Honeywell ML03 Series User manual

LED OUTDOOR WALL LANTERN
MODEL: ML03XX-XXXX
USE AND CARE GUIDE
TROUBLE SHOOTING
FCC WARNING:
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user authority to operate the equipment.
**********************************************************************************************
NOTES:This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
International Development, LLC.
899 Henrietta Creek Rd. Roanoke, TX 76262 USA
Toll-free: 1-877-723-0723
© 2016 IDC, all rights reserved.
The Honeywell Trademark is used under license from Honeywell International Inc.
Honeywell International Inc. makes no representations or warranties with respect to this product.
This product is manufactured for International Development, LLC.
PROBLEM
Light will not come on. A. Light switch is turned off.
B. Fuse is blown or circuit breaker
is turned off.
C. Incorrect circuit wiring.
A. Turn light switch on.
B. Replace fuse or turn circuit
breaker on.
C. Verify that fixture is wired properly.
POSSIBLE CAUSE SOLUTION
Lights come on during
the day.
A. Photocell covered. A. Clean photocell with damp cloth.
17”
11”
Fold Fold
Fold Fold

A
E
D
A:
Mounting Bracket (1)
C:
Screw Caps (2)
8.7 mm x 7 mm x 8.5 mm
B:
Washers (2)
10 mm x 4 mm x 2 mm
E:
Phillips Head Screws (2)
8-32UNC x 20
F:
Finial (1)
D:
Wire Nut (3)
P3 12 mm x 21.5 mm
C
B
A
WALL LANTERN MOUNTING BASE
LOOSE SCREWS AND NUTS
G
PHOTOCELL
CANOPY
A
H
G
F
I
INSTALLATION INSTALLATIONSAFETY INFORMATION
PRE-INSTALLATION
WARNING: Read all safety precautions and installation instructions carefully before installing or
servicing this fixture. Failure to comply with these instructions could result in a potentially fatal
electric shock, fire, and/or property damage.
• To reduce the risk of electrical shock or other personal injury, ensure the power is turned
OFF at the fuse or breaker box before making any electrical connections.
• For outdoor use only
• Must be connected to 120 volt, 60 Hz power source
• Fixture should be mounted to a grounded junction box marked for use in wet locations
• Suitable for wall mount
• NOT suitable for ground locations. Minimum of 4 feet or higher
• Wall lantern should be installed by a qualified electrician or person experienced with
household wiring. The electrical system, and method of electrical connection of the fixture,
must be in accordance with the National Electrical Code and local building codes.
SUITABLE FOR WET LOCATIONS
CONSULT A QUALIFIED ELECTRICIAN TO ENSURE CORRECT BRANCH CIRCUIT CONDUCTOR.
MINIMUM 90° C SUPPLY CONDUCTORS
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE
BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE
HAZARDS INVOLVED.
PLANNING INSTALLATION
• Turn off the electrical power at the fuse or circuit breaker box before installing or servicing
any part of this fixture.
• Carefully remove the fixture from the carton and check that all parts are included. Be careful
not to misplace any of the screws or parts needed for installing the fixture.
HARDWARE INCLUDED
PARTS
A - Bracket
F - Finial
G - Lantern
H - Motion Detector
I - Light Sensor
STEP 2
Position the mounting bracket (Part A) to the junction box and secure using screws (Part E).
Connect the AC wires to the corresponding wires (BLACK to BLACK, WHITE to WHITE and
GROUND to GROUND) in the junction box using the wire nuts (Part D).
RECOMMENDED: Wrap each wire nut with electrical tape (not included) after wires have
been attached.
CAUTION: Before beginning installation turn off the circuit breaker and light switch.
MOTION ACTIVATED-2 STAGE LIGHTING: 350 lumens accent lighting from dusk till dawn.
When motion is detected, the light automatically switches to 900 lumens security lighting
for 60 seconds.
STEP 1
Tighten finial (Part F) to bottom of lantern by turning clockwise until secure.
STEP 3
NOTE: The screws and nuts that are pre-installed on the mounting bracket (Part A) should fit
loose during test fitting of the wall lantern (Part G).
A. Place wall lantern (Part G) over pre-installed screws and nuts on the mounting bracket (Part A)
and through the mounting holes located on both sides of the wall lantern mounting base.
B. While holding the wall lantern (Part G) over mounting bracket (Part A) with the pre-installed
screws and nuts, adjust both screws protruding through mounting holes of the wall lantern
mounting base to a height of 3/16 inch.
C.Remove wall lantern (Part G) and tighten pre-installed nuts on the mounting bracket (Part A)
while retaining the adjusted screw height of 3/16 inch in the previous step.
D.Place wall lantern (Part G) back into position and secure to the mounting bracket (Part A)
using washers (Part B) and screw caps (Part C) onto the protruding screws that were adjusted
to a height of 3/16 inch in the previous step.
STEP 4
Caulk completely around the area where the canopy meets the wall surface with silicone caulking
compound to prevent water from seeping into the junction box. Turn power ON at the circuit
breaker. Verify light function.
NOTE: Verify light function by covering photocell with piece of electrical tape. Light should
come on. Remove electrical tape.
11”
Fold Fold
17”Fold Fold
