HW100SPI
DC-AC Power Inverter
For product inquires or support, visit www.honeywellpowerinverters.com
or call toll-free at 1-888-HWHELP1 (494-3571).
Owner’s Manual
Manual del Propietario
Si tiene preguntas acerca de los productos o requiere de asistencia,
visite www.honeywellpowerinverters.com o llame gratis al
1-888-HWHELP1 (494-3571).
Read and Save These Instructions
Lea y Conserve Estas Instrucciones

Congratulations on owning a Honeywell power inverter!
Please use the spaces provided below to record important information about
your power inverter. You may be asked to provide this information should you
require product service or support. The power inverter serial number can be
found on the data nameplate.
This manual contains important instructions for operating this power
inverter. For your safety, and the safety of others, read this manual
thoroughly before operating the power inverter. Failure to properly
follow all instructions and precautions can cause you and others to
be seriously hurt or killed.
FIGURE 1: Power Inverter Data Nameplate Location
Date of Purchase:
Store/Dealer Purchased From:
Model Number:
Serial Number:
WARNING
p/n 102600B
Northshore Power Systems, LLC
Milwaukee, WI 53212
S/N

HW100SPI Power Inverter Owner’s Manual www.honeywellpowerinverters.com i
Contents
IMPORTANT SAFETY INSTRUCTIONS ............................ 1
Getting Started ................................................................... 6
Unpacking Guidelines .......................................................................... 6
Features .............................................................................................. 6
Components ....................................................................... 7
Operation ............................................................................ 9
Preparing for Operation ....................................................................... 9
Operating Time .................................................................................. 10
Appliance Wattage Information ......................................................... 11
Connecting the Power Inverter .......................................................... 12
Disconnecting the Power Inverter ...................................................... 13
Troubleshooting .............................................................. 14
Specifications .................................................................. 16
Warranty ........................................................................... 17
Index ................................................................................. 21

1 www.honeywellpowerinverters.com HW100SPI Power Inverter Owner’s Manual
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
NOTE:
Since there are many variations in the circumstances surrounding the installa-
tion and operation of power inverters, we cannot possibly anticipate or provide
advice or safety messages to cover every situation.
Safety Messages
Signal Words
Safety messages are provided throughout this manual to help prevent per-
sonal injury and equipment damage. All safety messages are introduced by a
signal word indicating the hazard level.
ANYONE using or servicing this power inverter must read, under-
stand, and follow all safety and operation instructions provided in
the product manual. Failure to closely follow these instructions can
result in circumstances leading to property damage, serious injury,
and death.
Indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury to
the operator or to bystanders.
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury
to the operator or to bystanders.
Indicates a potentially hazardous situation which, if
not avoided, may result in moderate or minor injury
to the operator or to bystanders.
Indicates a situation which, if not avoided, may
result in damage to the power inverter components.
WARNING
DANGER
WARNING
CAUTION
NOTICE

IMPORTANT SAFETY INSTRUCTIONS
HW100SPI Power Inverter Owner’s Manual www.honeywellpowerinverters.com 2
Hazard Symbols and Meanings
In addition to the signal words, the following symbols may be used to draw
your attention to specific types of hazards.
Medical and Life Support Uses
Explosion Toxic fumes Fire Chemical
burn Electrical
shock Hot surface
• In case of emergency, call 911 immediately.
• NEVER use this product to power life support devices or life support
appliances.
• NEVER use this product to power medical devices or medical appli-
ances.
• Inform your electricity provider immediately if you or anyone in your
household depends on electrical equipment to live.
• Inform your electrical provider immediately if a loss of power would
cause you or anyone in your household to experience a medical emer-
gency.
+
WARNING

IMPORTANT SAFETY INSTRUCTIONS
3 www.honeywellpowerinverters.com HW100SPI Power Inverter Owner’s Manual
Electric Shock Hazards
Power inverter produces powerful voltage that can cause death or
great physical harm.
• NEVER operate in rain or snow, set on wet surfaces, immerse in liquid,
or use in marine applications.
• NEVER touch bare wires or receptacles.
• NEVER use electrical cords that are worn, frayed, bare, or otherwise
damaged.
• NEVER use power inverter for any purpose other than its intended use.
• NEVER place the power inverter near the vehicle’s heat vent or in direct
sunlight as this prevents proper cooling.
• NEVER use the power inverter if it is damaged; replace immediately.
• NEVER open the power inverter. There are no user-serviceable parts
inside.
• NEVER connect to AC distribution wiring or to any areas marked “Igni-
tion Protected”. This power inverter is NOT approved for ignition pro-
tected areas such as marine applications.
• NEVER insert foreign objects into the AC or USB outlets.
• ALWAYS disconnect the power inverter AND appliances from the power
supply when not in use and before servicing.
• The inverter produces the same potentially lethal AC power as a house-
hold outlet. It is suggested that it be treated as such.
• Store indoors in a dry location out of reach of children.
• Some appliances are not recommended for use with this power inverter.
See “Appliance Wattage Information” on page 11 for further details.
• Use only UL-listed, three-prong extension cords intended for outdoor use
when connecting appliances to the power inverter outdoors. Use the
proper size (wire-gauge) extension cord to handle the electric load that
will be plugged into it.
WARNING

IMPORTANT SAFETY INSTRUCTIONS
HW100SPI Power Inverter Owner’s Manual www.honeywellpowerinverters.com 4
Fire and Burn Hazards
NEVER operate near flammable materials, fumes, or gases.
• NEVER expose to extreme heat or flames.
• ALWAYS install the power inverter in a location not likely to come into
contact with skin as the surface may become hot.
• NEVER operate the power inverter near fumes or gases (such as the
cabin of a gasoline power boat or near propane tanks) or in an enclosed
area that contains lead-acid batteries for automotive use. This type of
battery emits explosive hydrogen gas which can be ignited by sparks.
• DO NOT replace any vehicle fuse with a rating higher than recom-
mended by the vehicle manufacturer. This product is rated to draw 10
amperes from a 12VDC accessory outlet. Ensure that the electrical sys-
tem in your vehicle can supply this product without causing the vehicle
fusing to open. This can be determined by making sure the fuse in the
vehicle which protects the outlet is rated higher than 10 amperes. Infor-
mation on the vehicle fuse ratings are typically found in the vehicle oper-
ator’s manual. If a vehicle fuse opens repeatedly, do not keep on
replacing it. The cause of the overload must be found. On no account
should fuses be patched up with tin foil or wire as this may cause serious
damage elsewhere in the electrical circuit or cause fire.
• Connect the power inverter to batteries with a normal output of 12VDC
only; Do not use with 6V or 24V systems.
• NEVER use with positive ground electrical systems. Reverse polarity
connections will result in a blown fuse and may cause permanent dam-
age to the inverter and void the product warranty. (Most modern automo-
biles, RVs, and trucks are negative ground systems.)
• NEVER operate the power inverter in areas with high levels of dirt, dust,
or debris.
• Follow ALL manufacturer instructions: power inverter instructions, bat-
tery manufacturer instructions, and the manufacturer of any equipment
intended for use with this power inverter.
WARNING
WARNING

IMPORTANT SAFETY INSTRUCTIONS
5 www.honeywellpowerinverters.com HW100SPI Power Inverter Owner’s Manual
• NEVER connect or set up the power inverter or appliances while operat-
ing a vehicle. Not paying attention to the road may result in a serious
accident.
• NEVER plug the power inverter into a location that interferes with the
vehicle controls (i.e. near the gear shift lever).
• ALWAYS use the power inverter where there is adequate ventilation.
NEVER block ventilation slots. NEVER install in an engine compartment
or in any enclosed area in the vehicle that does not allow air circulation.
• NEVER place materials that could be damaged by heat near the power
inverter during use.
• ALWAYS make all DC connections before making AC connections.
• NEVER service an AC appliance without first disconnecting from the
power inverter.
• NEVER connect the power inverter to live AC power circuits.
• Some chargers for small nickel-cadmium batteries can be damaged if
connected to the power inverter. Do not use the power inverter on the
following items:
- Small battery-operated appliances such as flashlights, razors, and
nightlights. Charge these items using a standard household outlet.
- Certain battery chargers for battery packs used in hand power tools.
These chargers will have a warning label indicating that dangerous volt-
ages are present at the battery terminals.
WARNING

HW100SPI Power Inverter Owner’s Manual www.honeywellpowerinverters.com 6
Getting Started
Unpacking Guidelines
1. Inspect for damage.
Carefully inspect the product for any damage that may have occurred
during shipment. If loss or damage is noted, return the product to the
retailer.
2. Register product information at www.honeywellpowerinverters.com to
ensure the product is covered by warranty.
Features
Short-Circuit Protection
The power inverter will shut down if a short circuit occurs.
Overload Protection
The power inverter will shut down if an overload situation occurs.
Thermal Shut-down Protection
The power inverter will shut down due to insufficient ventilation or a high-
temperature environment.
Low Voltage Shut-down
The power inverter will shut down if the power source voltage drops below
10.5 + 0.3 volts to avoid damaging the power source.
High Voltage Shut-down
The power inverter will shut down if the power source voltage exceeds
15.5 + 0.5 volts to avoid damaging the power inverter.
ANYONE using or servicing this power inverter must read, under-
stand, and follow all safety and operation instructions provided in
the product manual. Failure to closely follow these instructions can
result in circumstances leading to property damage, serious injury,
and death.
WARNING

7 www.honeywellpowerinverters.com HW100SPI Power Inverter Owner’s Manual
Components
A
F
D
E
B
C
G

Components
HW100SPI Power Inverter Owner’s Manual www.honeywellpowerinverters.com 8
A - Cooling Fan
Protects the inverter from over-heating.
B - LED Indicator
Illuminates green when DC power input is present. Illuminates red when the
power inverter has a fault.
C - Ventilation Openings
Draws air flow through the power inverter to the cooling fan to prevent over-
heating.
D - USB Port
Provides 5-volt power to run equipment with USB power cords.
E - AC Outlet
Provides up to a total of 100 watts of power to run equipment with AC power
cords.
F - DC Accessory Plug
Plugs into a vehicle’s accessory outlet and is adjustable.
G - Circuit Protection Fuse
Replace the 12 amp fuse by gently unscrewing the tip of the accessory plug.

9 www.honeywellpowerinverters.com HW100SPI Power Inverter Owner’s Manual
Operation
Preparing for Operation
Thoroughly read and understand all information provided in this
Owner’s Manual before operating this power inverter.
Power inverter produces powerful voltage that can cause death or
great physical harm.
• NEVER operate in rain or snow, set on wet surfaces, immerse in liquid,
or use in marine applications.
• NEVER place the power inverter near the vehicle’s heat vent or in direct
sunlight as this prevents proper cooling of the power inverter.
• ALWAYS use the power inverter where there is adequate ventilation.
NEVER block ventilation slots.
• NEVER operate the power inverter near fumes or gases (such as the
cabin of a gasoline power boat or near propane tanks) or in an enclosed
area that contains lead-acid batteries for automotive use. This type of
battery emits explosive hydrogen gas which can be ignited by sparks.
• NEVER operate the power inverter in areas with high levels of dirt, dust,
or debris.
WARNING
WARNING

Operation
HW100SPI Power Inverter Owner’s Manual www.honeywellpowerinverters.com 10
Care and Maintenance
The power inverter should be kept in areas that are:
• Dry - Do not allow water or other liquids to come in contact with the power
inverter.
• Ambient - Temperature should be between 32° and 104° F (0° - 40° C).
• Ventilated - During operation leave at least a 2” clearance around the
power inverter for air flow and ensure the ventilation openings are not
obstructed.
• Clean - Avoid environments with high levels of dirt, dust, or debris.
• Secure - Keep the power inverter in a location where it will not be
dropped, exposed to direct sunlight or heating units, or placed in areas
of high humidity or dampness. Keep out of reach of children.
Operating Time
Operating time varies depending on the battery charging level, capacity, and
power level drawn by the AC load.
With the vehicle running, the inverter can operate indefinitely.
With the vehicle not running, it may be necessary to start the vehicle periodi-
cally to recharge the battery.
Most vehicle batteries are designed to provide short periods of high current
for starting the engine. Constantly operating the power inverter from the vehi-
cle battery until the low-voltage shut-off occurs will affect battery life. If appli-
ances need to be powered for long periods of time, consider using a separate
deep cycle battery.

Operation
11 www.honeywellpowerinverters.com HW100SPI Power Inverter Owner’s Manual
Appliance Wattage Information
Before using the power inverter, take time to check the power rating of the
appliance and verify the wattage does not exceed the power inverter output.
Power rating information can usually be found on an appliance’s product
label, stamped inside, or on the back of the appliance.
If the appliance power consumption is rated in amps AC, simply multiply by
the AC volts (115) to determine the wattage.
Appliances with electric motors require additional power when starting.
High-wattage appliances or equipment that produces heat, such as hair dry-
ers, microwave ovens, and toasters cannot be operated by this power inverter.
NOTICE
The values provided in the following table are estimates only.
• ALWAYS verify actual wattage requirements for appliances by checking
appliance label, operating manuals, or contacting the manufacturer.
• Appliances with electric motors require additional power when starting.
Appliance Watts Appliance Watts
Bluetooth Headset 2 Cell Phone 10
MP3 Player 3 Handheld Video 50
Digital Camera 3 Laptop 60

Operation
HW100SPI Power Inverter Owner’s Manual www.honeywellpowerinverters.com 12
Connecting the Power Inverter
1
3
4
2
Plug the power inverter into
the vehicle’s accessory outlet.
Turn off the
Confirm the LED
indicator is green.
Plug in a second appliance
following steps 3 & 4, if desired.
5
Plug in and turn
on the appliance.
appliance to
be powered.
NOTE: Do not exceed rated
power of the power inverter.

Operation
13 www.honeywellpowerinverters.com HW100SPI Power Inverter Owner’s Manual
Disconnecting the Power Inverter
NOTICE
ALWAYS disconnect the power inverter when
not in use to avoid reducing vehicle battery life.
1Unplug appliances.
2Unplug the power inverter.
3Store the inverter in a location that is:
- Ambient (32°-104°F / 0°-40°C)
- Dry
- Away from direct sunlight,
heating units, dampness, high
humidity, dirt, dust, or debris.
- Out of reach of children.

HW100SPI Power Inverter Owner’s Manual www.honeywellpowerinverters.com 14
Troubleshooting
PROBLEM PROBABLE CAUSE SOLUTION
No power /
LED not
illuminated
Poor connection
Rotate the power inverter connector slightly
in the vehicle’s accessory outlet to ensure
there is good contact.
Ignition / accessory outlet
not providing power
Most vehicles require the ignition switch
to be in the on position.
Start vehicle to recharge vehicle battery or
check vehicle battery voltage.
Damaged vehicle fuse Replace vehicle fuse.
Damaged power inverter Never use a damaged power inverter.
See “Warranty”, page 17.
LED is red
Electrical overload
Disconnect appliance(s), disconnect
power inverter, wait a few minutes, plug
in the power inverter, and plug in
reduced load. Charge appliances with
power ratings less than 100 watts AND
with surge power less than 200 watts.
Low voltage input
Low voltage shutdown has occurred; Start
vehicle to recharge vehicle battery or check
vehicle battery voltage.
Overheating
Thermal shut-down protection has
occurred; Unplug accessories and
leave the power inverter plugged in
allowing fan to cool the unit. Clear
objects away from power inverter to
improve air flow, move it to a cooler
location, or reduce load if power
inverter is operated continuously.

Troubleshooting
15 www.honeywellpowerinverters.com HW100SPI Power Inverter Owner’s Manual
LED is green
but no power
output
Damaged power inverter Never use a damaged power inverter.
See “Warranty”, page 17.
Audiosystem
interference
Audio system internal
power supply not filtering
modified sine wave
Use audio system with higher
quality filtering.

HW100SPI Power Inverter Owner’s Manual www.honeywellpowerinverters.com 16
Specifications
POWER INVERTER HW100SPI
Dimensions
Length [in / mm] 4.8 / 123
Width [in / mm] 2.8 / 72
Height [in / mm] 1.2 / 30
Dry Weight [oz / g] 8 / 220
AC Power Output
Rated Power [watts] 100
Maximum Power [watts] 200
Frequency [hertz] 60
Voltage [volts]
(under load, modified sine wave) 115
DC Power Output (USB)
Voltage [volts] 5.0
Minimum Current [amperes] 0.5
DC Power Input
Rated Voltage [volts] 13.8 + 0.2
Rated Current [amperes] 10
Low Voltage Shutdown [volts] 10.5 + 0.3
High Voltage Shutdown [volts] 15.5 + 0.5
Circuit Protection Fuse 12A
Operating Temperature
Maximum [F / C] 104° / 40°
Minimum [F / C] 32°/ 0°

17 www.honeywellpowerinverters.com HW100SPI Power Inverter Owner’s Manual
Warranty
Northshore Power Systems Limited Warranty
Honeywell DC-AC Power Inverter
Consumer Use Warranty -- Product is Not for Commercial Use
LIMITED WARRANTY
Northshore Power Systems, LLC, will repair or replace, free of charge, to the
original retail customer, in North America, any parts of the Power Inverter
found by Northshore Power Systems to be defective in material or workman-
ship. This limited warranty covers the cost of the replacement parts and labor
for defects. Transportation charges are the responsibility of the customer. This
limited warranty has time period conditions, operating conditions and dis-
claimers, limitations of remedies & exclusions as stated below. For warranty
service, customer should visit www.honeywellpowerinverters.com or call 1-
888-HWHELP1 (494-3571).
LIMITED WARRANTY PERIOD
2 Years Limited for Consumer Personal Use Only
NO WARRANTY FOR COMMERCIAL OR RENTAL USE
COMMENCEMENT AND DEFINITIONS. The limited warranty period begins
on the date of retail purchase by the original purchaser. The limited warranty
is not transferable. "Consumer use" is personal use by a retail customer.
"Commercial use" or "rental use" is any usage for income producing, business
related use.
NO EXTENSION OF WARRANTY. Repair or replacement pursuant to this
limited warranty shall not renew or extend the original warranty period, and
any repaired product shall be warranted for the remaining original warranty
period only.
WARRANTY CLAIM PROCEDURE
A Power Inverter believed to be defective may be returned to retailer where it
was purchased within that retailer's return or exchange period. Please refer to
the retailer's return and/or exchange policies to determine that period. Proof
