Honeywell 3800gPDF - Hand Held Decoding Linear Imager User manual

The 3800gPDF is built specifically to serve applications that require
high-performance linear barcode scanning as well as an economical
solution for occasional PDF417 barcode reading.
Based on the proven 3800g platform, the 3800gPDF features
an ideal balance of performance, durability, ergonomics, and
connectivity that make it a reliable and user-friendly solution for
a broad range of light industrial environments including retail,
manufacturing, government, healthcare, and distribution.
Powered by Adaptus®Imaging Technology 5.0, the 3800gPDF
delivers high-performance linear barcode scanning across a range
of barcodes – including those that are damaged or poorly printed.
Combined with intuitive PDF417 reading functionality, the 3800gPDF
offers versatile, yet economical scanning capability.
Compact, ergonomic design and class-leading durability, coupled
with aggressive reading performance, makes the new 3800gPDF the
ideal choice for customers who appreciate a reliable, versatile, and
economical solution to meet their scanning needs.
3800gPDF
PDF Decoding Linear Imager
Swipe Action PDF417 Decoding: Fast, accurate, and
economical PDF417 reading.
Bright, Crisp, and Focused Aiming Line: Easy to aim
and scan codes, regardless of lighting conditions or close
barcode proximities.
Performance andVersatility Powered by Adaptus
ImagingTechnology 5.0
270 scans per second and high tolerance-to-hand motion
ensure fast scanning performance.
Working range from .3 inches to 8 inches on medium density
barcodes
Improved ability to read damaged or poorly printed
barcodes.
•
•
•
*
*
*
Modern, Ergonomic Design: Sleek, modern industrial
design results in a smaller, lighter device for increased
operator comfort and productivity.
Durable: Built-to-last with no moving parts to wear out and
backed by a 5-year warranty.
Plug and Play Connectivity: All popular interfaces are
on board. Includes Visual Xpress™ software for ease of
integration.
Future Proof Symbology Support: GTIN compliant, GS1
DataBar capable.
Intuitive User Feedback: Fully programmable options for
application-specific “good read”LED and beeper settings.
•
•
•
•
•
Features

Copyright ©2008 Honeywell International Inc.
Automation and Control Solutions
Honeywell
Imaging and Mobility
700 Visions Drive
PO Box 208
Skaneateles Falls, NY 13153-0208
www.honeywell.com/aidc
3800gPDF Specifications
3800GPDF-DS Rev B 8/08
Performance
Illumination: 617 NM Visible Amber LED
Receiving Device: 3648 element linear imager
Reading Distance: From 0.3 in. (0.8 cm) to 8.0 in.(20.3 cm) on medium density bar codes
ReadingWidth: 5 mil code: 3.0 in. (7.6 cm) from nose, 3.0 in.(7.6 cm) wide
10 mil code: 5.0 in. (12.7 cm) from nose, 4.0 in.(10.2 cm) wide
Resolution: 3 mil. at 1.75 in.(4.4 cm) distance
Skew Angle: +65o
Pitch Angle: +65o
HorizontalVelocity: 10 in. (25.4 cm) per second on medium density code at nominal focus
Minimum Symbol Contrast: 37%
Scan Rate: Up to 270 scans per second
Decode Rate: 270 decodes per second
Mechanical/Electrical
Length: 4.4 in. (11.2 cm)
Height: 5.9 in. (15.0 cm)
Width: 3.1 in. (7.9 cm)
Weight: 5.6 oz. (158.8 g)
Housing: UL 94V0 grade
Power Requirements: 3800GPDF04E: 4.5 - 5.5Vdc at scanner
Current Draw (Maximum): Input
5 V Scanning 450mA Idle 86mA
Power Supply
Noise Rejection: Maximum 100mV peak to peak, 10 to 100 kHz
Environmental
OperatingTemperature: +32oF to +122oF (0oC to +50oC)
StorageTemperature: -40oF to 140oF (-40oC to +60oC)
Humidity: 0 to 95%, non-condensing
Mechanical Shock: Operational after 50 drops from 5 ft.(1.5 m) to concrete
Ambient Illumination: 0 - 70,000 lux
ESD Protection: Functional after 15kV discharge
Vibration: Withstands 5G peak from 22 to 300 Hz
Agency: International: CB scheme to IEC60950-1 & IEC60825-1 Class 1 LED. USA: FCC Part 15 subpart B Class B. UL listed to
60950-1. Canada: ICES-003 Class B. cUL listed to CSA C22.2 No.60950-1-03. Europe: CE 2004/108/EC EMC Directive to
EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3. 2006/95/EC Low Voltage Directive. GS Mark: GS marked for I.T.E.
safety. Mexico: NOM-NYCE. Korea: MIC Class A. Australia/NZ: C-Tick mark.
MTBF: per MIL-HDBK-217F Ground Benign exceeds 100,000 hours
Symbologies: Codabar, Code 3 of 9 including PARAF, Interleaved 2 of 5, Straight 2 of 5 Industrial, Matrix 2 of 5, Code 11, Code 93, Code 128,
UPC, EAN/JAN, China Postal Code, GS1 DataBar, PDF417, MicroPDF417. 2005 Sunrise/GTIN compliant, and ISBT 128 Concat-
enation (requires a paid license).
Interfaces: 3800GPDFX4E: All popular PCs and terminals via keyboard wedge, keyboard replacement/direct connect, USB, and TTL level
RS-232
Warranty: Five year factory warranty.
Typical Performance*
NarrowWidth Depth of Field
5.0 mil (Code 39) 0.8 - 5.5 in. (2.0 - 14.0 cm)
10 mil (Code 39) 0.2 - 8.5 in. (0.6 - 21.6 cm)
13 mil (100% UPC) 0.6 - 8.2 in. (1.5 - 20.8 cm)
6.7 mil (PDF417) 1.5 - 2.6 in. (3.3 - 6.6 cm)
20 mil (PDF417) 1.8 - 2.7 in. (4.4 - 6.9 cm)
*may be impacted by barcode quality and environmental
conditions
