Honeywell CS08AM User manual

Portable Evaporative Air Cooler
User Manual
Read and save these instructions before use
www.honeywellaircoolers.com
E-mail: [e-mail]
Model: CS08AM

1
PARTS DESCRIPTION
EN
1) Control Panel 7) Honeycomb Cooling Media
2) Handle 8) Water Fill Door
3) Front Grill 9) Water Tank
4) Power Cord & Plug 10) Drain Plug
5) Casters 11) Rear Grill Screw
6) Water Level Indicator 12) Swing Knob
1
5
6
2
7
9
3
4
10
11
12
8
WARNING -- READ AND SAVE THE AIR COOLER SAFETY & MAINTENANCE GUIDE AND USER
MANUAL BEFORE USING THIS PRODUCT. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY
DAMAGE AND/ OR IMPAIR ITS OPERATION AND VOID THE WARRANTY. IN CASE THERE IS
ANY INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH VERSION AND ANY OTHER
LANGUAGE VERSION OF THE CONTENT OF THIS MATERIAL, THE ENGLISH VERSION SHALL
PREVAIL.

2
USE & OPERATION
EN
CONTROL PANEL
SPEED / ON - OFF
Connect to the power supply and turn the SPEED knob. The fan will start. Change the speed from 3
to 1 (3 for High, 2 for Medium and 1 for Low fan speed). To switch OFF the unit, turn the SPEED knob
to 0.
COOL
You must add water before operating the unit on Cool mode. Turn the COOL knob to the ON position
to activate evaporative cooling. The water pump will operate and you will feel the cooler air after the
Honeycomb Cooling Media is completely wet.
Make sure that the water in the tank is above the minimum water level mark. Running the unit in
COOL mode with inadequate water may cause pump failure.
SWING KNOB
Rotate it to right will lock the rotary grill, rotate it to left (normal/original position) the grill will rotate
once speed knob is turn to any speed level (except 0).
FUNCTION BUTTONS

3
CAUTION:
Unplug the unit from the electrical power outlet before emptying or refilling the water tank.
Open the Water Fill Door located on the top of the unit.
The Water Level Indicator is located at the front of the unit. Refill the water
tank when water level is low. Do not fill water above the "Max." water level
mark to avoid water droplets collecting on the louvers. Check the water
level in the tank before running the COOL function.
Make sure that the water in the tank is above the minimum water level mark. Running the unit in
COOL mode with inadequate water may cause pump failure.
Note: The water capacity refers to the total volume of water that can be contained within the air
cooler water tank and water distribution system. The water capacity in the tank at the “Max.” indicator
level may be lower than the actual water capacity of the air cooler.
WARNING: Do not fill water tank with dirty water or salt water. This can damage the unit and Honeycomb
media.
USE & OPERATION (CONTINUED)
EN
COOLER LOCATION
FILLING WITH WATER
Make sure to position the air cooler correctly before you set up and start using the product. Please
refer to the COOLER LOCATION section of the separate Safety & Maintenance Guide.
Water Fill Door

4
Move the unit to a location where the water can be drained. Remove the cap from the Drain Plug
located at the bottom of the unit. Allow the tank to empty.
Refill the water tank with clean water, up to the maximum level and drain it completely.
Use a damp cloth to remove the dirt and dust from the surface of the unit. Never use corrosive
elements or chemicals to clean this product.
When the product is not in use, store the unit in a dry place out of direct sunlight.
•
•
•
•
USE & OPERATION (CONTINUED)
EN
Below are instructions on how to clean and maintain your air cooler. If the cooler will not be used for
a long period of time, please refer to the STORAGE & MAINTENANCE GUIDELINES located in the
separate Safety & Maintenance Guide.
WARNING:
Before cleaning the unit, switch the unit OFF and disconnect from the power outlet..
CLEANING & DRAINING THE WATER TANK

5
USE & OPERATION (CONTINUED)
EN
CLEANING THE HONEYCOMB COOLING MEDIA
The appliance is supplied with a Honeycomb Cooling Media.
The Honeycomb Cooling Media is located inside the Rear Grill. See Figure 1 for instructions on
how to remove them from the unit for cleaning and maintenance.
Do not run the unit in COOL mode with stale water in the tank. You must empty the water tank
and refill with fresh water, especially if the tank has not been cleaned in a long time.
The cleaning frequency for the Honeycomb media depends on local air and water conditions.
In areas where the mineral content of water is high, mineral deposits may build up on the
Honeycomb Cooling Media and restrict air flow. Draining the water tank and refilling with fresh
water at least once a week will help reduce mineral deposits. If mineral deposits remain on the
Honeycomb Cooling Media, the media should be removed and washed under fresh water. The
media should be cleaned every two months or sooner, depending on your needs.
For best results allow the Honeycomb Cooling Media to dry after each use by turning off the cool
function 15 minutes before turning the unit off.
•
•
•
•
•
Remove all the screws from the Rear Grill of the
Air Cooler.
Carefully slide out the rear grill from the cooler.
Carefully pull out the Honeycomb Cooling Media
from the cooler.
There are two Horizontal Bars holding the
Honeycomb Cooling Media in place. Remove all
the screws from the Horizontal Bars and then pull
the bars off of the Honeycomb Cooling Media.
Replace or clean media with water and a damp
cloth as needed.
1.
2.
3.
4.
5.
Removing the Honeycomb Cooling Media:
WARNING: DO NOT operate the Air Cooler when the
Rear Grill or Honeycomb Media is removed from
the Air Cooler, or if there is a loose-fitting Rear Grill
or Honeycomb Cooling Media. Doing so can cause
serious injury or dangerous electrical shock.
Figure 1:
Rear Grill
Honeycomb
Cooling Media Horizontal Bar
Screws
Screws

JMATEK Limited
Manulife Financial Centre,
Kwun Tong, Hong Kong
Phone: 85225595522
Email: [email protected]
Web: www.jmatek.com
Made in China
© 2017 JMATEK Limited. All rights reserved.
The Honeywell Trademark is used under license
from Honeywell International Inc.
Honeywell International Inc. makes no
representations or warranties with respect to this product.
This product is manufactured by Airtek Int'l Corp. Ltd.
(subsidiary of JMATEK Ltd.).
