Q314, Q324, Q327, Q350, Q377, Q379, Q380
and Q382 Pilot Burners
APPLICATION
These pilot burners provide main burner ignition for natural
and LP gas-fired equipment. Used with a 30 mV thermopile
and/or thermocouple (depending on model) to provide
automatic pilot safety control.
FEATURES
•Q324 and Q327 are primary aerated, spud orifice pilot
burners.
•Q314 ,Q350, Q377 and Q379 are non-primary aerated,
insert orifice pilot burners. Q382 is primary aerated
with an insert orifice.
•Variety of mounting brackets available.
•Variety of tip styles to provide desired flame pattern.
•Interchangeable, color-coded orifice and inlet fittings
can be ordered to convert between natural and LP gas.
•Q350, Q377, and Q380 are energy efficient pilot
burners.
• Q380 is for horizontal mounting only.
•Q377, Q379 and Q382 design makes them ideal for use
with any millivolt standing pilot gas valves in fireplace
and space heating applications.
•Electrode assembly available for Piezo ignition on
Q377, Q379 and Q382.
Contents
Application........................................................................... 1
Features .............................................................................. 1
Ordering Information ........................................................... 2
Specifications ...................................................................... 2
Installation ........................................................................... 16
Startup and Checkout ......................................................... 20
Service ................................................................................ 21
Q324 Q350
Q314
Q327
Q380
Q377
Q379
Q382

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 2
ORDERING INFORMATION
When purchasing replacement and modernization products from your TRADELINE® wholesaler or distributor, refer to the
TRADELINE® Catalog or price sheets for complete ordering number, or specify—
1. Device number.
2. Tip style.
3. Mounting bracket style (number or letter)
4. Type of gas.
5. Target wingspan (Q327 and Q382 only).
6. Raised or standard target (Q314 and Q350 only).
7. Accessories, if required.
If you have additional questions, need further information, or would like to comment on our products or services, please write or
phone:
1. Your local Home and Building Control Sales Office (check white pages of your phone directory).
2. Home and Building Control Customer Logistics
Honeywell Inc., 1885 Douglas Drive North
Minneapolis, Minnesota 55422-4386
In Canada—Honeywell Limited/Honeywell Limitée, 35 Dynamic Drive, Scarborough, Ontario M1V 4Z9.
International Sales and Service Offices in all principal cities of the world. Manufacturing in Australia, Canada, Finland, France,
Germany, Japan, Mexico, Netherlands, Spain, Taiwan, United Kingdom, U.S.A.
Ordering Example:
Device Tip Style Mounting Bracket Style* Type of Gas
Q350A F 66R Natural
*"R" specifies a raised target.
Use this example to order a Q350AF66R Natural Pilot
Burner.
SPECIFICATIONS
IMPORTANT
The specifications given in this publication do not
include normal manufacturing tolerances. Therefore,
this unit may not exactly match the listed
specifications. Also, this product is tested and
calibrated under closely controlled conditions, and
some minor differences in performance can be
expected if those conditions are changed.
Tradeline® Models:
TRADELINE models are selected and packaged for ease of
handling, ease of stocking, and maximum replacement value.
TRADELINE model specifications are the same as those of
standard models, except as noted.
Tradeline® Models Available:
Q314A Pilot Burner
Q327A Pilot Burner
Fig. 1. Tradeline® pilot burner (Q314A shown).
Q314A Pilot Burner with natural and LP gas orifices, 1/4 in.
compression fitting, “F”, “K”, or “L” tip style, “B” mounting
bracket, and “A” mounting bracket adapter with screws.
Q327A Pilot Burner with natural and LP gas orifices and
1/4 in. compression fitting, and “B” mounting bracket
with screws.
Models:
Refer to Table 1.
Target and Tip Styles:
Refer to Fig. 2.
Mounting Brackets and Dimensions:
Refer to Table 2.

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3
3
Table 1. Model Specifications.
Table 2. Mounting Brackets and Dimensions.
Model Mounting Brackets Refer To Figure:
Q314 A, B, E and K Fig. 3
No. 11, No. 34, No. 48 and No. 64 Fig. 4
Q324 B and D Fig. 5
No. 3 and No. 5 Fig. 6
Q327 A, B, D and K Fig. 7
No. 1 and No. 2 Fig. 8
Q350 A, B, H and K Fig. 9
P, No. 35, No. 54 and No. 66 Fig. 10
No. 75 Fig. 11
Q377 A, B Fig. 12
Q379 A, B Fig. 13
Q380 No. 1 Fig. 14
Q382 A, B Fig. 15
“A” Mounting Bracket Adapter Dimensions:
See Fig. 16.
Electrode Assembly for Ignition (Q377, Q379, Q382 only):
18 in. (457 mm) leadwire with 0.093 receptacle for Piezo
igniter or 18 in. (457 mm) leadwire with 1/4 in. quick-connect.
Type of Gas:
Models available for natural and LP gas.
Btuh Flow (nominal for natural gas):
Q377: 500.
Q379: 1000.
Q382: 1250.
Maximum Temperature Ratings:
Target tip:
Q314, Q327, Q350, Q380: 1500°F (816°C).
Q324: 1350°F (732°C).
Q377, Q379, Q382: 1575°F (858°C).
Orifice:
Q324: 650°F (343°C).
Q314, Q327, Q350, Q380: 620°F (327°C).
Q377, Q379, Q382: 800°F (427°C).
Mounting Bracket: 1000°F (538°C).
Recommended Thermocouples:
Refer to Table 1.
Recommended Thermopiles:
Refer to Table 1.
Approvals:
International Approval Services: File no. L2025001.
Accessories (specify when ordering):
386449 Replacement 1/4 inch OD Compression Fitting.
390711 1/8 inch Bleed Tube Fitting.
Lint Screen (Q324).
Replacement Orifices:
See Table 3.
Table 3. Replacement Orifices.
Pilot Burner Type of Gas Orifice Stamping Orifice Part Number
Q377 Natural BBR12 390686-25
Q377 LP BBR9 390686-15
Q379 Natural BCR18 390686-4
Q379 LP BBR12 390686-25
Q382 Natural BCR20 390686-5
Q382 LP BCR13 390686-34
Model Primary Aerated Type of Orifice Pilot Tip Type Recommended Thermocouple
a
Recommended
Thermopile
a
Q314A No Insert Target Q309, Q340, Q390 Q313
Q324A Yes Spud Multiport Q309A Q313
Q327A Yes Spud Target Q309A Q313
Q350A No Insert Target Q309, Q340, Q390 None
Q377A,B Yes Insert Target None Q313
Q379A,B Yes Insert Target None Q313
Q380A Yes Insert Target Q309, Q340, Q390 None
Q382A,B Yes Insert Target Q335 Q313
a
Specify lead length and model number when ordering.

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 4
Fig. 2. Pilot Burner target and tip styles.
AF K L
MN PR
FKL
Q324
Q314, Q379
Q327
Q350
Q377 Q382
Q380
STRAIGHT 20 DEG. RIGHT 20 DEG. LEFT
STRAIGHT 15 DEG. RIGHT
15 DEG. LEFT
FKL
STRAIGHT 10 DEG. RIGHT
10 DEG. LEFT
THERMOCOUPLE
OR THERMOPILE
MAIN BURNER
IGNITION FLAME
THERMOCOUPLE
OR THERMOPILE
THERMOCOUPLE
THERMOCOUPLE
OR THERMOPILE
MAIN BURNER
IGNITER
FLAME (2)
THERMOCOUPLE
180°
135°
90°90°90°90°
90°90°
90°90°
MAIN BURNER
IGNITER FLAME
LF K
10°
10°
M11463
ELECTRODE
THERMOPILE
THERMOCOUPLE
MAIN BURNER
IGNITER FLAME

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3
5
Fig. 3. Q314 A,B,E and K mounting brackets and dimensions.
M3304
Inches
Milli-
meters
7/8
29/32
15/16
31/32
1
2
22.2
23.0
23.8
24.6
25.4
50.8
19/32
5/8
21/32
11/16
23/32
3/4
25/32
13/16
27/32
15.1
15.9
16.7
17.5
18.3
19.1
19.8
20.6
21.4
Inches
Milli-
metersInches
5/16
11/32
3/8
13/32
7/16
15/32
1/2
17/32
9/16
7.9
8.7
9.5
10.3
11.1
11.9
12.7
13.5
14.3
Milli-
meters
1/32
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
0.8
1.6
2.4
3.2
4.0
4.8
5.6
6.4
7.1
Inches
Milli-
meters
1
2
3
4
BLEED TUBE CLIP (OPTIONAL).
HOLE FOR BLEED TUBE.
MOUNTING HOLE (2), TAPPED FOR 10-32 NC SCREW.
MOUNTING HOLE (2), 11/64 IN. DIA (4 mm) (CLEARS NO. 8 SCREW).
A
2
11
B
EK
3
4
3
2
2
1
2
1
11
16
2
4
1
1
3
15/32 1-1/2
3/4
1-3/32
5/8
7/8
1/2 5/8
1-5/32
11/16
1-1/2
13/32
3/4
13/16
13/32
3/8
25/32
1/4
1/4
3/8
1-1/2
13/16
11/16
7/8
25/32
13/32
1/2
15/32
1-5/32
11/16
1-3/16
15/32
1-5/32
1/2

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 6
Fig. 4. Q314 No. 11, No. 34, No. 48 and No. 64 mounting brackets and dimensions.
M3305
Inches
Milli-
meters
7/8
29/32
15/16
31/32
1
2
22.2
23.0
23.8
24.6
25.4
50.8
19/32
5/8
21/32
11/16
23/32
3/4
25/32
13/16
27/32
15.1
15.9
16.7
17.5
18.3
19.1
19.8
20.6
21.4
Inches
Milli-
metersInches
5/16
11/32
3/8
13/32
7/16
15/32
1/2
17/32
9/16
7.9
8.7
9.5
10.3
11.1
11.9
12.7
13.5
14.3
Milli-
meters
1/32
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
0.8
1.6
2.4
3.2
4.0
4.8
5.6
6.4
7.1
Inches
Milli-
meters
No.34
No. 11
4
3
2
13
32 3
4
1
2
1
4
1
8
5
3
No. 48
5
9
1
No. 64
7
1
2
3
4
5
6
7
8
7/8 IN. STANDARD, 11/16 IN. RAISED.
7/8 IN. STANDARD, 21/32 IN. RAISED.
HOLE FOR BLEED TUBE.
MOUNTING HOLE (2), TAPPED FOR 10-32 NC SCREW.
MOUNTING HOLE (2), 11/64 IN. DIA (4 mm) (CLEARS NO. 8 SCREW).
MOUNTING HOLE (2), 13/64 IN. DIA (5mm) (CLEARS NO. 10 SCREW).
INLET FITTING HERE. MAY INCREASE OVERALL HEIGHT.
1/4 IN. COMPRESSION FITTING.
1/4
3/8
3/8
3/4
25/32
5/8
1-7/8
25/32
2-1/4
1-3/4 1/4
1/4 1/8
1/2
7/8
1-1/2
13/32
3/4
1-3/32
3/4
3/8
3/8 3/8
1/4
25/32
1-7/16
5/16
5/32
3/8
7/8
3/4
25/32
29/32
1-13/16
11/32
5/8

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3
7
Fig. 5. Q324 B and D mounting brackets and dimensions.
3
576
8
1
2
1-13/32
1/2
1-5/32
3/8
7/16 23/32
27/32 3/8
5/8
D
B
4
576
8
1
2
1-13/32
3/8
3/8
1-5/32
3/8
7/16 23/32
27/32
M1217
5/8
Inches Milli-
meters
7/8
29/32
15/16
31/32
1
2
22.2
23.0
23.8
24.6
25.4
50.8
19/32
5/8
21/32
11/16
23/32
3/4
25/32
13/16
27/32
15.1
15.9
16.7
17.5
18.3
19.1
19.8
20.6
21.4
Inches Milli- metersInches
5/16
11/32
3/8
13/32
7/16
15/32
1/2
17/32
9/16
7.9
8.7
9.5
10.3
11.1
11.9
12.7
13.5
14.3
Milli-
meters
1/32
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
0.8
1.6
2.4
3.2
4.0
4.8
5.6
6.4
7.1
Inches Milli- meters
1
2
3
4
5
6
7
8
LINT SCREEN - OPTIONAL.
1/4 IN. COMPRESSION FITTING.
MOUNTING HOLE (2), TAPPED FOR 10-32 NC SCREW.
MOUNTING HOLE (2), TAPPED FOR 5-40 NC SCREW).
MOUNTING HOLE (4), 11/64 IN. DIA (5.2 mm)
(CLEARS NO. 8 SCREW).
MOUNTING HOLE (2), 5/32 IN. DIA (4.0 mm).
MOUNTING HOLE, 1/4 IN. DIA (6.4 mm).
THERMOCOUPLE/THERMOPILE TAP, 7/16 - 27.

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 8
Fig. 6. Q324 No. 3 and No. 5 mounting brackets and dimensions.
No.5
No.3
573
8
1
2
3/8
1-5/32
3/8
5/16 23/32
27/32
M1218
3
573
8
1
2
1-13/32
3/8
3/8
1-5/32
5/16
7/16 23/32
27/32
5/8
Inches Milli-
meters
7/8
29/32
15/16
31/32
1
2
22.2
23.0
23.8
24.6
25.4
50.8
19/32
5/8
21/32
11/16
23/32
3/4
25/32
13/16
27/32
15.1
15.9
16.7
17.5
18.3
19.1
19.8
20.6
21.4
Inches Milli- metersInches
5/16
11/32
3/8
13/32
7/16
15/32
1/2
17/32
9/16
7.9
8.7
9.5
10.3
11.1
11.9
12.7
13.5
14.3
Milli-
meters
1/32
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
0.8
1.6
2.4
3.2
4.0
4.8
5.6
6.4
7.1
Inches Milli- meters
1
2
3
4
5
6
7
8
LINT SCREEN - OPTIONAL.
1/4 IN. COMPRESSION FITTING.
MOUNTING HOLE (2), TAPPED FOR 10-32 NC SCREW.
MOUNTING HOLE (2), TAPPED FOR 5-40 NC SCREW.
MOUNTING HOLE (4), 11/64 IN. DIA (5.2 mm)
(CLEARS NO. 8 SCREW).
MOUNTING HOLE (2), 5/32 IN. DIA (4.0 mm).
MOUNTING HOLE, 1/4 IN. DIA (6.4 mm).
THERMOCOUPLE/THERMOPILE TAP, 7/16 - 27.

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3
9
Fig. 7. Q327 A,B,D, and K mounting brackets and dimensions.
Inches Milli-
meters
7/8
29/32
15/16
31/32
1
2
22.2
23.0
23.8
24.6
25.4
50.8
19/32
5/8
21/32
11/16
23/32
3/4
25/32
13/16
27/32
15.1
15.9
16.7
17.5
18.3
19.1
19.8
20.6
21.4
Inches Milli- metersInches
5/16
11/32
3/8
13/32
7/16
15/32
1/2
17/32
9/16
7.9
8.7
9.5
10.3
11.1
11.9
12.7
13.5
14.3
Milli-
meters
1/32
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
0.8
1.6
2.4
3.2
4.0
4.8
5.6
6.4
7.1
Inches Milli- meters
K
5
1
2
3
4
5
6
SPECIFY WINGSPAN 1, 1 1/4, 1 1/2, 1 3/4, 2, 2 1/4, 2 1/2,
2 3/4, OR 3 IN.
1 1/4 TO 1 3/4 DEPENDING ON WINGSPAN DIMENSION.
HOLE FOR BLEED TUBE.
MOUNTING HOLE (2), TAPPED FOR 10-32 NC SCREW.
MOUNTING HOLE (2), TAPPED FOR 5-40 NC SCREW.
MOUNTING HOLE (2), 11/64 IN. DIA (CLEARS NO. 8 SCREW).
M1256A
2
1
3
1
2
4
B
A
2
1
1
5
D
2
1
3/4
15/32 1-1/2
5/8
5/8
7/16
1/2
1-1/2
11/32 11/16
19/32
3/8
13/32 25/32
1-1/2
11/32 11/16
1/2
1/2
5/8 11/16
25/3213/32
1-9/16
11/32 11/16
1/2
1/2
11/32
25/32

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 10
Fig. 8. Q327 No. 1 and No. 2 mounting brackets and dimensions.
Inches
Milli-
meters
7/8
29/32
15/16
31/32
1
2
22.2
23.0
23.8
24.6
25.4
50.8
19/32
5/8
21/32
11/16
23/32
3/4
25/32
13/16
27/32
15.1
15.9
16.7
17.5
18.3
19.1
19.8
20.6
21.4
Inches
Milli-
metersInches
5/16
11/32
3/8
13/32
7/16
15/32
1/2
17/32
9/16
7.9
8.7
9.5
10.3
11.1
11.9
12.7
13.5
14.3
Milli-
meters
1/32
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
0.8
1.6
2.4
3.2
4.0
4.8
5.6
6.4
7.1
Inches
Milli-
meters1
2
3
4
5
6
SPECIFY WINGSPAN 1, 1 1/4, 1 1/2, 1 3/4, 2, 2 1/4, 2 1/2,
2 3/4, OR 3 IN.
1 1/4 TO 1 3/4 DEPENDING ON WINGSPAN DIMENSION.
HOLE FOR BLEED TUBE.
MOUNTING HOLE (2), TAPPED FOR 10-32 NC SCREW.
MOUNTING HOLE (2), TAPPED FOR 5-40 NC SCREW.
MOUNTING HOLE (2), 11/64 IN. DIA (CLEARS NO. 8 SCREW).
No. 1
M1257A
2
1
1
4
2
No. 2
3/4 7/16
1/4
3/8
3/8
25/32
1-1/2
25/32

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3
11
Fig. 9. Q350 A,B,H, and K mounting brackets and dimensions.
M1250A
3
Inches
Milli-
meters
7/8
29/32
15/16
31/32
1
2
22.2
23.0
23.8
24.6
25.4
50.8
19/32
5/8
21/32
11/16
23/32
3/4
25/32
13/16
27/32
15.1
15.9
16.7
17.5
18.3
19.1
19.8
20.6
21.4
Inches
Milli-
metersInches
5/16
11/32
3/8
13/32
7/16
15/32
1/2
17/32
9/16
7.9
8.7
9.5
10.3
11.1
11.9
12.7
13.5
14.3
Milli-
meters
1/32
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
0.8
1.6
2.4
3.2
4.0
4.8
5.6
6.4
7.1
Inches
Milli-
meters
1
2
3
4
5
6
7
8
9
1 IN. STANDARD, 1-3/16 IN. RAISED.
25/32 IN (20 mm) STANDARD, 17/32 IN. (14 mm) RAISED.
HOLE FOR BLEED TUBE.
MOUNTING HOLE (2), TAPPED FOR 10-32 NC SCREW.
MOUNTING HOLE (2), 11/64 IN. DIA (4 mm) (CLEARS NO. 8 SCREW).
MOUNTING HOLE (2), 13/64 IN. DIA (5 mm) (CLEARS NO. 10 SCREW).
1/4 IN. COMPRESSION FITTING.
7/8 IN. STANDARD, 11/16 IN. RAISED.
7/8 IN. STANDARD, 21/32 IN. RAISED.
A
3
1
5
2
7
3
1
5
2
7
1
2
7
3
1
2
7
B
HK
44
4
4
11/32
11/16
1/2
1/2
1-1/8
13/32 25/32
1-9/16
7/16 1-1/2
3/8
3/4
1/4
5/8
1-3/32
21/32
1-1/16
25/32
3/8
1/4
3/8
3/8
3/4
1-1/2 1/2
1/4
3/8
25/32
1-1/16
21/32
3/16
5/16
5/8 1-3/32
11/32
11/16
1-3/16
1/2
1/2
7/16 25/32

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 12
Fig. 10. Q350 P, No. 35, No. 54 and No. 66 mounting brackets and dimensions.
M1251A
3
8
4
No. 35
9
7
3
1
6
5
2
No. 54
7
Inches
Milli-
meters
7/8
29/32
15/16
31/32
1
2
22.2
23.0
23.8
24.6
25.4
50.8
19/32
5/8
21/32
11/16
23/32
3/4
25/32
13/16
27/32
15.1
15.9
16.7
17.5
18.3
19.1
19.8
20.6
21.4
Inches
Milli-
metersInches
5/16
11/32
3/8
13/32
7/16
15/32
1/2
17/32
9/16
7.9
8.7
9.5
10.3
11.1
11.9
12.7
13.5
14.3
Milli-
meters
1/32
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
0.8
1.6
2.4
3.2
4.0
4.8
5.6
6.4
7.1
Inches
Milli-
meters
1
2
3
4
5
6
7
8
9
1 IN. STANDARD, 1-3/16 IN. RAISED.
25/32 IN (20 mm) STANDARD, 17/32 IN. (14 mm) RAISED.
HOLE FOR BLEED TUBE.
MOUNTING HOLE (2), TAPPED FOR 10-32 NC SCREW.
MOUNTING HOLE (2), 11/64 IN. DIA (4 mm) (CLEARS NO. 8 SCREW).
MOUNTING HOLE (2), 13/64 IN. DIA (5 mm) (CLEARS NO. 10 SCREW).
1/4 IN. COMPRESSION FITTING.
7/8 IN. STANDARD, 11/16 IN. RAISED.
7/8 IN. STANDARD, 21/32 IN. RAISED.
6
1
2
No. 66
7
P
5/16
3/8
1-1/2
7/16
7/16
3/4
1-15/16
5/8
25/32
3/8
1/4
1-1/16
9/32
5/8
1-1/8
13/32
1/4
3/8
3/8 3/8
25/32
1-1/8
2-3/16
1-3/4 7/32
1/4
3/16
7/16
7/8
3/4 25/32

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3
13
Fig. 11. Q350 No. 75 mounting brackets and dimensions.
M1252A
4
No. 75
7
Inches
Milli-
meters
7/8
29/32
15/16
31/32
1
2
22.2
23.0
23.8
24.6
25.4
50.8
19/32
5/8
21/32
11/16
23/32
3/4
25/32
13/16
27/32
15.1
15.9
16.7
17.5
18.3
19.1
19.8
20.6
21.4
Inches
Milli-
metersInches
5/16
11/32
3/8
13/32
7/16
15/32
1/2
17/32
9/16
7.9
8.7
9.5
10.3
11.1
11.9
12.7
13.5
14.3
Milli-
meters
1/32
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
0.8
1.6
2.4
3.2
4.0
4.8
5.6
6.4
7.1
Inches
Milli-
meters
1
2
3
4
5
6
7
8
9
1 IN. STANDARD, 1-3/16 IN. RAISED.
25/32 IN (20 mm) STANDARD, 17/32 IN. (14 mm) RAISED.
HOLE FOR BLEED TUBE.
MOUNTING HOLE (2), TAPPED FOR 10-32 NC SCREW.
MOUNTING HOLE (2), 11/64 IN. DIA (4 mm) (CLEARS NO. 8 SCREW).
MOUNTING HOLE (2), 13/64 IN. DIA (5 mm) (CLEARS NO. 10 SCREW).
1/4 IN. COMPRESSION FITTING.
7/8 IN. STANDARD, 11/16 IN. RAISED.
7/8 IN. STANDARD, 21/32 IN. RAISED.
2-3/16
1-3/4 7/32
7/8
7/16
1-13/16
13/16
25/32
3/4

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 14
Fig. 12. Q377 mounting brackets and dimensions in in. (mm).
1-11/16 (43)
1/2
(13)
3/4 (19)
1-1/2
(38)
2-5/16
(59)
NO. 10-32 STANDARD
TAPPED HOLES
M11146
1-3/16
(30)
2-5/16
(59)
3/4 (19)
1-7/8 (47)
2-1/4 (57)
AB
M11136
1-11/16 (43)
1/2
(13)
3/4 (19)
1-1/2
(38)
2-5/16
(59)
NO. 10-32 STANDARD
TAPPED HOLES
1-3/16
(30)
2-5/16
(59)
3/4 (19)
1-7/8 (47)
2-1/4 (57)
AB
Fig. 13. Q379 mounting brackets and dimensions in in. (mm).

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3
15
Fig. 14. Q380 No. 1 mounting bracket and dimensions.
1-17/32
(39)
1/4 IN.
COMPRESSION
FITTING
MOUNTING HOLES (2)
11/64 IN. DIA (4)
(CLEARS NO. 8 SCREW)
1-5/16 (33)
13/32
(10)
1/4 (6)
7/16
(11)
1-11/16
(43)
1-11/16 (43)
15/32 (12)
25/32 (20)
13/16
(21)
M1253

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 16
1-11/16 (43)
1/2
(13)
1-1/2
(38)
1-1/2
(38)
2-5/16
(59)
1-5/16
(33)
NO. 10-32
STANDARD
TAPPED
HOLES
M11170A
1
(25)
1-3/16
(30)
2-5/8 (67)
1-11/16 (43)
3-1/8 (79)
1-1/2
(38)
2-5/16
(59)
1/2 (13)
1-5/16 (33)
NO. 10-32
STANDARD
TAPPED HOLES
5/8
(16)
7/8 (22)
AB
Fig. 15. Q382 mounting brackets and dimensions in in. (mm).
Fig. 16. Tradeline Q314 “A” mounting bracket adapter dimensions.
INSTALLATION
When Installing this Product…
1. Read these instructions carefully. Failure to follow
instructions can damage product or cause a hazardous
condition.
2. Check ratings given in instructions and on product to
make sure product is suitable for your application.
3. Make sure installer is a trained, experienced service
technician.
4. After completing installation, use these instructions to
check out product operation.
5/16 (8)
1/2
(13)
5/16
(8)
5/32 (4)
13/16
(21)
1-1/8
(29)
1/4 (6)
5/8 (16)
5/8 (16)
3/8
(10)
MOUNTING HOLES (2)
3/16 IN. DIA (5)
MOUNTING HOLES (2)
TAPPED FOR 10-32
NC SCREWS
M1270B
3/16
(5)

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3
17
WARNING
FIRE OR EXPLOSION HAZARD
CAN CAUSE PROPERTY DAMAGE, SEVERE
INJURY, OR DEATH
Follow these warnings exactly.
1. Disconnect power supply before wiring to prevent
electrical shock or equipment damage.
2. To avoid dangerous accumulation of fuel gas, turn
off gas supply at appliance service valve before
starting Installation and perform Gas Leak Test
after completion of Installation.
3. Do not bend pilot tubing at the gas control or pilot
burner after compression nut has been tightened.
Gas leakage at the connection may result.
Follow appliance manufacturer’s instructions if available;
otherwise, use instructions provided below.
Location
1. Position the pilot burner for easy access, observation,
and lighting. In replacement applications, replace the
pilot burner with an identical unit and position the new
pilot burner in the same location and orientation as the
original pilot burner.
2. Mount the pilot burner on the main burner. Mounting
surfaces other than the main burner can shift, bend, or
warp as furnace expands and contracts while operating.
See Fig. 17.
3. Mount the pilot burner so the ignition flame remains
properly positioned with respect to the main burner
flame. See Fig. 18.
4. Supply the pilot flame with ample air free of combustion
products.
5. Do not impinge the pilot flame on adjacent parts. Do not
impinge the main burner flame on the pilot burner.
6. Do not expose the pilot flame to falling scale that could
impair the ignition of the main burner.
7. Do not expose the pilot burner to main burner rollout
while igniting or extinguishing.
8. Do not expose the pilot flame to drafts that push or pull
the pilot flame away from the thermocouple or
thermopile.
M11464
PILOT BURNER/GENERATOR
MUST BE RIGIDLY POSITIONED
RELATIVE TO MAIN BURNER.
PILOT BURNER/GENERATOR MUST BE RIGIDLY
POSITIONED RELATIVE TO MAIN BURNER.
Q377
Q382
Fig. 17. Mount pilot burner on main burner
(Q377 and Q382 shown).
NOTE: Q380 is for horizontal mounting only. Mounting
bracket must remain vertical.

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 18
PILOT BURNER/
IGNITION-
SENSOR
JUST RIGHT
PILOT BURNER/
IGNITION-
SENSOR
TOO LOW
PILOT BURNER/
IGNITION-
SENSOR
TOO HIGH
MAIN BURNER
FLAME
IMPINGES ON
IGNITION-
SENSOR
IGNITION
FLAME
IMPINGES ON
MAIN BURNER
IGNITION FLAME
JUST MISSES
MAIN BURNER
PILOT BURNER/
IGNITION-
SENSOR
JUST RIGHT
PILOT BURNER/
IGNITION-
SENSOR
TOO LOW
PILOT BURNER/
IGNITION-
SENSOR
TOO HIGH
MAIN BURNER
FLAME
IMPINGES ON
IGNITION-
SENSOR
IGNITION
FLAME
IMPINGES ON
MAIN BURNER
IGNITION FLAME
JUST MISSES
MAIN BURNER
M11465
Q377
Q382
Fig. 18. Location of pilot burner (Q377 and Q382 shown).
Connect Pilot Gas Tubing
1. Cut the tubing to the desired length and bend as
necessary for routing to the pilot burner. Do not make
sharp bends or deform the tubing. Do not bend the
tubing at the control after the compression nut has
been tightened because this can result in gas leakage
at the connection.
2. Square off and remove the burrs from the end of the
tubing.
3. Push the tubing into the compression nut clearance
hole until the tubing bottoms.
NOTE: When replacing a pilot burner or orifice, cut off
old compression fitting and replace with the
new compression fitting provided with new
pilot burner. Never use the old compression
fitting because it may not provide a gas-tight
seal. See Fig. 19.
4. While holding the tubing all the way in, engage the
threads and turn until finger tight.
5. Using a wrench, turn the compression nut one turn
beyond finger tight.
Do not overtighten .
6. Connect the other end of the tubing to the gas control
according to the gas control manufacturer instructions.
PILOT BURNER BODY
TIGHTEN NUT ONE
TURN BEYOND
FINGER TIGHT
FITTING BREAKS OFF
AND CLINCHES TUBING
AS NUT IS TIGHTENED
TO GAS CONTROL
M3295
Fig. 19. Always use new compression fitting.

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3
19
Install Thermocouple or Thermopile
Push-in Design
1. Insert the thermocouple or thermopile tip into the hole
or barrel provided beneath the pilot burner. See Fig. 20
and 21.
2. Push in firmly until the thermocouple or thermopile is
locked into place.
Attachment Nut Design
1. Insert the thermocouple or thermopile tip into the hole
or barrel provided beneath the pilot burner. See Fig. 21.
2. Engage the attachment nut threads and tighten until the
thermocouple or thermopile is locked into place.
M11140
PILOT BURNER
ASSEMBLY
THERMOPILE
PUSH-IN
CLIP
OPTIONAL
ATTACHMENT
NUT
PILOT BURNER
ASSEMBLY
M11168A
THERMOPILE
THERMOCOUPLE
PUSH-IN
CLIP
OPTIONAL
ATTACHMENT
NUT
ADAPTER
ATTACHMENT NUT
Fig. 20. Installing thermocouple or thermopile.
Fig. 21. Installing Q382 thermocouple and thermopile.
Install Bleed Gas Tubing (if used):
1. Route the bleed gas tubing from the bleed tapping on
the gas control to the pilot burner.
2. Push the clip into place as shown in Fig. 22.
3. Insert the bleed gas tubing until 3/8 inch (10 mm) of the
tubing is above the pilot burner bracket. The tip of the
bleed gas tubing must not extend into the pilot flame.
THIS DIMENSION SHOULD BE
MAXIMUM OF 3/8 INCH (10 MM)
WHEN BLEED TUBE IS IN FINAL
POSITION
BLEED TUBE CLIP
1/8 IN. STEEL TUBING M3284
Fig. 22. Install bleed gas tubing.
Install Q314 “A” Mounting Bracket Adapter
To convert the mounting bracket on a Q314 from a “B”
mounting bracket to an “A” mounting bracket, install the “A”
mounting bracket adapter to the pilot burner mounting
bracket. Then install the pilot burner to the main burner. See
Fig. 16.
Change Insert Orifice (See Fig. 23)
1. Disconnect the pilot tubing from the pilot burner and
remove the insert orifice. Light force may be required to
remove the orifice.
2. Cut off the old compression fitting.
NOTE: When replacing an orifice, cut off the old
compression fitting and replace with a new
compression fitting. Never use an old
compression fitting because it may not provide
a gas-tight seal. See Fig. 19.
3. Square off the end of the pilot tubing and remove all the
burrs.
4. Insert the new compression nut over the pilot tubing
and slide out of the way.
5. Insert the new orifice into the pilot burner and push the
pilot tubing into the pilot burner until it bottoms.
6. While holding the tubing all the way in, slide the
compression fitting into place and engage the threads.
Turn until finger tight.
7. Using a wrench, tighten the compression fitting one turn
beyond finger tight.

Q314, Q324, Q327, Q350, Q377, Q379, Q380 AND Q382 PILOT BURNERS
60-2075—3 20
M11466
Q377
Q382
PILOT BURNER
ASSEMBLY
INSERT ORIFICE
COMPRESSION
FITTING
PILOT
BURNER
ASSEMBLY
INSERT ORIFICE
COMPRESSION
FITTING
Fig. 23. Changing insert orifices (Q377 and Q382 shown).
STARTUP AND CHECKOUT
Perform Gas Leak Test
WARNING
FIRE OR EXPLOSION HAZARD
CAN CAUSE PROPERTY DAMAGE, SEVERE
INJURY, OR DEATH
Check for gas leaks with soap and water solution any
time work is done on a gas system.
Gas Leak Test
1. Ensure that the gas supply is turned on at the appliance
service valve.
2. Paint the pipe connections upstream of the pilot burner
with rich soap and water solution. Bubbles indicate a
gas leak.
3. If a leak is detected, tighten the pipe connections.
4. Stand clear of the main burner while lighting to prevent
injury caused from hidden leaks, which can cause
flashback in the appliance vestibule. Light the main
burner.
5. With the main burner in operation, paint the pipe joints
(including the adapters) and gas control inlet and outlet
with rich soap and water solution.
6. If another leak is detected, tighten the adapter screws,
joints, and pipe connections.
7. Replace the part if the leak cannot be stopped.
Adjust Pilot Flame
The pilot flame should envelop 3/8 to 1/2 in. (10 to 13 mm) of
the thermocouple or thermopile tip. See Fig. 24 To adjust the
pilot flame:
1. Remove the pilot adjustment cover screw from the gas
control.
2. Turn the inner pilot adjustment screw clockwise to
decrease or counterclockwise to increase the pilot
flame.
3. Replace the pilot adjustment cover screw and tighten
firmly after completing adjustment to ensure proper
operation.
3/8 TO 1/2 IN.
(10 TO 13 MM)
PROPER
FLAME
ADJUSTMENT
THERMOCOUPLE
OR THERMOPILE
M11144
Fig. 24. Thermocouple or thermopile tip
must be in pilot flame.
