Honeywell Home T6 Pro Z-Wave User manual

Package Includes:
• T6 PRO ZWave Thermostat
• UWP™ Mounting System
• Decorative Cover Plate
• Screws and anchors
• 3 AA batteries
• Thermostat Literature *TH6320ZW2003 depicted.
Actual size 4.09'' x 4.09'' x 1.06''
T6 Pro Z-Wave
Programmable Thermostat
TH6320ZW2003
Professional Install
Guide
33-00294-11
PM
Menu FanMode
Fan
Auto
Mode
Heat
Wake Away HomeSleep
Following Schedule
ProSeries
Compatibility
• Designed for battery operation (3 x AA batteries) or for 24 VAC power operation
(via a “C” or common wire).
• Compatible with most single and multi-stage conventional and heat pump
systems.
• Designed to work with any ZWave compliant controller or gateway; however,
a security enabled ZWave Plus Controller is recommended to fully utilize all
thermostat features.
• Works with millivolt systems.
• Does not work with electric baseboard heat (120240V).
User Guide
Visit honeywellhome.com for a complete user guide.
Customer assistance
For assistance with this product, please visit
customer.resideo.com.
Or call Resideo Customer Care toll-free at
18004681502.

2
Read and save these instructions.
Introduction
The T6 Pro ZWave Programmable Thermostat is a ZWave Plus certified thermostat
capable of controlling up to three heat and two cool stages of heat pump, (incl. dual
fuel heat pump systems) and up to two heat and two cool stages of conventional
system (3H/2C HP, 2H/2C Conv.) It also measures, displays and reports % indoor
relative humidity; however, this model does not control humidification equipment.
It is one of the easiest smart thermostats to install and is controllable by all ZWave
compliant controllers that have the control capability for "Thermostat" devices.
When integrated with the app that controls your ZWave controller, it lets you pro-
gram and control your home’s HVAC system as well as controlling other ZWave
devices connected to the same ZWave controller.
Because the thermostat is battery-powered, low-voltage integrators
can easily connect the thermostat to most HVAC systems. Optional
24 VAC powering via “C” or common wire is also available, if desired.
CAUTION
• We strongly recommend that installation is performed by a trained HVAC
technician.
• Read the enclosed instructions carefully before installing the new T6 Pro
ZWave Programmable Thermostat.
• ELECTRICAL HAZARD: Can cause electrical shock or equipment damage.
Disconnect power before beginning installation.
• To prevent abnormal operation, it is highly recommended to configure
the installer setup and set the thermostat to correct HVAC system before
including the thermostat to ZWave network. If the configuration must
be changed, first EXCLUDE the thermostat from the network, change
the thermostat configuration, and INCLUDE the thermostat back to the
network.
• Before disconnecting wires from the existing thermostat, label the wires
with the terminal markings from the old thermostat and record them. Take
a picture of the old wiring.
• Use 3 new AA batteries in the thermostat.

3
UWP Mounting System installation
1. Open package to find the UWP. See
Figure 1.
2. Position the UWP on the wall. Level and
mark hole positions. See Figure 2.
Drill holes at marked positions, and
then lightly tap supplied wall anchors
into wall using a hammer.
‒If your box contains red anchors, drill
7/32” holes for drywall. If your box
contains yellow anchors, drill 3/16”
holes for drywall.
3. Pull the door open and insert wires
through wiring hole of the UWP. See
Figure 3.
4. Place the UWP over the wall anchors.
Insert and tighten mounting screws
supplied with the UWP. Do not
overtighten. Tighten until the UWP
no longer moves. Close the door. See
Figure 4.
1
2
3
4
Optional Decorative Cover Plate installation
Use the Optional Cover Plate when you need
to cover paint gap from the old thermostat.
There are different cover plates depending
on when the thermostat was manufactured.
One plate is square, the other is rectangular.
1. If the square mounting plate is used,
separate the cover plate from the
mounting plate. See Figure 1.
2. Mount the mounting plate to the wall
using any of the screw holes. Insert and
tighten mounting screws supplied with
the cover plate. Do not overtighten. Make
sure the mounting plate is level. See
Figure 2a (square) or 2b (rectangle).
3. Attach the UWP by hanging it on the top
hook of the mounting plate and then
snapping the bottom of the UWP in place.
See Figure 3.
4. Snap the Cover Plate onto the mounting
plate. See Figure 4.
Use 3x supplied
screws (#8 11/2
for red anchors and
#6 11/2 for yellow
anchors)
Use 2x
supplied
screws
#6 5/8”
1
2
3 4
1 2
3
4
1
4
3
2a 2b

4
S
S
Y2
U
U
G
C
Y
A
Rc
W
K
W2
R
L/A
O/B
AUX
E
Power options
Insert Rand Cwires into designated
terminals for primary AC power (C terminal
is optional if batteries are installed, but
it is recommended). Remove wires by
depressing the terminal tabs.
Insert 3 AA batteries for primary or
backup power. Match the polarity
of the batteries with the + / – marks
inside the battery compartment.
NOTES:
• The T6 Pro ZWave thermostat works in battery mode or normal power mode
based on its power source. The ZWave power mode can only be changed when
the thermostat is NOT included in a ZWave network. You can check the power
mode in the thermostat menu under MENU/DEVICE INFO.
• If a C wire is not used or present, the thermostat must be powered by batteries.
The thermostat will operate in LSS mode (power-save, sleep mode) to help
conserve battery life after it has been included in a ZWave network. The ZWave
radio supports beaming. It allows other devices in the network to wake up the
ZWave thermostat, accept commands, and then go back to sleep.
• If you need the thermostat to operate in AOS mode (always listening mode)
to act as signal repeater and to increase network reliability, you need to power
the thermostat by 24 VAC. The AOS mode information is provided via Node
Information Frame (NIF).
For the rectangular cover plate
1 Mount the cover plate on the wall using any of the 6 screw holes. Insert and tighten the
mounting screws supplied with the Cover Plate. Do not overtighten. See Figure 1. Make
sure the Cover Plate is level. Attach the UWP by hanging it on the top hook of the Cover
Plate and then snapping the bottom of the UWP in place. See Figure 2.
2 If there are no existing wall anchors:
a. Position the Cover Plate on wall. Level and mark hole positions. See Figure 1.
b. Drill holes at marked positions, and then lightly tap supplied wall anchors
into the wall
using a hammer.
• If your box contains red anchors, drill 7/32” (5.6 mm) holes.
• If your box contains yellow anchors, drill 3/16” (4.8 mm) holes.
• Use 2x supplied screws (#8 1 1/2” (38 mm) for red anchors and #6 1 1/2” (38
mm) for yellow anchors).

5
Wiring UWP
Push down on the tabs to put the wires into the inner
holes of their corresponding terminals on the UWP (one
wire per terminal) until they are firmly in place. Gently
tug on the wires to verify they are secure. If you need to
release the wires again, push down the terminal tabs on
the sides of the UWP.
This wiring is just an example,
yours may vary.
Wiring terminal designations
SInput for wired
indoor or outdoor
sensors
L/A
- A
Heat Pump fault input
(C wire required)
SO/B Changeover valve
YCompressor
contactor (stage 1)
AUX -
W2
Auxiliary heat relay
Heat relay (stage 2)
Y2 Compressor
contactor (stage 2) EEmergency Heat relay
GFan Relay WHeat relay (stage 1)
C
24 VAC common.
For 2 transformer
systems, use
common wire from
cooling transformer.
KConnect to K on C-wire
adapter**
U
Unused
R24 VAC power from
heating transformer*
URc 24 VAC power from
cooling transformer*
Note: Not all
terminals may be
used, depending
on the system
type that is being
wired. The most
commonly used
terminals are
shaded.
* Terminal can be jumped using Slider Tab. See “Setting Slider Tabs” above.
** The THP9045A1098 C-wire adapter is used on heat/cool systems when you
only have four wires at the thermostat and you need a fifth wire for a common
wire. Use the K terminal in place of the Y and G terminals on conventional or
heat pump systems to provide control of the fan and the compressor through
a single wire—the unused wire then becomes your common wire. See THP9045
instructions for more information.
Set R Slider Tab.
• Use built-in jumper (R Slider Tab) to
differentiate between one or two transformer
systems.
• If there is only one R wire, and it is connected
to the R, Rc, or RH terminal, set the slider to
the up position (1 wire).
• If there is one wire connected to the R
terminal and one wire connected to the Rc
terminal, set the slider to the down position (2
wires).
NOTE: Slider Tabs for U terminals should be left
in place for other thermostat models.
Setting Slider Tabs
R/Rc slider tab
UWP Mounting System

6
Wiring conventional systems: forced air and hydronics
NOTES:
• Available wiring configurations may differ by product models/product numbers.
• Wire specifications: Use 18 to 22-gauge thermostat wire. Shielded cable is not required.
[1] Power supply. Provide disconnect means and
overload protection as required.
[2] Move RSlider Tab on UWP to the Rsetting. For
more information, see "Setting Slider Tabs" on
page 5.
[3] Optional 24 VAC common connection.
[4] If you do not have separate wires for the Aux
and E terminals, connect the wire to the Aux
terminal.
[5] In Installer Setup Options (ISU), set system type
to Boiler. Set number of cool stages to 0.
[6] In Installer Setup Options (ISU), set system type
to Conventional. Set cool stages to 2, and set
heat stages to 2.
1H/1C System (1 transformer)
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
Y Compressor contactor
C24 VAC common [3]
W Heat relay
G Fan relay
Heat-only System
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
C 24 VAC common [3]
W Heat relay
Heat-only System (Series 20) [5]
R Series 20 valve terminal “R” [1]
Rc [R+Rc joined by Slider Tab] [2]
Y Series 20 valve terminal “W”
C 24 VAC common [3]
W Series 20 valve terminal “B”
Heat-only System
(power open zone valve) [5]
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
W Valve
C 24 VAC common [3]
1H/1C System (2 transformers)
R Power (heating transformer) [1]
Rc Power (cooling transformer) [1]
Y Compressor contactor
C 24 VAC common [3, 4]
W Heat relay
G Fan relay
Heat-only System with Fan
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
C 24 VAC common [3]
W Heat relay
G Fan relay
Cool-only System
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
Y Compressor contactor
C 24 VAC common [3]
G Fan relay
2H/2C System (1 transformer) [6]
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
Y Compressor contactor (stage 1)
C 24 VAC common [3]
W Heat relay (stage 1)
G Fan relay
W2 Heat relay (stage 2)
Y2 Compressor contactor (stage 2)

7
1H/1C Heat Pump System
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
Y Compressor contactor
C 24 VAC common [3]
O/B Changeover valve [7]
G Fan relay
2H/1C Heat Pump System [8]
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
Y Compressor contactor
C 24 VAC common [3]
O/B Changeover valve [7]
G Fan relay
Aux Auxiliary heat [4]
E Emergency heat relay [4]
L Heat pump fault input
2H/2C Heat Pump System [6]
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
Y Compressor contactor (stage 1)
C 24 VAC common [3]
O/B Changeover valve [7]
G Fan relay
Y2 Compressor contactor (stage 2)
L Heat pump fault input
3H/2C Heat Pump System [10]
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
Y Compressor contactor (stage 1)
C 24 VAC common [3]
O/B Changeover valve [7]
G Fan relay
Aux Auxiliary heat [4]
E Emergency heat relay [4]
Y2 Compressor contactor (stage 2)
L Heat pump fault input
Dual Fuel System
R Power [1]
Rc [R+Rc joined by Slider Tab] [2]
Y Compressor contactor (stage 1)
C 24 VAC common [3]
O/B Changeover valve [7]
G Fan relay
Aux Auxiliary heat [4]
E Emergency heat relay [4]
Y2 Compressor contactor (stage 2 - if
needed)
L Heat pump fault input
S Outdoor sensor
S Outdoor sensor
Wiring heat pump systems
[1] Power supply. Provide disconnect means and
overload protection as required.
[2] Move RSlider Tab on UWP to the Rsetting. For
more information, see "Setting Slider Tabs" on
page 5.
[3] Optional 24 VAC common connection.
[4] If you do not have separate wires for the Aux
and E terminals, connect the wire to the Aux
terminal.
[6] In Installer Setup Options (ISU), set system type
to Heat Pump. Set compressor stages to 2, and
set Aux/E stages to 0.
[7] In Installer Setup Options (ISU), set Reversing
Valve to O/B on Cool (for cool changeover) or
to O/B on Heat (for heat changeover).
[8] In Installer Setup Options (ISU), set heat sys-
tem type to Heat Pump. Set compressor stages
to 1, and set Aux/E stages to 1.
[10] In Installer Setup Options (ISU), set system type
to Heat Pump, set compressor stages to 2, and
set Aux/E stages to 1.
NOTES:
• Do NOT use Wfor heat pump applications. Auxiliary heat must wire to AUX or E.
• Available wiring configurations may differ by product models/product numbers.
• Wire specifications: Use 18 to 22-gauge thermostat wire. Shielded cable is not required.

8
Mounting thermostat
1 Push excess wire back into the wall
opening.
2 Close the UWP door. It should remain
closed without bulging.
3 Align the UWP with the thermostat, and
push gently until the thermostat snaps in
place.
4 If needed, gently pull to remove the
thermostat from the UWP.
5 Turn the power on at the breaker box or
switch.
Initial installer setup
• After the T6 Pro ZWave thermostat has
powered up, touch START SETUP on the
thermostat.
• Touch or to toggle between Installer
Set Up (ISU) options.
• Touch Edit or touch text area, and then
touch or to edit default setup
option.
• Touch Done or touch text area to confirm
the setting or press Cancel.
• Touch or to continue to setup
another ISU option.
• To finish setup and save your settings,
scroll to the Finish screen at the end of
the ISU list.
NOTES:
• To see a list of all setup parameters, go to
"Installer setup options (ISU) – advanced
menu" on page 15. The thermostat
displays the ISU name and the ISU
number.
• To prevent abnormal operation, it is
highly recommended to perform installer
setup and set thermostat to correct
HVAC system before including it in a
ZWave network.
Cancel
Done
Edit ISU
ISU #
ISU option blinking
Cancels
ISU option
selection, go
back to view
ISU
Arrow buttons
used to scroll
through ISU
options
Saves selected ISU
option moves on to
the next ISU screen
Edit
View ISU
ISU option and
name (scrolling)
Arrow buttons
used to scroll
through ISUs

9
After you finish the installer setup and set the
date and time, you will be asked to set up a
ZWave to include the thermostat into ZWave
network.
• Touch Yes to include the thermostat in to
ZWave network, or touch No if you want this to
be done later.
• You’ll be asked to set your primary controller
to INCLUDE MODE. Please refer to the user
manual of your ZWave controller.
• After inclusion procedure has been initiated
on your ZWave controller, touch Select on the
thermostat.
• If the inclusion procedure is successful,
INCLUDED, the node ID, and the ZWave connected status icon appear on the
screen. If the procedure fails, FAILED TO INCLUDE appears on the screen. If this
happens, position the thermostat closer to the ZWave controller and repeat the
inclusion procedure.
• Your controller will indicate whether the thermostat was successfully added to its
network. (Please refer to the user manual of your ZWave controller.)
NOTES:
• This thermostat will function as a normal programmable thermostat with the
default program schedule if not included in a ZWave network. Once you include
the thermostat in to ZWave network, it assumes to be programmed from your
ZWave controller and the program schedule on the thermostat is turned OFF by
default. For more information, see "Scheduling options" on page 12.
• To include or exclude the thermostat from ZWave network after initial thermostat
setup, go to thermostat MENU/ZWAVE SETUP.
• Before adding the thermostat to a ZWave network, check that it does not already
belong to one. If the thermostat is included in ZWave network, it offers an option
to exclude. If the thermostat is excluded from ZWave network, it offers an option
to include. You can also check the status by viewing the Node ID located in the
thermostat MENU/DEVICE INFO. An excluded thermostat should show zero for
the Node ID (000).
• Whether you are including or excluding the thermostat from ZWave network, first
you have to initiate it on your ZWave controller. Please refer to the user manual of
your Z-wave controller.
• For other specific tasks such as adding the thermostat to home automation
scenes or groups, refer to the user manual of your ZWave controller.
ZWave setup
Cancel
Back Select
No Yes

10
ZWave connection status is located in the upper-right corner of the screen.
• Thermostat is included and connected to a ZWave network.
• Thermostat is excluded from a ZWave network.
• Thermostat is either included in a ZWave network but the ZWave signal
is lost, or is included but AC power is lost (battery used as backup). In this
case, ZWave radio is turned off to preserve battery life. AC power must be
restored or you have to change the power mode. It can be done via excluding
thermostat from Z-wave network and including again in battery power mode
where batteries are used as main power source. You can check the actual
power mode in the thermostat MENU/DEVICE INFO.
ZWave connection status
AM
Menu FanMode
Fan
Auto
Mode
Heat
Wake AwayHomeSleep
Following Schedule
Example of Wi-Fi is connected.
Wifi is on and
connected
Wifi is disconnected
or wifi is not setup
Wifi is off
AM
Menu FanMode
Fan
Auto
Mode
Heat
Wake AwayHomeSleep
Following Schedule
Example of Wi-Fi is connected.
Wifi is on and
connected
Wifi is disconnected
or wifi is not setup
Wifi is off
AM
Menu FanMode
Fan
Auto
Mode
Heat
Wake AwayHomeSleep
Following Schedule
Example of Wi-Fi is connected.
Wifi is on and
connected
Wifi is disconnected
or wifi is not setup
Wifi is off
This thermostat may be configured to report the actual room temperature in
a higher resolution than can be shown on the thermostat display. The default
temperature reporting resolution is 1 °F or 0.5 °C. When configured to ADVANCED,
the temperature reporting resolution will be 0.5 °F or 0.25 °C. To change default
temperature reporting to a higher resolution, go to thermostat MENU/ZWAVE
SETUP/TEMP REPORT and set to ADVANCED. The temperature is reported by
every displayed value change, and no later than 2 hours from last report.
NOTE: When higher temperature resolution reporting set, you may experience
different resolution of temperature displayed on the thermostat and ZWave
controller.
Advanced ZWave temperature reporting
