PARTS LIST
PART NO. PS05001
Homelite®
EasyTrim™UT20693
d825cdp UT20705
Trim N' Edge™UT20694, UT20697, UT20698,UT20702,
UT20707, UT20728
d725cde UT20695, UT20713
Easy Reach™UT20699, UT20703, UT20704,UT20730,
UT20737, UT20738
d825sd UT20700, UT20701, UT20709,UT20729
Expand-it™UT20710, UT20712,
UT20735
d825ca UT20711, UT20736
VersaTool™UT15151, UT15154, UT15157,UT20722,
UT20723
d825sb UT15152, UT15160
ST2517CR UT20726R, UT20823
ST2537S UT20734R, UT20827
BC2500 MR UT15159R, UT15204
Zip Start™
Trimmers/Brushcutters

2
IGNITION - ROTOR - STARTER
No. Part No. Description Qty.
C•A07174 IGNITION KIT 1
1UP 03868 TERMINAL & COVER 1
2UP 03896 SCREW-Taptite (8-32 X 1") 2
3UP 03883 SPARK PLUG 1
4UP 04690 LEAD-Electrical 1
5•UP 03009 ROTOR KIT 1
6UP 03906 WASHER-Flat 1
7UP 04271 CONNECTOR-Drive (.250) 1
8UP 02994 SHORT BLOCK (See Engine Internal) 1
E•UP 02963 COMPLETE STARTER ASSEMBLY 1
9UP 04164 SCREW-Thread Form (8-16 X 1/2") 3
1 0 UP 03013 BAFFLE-Air 1
1 1 UP 03012 PULLEY-Starter 1
1 2 UP 03912 ROPE-Starter (42") 1
1 3 UP 03917 SPRING & CONTAINER 1
1 4 UP 03026 GRIP-Starter (Yellow) 1
1 5 •UP 02964 HOUSING-Rear Kit 1
1 6 UP 03900 SCREW-Taptite (10-14 X 3/4") 2
1 7 UP 03406 SCREW-Taptite (10-24 X 3/4") 4
1 8 •UP 03113 CONTROL HANDLE ASSY.1
1 9 UP 03015 TRIGGER-Throttle 1
2 0 UP 03027 PLUG-Switch 1
2 1 UP 03895 SCREW-Taptite (10-14 X 7/8") 4
2 2 UP 04247 SCREW-Truss Hd. (10-14 x 1") 4
2 3 UP 03020 CABLE-Throttle 1
2 4 •UP 03113 CONTROL HANDLE ASSY.1
2 5 UP 03207 TRIGGER 1
2 6 UP 03172 CABLE-Throttle 1
2 7 UP 03210 SPRING 1
2 8 UP 04247 SCREW-Truss Hd. (10-14 x 1") 9
2....... 30-40 ......... 3.4-4.5 ...... Blue 242
3....... 120-180 ....... 13.6-20.3
7....... 100-150 ....... 11.3-16.9
9....... 10-20 ......... 1.1-2.3
16 ....... 30-50 ......... 3.4-5.6
17 ....... 30-40 ......... 3.4-4.5
21 ....... 30-50 ......... 3.4-5.6
22 ....... 30-50 ......... 3.4-5.6
28 ....... 30-50 ......... 3.4-5.6
Warranty Flat Rate
Job Description Time/Hr.
16
8
C
4
2
1310
11
9
12
13
17
15
5
6
7
E
©2001, John Deere Consumer Products, Inc.
FA11 ....Ignition Mod. ................................ .3
FA12 ....Ground Lead ............................... .3
FG10 ...Starter .......................................... .4
FD12....Engine Housing, Rear................. .4
FF13 ....Trigger, Throttle cable ................. .3
Torque Specs
Item Required
No. In/Lbs Nm Loctite
{
19
23
20
22
18
21
21
Non-Clutch
EasyTrim™................(UT20693)
d825cdp ......................(UT20705)
d825cde ......................(UT20695, UT20713)
d825sd ........................(UT20700, UT20701, UT20709, UT20729)
26
28
28
25
27
Beginning with Serial
Number HA06100230
28
24
03/08/2001
14

3
IGNITION - ROTOR - STARTER
16
8
C
4
2
1310
11
12
13
17
15
5
6
7
E
9
Non-Clutch
Trim N' Edge™...........(UT20694, UT20697, UT20698,
UT20702,UT20707,UT20728)
EasyReach™............(UT20699,UT20703,UT20704,
UT20730,UT20737,UT20738)
ST2517CR ...................(UT20826R, UT20823)
ST2537S .....................(UT20734R, UT20827)
{
21
23
20
22
18
21
No. Part No. Description Qty.
C•A07174 IGNITION KIT 1
1UP 03868 TERMINAL & COVER 1
2UP 03896 SCREW-Taptite (8-32 X 1") 2
3UP 03883 SPARK PLUG 1
4UP 04690 LEAD-Electrical 1
5•UP 03009 ROTOR KIT 1
6UP 03906 WASHER-Flat 1
7UP 04271 CONNECTOR-Drive (.250) 1
8UP 02994 SHORT BLOCK (See Engine Internal) 1
E•UP 02962 COMPLETE STARTER ASSEMBLY 1
9UP 04164 SCREW-Thread Form (8-16 X 1/2") 3
1 0 UP 03013 BAFFLE-Air 1
1 1 UP 03012 PULLEY-Starter 1
1 2 UP 03912 ROPE-Starter (42") 1
1 3 UP 03917 SPRING & CONTAINER 1
1 4 UP 03026 GRIP-Starter (Yellow) 1
1 5 •UP 02965 HOUSING-Rear Kit 1
1 6 UP 03895 SCREW-Taptite (10-14 X 7/8") 2
1 7 UP 03406 SCREW-Taptite (10-24 X 3/4") 4
1 8 •UP 03113 CONTROL HANDLE ASSY.1
1 9 UP 03015 TRIGGER-Throttle 1
2 0 UP 03027 PLUG-Switch 1
2 1 UP 03895 SCREW-Taptite (10-14 X 7/8") 4
2 2 UP 04247 SCREW-Truss Hd. (10-14 x 1") 4
2 3 UP 03020 CABLE-Throttle 1
2 8 UP 04247 SCREW-Truss Hd. (10-14 x 1") 9
2....... 30-40 ......... 3.4-4.5 ...... Blue 242
3....... 120-180 ....... 13.6-20.3
7....... 100-150 ....... 11.3-16.9
9....... 10-20 ......... 1.1-2.3
16 ....... 30-50 ......... 3.4-5.6
17 ....... 30-40 ......... 3.4-4.5
21 ....... 30-50 ......... 3.4-5.6
22 ....... 30-50 ......... 3.4-5.6
28 ....... 30-50 ......... 3.4-5.6
Warranty Flat Rate
Job Description Time/Hr.
FA11 ....Ignition Mod. ................................ .3
FA12 ....Ground Lead ............................... .3
FG10 ...Starter .......................................... .4
FD12....Engine Housing, Rear................. .4
FF13 ....Trigger, Throttle cable ................. .3
Torque Specs
Item Required
No. In/Lbs Nm Loctite
26
28
28
25
27
Beginning with Serial
Number HA06100230
28
24
19
No. Part No. Description Qty.
2 4 •UP 03113 CONTROL HANDLE ASSY.1
2 5 UP 03207 TRIGGER 1
2 6 UP 03172 CABLE-Throttle 1
2 7 UP 03210 SPRING 1
2 8 UP 04247 SCREW-Truss Hd. (10-14 x 1") 9
03/08/2001
14

4
Clutch
d825ca ........................(UT20711, UT20736)
d825sb ........................(UT15152, UT15160)
IGNITION - ROTOR - STARTER - CLUTCH
21
13
4315
16
14
17
18
22
20
6
7
E
No. Part No. Description Qty.
2....... 30-40 ......... 3.4-4.5 ...... Blue 242
3....... 120-180 ....... 13.6-20.3
14 ....... 10-20 ......... 1.1-2.3
21 ....... 30-50 ......... 3.4-5.6
22 ....... 30-40 ......... 3.4-4.5
27 ....... 30-50 ......... 3.4-5.6
28 ....... 30-50 ......... 3.4-5.6
36 ....... 30-50 ......... 3.4-5.6
Warranty Flat Rate
Job Description Time/Hr.
FA11 ....Ignition Mod. ................................ .3
FA12 ....Ground Lead ............................... .3
FG10 ...Starter .......................................... .4
FD12....Engine Housing, Rear................. .4
FF13 ....Trigger, Throttle cable ................. .3
Torque Specs
Item Required
No. In/Lbs Nm Loctite
11 10
12
9
C
2
15
8
No. Part No. Description Qty.
{
27
25
24 30
29
26
27
23 {
37
38
36
31
36 34
35
32
33
36
C•A07174 IGNITION KIT 1
1UP 03868 TERMINAL & COVER 1
2UP 03896 SCREW-Taptite (8-32 X 1") 2
3UP 03883 SPARK PLUG 1
4UP 04537 LEAD-Electrical 1
5UP 04536 LEAD-Electrical 1
6•UP 03009 ROTOR KIT 1
7UP 04241 WASHER-Flat 1
8•UP 00034 CLUTCH AND DRUM KIT 1
9UP 04118 SPACER 1
1 0 UP 04275 WASHER-Flat 1
1 1 UP 04103 CLUTCH 2
1 2 UP 04104 CONNECTOR AND DRUM 1
1 3 UP 02995 SHORT BLOCK (See Engine Internal) 1
E•UP 02963 COMPLETE STARTER ASSEMBLY 1
1 4 UP 04164 SCREW-Thread Form (8-16 X 1/2") 3
1 5 UP 03013 BAFFLE-Air 1
1 6 UP 03012 PULLEY-Starter 1
1 7 UP 03912 ROPE-Starter (42") 1
1 8 UP 03917 SPRING & CONTAINER 1
1 9 UP 03026 GRIP-Starter (Yellow) 1
2 0 •UP 02964 HOUSING-Rear Kit 1
2 1 UP 03900 SCREW-Plastite (10-14 X 3/4") 2
2 2 UP 03406 SCREW-Taptite (10-24 X 3/4") 4
2 3 •UP 02967 CONTROL HANDLE ASSY.1
2 4 UP 03015 TRIGGER-Throttle 1
2 5 UP 03014 THROTTLE INTERLOCK 1
2 6 UP 03833 SWITCH 1
2 7 UP 03895 SCREW-Taptite (10-14 X 7/8") 4
2 8 UP 03406 SCREW-Taptite (10-24 X 3/4") 4
2 9 UP 03020 CABLE-Throttle 1
3 0 UP 04566 LEAD-Electrical 1
31 •UP 03114 CONTROL HANDLE ASSY.1
32 •UP 03207 TRIGGER-Throttle 1
33 UP 03210 SPRING 1
34 UP 03173 THROTTLE INTERLOCK 1
35 UP 04197 SWITCH 1
36 UP 04247 SCREW-Taptite (10-14 X 1") 9
37 UP 03172 CABLE-Throttle 1
38 UP 03174 LEAD-Electrical 1
28
Beginning with Serial
Number HA06100230
03/08/2001
19

5
21
13
4315
16
14
17
18
22
20
6
7
E
No. Part No. Description Qty.
2....... 30-40 ......... 3.4-4.5 ...... Blue 242
3....... 120-180 ....... 13.6-20.3
14 ....... 10-20 ......... 1.1-2.3
21 ....... 30-50 ......... 3.4-5.6
22 ....... 30-40 ......... 3.4-4.5
27 ....... 30-50 ......... 3.4-5.6
28 ....... 30-50 ......... 3.4-5.6
36 ....... 30-50 ......... 3.4-5.6
Warranty Flat Rate
Job Description Time/Hr.
FA11 ....Ignition Mod. ................................ .3
FA12 ....Ground Lead ............................... .3
FG10 ...Starter .......................................... .4
FD12....Engine Housing, Rear................. .4
FF13 ....Trigger, Throttle cable ................. .3
Torque Specs
Item Required
No. In/Lbs Nm Loctite
11 10
12
9
C
2
15
IGNITION - ROTOR - STARTER - CLUTCH
8
No. Part No. Description Qty.
Clutch
Expand-it™................(UT20710, UT20712, UT20735)
VersaTool™................(UT15151, UT15154, UT15157,
UT20722,UT20723)
BC2500MR ..................(UT15159R, UT15204)
{
27
25
24 30
29
26
27
23 {
37
38
36
31
36 34
35
32
33
Beginning with Serial
Number HA06100230
36
C•A07174 IGNITION KIT 1
1UP 03868 TERMINAL & COVER 1
2UP 03896 SCREW-Taptite (8-32 X 1") 2
3UP 03883 SPARK PLUG 1
4UP 04537 LEAD-Electrical 1
5UP 04536 LEAD-Electrical 1
6•UP 03009 ROTOR KIT 1
7UP 04241 WASHER-Flat 1
8•UP 00034 CLUTCH AND DRUM KIT 1
9UP 04118 SPACER 1
1 0 UP 04275 WASHER-Flat 1
1 1 UP 04103 CLUTCH 2
1 2 UP 04104 CONNECTOR AND DRUM 1
1 3 UP 02995 SHORT BLOCK (See Engine Internal) 1
E•UP 02962 COMPLETE STARTER ASSEMBLY 1
1 4 UP 04164 SCREW-Thread Form (8-16 X 1/2") 3
1 5 UP 03013 BAFFLE-Air 1
1 6 UP 03012 PULLEY-Starter 1
1 7 UP 03912 ROPE-Starter (42") 1
1 8 UP 03917 SPRING & CONTAINER 1
1 9 UP 03026 GRIP-Starter (Yellow) 1
2 0 •UP 02965 HOUSING-Rear Kit 1
2 1 UP 03895 SCREW-Plastite (10-14 X 7/8") 2
2 2 UP 03406 SCREW-Taptite (10-24 X 3/4") 4
2 3 •UP 02967 CONTROL HANDLE ASSY.1
2 4 UP 03015 TRIGGER-Throttle 1
2 5 UP 03014 THROTTLE INTERLOCK 1
2 6 UP 03833 SWITCH 1
2 7 UP 03895 SCREW-Taptite (10-14 X 7/8") 4
2 8 UP 03406 SCREW-Taptite (10-24 X 3/4") 4
2 9 UP 03020 CABLE-Throttle 1
3 0 UP 04566 LEAD-Electrical 1
31 •UP 03114 CONTROL HANDLE ASSY.1
32 •UP 03207 TRIGGER-Throttle 1
33 UP 03210 SPRING 1
34 UP 03173 THROTTLE INTERLOCK 1
35 UP 04197 SWITCH 1
36 UP 04247 SCREW-Taptite (10-14 X 1") 9
37 UP 03172 CABLE-Throttle 1
38 UP 03174 LEAD-Electrical 1
28
03/08/2001
19

6
1•UP 02994 SHORT BLOCK (Non-Clutch) 1
•UP 02995 SHORT BLOCK (Clutch) 1
2•UP 00768 PISTON & ROD ASSY.1
3PS 01359 RING-Piston 1
4•UP 04136 CYLINDER ASSY.1
5UP 03857 GASKET-Cylinder 1
6UP 04308 GASKET-Heat Dam 1
7UP 03916 GASKET-Carburetor 1
8UP 04710 GASKET-Muffler 1
9UP 04345 SCREW-Sems (12-24 X 3/4") 3
1 0 •UP 00019 CRANKCASE COVER ASSEMBLY1
1 1 UP 04335 GASKET-Crankcase Cover (Also 1
included w/short block)
1 2 UP 04295 SCREW-Sems (10-24 X 1/2") 4
1 3 •UP 00027 MUFFLER GUARD 3
1 4 UP 03897 SCREW-Plastite (10-14 X 1/2") 2
ENGINE INTERNAL
13
14
12
11
3
2
5
OPTIONAL MUFFLER GUARD
4
1
No. Part No. Description Qty.
10
9....... 55-65 ........... 6.2-7.3 ........ Red 262
12 ....... 35-45 ........... 4.0-5.1 ........ Red 262
14 ....... 5-20 ........... .6-2.3
Warranty Flat Rate
Job Description Time/Hr.
9
7
FB10 ....Partial Rebuild ............................. 1.0
FB20 ....Short Block .................................. 1.0
FD25....Crankcase Cover ....................... .3
Torque Specs
Item Required
No. In/Lbs Nm Loctite
9
86
Non-Clutch
EasyTrim™.............. (UT20693)
d825cdp .................. (UT20705)
d825cde .................. (UT20695,UT20713)
d825sd .................... (UT20700,UT20701,UT20709,UT20729)
TrimN'Edge™........ (UT20694,UT20697,UT20698,UT20702,UT20707,UT20728)
EasyReach™........ (UT20699,UT20703,UT20704,UT20730,UT20737,UT20738)
ST2517CR............... (UT20726R,UT20823)
ST2537S ................. (UT20734R,UT20827)
Clutch
Expand-it™............. (UT20710,UT20712,UT20735)
VersaTool™............. (UT15151,UT15154,UT15157,UT20722,UT20723)
d825ca .................... (UT20711,UT20736)
d825sb .................... (UT15152,UT15160)
BC2500MR .............. (UT15159R,UT15204)
03/08/2001

7
CARBURETOR - FUEL TANK
F
79
8
12
11
5
4
32
B
No. Part No. Description Qty.
1UP 04308 GASKET-Heat Dam 1
2UP 04131 SCREW-Machine (10-24 X 2 1/4") 2
3UP 04348 HEAT DAM 1
4UP 04140 SCREW-Sems (10-24 X 1") 2
B•UP 00608 CARBURETOR KIT (Non-Clutch) 1
•UP 00654 CARBURETOR KIT (Clutch) 1
5UP 03916 GASKET-Carburetor 1
6UP 04278 Lever-Choke (Zama) 1
F•UP 00020 FUEL TANK ASSY.1
7UP 03871 FILTER-Fuel 1
8UP 04293 TUBING-Rubber 1
9UP 04292 TUBING-Rubber 1
10 UP 04715 TUBING-Rubber 1
11 UP 00106 FUEL CAP 1
12 UP 03501 BUMPER-Rubber 3
13 UP 03831 FITTING-Inline 1
14 UP 03913 CLAMP 1
4....... 35-45 ........... 4.0-5.1 ........ Red 262
Warranty Flat Rate
Job Description Time/Hr.
13
10
FF17 ....Manifold........................................ .3
FF10 ....Carburetor Rep. .......................... .3
FF16 ....Fuel Tank ..................................... .3
FF12 ....Fuel/Return Line.......................... .3
Torque Specs
Item Required
No. In/Lbs Nm Loctite
6
1
Non-Clutch
EasyTrim™.............. (UT20693)
d825cdp .................. (UT20705)
d825cde .................. (UT20695,UT20713)
d825sd .................... (UT20700,UT20701,UT20709,UT20729)
TrimN'Edge™........ (UT20694,UT20697,UT20698,UT20702,UT20707,UT20728)
EasyReach™......... (UT20699,UT20703,UT20704,UT20730,UT20737,UT20738)
ST2517CR............... (UT20726R,UT20823)
ST2537S ................. (UT20734R,UT20827)
Clutch
Expand-it™............. (UT20710,UT20712,UT20735)
VersaTool™............. (UT15151,UT15154,UT15157,UT20722,UT20723)
d825ca .................... (UT20711,UT20736)
d825sb .................... (UT15152,UT15160)
BC2500MR .............. (UT15159R,UT15204)
03/08/2001
14

8
No. Part No. Description Qty.
A•UP 04634 MUFFLER ASSY.1
1UP 04248 SCREW, Taptite- (8-32 X 3/8") 3
2UP 04629 SCREEN-Spark 1
3UP 04710 GASKET-Muffler 1
4UP 04258 SCREW, Truss Hd. - (10-24 X 2.188) 2
D•A04707 A AIR FILTER KIT (Non-Clutch) 1
5D98760 B FILTER-Air 1
6UP 06341 BUTTON-Switch 1
7UP 04716 SPRING-Compression 1
8UP 04082 SCREW-Thread Form (6-19 x 1/2") 1
9UP 04690 LEAD-Electrical 1
1 0 UP 03885 NUT-Hex (10-24) 2
D•UP 00022 AIR FILTER KIT (Clutch) 1
5D98760 B FILTER-AIR 1
1 0 UP 03885 NUT-Hex (10-24) 2
MUFFLER - AIR CLEANER
*See Engine Internal page.
A1
42
3
D5
10
Warranty Flat Rate
Job Description Time/Hr.
1....... 25-35 ........... 2.8-4.0
4....... 50-60 ........... 5.6-6.8
8....... 5-10 ........... .6-1.1
10 ..... 30-40 ........... 3.4-4.5
FB18 ....Muffler-Replace........................... .3
FF42 ....Air Filter Assy. ............................. .2
Torque Specs
Item Required
No. In/Lbs Nm Loctite
D
8
10
5
6
7
9
Non-Clutch
EasyTrim™.............. (UT20693)
d825cdp .................. (UT20705)
d825cde .................. (UT20695,UT20713)
d825sd .................... (UT20700,UT20701,UT20709,UT20729)
TrimN'Edge™........ (UT20694,UT20697,UT20698,UT20702,UT20707,UT20728)
EasyReach™......... (UT20699,UT20703,UT20704,UT20730,UT20737,UT20738)
ST2517CR............... (UT20726R,UT20823)
ST2537S ................. (UT20734R,UT20827)
Clutch
Expand-it™............. (UT20710,UT20712,UT20735)
VersaTool™............. (UT15151,UT15154,UT15157,UT20722,UT20723)
d825ca .................... (UT20711,UT20736)
d825sb .................... (UT15152,UT15160)
BC2500MR .............. (UT15159R,UT15204)
03/08/2001

9
SHAFT - SPOOL & STRING - GRASS DEFLECTOR
10
9
6
4
3
1
2
15
14
13
11
716
8
EasyTrim™................(UT20693, UT20705)
ST2517 CR ..................(UT20726R,UT20823)
5
1•UP 06959 HANDLE-Anti-Vibe 1
2UP 04262 NUT-Wing, Washer Faced (1/4-20) 1
3UP 06523 SCREW-Cap Hex Hd. 1
4•UP 00710 DRIVESHAFT HOUSING ASSY.1
5UP 03031 SHAFT-Flexible 1
6UP 04352 DECAL-Warning 1
7UP 04137 CLAMP 1
8UP 04256 SCREW-Sems Hex Hd. (#10-24 X 3/8") 1
9•UP 06710 DEFLECTOR & BLADE KIT (55 Deg.) 1
1 0 UP 06523 SCREW-Cap Hex Hd. (10-24 X 2") 1
1 1 UP 03415 WASHER-Flat (1/4") 1
1 2 UP 03409 WASHER-Lock (1/4") 1
1 3 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1
1 4 •UP 04119 BLADE-Cut-Off 1
1 5 UP 04159 SCREW-Mech. Hex Hd. (10-24 X 7/8") 2
1 6 UP 03885 NUT-Hex (10-24) 2
1 7 • DA 09364 STRINGHEAD-Pro-Cut w/line 1
(UT20693,UT20705)
1 8 UP 04102 SCREW (5/16-18 x 5/8") 1
1 9 D09365 LINE-Replacement 1
No. Part No. Description Qty.
Warranty Flat Rate
Job Description Time/Hr.
2....... 5-25 ........... .6-2.8
8....... 15-25 ........... 1.7-2.8
13 ....... 5-25 ........... .6-2.8
16 ....... 30-40 ........... 3.4-4.5
18 ....... 40-60 ........... 4.5-6.8
FM10 ...Stringhead Assy. ......................... .2
FN12....Driveshaft .................................... .3
FN13....Driveshaft Hsg. ........................... .3
FN16....Deflector-Grass .......................... .2
FD20....Front Handle................................ .2
Torque Specs
Item Required
No. In/Lbs Nm Loctite
17 19
18
12
20
23
24
21
22
20 •DA 03001 A STRINGHEAD-Complete (.080") 1
(UT20726R, UT20823)
21 UP 06567 HOUSING & EYELET (Dual Line) 1
22 UP 06526 SPRING-Compression 1
23 UP 00145 SPOOL & STRING (.080") 1
24 DA 98866 A RETAINER-Spool (R.H. Thread, Black) 1
No. Part No. Description Qty.
03/08/2001

10
SHAFT - SPOOL & STRING - GRASS DEFLECTOR
10
9
6
4
3
1
2
15
14
13
11
716
8
26
24
25
27
2624
25
23
22
Warranty Flat Rate
Job Description Time/Hr.
2....... 5-25 ........... .6-2.8
8....... 15-25 ........... 1.7-2.8
13 ....... 5-25 ........... .6-2.8
16 ....... 30-40 ........... 3.4-4.5
26 ....... 5-25 ........... .6-2.8
FM10 ...Stringhead Assy. ......................... .2
FN12....Driveshaft .................................... .3
FN13....Driveshaft Hsg. ........................... .3
FN16....Deflector-Grass .......................... .2
FD20....Front Handle................................ .2
FN25....Edger Attachment-Replace ........ .2
1•UP 06959 HANDLE-Anti-Vibe 1
2UP 04262 NUT-Wing, Washer Faced (1/4-20) 1
3UP 06523 SCREW-Cap Hex Hd. 1
4•UP 00710 DRIVESHAFT HOUSING ASSY.1
5UP 03031 SHAFT-Flexible 1
6UP 04352 DECAL-Warning 1
7UP 04137 CLAMP 1
8UP 04256 SCREW-Sems Hex Hd. (#10-24 X 3/8") 1
9•UP 06710 DEFLECTOR & BLADE KIT (55 Deg.) 1
1 0 UP 06523 SCREW-Cap Hex Hd. (10-24 X 2") 1
1 1 UP 03415 WASHER-Flat (1/4") 1
1 2 UP 03409 WASHER-Lock (1/4") 1
1 3 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1
1 4 •UP 04119 BLADE-Cut-Off 1
1 5 UP 04159 SCREW-Mech. Hex Hd. (10-24 X 7/8") 2
1 6 UP 03885 NUT-Hex (10-24) 2
17 •DA 03001 A STRINGHEAD-Complete (.080") 1
(UT20694, UT20697, UT20702, UT20728)
•DA 04591 A STRINGHEAD-Complete (.095") 1
(UT20695, UT20698, UT20707, UT20713)
18 UP 06567 HOUSING & EYELET (Dual Line) 1
19 UP 06526 SPRING-Compression 1
20 UP 00145 SPOOL & STRING (.080") 1
UP 00147 SPOOL & STRING (.095") 1
21 DA 98866 A RETAINER-Spool (R.H. Thread, Black) 1
No. Part No. Description Qty.
Torque Specs
Item Required
No. In/Lbs Nm Loctite
22 •UP 00008 EDGER GUIDE KIT 1
23 UP 04148 SCREW-Hex Hd. (1/4-20 X 2 1/2") 1
24 UP 03415 WASHER-Flat (1/4") 2
25 UP 03409 WASHER-Lock (1/4") 2
26 UP 04262 NUT-Wing, Washer Faced (1/4-20) 2
27 UP 04158 SCREW-Hex Hd. (1/4-20 X 1") 1
No. Part No. Description Qty.
Trim N' Edge™.... (UT20694,UT20697,UT20698,UT20702,UT20707),
UT20728
d725cde ............... (UT20695,UT20713)
12
17
20
21
18
19
5
03/08/2001

11
1•UP 06959 HANDLE-Anti-Vibe 1
2UP 04262 NUT-Wing, Washer Faced (1/4-20) 1
3UP 06523 SCREW-Cap Hex Hd. (1/4-20 x 2") 1
4•UP 00029 DRIVESHAFT ASSY. (Upper) 1
5A07667 FLEXSHAFT w/Collar & Liner 1
6UP 04116 DECAL-Warning 1
7•A07901 COUPLER ASSEMBLY1
8UP 04153 SCREW-Hex Hd. (1/4-20 x 1 1/2") 3
9UP 06523 SCREW-Cap Hex (1/4-20 x 2") 1
10 UP 04143 COUPLER (L.H.) 1
11 UP 04144 COUPLER (R.H.) 1
12 UP 03400 NUT-Hex (1/4-20) 3
13 UP 04138 KNOB (1/4-20) 1
14 •UP 02887 DRIVESHAFT HOUSING (Lower) 1
1 5 UP 04541 SHAFT-Flex 1
1 6 UP 04352 DECAL-Warning 1
17 UP 04137 CLAMP 1
18 UP 04256 SCREW-Sems Hex (10-24 X 3/8") 1
19 •UP 06710 DEFLECTOR & BLADE KIT (55 Deg.) 1
20 UP 06523 SCREW-Cap Hex Hd. (10-24 X 2") 1
21 UP 03415 WASHER-Flat (1/4") 1
22 UP 03409 WASHER-Lock (1/4") 1
23 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1
24 •UP 04119 BLADE-Cut-Off 1
25 UP 04159 SCREW-Mech. Hex Hd. (10-24 X 7/8") 2
26 UP 03885 NUT-Hex (10-24) 2
27 •DA 09364 STRINGHEAD-Pro-Cut w/line (UT20710, 1
28 UP 04102 SCREW-(5/16-18 x 5/8") 1
29 D09365 LINE-Replacement 1
30 •DA 03001 A STRINGHEAD-Complete (.080") (UT20712) 1
•DA 04591 A STRINGHEAD-Complete (.095") (UT20711, 1
UT20736)
31 UP 06567 HOUSING & EYELET (Dual Line) 1
32 UP 06526 SPRING-Compression 1
33 UP 00145 SPOOL & STRING (.080") 1
UP 00147 SPOOL & STRING (.095") 1
34 DA 98866 A RETAINER-Spool (R.H. Thread, Black) 1
No. Part No. Description Qty.
20
19
16
14
24
21
17
26
18
4
56
8
9
12
12
13
10
11
7
Expand-it™........ (UT20710,UT20712,
UT20735)
d825ca ................ (UT20711,UT20736)
SHAFT - SPOOL & STRING - GRASS DEFLECTOR
3
1
2
Warranty Flat Rate
Job Description Time/Hr.
2....... 5-25 ......... .6-2.8
12 ....... 50-60 ......... 5.7-6.8
13 ....... Hand Tight
18 ....... 15-25 ......... 1.7-2.8
23 ....... 5-25 ......... .6-2.8
26 ....... 30-40 ......... 3.4-4.5
28 ....... 40-60 ......... 4.5-6.8
FM10 ...Stringhead Assy. ......................... .2
FN12....Driveshaft (Upper) ...................... .3
FN13....Driveshaft Housing ..................... .3
FN16....Deflector ...................................... .2
CD98 ...Coupler-Shaft .............................. .3
Page 14
Page 17
Page 16
Page 15
*ATTACHMENTS for Expand-it™
See Parts Lists on:
Torque Specs
Item Required
No. In/Lbs Nm Loctite
25
15
28
27 29
23
22
30
33
34
31
32
03/08/2001

12
3
1
2
14
13
12
11
10 6
5
4
15
8
SHAFT - SPOOL & STRING - GRASS DEFLECTOR
16 18
17 19
22
23
20
21
EasyReach™........ (UT20699,UT20703,UT20704,UT20730,
UT20737,UT20738)
d825sd ................... (UT20700,UT20701,UT20709,UT20729)
ST2537S ................ (UT20734R,UT20827)
24
1•UP 06959 HANDLE-Anti-Vibe 1
2UP 04262 NUT-Wing, Washer Faced (1/4-20) 1
3UP 06523 SCREW-Cap Hex Hd. (1/4-20 x 2") 1
4•UP 02968 DRIVESHAFT HOUSING ASSY.1
5UP 04717 SHAFT-Flexible 1
6UP 04352 DECAL-Warning 1
7•UP 06970 GEARHEAD 1
8UP 04157 Screw, Taptite Hex Hd. (10-24 x 1/2") 5
9UP 04155 Screw-Hex Hd. (10-24 x 5/8") 2
1 0 UP 04126 WASHER-Flanged 1
1 1 UP 04128 ADAPTER-Shaft 1
1 2 •A04683 A GRASS DEFLECTOR KIT 1
1 3 UP 04538 BLADE-Cut-off 1
1 4 UP 04149 SCREW-Mach.Hex Hd. (10-24 X 3/8") 2
1 5 UP 03885 NUT-Lock Hex (10-24) 2
1 6 •DA 09364 STRINGHEAD-Pro-Cut w/line 1
(UT20699, UT20703, UT20701, UT20730,
UT20729, UT20737)
1 7 UP 04102 SCREW (5/16-18 x 5/8") 1
1 8 D09365 LINE-Replacement 1
1 9 •DA 03001 A STRINGHEAD-Complete (.080") (UT20704, 1
UT20738, UT20734R, UT20827)
•DA 04591 A STRINGHEAD-Complete (.095") 1
(UT20700, UT20709)
20 UP 06567 HOUSING & EYELET (Dual Line) 1
21 UP 06526 SPRING-Compression 1
22 UP 00145 SPOOL & STRING (.080") 1
UP 00147 SPOOL & STRING (.095") 1
23 DA 98866 A RETAINER-Spool (R.H. Thread, Black) 1
24 UP 00108 HARNESS 1
No. Part No. Description Qty.
Warranty Flat Rate
Job Description Time/Hr.
2....... 5-25 ......... .6-2.8
8....... 15-20 ......... 1.7-2.3
9....... 40-50 ......... 4.5-5.6
11 ....... 100-120 ....... 11.3-13.6
15 ....... 30-40 ......... 3.4-4.5
17 ....... 40-60 ......... 4.5-6.8
FM10 ...Stringhead Assy. ......................... .2
FN12....Driveshaft .................................... .3
FN13....Driveshaft Hsg. ........................... .3
FN15....Gearhead .................................... .3
FD20....Front Handle................................ .2
Torque Specs
Item Required
No. In/Lbs Nm Loctite
8
9
7
03/08/2001

13
VersaTool™............ (UT15151,UT15154,UT20722,UT20723,
UT15157)
d825sb .................... (UT15152,UT15160)
BC2500MR .............. (UT15159R,UT15204)
1•UP 06534 HANDLE(“J”)1
2UP 04154 SCREW-Hex Hd. (1/4-20 X 1 1/2") 1
3UP 04158 SCREW-Hex Hd. (1/4-20 X 1") 1
4UP 04105 CLAMP-Handle Bar 2
5UP 04251 WASHER-Flat (1/4") 2
6UP 03409 WASHER-Lock (1/4") 2
7UP 03399 NUT-Hex (1/4-20) 2
8•UP 02969 DRIVESHAFT HOUSING 1
9UP 04717 DRIVESHAFT-Flexible 1
1 0 UP 04352 DECAL-Warning 1
1 1 •UP 06970 GEAR HEAD 1
1 2 UP 04157 Screw, Taptite Hex Hd. (10-24 x 1/2") 5
1 3 UP 04155 Screw-Hex Hd. (10-24 x 5/8") 2
1 4 •A04683 A GRASS DEFLECTOR KIT 1
1 5 UP 04538 BLADE-Cut-Off 1
1 6 UP 04149 SCREW-Mach. Hex Hd. (10-24 X 3/8") 2
1 7 UP 03885 NUT-Hex (10-24) 2
1 8 UP 04126 WASHER-Flanged 1
1 9 UP 04128 ADAPTER-Shaft 1
2 0 •DA 09364 STRINGHEAD-Pro-Cut w/line 1
(UT15151, UT15154, UT20722, UT20723,
UT15157)
2 1 UP 04102 SCREW-(5/16-18 x 5/8") 1
2 2 D09365 LINE-Replacement 1
2 3 •DA 04591 A STRINGHEAD-Complete (.095") (UT15152, 1
UT15160, UT15159R, UT15204)
2 4 UP 06567 HOUSING & EYELET (Dual Line) 1
2 5 UP 06526 SPRING-Compression 1
2 6 UP 00147 SPOOL & STRING (.095") 1
2 7 DA 98866 A RETAINER-Spool (R.H. Thread, Black) 1
No. Part No. Description Qty.
28 19
16
15
14
18 17
12
4
32
1
5
7
56
6
SHAFT - SPOOL & STRING - GRASS DEFLECTOR - BLADE GUARD - BLADE
20 22
21
Warranty Flat Rate
Job Description Time/Hr.
7....... 90-100 ....... 10.2-11.3
12 ....... 15-20 ......... 1.7-2.3
13 ....... 40-50 ......... 4.5-5.6
17 ....... 30-50 ......... 3.4-5.6
19 ....... 100-120 ....... 11.3-13.6
21 ....... 40-60 ......... 4.5-6.8
31 ....... 100-120 ....... 11.3-13.6
FM10 ...Stringhead Assy. ......................... .2
FN12....Driveshaft (Upper) ...................... .3
FN13....Driveshaft Housing ..................... .4
FN15....Gearhead .................................... .3
FN16....Deflector ...................................... .3
10
Torque Specs
Item Required
No. In/Lbs Nm Loctite
2 8 UP 04535 BLADE GUARD 1
2 9 UP 06729 BLADE-Tri-Arc™1
3 0 UP 04129 WASHER-Cupped (Lower) 1
3 1 UP 03492 NUT-Hex (5/16-18) (R.H.) 1
3 2 UP 04100 TOOL-Holding Pin 1
3 3 UP 00108 HARNESS 1
No. Part No. Description Qty.
23
26
27
24
25
33
32
12
13
11
8
9
31
30
29
03/08/2001

14
1•UP 06790 DRIVESHAFT HOUSING 1
2UP 04116 DECAL-Warning 1
3UP 04542 CABLE-Flex 1
4UP 04142 CLAMP 1
5UP 06874 UPPER HOUSING 1
6•UP 06875 BEARING HOUSING 1
7UP 04713 ADAPTER-Arbor 1
8UP 06876 BUSING 1
9UP 04699 SHAFT-Arbor 1
10 UP 04112 SCREW (10-24 x .312") 1
11 UP 041231 WASHER, Lock (#10) 1
12 UP 04714 IMPELLER 1
13 UP 04701 Clip 1
14 UP 04141 SCREW, Pan Hd. (8-16 x .750) 1
15 UP 04697 LOWER HOUSING 1
16 UP 04250 SCREW-Thread Forming (8-16 x 1") 1
17 UP 04145 GUARD-Lower Housing 1
18 GM 01110 8SCREW (10-16 x 1/4") 1
No. Part No. Description Qty.
BLOWER ATTACHMENT
*Note: Blower must be completely disassembled to install the flex cable.
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
16
17
18
Warranty Flat Rate
Job Description Time/Hr.
10 ....... 25-35 ........... 2.8-4.0
14 ....... 35-45 ........... 4.0-5.1
16 ....... 35-45 ........... 4.0-5.1
18 ....... 5-20 ........... .56-2.3
CD81 ...Fan, Blower.................................. .4
FN12....Driveshaft .................................... .2
FN13....Driveshaft Hsg. ........................... .3
Torque Specs
Item Required
No. In/Lbs Nm Loctite
Expand-it™............ (UT20710,UT20712,
UT20735)
d825ca .................... (UT20711,UT20736)
03/08/2001

15
1GM 23610 3 LOWER COVER 1
2A07934 UPPER HOUSING 1
3•A07930 DRIVESHAFT HOUSING 1
4A08177 FLEX CABLE 1
5GM 97030 7 BOLT-Sems (1/4 - 28 x 1") 2
6GM 23670 6 SUPPORT-Tine 2
7GM 97690 3 TINE 2
8GM 23570 1 “O” RING 2
9A07868 ROCKER ARM (L.H.) 1
10 82618 SCREW, Thread Form (10-24 x 3/4") 4
11 •A07867 CRANK ASSY.1
12 A07870 FLOATING BUSHING 2
13 GM 23690 3 WASHER 2
14 GM 23610 6 CRANKSHAFT CLAMP 2
15 GM 23610 4 SHAFT CLAMP 1
16 82618 SCREW, Thread Form (10-24 x 3/4") 14
17 GM 23610 5 SHAFT CLAMP 2
18 GM 01130 8 SCREW (8-16 x 1") 4
19 A07869 ROCKER ARM (R.H.) 1
20 •A07866 PINNON GEAR & BEARING 1
21 GM 06210 1 SNAP RING 1
CULTIVATOR ATTACHMENT
No. Part No. Description Qty.
15
14
13
12
11
10
9
8
7
6
5
4
3
1
2
16
17
18
19
20
8
7
6
5
12
13
16
21
Warranty Flat Rate
Job Description Time/Hr.
5....... 90-100 ......... 10.2-11.3
10 ....... 40-55 ........... 4.5-6.2 ........ Red 262
16 ....... 40-55 ........... 4.5-6.2 ........ Red 262
18 ....... 35-45 ........... 4.0-5.1
FN12....Driveshaft .................................... .3
FN13....Driveshaft Hsg. ........................... .3
FN17....Transmission (Rebuild) .............. .6
Torque Specs
Item Required
No. In/Lbs Nm Loctite
Expand-it™............ (UT20710,UT20712,
UT20735)
d825ca .................... (UT20711,UT20736)
03/08/2001

16
1•A07931 DRIVESHAFT HOUSING 1
2UP 04369 SHAFT-Flexible 1
3UP 04116 DECAL-Warning 1
4UP 05572 SCREW-Cap Socket Hd. (1/4-20 X 7/8") 1
5UP 04254 SCREW-Sems Hex Hd. (10-24 X 1/2") 1
6UP 04124 GEAR HEAD 1
7•UP 06879 BLADE KIT 1
8UP 04126 WASHER-Flanged 1
9UP 04129 WASHER-Flanged (Lower) 1
10 UP 04127 NUT-Lock 1
11 D04359 A BLADE (2" X 9") (Qty.-2) 1
12 •UP 06881 SUPPORT ARM ASSEMBLY 1
13 UP 04132 KNOB-Adjusting 1
14 UP 03397 NUT-Hex 1
15 UP 04252 WASHER-Flat 1
16 •UP 06882 WHEEL KIT 1
17 UP 04252 WASHER-Flat 2
18 •UP 06738 GUARD KIT 1
19 UP 04532 DECAL-Warning 1
20 UP 04155 SCREW-Hex Hd. (10-24 X 5/8") 3
21 UP 03411 WASHER-Lock (#10) 3
22 UP 06883 FLAP KIT 1
EDGER ATTACHMENT
No. Part No. Description Qty.
15 14
13
12
11
10 9
8
7
6
54
3
1
2
16
17
18
19
20 21 22
Warranty Flat Rate
Job Description Time/Hr.
4....... 40-50 ......... 4.5-5.6
5....... 40-50 ......... 4.5-5.6
10 ....... 100-120 ....... 11.3-13.6
20 ....... 40-50 ......... 4.5-5.6
FN15....Gearhead .................................... .4
JE20 ....Wheel Assembly ......................... .3
JE26 ....Wheel/Axle................................... .3
JR11 ....Blade Cutter................................. .3
FN12....Driveshaft .................................... .3
FN13....Driveshaft Hsg. ........................... .3
FN16....Bladeguard .................................. .4
Torque Specs
Item Required
No. In/Lbs Nm Loctite
Expand-it™............ (UT20710,UT20712,
UT20735)
d825ca .................... (UT20711,UT20736)
03/08/2001

17
1•A07904 DRIVESHAFT HOUSING 1
2UP 04116 DECAL-Warning 1
3UP 04369 SHAFT-Flexible 1
4•UP06534 FRONTHANDLE(“J”)1
5UP 03409 WASHER-Lock (1/4") 2
6UP 04154 SCREW-Hex Hd. (1/4-20 X 1/2") 1
7UP 04158 SCREW-Hex Hd. (1/4-20 X 1") 1
8UP 04105 CLAMP-Handle Bar 1
9UP 03399 NUT-Hex (1/4-20) 2
10 UP 04251 WASHER-Flat (1/4") 2
11 •UP06970 GEAR HEAD 1
12 UP 04157 Screw, Taptite Hex Hd. (10-24 x 1/2") 5
13 UP 04155 Screw-Hex Hd. (10-24 x 5/8") 2
14 UP 04126 WASHER-Flanged 1
15 D98717 CBLADE-Tri-Arc™ (8") 1
16 UP 04129 WASHER-Cupped 1
17 UP 03492 NUT-Hex Locking (R.H.) 1
18 UP 04535 BLADE GUARD 1
BRUSHCUTTER ATTACHMENT
No. Part No. Description Qty.
12
13
14
11
10
9
8
76
5
4
3
1
2
18
Warranty Flat Rate
Job Description Time/Hr.
9....... 90-100 ....... 10.2-11.3
12 ....... 15-20 ......... 1.7-2.3
13 ....... 40-50 ......... 4.5-5.6
17 ....... 100-120 ....... 11.3-13.6
FN12....Driveshaft .................................... .3
FN15....Gearhead .................................... .3
FN16....Blade Guard ................................ .3
FD20....Front Handle................................ .2
Torque Specs
Item Required
No. In/Lbs Nm Loctite
15
16
17
12
Expand-it™............ (UT20710,UT20712,
UT20735)
d825ca .................... (UT20711,UT20736)
03/08/2001

18
ACCESSORIES
GREASE, MULTI-PURPOSE ................................................ 18453
MODULE AIR GAP SHIM ............................................... PS 24306
GRASS ANTI-WRAP KIT ................................................... A 04191
STARTER ROPE (250 Ft. Reel) ........................................ 98052 A
TORX BIT (T25)..................................................................... UP 06544
(For Clutch Drums)
TORX BIT (T27)..................................................................... UP 07160
IGNITION TEST SPARK PLUG ................................... JA 31316 4
RUBBER TUBING (10 Ft.) .............................................. UP 05860
STRINGHEAD-Complete - E-Z Line™....................... DA 03001 A
(.080 Line) (Right Hand Thread) (Black Retainer)
REPLACEMENT STRING - E-Z Line™ (3 lb. Box) ............98011 06
(.080" Dia.)
STRINGHEAD-Complete - E-Z Line™....................... DA 04591 A
(.095 Line) (Right Hand Thread) (Black Retainer)
REPLACEMENT STRING - E-Z Line™ (3 lb. Box) ............03959 04
(.095" Dia.)
STRINGHEAD-Complete-Pro-Cut™ Fixed Line Head .....DA 09364
(.105" Dia.)
REPLACEMENT DuraLine™ (.105" Dia.)..............................D 09365
(Cartridges for Pro-Cut™ Fixed Line Head)
SAFETY GOGGLES................................................................A 06933
DUST MASK ......................................................................... UP 03036
COMFORT STRAP .............................................................. UP 00108
FOR USE ON BRUSHCUTTER UNITS ONLY
TRI-ARC™ BLADE .........................................................D 98717 C
03/08/2001
