Honeywell 4850DR User manual

Leitor Fixo Honeywell
4850dr
O Leitor Honeywell 4850dr é direcionado especialmente
para farmácias e drogarias, pois facilita o trabalho de
controle das receitas e dos medicamentos. Além de
digitalizar a receita e ler os códigos de barras, o leitor
também salva as imagens em diversos tamanhos.
www.bztech.com.br

4850DR
Document Reader
Bar Code Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been
made. The information in this publication does not represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages
resulting from the furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document
may be photocopied, reproduced, or translated into another language without the prior written consent of HII.
2014 Honeywell International Inc. All rights reserved.
Web Address: www.honeywellaidc.com
Microsoft® Windows®, Windows NT®, Windows 2000, Windows ME, Windows XP, and the Windows logo are trademarks or
registered trademarks of Microsoft Corporation.
Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies
and are the property of their respective owners.

i
Chapter 1 - Getting Started
About This Manual ...............................................................................................................1-1
Unpacking Your Device .......................................................................................................1-1
Document Reader Models ...................................................................................................1-1
Aligning the Document Reader Tray....................................................................................1-2
Reading Techniques ............................................................................................................1-2
Using the Scanner Out of the Stand ..............................................................................1-3
Resetting the Defaults..........................................................................................................1-3
Chapter 2 - Programming the Interface
Introduction ..........................................................................................................................2-1
Programming the Interface - Plug and Play .........................................................................2-1
USB IBM SurePos ...............................................................................................................2-1
USB PC Keyboard ...............................................................................................................2-1
USB HID ..............................................................................................................................2-1
USB Serial ...........................................................................................................................2-2
CTS/RTS Emulation.......................................................................................................2-2
ACK/NAK Mode .............................................................................................................2-2
Remote MasterMind™ for USB ...........................................................................................2-2
Wincor Nixdorf Beetle™ Terminal Default Settings .............................................................2-3
Keyboard Country Layout ....................................................................................................2-3
Keyboard Style...................................................................................................................2-11
Keyboard Conversion ........................................................................................................2-12
Control Character Output...................................................................................................2-12
Keyboard Modifiers ............................................................................................................2-12
Chapter 3 - Input/Output Settings
Power Up Beeper.................................................................................................................3-1
Beep on BEL Character .......................................................................................................3-1
Trigger Click.........................................................................................................................3-1
Good Read and Error Indicators ..........................................................................................3-2
Beeper – Good Read .....................................................................................................3-2
Beeper Volume – Good Read........................................................................................3-2
Beeper Pitch – Good Read ............................................................................................3-2
Beeper Pitch – Error.......................................................................................................3-3
Beeper Duration – Good Read.......................................................................................3-3
LED – Good Read..........................................................................................................3-3
LED – Indicator State.....................................................................................................3-4
Number of Beeps – Good Read.....................................................................................3-4
Number of Beeps – Error ...............................................................................................3-4
Beeper Volume Max.......................................................................................................3-4
Good Read Delay...........................................................................................................3-5
User-Specified Good Read Delay..................................................................................3-5
Manual Trigger Modes .........................................................................................................3-5
Table of Contents

ii
Serial Trigger Mode.............................................................................................................3-5
Read Time-Out .............................................................................................................. 3-6
Scan Stand Presentation Mode...........................................................................................3-6
Presentation LED Behavior after Decode......................................................................3-6
Presentation Sensitivity ................................................................................................. 3-6
Presentation Centering .................................................................................................. 3-6
CodeGate®.......................................................................................................................... 3-8
Hands Free Time-Out.......................................................................................................... 3-8
Reread Delay....................................................................................................................... 3-8
User-Specified Reread Delay ........................................................................................ 3-9
2D Reread Delay ...........................................................................................................3-9
Illumination Lights.............................................................................................................. 3-10
Aimer Delay ....................................................................................................................... 3-10
User-Specified Aimer Delay.........................................................................................3-10
Aimer Mode ....................................................................................................................... 3-10
Centering........................................................................................................................... 3-11
Preferred Symbology......................................................................................................... 3-12
High Priority Symbology .............................................................................................. 3-13
Low Priority Symbology ............................................................................................... 3-13
Preferred Symbology Time-out....................................................................................3-13
Preferred Symbology Default.......................................................................................3-13
Output Sequence Overview............................................................................................... 3-13
Output Sequence Editor ..............................................................................................3-13
To Add an Output Sequence .......................................................................................3-14
Other Programming Selections.................................................................................... 3-14
Output Sequence Editor ..............................................................................................3-15
Partial Sequence ......................................................................................................... 3-15
Require Output Sequence ........................................................................................... 3-16
Multiple Symbols ............................................................................................................... 3-16
No Read ............................................................................................................................ 3-16
Video Reverse ...................................................................................................................3-17
Working Orientation........................................................................................................... 3-17
Chapter 4 - Data Editing
Prefix/Suffix Overview ......................................................................................................... 4-1
To Add a Prefix or Suffix:...............................................................................................4-1
To Clear One or All Prefixes or Suffixes........................................................................4-2
To Add a Carriage Return Suffix to All Symbologies.....................................................4-2
Prefix Selections.................................................................................................................. 4-2
Suffix Selections.................................................................................................................. 4-2
Function Code Transmit ......................................................................................................4-3
Intercharacter, Interfunction, and Intermessage Delays......................................................4-3
Intercharacter Delay ...................................................................................................... 4-3
User Specified Intercharacter Delay..............................................................................4-3
Interfunction Delay......................................................................................................... 4-4
Intermessage Delay....................................................................................................... 4-4

iii
Chapter 5 - Data Formatting
Data Format Editor Introduction ..........................................................................................5-1
Add a Data Format ..............................................................................................................5-1
Other Programming Selections...................................................................................... 5-2
Terminal ID Table................................................................................................................ 5-3
Data Format Editor Commands........................................................................................... 5-3
Move Commands........................................................................................................... 5-5
Search Commands ........................................................................................................ 5-6
Miscellaneous Commands............................................................................................. 5-8
Data Formatter ..................................................................................................................5-10
Data Format Non-Match Error Tone............................................................................5-11
Primary/Alternate Data Formats........................................................................................ 5-12
Single Scan Data Format Change...............................................................................5-12
Chapter 6 - Symbologies
All Symbologies................................................................................................................... 6-1
Message Length Description ............................................................................................... 6-1
Codabar............................................................................................................................... 6-2
Codabar Concatenation................................................................................................. 6-3
Code 39 ............................................................................................................................... 6-4
Code 32 Pharmaceutical (PARAF)................................................................................6-5
Full ASCII....................................................................................................................... 6-6
Code 39 Code Page ......................................................................................................6-6
Interleaved 2 of 5................................................................................................................. 6-7
NEC 2 of 5........................................................................................................................... 6-8
Code 93 ............................................................................................................................... 6-9
Code 93 Code Page ....................................................................................................6-10
Straight 2 of 5 Industrial (three-bar start/stop)...................................................................6-11
Straight 2 of 5 IATA (two-bar start/stop)............................................................................ 6-12
Matrix 2 of 5....................................................................................................................... 6-13
Code 11 ............................................................................................................................. 6-14
Code 128........................................................................................................................... 6-15
ISBT 128 Concatenation..............................................................................................6-15
Code 128 Code Page ..................................................................................................6-16
GS1-128 ............................................................................................................................ 6-17
Telepen.............................................................................................................................. 6-18
UPC-A ............................................................................................................................... 6-19
UPC-A/EAN-13
with Extended Coupon Code .......................................................................................... 6-21
Coupon GS1 DataBar Output............................................................................................ 6-21
UPC-E0 ............................................................................................................................. 6-22
UPC-E1 ............................................................................................................................. 6-24
EAN/JAN-13 ......................................................................................................................6-25
Convert UPC-A to EAN-13 .......................................................................................... 6-25
ISBN Translate ............................................................................................................ 6-27
EAN/JAN-8 ........................................................................................................................ 6-28
MSI .................................................................................................................................... 6-30

iv
GS1 DataBar Omnidirectional ........................................................................................... 6-32
GS1 DataBar Limited......................................................................................................... 6-32
GS1 DataBar Expanded .................................................................................................... 6-33
Trioptic Code ..................................................................................................................... 6-33
Codablock A ...................................................................................................................... 6-34
Codablock F ...................................................................................................................... 6-35
PDF417 ............................................................................................................................. 6-36
MacroPDF417 ................................................................................................................... 6-36
MicroPDF417.....................................................................................................................6-37
GS1 Composite Codes...................................................................................................... 6-37
UPC/EAN Version........................................................................................................ 6-38
GS1 Emulation .................................................................................................................. 6-38
TCIF Linked Code 39 (TLC39) .......................................................................................... 6-39
QR Code............................................................................................................................ 6-39
QR Code Page ............................................................................................................6-40
Data Matrix ........................................................................................................................ 6-41
Data Matrix Code Page ...............................................................................................6-41
MaxiCode .......................................................................................................................... 6-42
Aztec Code ........................................................................................................................ 6-43
Aztec Code Page......................................................................................................... 6-43
Chinese Sensible (Han Xin) Code.....................................................................................6-44
Postal Codes - 2D .............................................................................................................6-45
Single 2D Postal Codes:..............................................................................................6-45
Combination 2D Postal Codes:.................................................................................... 6-46
Postal Codes - Linear........................................................................................................ 6-49
China Post (Hong Kong 2 of 5)....................................................................................6-49
Korea Post ................................................................................................................... 6-50
Chapter 7 - Interface Keys
Keyboard Function Relationships........................................................................................7-1
Supported Interface Keys .................................................................................................... 7-3
Chapter 8 - Utilities
To Add a Test Code I.D. Prefix to All Symbologies.............................................................8-1
Show Decoder Revision ...................................................................................................... 8-1
Show Scan Driver Revision .................................................................................................8-1
Show Software Revision...................................................................................................... 8-1
Show Data Format............................................................................................................... 8-1
Test Menu............................................................................................................................ 8-2
TotalFreedom ...................................................................................................................... 8-2
Application Plug-Ins (Apps) .................................................................................................8-2
EZConfig-Scanning Introduction.......................................................................................... 8-3
Installing EZConfig-Scanning from the Web.................................................................. 8-3
Resetting the Defaults ......................................................................................................... 8-4
Chapter 9 - Serial Programming Commands
Conventions......................................................................................................................... 9-1

v
Menu Command Syntax ...................................................................................................... 9-1
Query Commands ............................................................................................................... 9-1
Responses..................................................................................................................... 9-2
Trigger Commands.............................................................................................................. 9-3
Resetting the Custom Defaults............................................................................................ 9-3
Menu Commands ................................................................................................................ 9-4
Chapter 10 - Product Specifications
Depth of Field Charts.........................................................................................................10-2
Typical Performance.................................................................................................... 10-2
Guaranteed Performance ............................................................................................10-2
Standard Connector Pinout ...............................................................................................10-4
USB Type A Connector ...............................................................................................10-4
USB Micro Type B Connector......................................................................................10-4
Chapter 11 - Maintenance
Repairs .............................................................................................................................. 11-1
Maintenance ...................................................................................................................... 11-1
Cleaning the Scanner .................................................................................................. 11-1
Inspecting Cords and Connectors ............................................................................... 11-1
Replacing Cables in Corded Scanners.............................................................................. 11-1
Replacing an Interface Cable ...................................................................................... 11-1
Troubleshooting a Scanner ............................................................................................... 11-1
Chapter 12 - Customer Support
Technical Assistance......................................................................................................... 12-1
Product Service and Repair............................................................................................... 12-1
Appendix A - Reference Charts
Symbology Charts ...............................................................................................................A-1
Linear Symbologies .......................................................................................................A-1
2D Symbologies.............................................................................................................A-3
Postal Symbologies .......................................................................................................A-3
ASCII Conversion Chart (Code Page 1252)........................................................................A-3
Lower ASCII Reference Table.............................................................................................A-4
ISO 2022/ISO 646 Character Replacements ......................................................................A-8
Unicode Key Maps ............................................................................................................A-10

vi

1 - 1
1
Getting Started
About This Manual
This Bar Code Guide provides installation and programming instructions for the 4850dr document reader. Product specifica-
tions, dimensions, warranty, and customer support information are also included.
Honeywell document readers are factory programmed for the most common terminal and communications settings. If you need
to change these settings, programming is accomplished by scanning the bar codes in this guide.
An asterisk (*) next to an option indicates the default setting.
Unpacking Your Device
After you open the shipping carton containing the product, take the following steps:
• Check for damage during shipment. Report damage immediately to the carrier who delivered the carton.
• Make sure the items in the carton match your order.
• Save the shipping container for later storage or shipping.
The packaging for this device is as eco-friendly as we could make it. Please recycle the packaging.
Document Reader Models
The chart below lists the interfaces that can be used with your 4850DR document reader:
Connecting the Document Reader with USB
A document reader can be connected to the USB port of a computer.
1. Connect the appropriate interface cable to the document reader first, then to the computer.
2. The document reader beeps.
3. Verify the document reader operation by scanning a bar code from the Sample Symbols in the back of this manual.
4. The unit defaults to a USB Serial. Refer to page 2-1 for other USB terminal settings.
For additional USB programming and technical information, refer to Honeywell “USB Application Note,” available at
www.honeywell.com/aidc.
Interface
USB keyboard
USB HID
USB retail (IBM SurePOS)
USB COM port emulation

1 - 2
Aligning the Document Reader Tray
Proper cable placement is important for accurate alignment of the device. Place the cable in the wire channel if the imager will
remain in the base most of the time. If you plan to frequently lift out the imager to scan items, then set the cable in the location
where it will rest while the imager is in the stand.
Note: The 4850dr will not capture any images until it has been properly aligned using the following procedure.
1. Loosen the screw in the base tray with a coin.
2. Place the alignment page on the tray. Align the upper left corner of the alignment page to the upper left corner of the tray.
3. Make sure the serial number on the alignment page matches the serial number on your document reader.
4. Press the button on the imager to display the illuminated aimer crosshairs. You will hear a single beep that indicates you are
using the correct page.
(If you hear an error razz and the aimer turns off, then you have the wrong alignment page for your document reader.)
5. Move the tray until the illuminated aimer crosshairs line up with the printed crosshairs on the alignment page. (Be sure to
wait until the crosshairs go off before removing power or attempting to capture an image.)
6. Remove the alignment page and tighten the screw. Save the alignment page in the event that the tray needs to be realigned
in the future.
Note: If you need to print a new copy of the alignment page, make sure to print the page in landscape mode.
Reading Techniques
The document reader has a view finder that projects a bright aimer that corresponds to the document reader’s horizontal field of
view. The bar code should be centered under the aiming crosshairs, but can be positioned in any direction for a good read.
The aimer is smaller when the bar code is closer to the document reader and larger when it is farther away. Symbologies with
smaller bars or elements (mil size) should be read closer to the unit. Symbologies with larger bars or elements (mil size) should
be read farther from the unit. To read single or multiple symbols (on a page or on an object), hold the bar code at an appropri-
ate distance from the document reader, press the trigger, and center the aimer on the symbol. If the code being scanned is
highly reflective (e.g., laminated), it may be necessary to tilt the code +5° to prevent unwanted reflection.
4850dr s/n
Linear bar codes
with aiming pattern 2D Matrix symbol
with aiming pattern

1 - 3
Using the Scanner Out of the Stand
If you remove the scanner from the stand to read bar codes, you should hold it closer to the bar code. The optimum read
range is 9 to 11 inches (22.86 to 27.94cm). Since this is primarily a document imager and works like a camera, you must
hold the scanner steady when scanning bar codes out of the stand.
Resetting the Defaults
If you want the factory default settings restored to your device, scan the Activate Custom Defaults bar code below. This is the
recommended default bar code for most users. It resets the device to the custom default settings. If there are no custom
defaults, it will reset the device to the factory default settings.
Activate Custom Defaults

1 - 4

2 - 1
2
Programming the Interface
Introduction
This chapter describes how to program your document reader for the desired interface.
Programming the Interface - Plug and Play
Plug and Play bar codes provide instant set up for commonly used interfaces.
Note: After you scan one of the codes, power cycle the host terminal to have the interface in effect.
USB IBM SurePos
Scan one of the following “Plug and Play” codes to program the scanner for an IBM SurePos (USB handheld scanner) or IBM
SurePos (USB tabletop scanner) interface.
Note: After scanning one of these codes, you must power cycle the cash register.
Each bar code above also programs the following suffixes for each symbology:
USB PC Keyboard
Scan the following code to program the scanner for a USB PC Keyboard with a CR suffix.
USB HID
Scan the following code to program the scanner for USB HID bar code scanners.
Symbology Suffix Symbology Suffix
EAN 8 0C Code 39 00 0A 0B
EAN 13 16 Interleaved 2 of 5 00 0D 0B
UPC A 0D Code 128 00 18 0B
UPC E 0A Code 39 00 0A 0B
USB IBM SurePos
(USB Handheld Scanner)
Interface
USB IBM SurePos
(USB Tabletop Scanner)
Interface
USBKeyboard(PC)
USB HID Bar Code Scanner

2 - 2
USB Serial
Scan the following code to program the scanner to emulate a regular RS232-based COM Port. If you are using a Microsoft®
Windows® PC, you will need to download a driver from the Honeywell website (www.honeywellaidc.com). The driver will use
the next available COM Port number. Apple® Macintosh computers recognize the scanner as a USB CDC class device and
automatically use a class driver.
Note: No extra configuration (e.g., baud rate) is necessary.
CTS/RTS Emulation
ACK/NAK Mode
Remote MasterMind™ for USB
When using a USB interface, you may wish to configure your scanner to communicate with Remote MasterMind Scanner Man-
agement Software (ReM). Scan the ReM On bar code to communicate with ReM. To disable this capability, scan ReM Off.
Default = ReM On.
USB Serial
CTS/RTS Emulation On
* CTS/RTS Emulation Off
ACK/NAK Mode On
* ACK/NAK Mode Off
ReM Off
* ReM On

2 - 3
Wincor Nixdorf Beetle™ Terminal Default Settings
Scan the following Plug and Play code to program the scanner for a Wincor Nixdorf Beetle terminal. The following prefixes are
programmed for each symbology:
Keyboard Country Layout
Scan the appropriate country code below to program the keyboard layout for your country or language. As a general rule, the
following characters are supported, but need special care for countries other than the United States:
@ | $ # { } [ ] = / ‘ \ < > ~
Symbology Prefix Symbology Prefix
Code 128 K EAN-13 A
Code 93 L GS1-128 P
Codabar N Interleaved 2 of 5 I
UPC-A A0 Plessey O
UPC-E C Straight 2 of 5 IATA H
EAN-8 B All other bar codes M
Keyboard Countries
Wincor Nixdorf Beetle Settings
* United States
Albania
Azeri (Cyrillic)
Azeri (Latin)
Belarus
Belgium

2 - 4
Keyboard Countries (Continued)
Bosnia
Brazil
Brazil (MS)
Bulgaria (Cyrillic)
Bulgaria (Latin)
Canada (French legacy)
Canada (French)
Canada (Multilingual)
Croatia
Czech
Czech (Programmers)

2 - 5
Keyboard Countries (Continued)
Czech (QWERTY)
Czech (QWERTZ)
Denmark
Dutch (Netherlands)
Estonia
Faroese
Finland
France
Gaelic
Germany
Greek

2 - 6
Keyboard Countries (Continued)
Greek (220 Latin)
Greek (220)
Greek (319 Latin)
Greek (319)
Greek (Latin)
Greek (MS)
Greek (Polytonic)
Hebrew
Hungarian (101 key)
Hungary
Iceland

2 - 7
Keyboard Countries (Continued)
Irish
Italian (142)
Italy
Japan ASCII
Kazakh
Kyrgyz (Cyrillic)
Latin America
Latvia
Latvia (QWERTY)
Lithuania
Lithuania (IBM)
