Honeywell 3800 Linear Series User manual

3800 Linear Series
Quick Start Guide

2

EN-1
Note: Refer to your user’s guide for information
about cleaning your device.
Getting Started
Turn off computer’s power before connecting the
scanner, then power up the computer once the
scanner is fully connected.
USB Connection

EN-2
Keyboard Wedge Connection
Serial (RS-232) Connection
Note: Does not apply to the 3800g Lite Plus.

EN-3
Reading Techniques
The view finder
projects a red
aiming beam that
should be
centered over the
bar code.
Hold the scanner
over the bar code,
pull the trigger,
and center the
aiming beam on
the bar code.
The aiming beam is smaller when the scanner is
closer to the code and larger when it is farther from
the code. Hold the scanner close to smaller bar
codes, and farther away from large bar codes to get
a proper read.
If the bar code is highly reflective (e.g., laminated),
you may need to tilt the scanner at an angle so the
bar code can be scanned.

EN-4
To read PDF417 bar codes with a PDF-enabled
3800, hold the trigger down and move the scanner
up and down so the aiming line sweeps from the top
of the bar code to the bottom, and back up.
This ensures that the entire code is scanned.
Note: This only applies to a PDF enabled 3800/
3800g.
Standard Product Defaults
The following bar code resets all standard product
default settings.
Standard Product Defaults

EN-5
Interface
Scan the bar code that describes the PC or
interface you are using.
AT/PS2 Keyboard Wedge
(Default)
RS-232
(Does not apply to 3800g Lite Plus)
USB Keyboard (PC)
Emulate External Keyboard

EN-6
Keyboard Country
Scan the Program Keyboard Country bar code
below, then scan the numeric bar code(s) from
page EN-10, then the Save bar code to program the
keyboard for your country. As a general rule, the
following characters are not supported by the
scanner for countries other than the United States:
@ | $ # { } [ ] = / ‘ \ < > ~.
Note: For a complete list of country codes, see the
User’s Guide for your product at our website,
www.honeywell.com/aidc.
Country Code Scan Country Code Scan
Belgium 1 Italy 5
Denmark 8 Norway 9
Finland 2 Spain 10
France 3 Switzerland 6
Germany/Austria 4 USA (Default) 0
Great Britain 7
Program Keyboard Country
Save

EN-7
Trigger
The following bar codes will allow you to use the
reader in Manual Trigger mode (need to press the
trigger to read), Automatic Trigger mode (the beam
is always on), or Presentation mode (the reader is
activated when it “sees” a bar code).
Reread Delay
This sets the time period before the scanner can
read the
same bar code a second time. Setting a
reread delay protects against accidental rereads of
the same bar code.
Manual Trigger
(Default)
Automatic Trigger
Presentation Mode
Medium Reread Delay
for 3800 only
Medium Reread Delay
for 3800g, 3800g Lite Plus, 3800r, and 3800i

EN-8
Suffix
If you want a carriage return after the bar code,
scan the Add CR Suffix bar code. To add a tab
after the bar code, scan the Add Tab Suffix bar
code. Otherwise, scan the Remove Suffix bar
code to remove the suffixes.
Add Code ID Prefix to all Symbologies
Scan the following bar code if you wish to add a
Code ID prefix to all symbologies at once.
Note: For a complete list of Code IDs, see the
User’s Guide for your product at our website,
www.honeywell.com/aidc.
Add CR Suffix
Remove Suffix
Add Tab Suffix
Add Code ID Prefix To All Symbologies
(Temporary)

EN-9
Data Format Editor Instructions
The following are abbreviated instructions for
entering a data format. For complete instructions
refer to your User’s Guide, available at our website,
www.honeywell.com/aidc.
1. Scan the Enter Data Format symbol.
2. Primary/Alternate Format: scan 0for Primary
Format.
3. Terminal Type: scan 099 for any terminal type.
4. Code I.D.: scan 99 for any bar code type.
5. Length: scan 9999 for any length bar code.
6. Editor commands: use the Programming Chart
that follows.
7. Scan Save to save your entries.
Enter Data Format
Clear All Data Formats
Save

EN-10
Programming Chart
0
2
1
4
3
5
6
7

EN-11
A
B
C
D
E
F
9
8
Save

EN-12
Note: For the 3800ISR000E and 3800RSR000E,
software 35122063.bin is required.
Visual Menu
To obtain access to additional features for the 3800,
use Visual Menu, available from our website at
www.honeywell.com/aidc. For complete download
instructions and descriptions of Visual Menu’s
features, refer to your User’s Guide.
Visual Xpress™
To obtain access to additional features for the
3800g, 3800gHD, 3800gPDF, 3800g Lite Plus,
3800i, or 3800r, use Visual Xpress, available from
our website at www.honeywell.com/aidc. For
complete download instructions and descriptions of
Visual Xpress features, refer to your User’s Guide.
Technical Assistance
If you need assistance installing or troubleshooting
your device, please call your distributor or the
nearest technical support office:
Visual Menu

EN-13
North America/Canada
Telephone: [phone]
E-mail: [email protected]
Latin America
Telephone: [phone]
Telephone: [phone]
E-mail: [email protected]
Brazil
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Mexico
Telephone: [phone]
E-mail: [email protected]
Europe, Middle East, and Africa
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Hong Kong
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Singapore
Telephone: [phone]

EN-14
Fax: [phone]
E-mail: [email protected]
China
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Japan
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Online Technical Assistance
You can also access technical assistance online at
www.honeywellaidc.com.
Product Service and Repair
Honeywell International Inc. provides service for all
its products through service centers throughout the
world. To obtain warranty or non-warranty service,
contact the appropriate location below to obtain a
Return Material Authorization number (RMA #)
before returning the product.
North America
Telephone: [phone]
E-mail: [email protected]

EN-15
Latin America
Telephone: [phone]
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Brazil
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Mexico
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Europe, Middle East, and Africa
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Hong Kong
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Singapore
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]

EN-16
China
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Japan
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Online Product Service and Repair
Assistance
You can also access product service and repair
assistance online at www.honeywellaidc.com.

EN-17
Limited Warranty
Honeywell International Inc. ("HII") warrants its products
and optional accessories to be free from defects in
materials and workmanship and to conform to HII’s
published specifications applicable to the products
purchased at the time of shipment. This warranty does not
cover any HII product which is (i) improperly installed or
used; (ii) damaged by accident or negligence, including
failure to follow the proper maintenance, service, and
cleaning schedule; or (iii) damaged as a result of (A)
modification or alteration by the purchaser or other party,
(B) excessive voltage or current supplied to or drawn from
the interface connections, (C) static electricity or electro-
static discharge, (D) operation under conditions beyond
the specified operating parameters, or (E) repair or
service of the product by anyone other than HII or its
authorized representatives.
This warranty shall extend from the time of shipment for
the duration published by HII for the product at the time of
purchase ("Warranty Period"). Any defective product
must be returned (at purchaser’s expense) during the
Warranty Period to HII factory or authorized service center
for inspection. No product will be accepted by HII without
a Return Materials Authorization, which may be obtained
by contacting HII. In the event that the product is returned
to HII or its authorized service center within the Warranty
Period and HII determines to its satisfaction that the
product is defective due to defects in materials or
workmanship, HII, at its sole option, will either repair or
replace the product without charge, except for return
shipping to HII.

EN-18
EXCEPT AS MAY BE OTHERWISE PROVIDED BY
APPLICABLE LAW, THE FOREGOING WARRANTY IS
IN LIEU OF ALL OTHER COVENANTS OR
WARRANTIES, EITHER EXPRESSED OR IMPLIED,
ORAL OR WRITTEN, INCLUDING, WITHOUT
LIMITATION, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, OR NON-INFRINGEMENT.
HII’S RESPONSIBILITY AND PURCHASER’S
EXCLUSIVE REMEDY UNDER THIS WARRANTY IS
LIMITED TO THE REPAIR OR REPLACEMENT OF THE
DEFECTIVE PRODUCT WITH NEW OR REFURBISHED
PARTS. IN NO EVENT SHALL HII BE LIABLE FOR
INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES, AND, IN NO EVENT, SHALL ANY LIABILITY
OF HII ARISING IN CONNECTION WITH ANY
PRODUCT SOLD HEREUNDER (WHETHER SUCH
LIABILITY ARISES FROM A CLAIM BASED ON
CONTRACT, WARRANTY, TORT, OR OTHERWISE)
EXCEED THE ACTUAL AMOUNT PAID TO HII FOR THE
PRODUCT. THESE LIMITATIONS ON LIABILITY SHALL
REMAIN IN FULL FORCE AND EFFECT EVEN WHEN
HII MAY HAVE BEEN ADVISED OF THE POSSIBILITY
OF SUCH INJURIES, LOSSES, OR DAMAGES. SOME
STATES, PROVINCES, OR COUNTRIES DO NOT
ALLOW THE EXCLUSION OR LIMITATIONS OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION OR EXCLUSION MAY NOT
APPLY TO YOU.
