)
Rear button
Headrest
Press to adjust headrest height
Press
(Seat Recline)
Front button
Seat
Press to recline/ close the seat

CARE INSTRUCTION FOR FABRIC:
In order to maintain the original appearance of your fabric furniture, please follow below simple care
procedure :
Avoid exposing furniture directly to sunlight or heating and air conditioning outlets. Exposure to sunlight or heating and air
conditioning outlets will fade/damage fabric.
Wipe gently with a damp soft cloth to remove dust, dirt and any grime build up.
Disconnect the eletrical plug from the wall outlet before cleaning, moving, servicing or when not in use for an
extended period of time.
Plug directly into a wall outlet. Do not use an extension cord or adaptor.
Check the condition of the power transfomers, electrical cords, plugs and connectors monthly. Keeps the power
adaptor and electrical cords away from heat sources. Never operate the unit with a damaged power adaptor,
electrical cord, plug or connector.
Before moving the product, please disconnect the electrical plug from the wall outlet and secure the mechanism to prevent
unexpected opening or movement. Never move the product by the mechanism, legrest, handle, or reclining back.
Do not attempt to disassemble or service the adaptor or motor. No serviceable parts are inside.
Do not allow electrical cord to be pinched between moving parts or between the frame and the floor. Do not place cord
under carpet or in location where it could become worn.
Unplug the power cord immediately if you detect strange odors or fumes coming from the chair.
PLEASE KEEP ASSEMBLY INSTRUCTION FOR FUTURE REFERENCE 3/3
