C7189R
Wireless Indoor Sensor
Capteur d’intérieur sans fil
Sensor inalámbrico para interiores
Installation instructions
Notice d’installation
Instrucciones de instalación

Installation Guide
ii
69-2459EFS—09
This sensor monitors temperature and humidity in any indoor location and transmits it
wirelessly to the thermostat.
You can set the system to monitor temperature at the thermostat, or at the sensor location,
or use an average of both to optimize comfort throughout the home. The thermostat can use
up to 6 wireless indoor sensors.
When multiple sensors are installed, the thermostat can monitor temperature and humidity
in separate locations. For example, one sensor can control humidification on the main level,
while another controls dehumidification in a crawl space. For more information, see the
instructions provided with the thermostat.
Note: The wireless indoor sensor is compatible only with RedLINK 2.0 thermostats.
Operating Ambient Temperature: 0 to 120° F (17.8 to 48.9° C)
For Optimal Battery Life: 35 to 114° F (1.7 to 45.6° C)
Operating Relative Humidity: 5% to 90% (non-condensing)
Physical Dimensions: 27/8 x 17/8 x 15/16 inches (74 x 48 x 24 mm)
The thermostat will display a warning to replace batteries in the indoor sensor about 2 months before power
is depleted. The sensor status light will begin flashing red about 23 weeks before power is depleted. During
normal operation, the status light remains off.
About your wireless indoor sensor

Wireless Indoor Sensor
169-2459EFS—09
MCR32933
MCR32934
MCR32935
Install 2 fresh AAA alkaline batteries.
Status light will briefly flash green. If it
flashes red, batteries are not good.
Install batteries and link sensor to thermostat
1
Install batteries, then enter Wireless Setup mode at the thermostat. Press and
release the CONNECT button to link the wireless sensor to the thermostat.
Press and release CONNECT. After
a short delay, the status light will
glow green for 15 seconds.
If the status light is red, the
sensor did not link with the
thermostat. See Note.
Verify the thermostat is in the Wireless Setup
mode and the indoor sensor is at least 2 feet
away from the EIM or thermostat.

Installation Guide
2
69-2459EFS—09
M32936A
Mount sensor in suitable location
2
Install sensor on an interior wall, about 4 to 6 feet above the floor. To ensure
accurate temperature readings, choose a location away from air vents and not
exposed to direct sunlight.
1 Remove the wallplate and mount
it 4 to 6 feet above the floor on an
interior wall. Drill 3/16-inch holes
for drywall, 7/32-inch for plaster.
2 Attach sensor securely to wallplate
as shown.
If you replace a thermostat or Equipment Interface Module: You must disconnect the indoor
sensor from the old device. To disconnect, press and hold the CONNECT button on the indoor sensor
until the status light glows amber (hold for about 10 seconds). Then follow the steps on page 1 to
re-link the indoor sensor to the wireless network.

Wireless Indoor Sensor
369-2459EFS—09
5-year limited warranty
Resideo warrants this product, excluding battery, to be
free from defects in workmanship or materials, under nor-
mal use and service, for a period of five (5) years from the
date of first purchase by the original purchaser. If at any
time during the warranty period the product is determined
to be defective due to workmanship or materials, Resideo
shall repair or replace it (at Resideo’s option).
If the product is defective,
(i) return it, with a bill of sale or other dated proof of pur-
chase, to the place from which you purchased it; or
(ii) call Resideo Customer Care at 18004681502.
Customer Care will make the determination whether the
product should be returned to the following address:
Resideo Return Goods, 1985 Douglas Dr. N., Golden Valley,
MN 55422, or whether a replacement product can be sent
to you.
This warranty does not cover removal or reinstallation
costs. This warranty shall not apply if it is shown by
Resideo that the defect was caused by damage which
occurred while the product was in the possession of a
consumer.
Resideo’s sole responsibility shall be to repair or replace
the product within the terms stated above. RESIDEO
SHALL NOT BE LIABLE FOR ANY LOSS OR DAMAGE
OF ANY KIND, INCLUDING ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING, DIRECTLY OR
INDIRECTLY, FROM ANY BREACH OF ANY WARRANTY,
EXPRESS OR IMPLIED, OR ANY OTHER FAILURE OF THIS
PRODUCT.
Some states do not allow the exclusion or limitation of
incidental or consequential damages, so this limitation
may not apply to you.
THIS WARRANTY IS THE ONLY EXPRESS WARRANTY
RESIDEO MAKES ON THIS PRODUCT. THE DURATION
OF ANY IMPLIED WARRANTIES, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, IS HEREBY LIMITED TO THE
FIVE YEAR DURATION OF THIS WARRANTY. Some states
do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you.
This warranty gives you specific legal rights, and you may
have other rights which vary from state to state. If you
have any questions concerning this warranty, please write
Resideo Customer Care, 1985 Douglas Dr, Golden Valley,
MN 55422 or call 18004681502.

Installation Guide
4
69-2459EFS—09
Regulatory information
FCC Compliance Statement (Part 15.19) (USA only)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
FCC Warning (Part 15.21) (USA only)
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC Interference Statement (Part 15.105 (b)) (USA only)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.

Wireless Indoor Sensor
569-2459EFS—09
Regulatory information
Equipment interface module, thermostats and indoor sensor
To comply with FCC and Industry Canada RF exposure limits for general population/ uncontrolled
exposure, the antenna(s) used for these transmitters must be installed to provide a separation distance
of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other
antenna or transmitter.
Section 7.1.2 of RSSGEN
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of type
and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
Section 7.1.3 of RSSGEN
Operation is subject to the following two conditions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operation of the device.
The product should not be disposed of with other household waste. Check for the nearest authorized
collection centers or authorized recyclers. The correct disposal of end-of-life equipment will help prevent
potential negative consequences for the environment and human health.

i
69-2459EFS—09
Guide d’installation
Ce capteur contrôle la température et l’humidité dans tout espace intérieur et la transmet
sans fil au thermostat.
Le système peut être réglé pour contrôler la température au thermostat ou à l’emplacement
du capteur, ou pour utiliser une moyenne des deux pour maximiser le confort dans toute la
maison. Le thermostat peut utiliser jusqu’à 6 capteurs intérieurs sans fil.
Lorsque plusieurs capteurs sont installés, le thermostat peut contrôler la température
et l’humidité dans des endroits différents. Par exemple, un capteur peut contrôler
l’humidification à l’étage principal, tandis qu’un autre peut contrôler la déshumidification
dans un vide sanitaire. Pour plus d’informations, consulter les instructions fournies avec le
thermostat.
Remarque : Le capteur intérieur sans fil est uniquement compatible avec les thermostats
RedLINK 2.0.
Le thermostat affiche un avertissement indiquant de remplacer les piles dans le capteur d’intérieur environ 2
mois avant qu’elles ne soient complètement déchargées. Le voyant de statut du capteur commence à clignoter
en rouge environ 2 à 3 semaines avant que la charge soit complètement épuisée. Durant le fonctionnement
normal, le voyant de statut est éteint.
Température ambiante de service : 17,8 à 48,9 °C (0 à 120 °F)
Pour une durée optimale de la pile : 1,7 à 45,6 °C (35 à 114 °F)
Humidité relative de service : 5 % à 90 % sans condensation
Dimensions physiques : 74 x 48 x 24 mm (2 7/8 x 1 7/8 x 15/16 po)
À propos du capteur d’intérieur sans fil

Capteur d’intérieur sans fil
169-2459EFS—09
MCR32933
MCR32934
MCR32935
Installation des piles et connexion du capteur au thermostat
1
Insérer 2 piles alcalines AAA neuves. Le
voyant de statut clignote brièvement en
vert. S’il clignote en rouge, les piles sont
usées.
Installer les piles et mettre le thermostat en mode de configuration sans fil.
Appuyer sur le bouton CONNECT (Connexion) puis le relâcher pour connecter le
capteur sans fil au thermostat.
Appuyer sur le bouton CONNECT
(Connexion) et le relâcher. Après
un court délai, le voyant de statut
s’allume en vert pendant 15
secondes.
Si le voyant de statut est rouge,
le capteur n’est pas connecté au
thermostat. Voir la remarque.
Vérifier que le thermostat est en mode de
configuration sans fil et que le capteur intérieur
est situé à au moins 61 cm (2 pi) du module
d’interface d’équipement ou du thermostat.

2
69-2459EFS—09
Guide d’installation
Installation du capteur dans un endroit approprié
2
Installer le capteur sur un mur intérieur entre 1,2 et 1,8 m (4 et 6 pi) au-dessus
du sol. Pour assurer des relevés de température précis, choisir un emplacement
éloigné de conduites d’air et non exposé aux rayons directs du soleil.
1 Retirer la plaque murale et la
monter de 1,2 à 1,8 m (4 à 6 pi)
au-dessus du sol sur un mur
intérieur. Percer des trous de 3/16
po sur les cloisons sèches ou des
trous de 7/32 po pour le plâtre.
2 Bien attacher le capteur à la
plaque murale comme illustré.
En cas de remplacement d’un thermostat ou d’un module d’interface d’équipement : Le capteur
d’intérieur doit être débranché de l’ancien appareil. Pour débrancher, appuyer (pendant environ 10
secondes) sur le bouton CONNECT (Connexion) du capteur d’intérieur jusqu’à ce que le voyant de
statut orange clignote. Suivre ensuite les étapes indiquées à la page 1 pour reconnecter le capteur
d’intérieur au réseau sans fil.
M32936A
