Honeywell Cube M ST LED User manual

The light source of this luminaire is not replaceable when the light source reaches its end of
life the whole luminaire shall be replaced.
ATTENTION!!!
45
(*) Maintained operation: The luminaire lights its illumination source, when it is powered by the
mains power supply or not.
Non Maintained operation: The luminaire lights its illumination source, only in mains power supply’s
failure.
Cube M ST LED
SELFTESTING MAINTAINED
EMERGENCY LUMINAIRE
Cube
Technical Characteristics
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERY (Ni-MH)
MINIMUM POWER FACTOR
WIRE CROSS SECTION
MAX OPEN CIRCUIT VOLTAGE
Irated
Prated
U-OUT
MAXIMUM SUPPLY CURRENT
INSULATION BETWEEN SUPPLY & CONTROL TERMINALS
INSULATION BETWEEN SUPPLY & BATTERY CIRCUIT
BATTERY PROTECTION
CHARGE TIME
MINIMUM DURATION
LIGHT SOURCE
DEGREES OF COVER PROTECTION
LIGHT SOURCE LUMINOUS FLUX (MAINS / EMERGENCY)
INDICATIONS/CONTROLS
MAX CHARGE VOLTAGE
TRICKLE CHARGE VOLTAGE/CURRENT
MIN MAX. CHARGE CURRENT
MIN MAX. DISCHARGE CURRENT
MIN MAX. DISCHARGE VOLTAGE
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
CONTROL GEAR MAX.TEMPERATURE: tc
RELATIVE HUMIDITY
CONSTRUCTION MATERIAL
EXTERNAL DIMENSION (L x W x H)
WEIGHT
GUARANTEE
4. Remove the old battery and place a new one of the same type and characteristics.
3. Replace the removed parts.
1. Remove the top cover (Step 1 of hanging or ceiling installation).
2. Unscrew the 2 screws that hold the battery to its base.
It can be done only by a competent person and after the mains interruption.
Battery Replacement
Module Connection & Dip Switch
1: Maintained operation (*)
A: Including test device
B: Including remote test mode
NOTE: LED= Light Emitting Diode
X: Self contained
E: With non-replacable lamp(s) and/or battery
LABELING EXPLANATION:
60: 1 hour duration
C: Including inhibiting mode
480: 8 hours duration
180: 3 hours duration
X16 0A E
IP40
Maintained
Μ
370/270/110lm
Light output
1h/3h/8h
Duration
50m
NM
Non-Maintained
Controlgear classification in accordance with IEC 62034: with automatic test function.
220-240V AC / 50-60Hz
6.4W / 6.6VA
2 2
0.5mm - 2.5mm
33V
1h: 2.2W
1h: 200 mA
3h: 1.5W
3h: 141mA 8h: 57mA
8h: 0.6W
33V
29.2 mA
4.8V/2Ah
0.92
Basic insulation
Basic insulation
3 hours
370/270lm
310-490mA
190-210mA
5.8V/70mA
6V
16h
4-6V
8 hours
360/110lm
170-191mA
1 hour
370/370lm
438-700mA
16 power LEDs
LED Charge, Lamp Fault LED, Battery Fault LED/Test BUTTON
IP40
Deep discharge and overcharge protection / the control gear will recharge the battery normally after the test of 22.3
o
5 to 40 C
o
53 C at PSU1
Aluminium, ABS/PC, PC, Acrylic Plate
2326gr.
310 x 310 x 330 mm
Up to 95%
4 years
EN 60598-1, EN 60598-2-22, EN 55015, EN 61547,
EN 61000-3-2, EN 61000-3-3
1
3 4
2
Module connection
ON
1 2 3 4
Maintained operation
(default position)
ON
1 2 3 4
Non-maintained operation
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
1h
(default position)
3h 8h
Dip Switch (DS1) Settings
Autonomy duration selection
Technical label installation
Changing the operating mode
The user can select one of the 3 available minimum autonomy durations: 1 hour, 3 hours and 8 hours. The selection
must be done while the luminaire is disconnected from AC and battery supplies. The selection is achieved through
Switches 2 & 3 of DS1. Switch 1 is not used.
Two additional labels are included in the package, one for 3 hours duration (180) and one for 8 hour duration (480).
Depending on the selected duration, the installer must cover the default 1 hour (60) printing with one that has the
required duration. Please take notice of the orientation of the label.
The control of maintained or non maintained operation of the luminary is achieved through Switch 4 of DS1. For
maintained operation, switch number 4 must be in ON position. For non-maintained operation,switch number 4
must be in OFF position.
Honeywell Life Safety AS
http://www.hls-nordic.com
Po. Box 3514, N-3007 Drammen, Norway

1 3
General
Description
Indications LED Status
Fully charged
Charging
Battery fault or
emergency mode
Operational test
Light source fault
Autonomy test
Duration fault
CHARGE
(green)
LAMP
FAULT
(red)
BATT.
FAULT
(yellow)Note:
Permanently
ON
Blink
Indifferent
Off
Every 15 days the luminaire will perform an
emergency operation test. This will light the white
LEDs for approximately 3 seconds. The red LED will
flash during this test sequence. Every 6 months the
luminaire will perform a battery condition test. The
test will last for the stated duration. The white LEDs
will be lit and the yellow LED will flash during this
test sequence.
Cube is a self-contained luminary with selftest
function.
It can be configured as maintained or non-
maintained.
Selftest Functions
Emergency Operation Test
Press the TEST button less than 5 seconds. The
white LEDs light for about 3 seconds and the red
LED flashes.
Battery Condition Test
Press the TEST button for 5 to 10 seconds. This test
will last for for the stated duration and can only be
performed when the battery is fully charged (steady
green LED). The white LEDs light and the yellow LED
flashes.
Manual Test Functions
Resetting Errors
Press the TEST button more than 10 seconds to
delete all indicated errors. The luminaire enters
regular operation mode.
Note: When using DALI or Wireless communication,
the frequencies and schedules for tests will instead
be determined by the connected PC software.
In case that the luminaire no longer meets its rated
duration of operation, the battery must be
replaced.
To avoid that luminaires perform their battery test
at the same day, connect the battery packs with
more than 1,5 minutes in between.
Important notice when installing luminaires
within the same area!!!
1. Operations for installation, maintainance or
testing must be done by authorized personnel
only. Always use in any case round mains cable,
with a diameter of 5-10mm (H05RN-F type
2
2x1mm ) or any other type, at least equal to it's
mechanical and electrical properties).
3. In case of battery replacement, it must be
replaced by the same type, by the manufacturer
or a competent person.
5. The control gear within this luminaire is a built in
control gear which relies on the luminaire for
protection against electric shock.
4. In case of inactive use for a period greater than 2
months, disconnect the battery by pulling out
the battery’s connector.
6. The control gear is proof against supply voltage
polarity reversal.
7. This control gear has mains connected primary
windings.
8. I s not allowed to discard batteries into t i
common trash bins, they must be discarded
only in battery recycling points. Do not
incinerate.
ΑΤΤΕΝΤΙΟΝ!!!
2. The device must be connected to the mains
power supply through a fuse that is dependent
on the total line’s power load.
Connectors
CN15: Indication LEDs connector
CN2: Communication Connector
CN5: Module connector
CN1: Power connector
CN13: Non user connector
CN11: Non user connector
2
Installation Methods
1
1
1
1
1
Luminaire
Manual
Package Contents
Mounting accessories
Indication sign
The luminaire can be installed in 3 different ways. It can be installed either at the ceiling, either hanging (hanging with
chain and hanging with eye bolts. For ceiling installation special accessories are including. For hanging installation only
eye bolts are including.
Installation Instructions
Ceiling Mounting
12
ACB
Ceiling
mounting
Hanging installation
with chain
Hanging installation
with hooks
12
3
1
4
12
Changing Pictogram
Hanging Installation
56
3
3
4
4
2
Mind the orientation of placement!!
The top cover placement is achieved
according to the bottom part of the
luminaire and the already installed
pictograms.
LNC1C2
LNC1C2
LNC1 C2
LNC1 C2 Battery Connection
Battery Connection
12
12
56
Follow the same steps for the remaining sides of the pictogram.
Make a hole in the center of the
rubber gasket by using a small
screwdriver. Pass the round
cable through the rubber
gasket and install the gasket in
the appropriate hole.
Connect the mains cable to
the respective terminal block:
L for live wire, N for neutral
and for ground. Install the
included tie (if needed) to
fasten securely the power cables. Power supply cables cross
2
section should be 0.8 – 3 mm . The C1 and C2 terminals are
used for elBus communication (optional), DALI communication
(optional) or voltage free contact (optional).
Connect the mains cable to
the respective terminal block:
L for live wire, N for neutral
and for ground. Install the
included tie (if needed) to
Make a hole in the center of the
rubber gasket by using a small
screwdriver. Pass the round
cable through the rubber
gasket and install the gasket in
the appropriate hole.
cables. Power supply cables cross section should be 0.8 – 3
2
mm . The C1 and C2 terminals are used for elBus
communication (optional), DALI communication (optional) or
voltage free contact (optional).
