Honeywell AQUASTATIC L7224 Series User manual

TECHNICIAN’S QUICK REFERENCE GUIDE
69-1957—1
L7224 Series
Oil Electronic
Aquastat® Controller
The following service procedure provides a quick overview for
L7224 Series Controllers. For more information, refer to form
69-1384.
On the L7224U the High Limit, High Limit Differential, Low Limit,
and Low Limit Differential can be adjusted to the settings
recommended by the boiler OEM.
Adjusting Settings
To discourage unauthorized changing of Aquastat® settings, a
procedure to enter the adjustment mode is required. To enter the
adjustment mode, press the UP, DOWN, and Ibuttons
simultaneously for three seconds. Press the I button until the
feature requiring adjustment is displayed:
• HL—High Limit.
• LL—Low Limit.
• Ldf—Low Limit differential.
• F - C—°F or °C.
Then press the UP and/or DOWN buttons to move the set point to
the desired value. After 60 seconds without any button inputs, the
control will automatically return to the READ mode.
To use the L7224U in a cold start boiler application, disable the
Low Limit function by pressing the UP arrow button, DOWN arrow
button and Ibuttons simultaneously for three seconds. Then push
the Ibutton until LL is displayed. Then press the down arrow
button until OFF is displayed.
Display
In the RUN mode, the Aquastat® will flash “bt” (boiler temp)
followed by the temperature (i.e., 220), followed by °F or °C.
To read boiler settings, press the Ikey to read the parameter of
interest. For example, press I(HL) High Limit is displayed,
followed by a three-digit number, i.e., 220, followed by °F or °C.
69-1957-1.fm Page 1 Tuesday, June 20, 2006 11:06 AM

69-1957—1 2
L7224 SERIES
Pressing the I button again will display the LL (Low Limit) followed
by a three-digit number and the corresponding degree designator.
See the table below for an explanation of display readout.
After approximately 60 seconds without any key presses, the
display will enter a dim display mode. To return to the bright
display mode, simply press and release any key.
Table 1. LED Error Codes
Error Code Cause/Action
Err1 Sensor fault; check sensor.
Err2 ECOM fault; check EnviraCOM. wiring.
Err3 Hardware fault; replace control.
Err4 B1 fault; check B1 wiring/voltage.
Err5 Low Line; Check L1-L2, 110 Vac.
Err6 Fuse; Check ECOM wires, Replace fuse.
Err7 EEPROM, HL, LL, Hdf, Ldf, Reset to default values.
Err8 Repeated B1 fault (voltage present at B1 when
output is turned off); check B1 wiring/voltage.
Boiler Temperature
Text Description
Display
Shows
bt
High LimitHL
Low LimitLL
High Limit DifferentialHdf
Low Limit DifferentialLdf
Local Thermostat Statustt
Enviracom Thermostat Statustte
Burner Statusbrn
Circulator Statuscir
Zone ControlZc
Zone RequestZr
Error Codeerr
Degrees Fahrenheit
f
Degrees Celsius
M22149
c
69-1957-1.fm Page 2 Tuesday, June 20, 2006 11:06 AM

3 69-1957—1
L7224 SERIES
Table 2. L7224 Controller Operating Sequence
Troubleshooting
When attempting to diagnose system performance, reference the
LED display to help identify specific areas not working properly.
The LED display will scroll “err”, followed by a digit (1-8). See
Table 1 for a description of the error and suggested actions. See
below for a troubleshooting guide.
Action System Response
Thermostat
calls for heat.
Circulator starts when water temperature is
above Low Limit setting (if applicable). Boiler
temperature is checked. Burner starts when
water temperature is below High Limit setting.
Boiler exceeds
the High Limit.
Burner is turned off. Burner restarts when the
water temperature drops below the High Limit
setting minus the differential.
Thermostat is
satisfied.
Circulator and burner turn off.
Error conditions
1-5.
If an error condition is detected, all outputs
except ZC are shut down. Burner is off. Control
continues to function and restarts when error is
corrected. During the error check sequence, the
system checks for drift in the sensor and
corrosion in the connections.
Error conditions
6-7.
If error condition 6 or 7 occurs, the control has
reset the High Limit, Low Limit and Differential
Setting to a default setting and will continue to
run at those settings. Performance of the system
will be degraded.
Error condition
8.
If the error condition is detected, all outputs
except ZC are shut down. Burner is off. Control
continues to function and restarts when all three
user keys have been pressed longer than 60
seconds.
Table 3. Troubleshooting Guidea.
System
Condition
Diagnostic
Condition Check Action
Boiler is
cold,
house is
cold
Display is OFF 120 Vac system
power.
Turn system power on.
Display is ON;
TT-LED is OFF
24 Vac T-T No 24V; replace
control
Display is ON;
TT-LED is OFF
24V present;
disconnect
thermostat,
short T-T
Boiler starts, check
wiring and thermostat
a. Refer to Fig. 5 for Display and LED locations.
b. ZC LED ON indicates ZC terminal power is OFF.
c. ZC LED OFF indicates ZC terminal power is ON.
69-1957-1.fm Page 3 Tuesday, June 20, 2006 11:06 AM

Automation and Control Solutions
Honeywell International Inc. Honeywell Limited-Honeywell Limitée
1985 Douglas Drive North 35 Dynamic Drive
Golden Valley, MN 55422 Toronto, Ontario M1V 4Z9
customer.honeywell.com
® U.S. Registered Trademark
© 2006 Honeywell International Inc.
69-1957—1 Rev. 06-06
Boiler is
cold,
house is
cold
Display is ON;
TT-LED is ON
B1 LED is ON
120 Vac at B1-
B2
•If no, replace control.
•If yes, check burner
and wiring
Display is ON;
TT-LED is ON
Refer to err on
display
—
Boiler is
hot, house
is cold
Display is ON;
TT-LED is ON
C1 LED is ON
120 Vac at C1-
C2
•120 Vac at C1-C2,
check wiring to pump
•Wiring ok, is pump
running? If not,
replace the pump.
•If pump is running,
check for trapped air
or closed zone
valves.
Display is ON;
TT-LED is ON
C1 LED is OFF;
ZC LED is ONb
Boiler below the
Low Limit
temperature,
wait for boiler to
go above Low
Limit
temperature.
Display is ON;
TT-LED is ON
ZC LED is
OFFc
Boiler above
LL? If yes,
check for 120
Vac between ZC
and L2
•If no 120 Vac,
replace control.
•If yes, check zone
relays, circulators
and wiring.
Table 3. Troubleshooting Guidea.
System
Condition
Diagnostic
Condition Check Action
a. Refer to Fig. 5 for Display and LED locations.
b. ZC LED ON indicates ZC terminal power is OFF.
c. ZC LED OFF indicates ZC terminal power is ON.
69-1957-1.fm Page 4 Tuesday, June 20, 2006 11:06 AM
