ETC High End Systems SolaFrame Studio User manual

High End Systems
SolaFrame Studio
Automated Luminaire User Manual
Version 1.5.0
Part Number: 2560M1210-1.5.0 Rev: A
Released: 2023-03

To view a list of ETCtrademarks and patents, go to etcconnect.com/ip. All other trademarks, both marked
and not marked, are the property of their respective owners.
You can find complete High End Systems terms and conditions and warranty information at
etcconnect.com/Support/Warranty.aspx.
ETC intends this document, whether printed or electronic, to be provided in its entirety.

Table of Contents
Table of Contents i
Introduction 1
Document Conventions 1
Help from Technical Services 2
Safety Considerations 3
General Operation and Use Guidelines 5
Fixture Overview 6
Specifications 7
Environment 7
Power 7
Electrical 7
Input and Power Factor 7
Connector Specifications 8
Install the Fixture 8
DMX Control 11
DMX Connector Pinout 11
Connect DMXCables to Fixture 11
Terminate DMX 12
DMX Control and Ethernet Output 12
Set the DMX Start Address 12
DMX Channels 12
Ethernet Control 13
Connect EthernetCables to a Fixture 13

Ethernet Control and DMX Thru 14
Terminate DMX 14
Set the DMX Start Address 14
Set the Control Input and Universe 14
Configure the Fixture 15
Navigate the User Interface 15
Set Fixture Parameters 16
DMX Address 16
Info Menu 16
Set Menu 17
Test Menu 21
Preset Menu 21
Install the Secondary Diffusion Accessory 22
Error Codes 25
Maintenance 28
Clean the Fixture 28
Replace the Fuse 28
Compliance 29
FCC Compliance 29
ii SolaFrame Studio User Manual

Introduction 1
Introduction
Congratulations on your purchase of the High End Systems SolaFrame Studio automated
framing fixture.
This manual provides important information for the safe installation, configuration, and
maintenance of your SolaFrame Studio fixture. For your safety, read this entire manual prior to
installing, operating, or servicing the fixture.
ETC recommends that you update your fixture with the latest version of software before you
use the fixture. Software is available for free download from the ETC website:
etcconnect.com/Products/Automated-Fixtures.
• See View Software Version on page17 to determine which version of software is
currently installed on your fixture.
• See Update Fixture Software Using the USB Port on page20 for instructions about
updating your fixture.
Document Conventions
This document uses the following conventions to draw your attention to important
information.
Note: Notes are helpful hints and information that is supplemental to the main text.
CAUTION: A Caution statement indicates situations where there may be
undefined or unwanted consequences of an action, potential for data loss or
an equipment problem.
CAUTION: Hot Surfaces. This statement indicates that while operating,
equipment surfaces may reach very high temperatures. Allow the
fixture to cool before handling or servicing.
WARNING: A Warning statement indicates situations where damage may
occur, people may be harmed, or there are serious or dangerous
consequences of an action.
WARNING: RISK OF ELECTRIC SHOCK! This warning statement indicates
situations where there is a risk of electric shock.
All ETC High End Systems documents are available for free download from our website:
etcconnect.com/Products/Automated-Fixtures.
Please email comments about this manual to: [e-mail].

2 SolaFrame Studio User Manual
Help from Technical Services
If you have questions that are not answered by this document, try the ETC support website at
support.etcconnect.com or the High End Systems product website at
etcconnect.com/Products/Automated-Fixtures. If none of these resources are sufficient,
contact ETC Technical Services directly at one of the offices identified below. Emergency
service is available from all offices outside of normal business hours.
When calling for help, take these steps first:
• Prepare a detailed description of the problem
• Go near the equipment for troubleshooting
• Find your notification number if you have called in previously
ETC, Inc.
Americas
Technical Services Department
3031 Pleasant View Road
Middleton, WI 53562
800-775-4382 (USA, toll-free)
[phone]
[e-mail]
ETC GmbH
Germany, Austria, Switzerland,
Eastern Europe, and Russia
Technical Services Department
Ohmstrasse 3
83607 Holzkirchen, Germany
[phone]
[e-mail]
ETC Austin
High End Systems Products
Technical Services Department
2105 Gracy Farms Lane
Austin, TX 78758 USA
800-890-8989 (USA, toll-free)
[phone]
[e-mail]
ETC France
France
Zone Urbaparc -
Bâtiment E
6 Boulevard de la Libération
Saint-Denis, 93200
[phone]
[e-mail]
ETC Ltd
Europe, Middle East, and Africa
Technical Services Department
26-28 Victoria Industrial Estate
Victoria Road,
London W3 6UU England
[phone]
[e-mail]
ETCAsia
Asia
Technical Services Department
Room 1801, 18/F
Tower 1, Phase 1 Enterprise Square
9 Sheung Yuet Road
Kowloon Bay, Kowloon, Hong Kong
[phone]
[e-mail]

Safety Considerations 3
Safety Considerations
To ensure safe operation, follow the safety instructions and warning notes in the user manual.
• This fixture is intended for professional use only. Not for residential use. Read the entire
manual before using this equipment.
• Contact your authorized ETC dealer or Technical Services before performing any service
in order to maintain warranty coverage.
WARNING: Note the following safety warnings before use:
• This equipment is designed for operation by qualified personnel only.
• Replace fuses with the specified type and rating only. See page 28 .
• Ensure that the available voltage is within the stated range. See page 7 .
• Do not use this fixture with a damaged power lead (cord set). If the lead
is damaged, it must be replaced by a qualified technician with an
equivalent type before use. Contact your local authorized dealer for
replacement power leads.
• Do not use this fixture if the lens is damaged. Damaged lenses must be
replaced before use. Contact your local authorized dealer for a
replacement.
• Do not mount the fixture on or near flammable surfaces.
• The fixture should be positioned so that prolonged staring into the
fixture at a distance closer than 6.4 m (21 ft) is not expected.
• Minimum distance from fixture head to combustible materials:
0.1 m (4 in).
• Minimum distance to lighted objects:2 m (6ft 7in).
AVERTISSEMENT : Pour votre sécurité, lisez les mises en garde et les avis
suivants avant toute utilisation :
• Cet équipement est conçu pour être utilisé par un personnel qualifié
uniquement.
• Remplacez les fusibles uniquement par le type et le calibre indiqués.
Voir page 28 .
• Veillez à ce que la tension disponible soit dans la plage indiquée. Voir
page 7 .
• N'utilisez pas ce projecteur avec un cordon d'alimentation endommagé
(fils électriques). Si le cordon est endommagé, un technicien qualifié doit
le remplacer par un cordon de type équivalent avant que l'appareil ne
puisse être utilisé. Contactez votre distributeur agréé local pour obtenir
des cordons d'alimentation de rechange.
• N'utilisez pas cet appareil si la lentille est endommagée. Les lentilles
endommagées doivent être remplacées avant l'utilisation. Contactez
votre revendeur agréé local pour un remplacement.
• L'appareil doit être positionné de manière à ce qu'un regard prolongé
dans l'appareil à une distance inférieure à 6,4 m (21 pi) soit peu
probable.
• Distance minimum entre la tête du luminaire et les matériaux
combustibles : 0.1 m (4 in).
• Distance minimum avec les objets éclairés :2 m (6ft 7in).

4 SolaFrame Studio User Manual
WARNING: RISK OF ELECTRIC SHOCK!
• Do not operate this device with the cover open.
• Disconnect the fixture from power and DMX and allow it to cool before
performing any cleaning and maintenance.
AVERTISSEMENT : RISQUE DE CHOC ÉLÉCTRIQUE!
• N'utilisez pas cet appareil avec le couvercle ouvert.
• Débrancher la lampe de son alimentation et du DMX et la laisser
refroidir avant d’effectuer un nettoyage ou un entretien.
RISK GROUP 2: CAUTION. Possibly hazardous optical radiation emitted
from this product. Do not stare at operating lamp. May be harmful to the
eyes.
GROUPE DE RISQUE 2 (RISQUE MODÉRÉ) : ATTENTION. Rayonnement
optique potentiellement dangereux émis par ce produit. Ne regardez pas la
lampe en fonctionnement. Peut être nocif pour les yeux.
CAUTION: Hot Surfaces. Allow the device to cool completely before
handling and servicing.
ATTENTION : Surfaces chaudes. Laissez le luminaire refroidir complètement
avant de le manipuler et de procéder à son entretien.
Note: The light source in this luminaire is not user-replaceable, and must be
replaced only by a qualified technician. Contact ETC Customer Support for assistance.
Symbols used on the product label are defined below:
2.0 m
The luminaire must be installed at least 2.0m (6ft
7in) away from all lighted objects.
Le luminaire doit être installé à au moins 2,0m
(6pi. 7po.) de tout objet éclairé.
General warning Avertissement général
Do not stare at the operating light source. Ne pas regarder la source de lumière lorsqu’elle
fonctionne.
This product should not be discarded as unsorted
waste but must be sent to separate collection
facilities for recovery and recycling.
Ce produit ne doit pas être jeté avec les déchets
ménagers mais doit être déposé dans une collecte
de déchets électroniques ou dans un point de
collecte.
taorTaRated maximum ambient temperature Température ambiante maximale recommandée
tcorTcRated maximum case temperature Température maximale recommandée pour le
boîtier
Operate indoors only, not where this product
would be exposed to the weather.
Ne fonctionne qu'à l'intérieur, pas là où ce produit
serait exposé aux intempéries.

Safety Considerations 5
General Operation and Use Guidelines
• This fixture is only allowed to be operated with the maximum alternating current that is
stated in the technical specifications label provided on the fixture.
• Lighting effects are not designed for permanent operation. Consistent operation breaks
may extend the life of the fixture.
• When choosing the installation location, make sure the fixture will not be exposed to
extreme heat, moisture, or dust.
• Do not point the lens toward the sun or other bright light source. Doing so could damage
the fixture.
• If using the supplied Omega brackets with quick-locking thumb screws for fixture
hanging, ensure that the thumb screws have engaged a complete 90-degree positive
latch.
• Operate the fixture only after having familiarized yourself with its functions. Do not
permit persons who are not qualified and familiar with its functions to operate the
fixture.
• Do not modify the fixture. Any modifications will void the warranty.
• This manual describes the proper installation and operation of this fixture. Using this
fixture in any way other than the intended use may cause damage and void the warranty.
• When the fixture has been stored or transported in cold temperatures, allow it to warm
to room temperature for a minimum of one hour before applying power. Applying power
to a cold fixture may cause damage to the fixture and void the manufacturer warranty.
• When you power on the fixture, you may notice smoke or odor. This is normal and should
decrease gradually. If smoke or odor persists, disconnect the fixture from power and
contact your ETC dealer or Technical Services.
• Please use the original packaging if the fixture is to be transported. ETC will not be
responsible for the fixture if packaging other than manufacturer provided packaging is
used.

6 SolaFrame Studio User Manual
Fixture Overview
1: Lens
2: Tilt Lock
3: Yoke Handle
4: Display
5: Navigation Controls
6: Pan Lock
7: Enclosure Handle
8: USB
9: Power In
10: Power Out
11: DMXThru
12: DMX In
13: Ethernet ports (x2)

Specifications 7
Specifications
For complete technical specifications, see the technical datasheet:
etcconnect.com/Products/High-End-Systems/Lighting-Fixtures/SolaFrame/Studio/Documentation.aspx.
Environment
• Ambient operating temperature range: -10°C to 35°C (14°F to 95°F).
• Relative humidity: 0%–90%, non-condensing.
• Storage temperature: -20°C to 60°C (-4°F to 140°F).
• Indoor use only.
• Dry locations only, IP20 rated.
Power
WARNING: Connect the fixture to a non-dimmable power source in order
to avoid damage to the fixture's internal power supply and other electrical
components. Using a dimmable power source can damage the fixture and
will void the warranty.
Electrical
• 100–240 VAC at 50/60 Hz
• Maximum power consumption: 629 W; with Defogger 667 W
Input and Power Factor
The values listed below were measured with the fixture in Standard mode with LEDs at full and
all motors functioning.
VAC Amps Hz Watts VA PF
100 6.3 50 629 628 0.99
120 5.2 60 614 619 0.99
200 3.0 50 588 610 0.97
208 2.9 60 587 604 0.97
220 2.8 50 586 613 0.96
230 2.7 50 592 615 0.96
240 2.5 60 585 607 0.96
CAUTION: Using this fixture below 100 V on a 15 A breaker may cause the
breaker to trip. Ensure that the circuit can handle the fixture's maximum
potential draw before you connect it.

8 SolaFrame Studio User Manual
Connector Specifications
WARNING: Risk of Shock and Fire. Assemble a grounding-type attachment
plug with integral cord grip that is within the voltage and amperage rating
of this luminaire.
AVERTISSEMENT : Risque de choc et d'incendie. Assurez-vous d'utiliser
une prise de mise à la terre avec décharge de traction intégrée qui respecte
la tension et l'ampérage de ce luminaire.
A power input cable with powerCON®TRUE1®TOP input to bare ends is provided. The power
input cable is rated for maximum 20A/120VAC and 16A/240VAC. Install a suitable
connector to meet the installation requirements. See the following wire color code chart:
Wire Color Code (EU) Wire Color Code (US Standard) Connection type Terminal
Green/Yellow Green Earth/Ground
Blue White Neutral N
Brown Black Line (Live) L
Install the Fixture
Overhead rigging must be performed by qualified personnel. Follow all local and national
codes and recommended practices.
WARNING:
• The installation location must support a minimum point load of 10 times
the weight of the fixture. Fixture weight is 34kg (75lb).
• The installation must always be secured with a secondary safety
attachment. An appropriate safety cable is supplied.
• Safety cable attachment must be rated by a safety factor of 10.
• A supportive and stable surface must be used when fixtures are placed
on their feet.
• Never stand directly below the installed fixture when mounting,
removing, or servicing the fixture.
• All safety and technical aspects of fixture installation must be approved
by qualified personnel before operation.
• The installation must be regularly inspected by qualified personnel.

Install the Fixture 9
AVERTISSEMENT :
• L'emplacement d'installation doit supporter une charge concentrée
minimale de 10 fois le poids de l'appareil. Le poids du projecteur est de
34kg (75lb).
• L'installation doit toujours être sécurisée par une fixation de sécurité
auxiliaire. Un câble de sécurité approprié est fourni.
• La fixation du câble de sécurité doit être classée avec un facteur de
sécurité de 10.
• Une surface d'appui stable doit être utilisée quand les projecteurs sont
placés sur pieds.
• Ne vous placez jamais directement sous le projecteur lors du montage,
du démontage ou de son entretien.
• Tous les aspects techniques et de sécurité de l'installation du projecteur
doivent être approuvés par un personnel qualifié avant qu'il ne soit
utilisé.
• L'installation doit être régulièrement inspectée par du personnel
qualifié.
You can install the fixture in any of the orientations shown below.

10 SolaFrame Studio User Manual
1. Assemble the clamp (provided by others) to the Omega bracket that was provided with
the fixture and secure together using appropriately sized hardware (not provided).
2. Align the assembled Omega bracket and quick-lock fasteners into the respective holes on
the bottom of the fixture upper enclosure.
3. Tighten each of the quick-lock fasteners fully, turning clockwise. You will hear and feel a
click when the fastener is fully secured.
4. Repeat steps 1 through 3 for the second clamp and bracket.
5. Attach the provided safety cable through the attachment point on the bottom of the
fixture upper enclosure, and secure the cable to the trussing system or other safe
installation point. Follow local codes and recommended safety standards for securing the
fixture to the installation location.
6. Attach the fixture to the installation location using the clamp manufacturer's instructions
for a secure fit. When using an Omega clamp, close the safety and fully tighten the clamp
wing nut until secure.
7. Inspect the installation prior to lifting the fixture overhead.

DMX Control 11
DMX Control
The SolaFrame Studio fixture operates on standard DMX-512 control bus, controlled by a DMX
console. The fixture requires 48 channels of DMX-512 in standard mode.
Attach the fixture to the control bus using a two-core, shielded cable with a 5-pin XLR
connector (Belden 9729 is preferred).
Two XLR termination receptacles are available: one for connection of DMXInput and one for
DMXThru (used when daisy-chaining to additional fixtures on the DMX control bus).
DMX Connector Pinout
Use the following standard pinout when preparing DMX cable with 5-pin XLR connectors. ETC
recommends using Belden 9729 or equivalent cable. (See the ETC cable cross database for
equivalent alternatives: etcconnect.com/Support/Cable-Cross-Database.aspx.) The second
data pair in the recommended cable type is not used, but is reserved future service.
DMX-512 Pinout
for Five-Pin XLR Pin Use
1
2
3
4
5
Push
1
2
3
4
5
1 Common (shield)
2 Data -
3 Data +
4 Not connected
5 Not connected
Connect DMXCables to Fixture
The following instructions are guidelines for connecting DMX to your fixture. Your installation
may vary.
1. Connect a DMX data cable to the DMX control source and the DMX In XLR receptacle on
the first fixture in the DMX data run.
2. Link the remaining fixtures in the data run by connecting a DMX data cable from the
DMX Thru connector on a fixture to the DMX In connector on the next fixture in the data
run.
Note: A maximum of 32 DMX devices may be connected in any one DMX data run
when installed in a daisy-chain fashion.

12 SolaFrame Studio User Manual
Terminate DMX
Use a DMX terminator or install a resistor on the last fixture of the DMXcontrol run to prevent
corruption (data reflection) of the digital control signal by electrical noise.
A DMXterminator is an XLR plug with a 120 Ωresistor connected between pins 2 and 3 that
can be installed into the DMX output receptacle of the last fixture in the DMX control run.
Contact your authorized dealer or ETC for ordering information (etcconnect.com/contactETC),
or purchase an XLR DMX terminator from the ETC Online Shop (shop.etcconnect.com).
DMX Control and Ethernet Output
You can use DMX-512 control and Ethernet output. When a fixture is set up to receive
DMX-512 control input, it converts the signal to Art-Net on IP10 and sends the signal to the
Ethernet port, continuing the Art-Net on IP10 signal to the next fixture in the control run.
Set the DMX Start Address
Give each fixture a unique DMX starting address so that the correct fixture responds to the
control signals. This DMX start address is the channel number from which the fixture starts to
“listen” to the digital control information sent out from the control source.
Modify the fixture DMX start address on the user interface, located on the upper enclosure.
See DMX Address on page 16 .
Example: The SolaFrame Studio has 48 channels. If you set the DMXstarting
address of the first fixture to 1, you could set the second fixture to 49 (48+1), the
third to 97 (48+49), and so on.
DMX Channels
The current DMX channel map for the SolaFrame Studio can be found on the ETC website:
etcconnect.com/Products/High-End-Systems/Lighting-Fixtures/SolaFrame/Studio/Documentation.aspx.

Ethernet Control 13
Ethernet Control
The SolaFrame Studio fixture includes two Ethernet ports that allow sending and receiving of
control signals using the Art-Net protocol or sACN.
Use a Cat5e (or better) cable and terminate to RJ45 connectors following the TIA/EIA 568B
wiring standard.
Connect EthernetCables to a Fixture
The following instructions are guidelines for connecting Ethernet to your fixture. Your
installation may vary.
1. Connect a cable from the Ethernet control source to one of the Ethernet ports on the
first fixture in the Ethernet control run.
2. Connect the first fixture to a second fixture by connecting a cable from the second
Ethernet port on the first fixture to one of the Ethernet ports on the second fixture.
3. Continue linking the remaining fixtures by connecting a cable from Ethernet port to
Ethernet port on the fixtures on the control run.
Note: The Cat5e cable distance should not exceed 100 m (328 ft), and you should
not connect more than 20 fixtures in one Ethernet control run when the fixtures are
linked together.

14 SolaFrame Studio User Manual
Ethernet Control and DMX Thru
You can use Ethernet control and DMX Thru. When a fixture is set up to receive Ethernet
control input using the Art-Net protocol, it automatically distributes DMX via the DMX Thru
port. The DMX-512 signal is sent as a single universe that corresponds to the universe of the
fixture that is receiving Ethernet control.
Terminate DMX
Use a DMX terminator or install a resistor on the last fixture of the DMXcontrol run to prevent
corruption (data reflection) of the digital control signal by electrical noise.
A DMXterminator is an XLR plug with a 120 Ωresistor connected between pins 2 and 3 that
can be installed into the DMX output receptacle of the last fixture in the DMX control run.
Contact your authorized dealer or ETC for ordering information (etcconnect.com/contactETC),
or purchase an XLR DMX terminator from the ETC Online Shop (shop.etcconnect.com).
Set the DMX Start Address
Give each fixture a unique DMX starting address so that the correct fixture responds to the
control signals. This DMX start address is the channel number from which the fixture starts to
“listen” to the digital control information sent out from the control source.
Modify the fixture DMX start address on the user interface, located on the upper enclosure.
See DMX Address on page 16 .
Example: The SolaFrame Studio has 48 channels. If you set the DMXstarting
address of the first fixture to 1, you could set the second fixture to 49 (48+1), the
third to 97 (48+49), and so on.
Set the Control Input and Universe
For Ethernet control, you must configure the control input (Art-Net on IP2, Art-Net on IP10, or
sACN) and set a universe for each fixture. See Select Input on page19 and Set Universe for
Art-Net and sACN on page19 for details.

Configure the Fixture 15
Configure the Fixture
You can configure SolaFrame Studio fixtures through the onboard user interface.
Navigate the User Interface
1. Press the [MODE/ESC] button
Mode
Esc.
to access the main menu. (The display is powered by
battery when the fixture has no power; press and hold the [MODE/ESC] button
Mode
Esc.
for
three seconds to access the main menu.)
2. Browse the menu by pressing the up, down, left, or right navigation buttons.
3. Press the Enter button to select a menu item.
4. Modify the selection by pressing the up, down, left, or right navigation buttons
according to the selection.
5. Press the Enter button to confirm a modified selection.
6. To exit the menu, press the [MODE/ESC]
Mode
Esc.
button.
Note: If you press the Enter button to confirm a selection and push no other
buttons, the user interface returns to the default display after 15 seconds.

16 SolaFrame Studio User Manual
Set Fixture Parameters
This section provides instructions to configure and set up the SolaFrame Studio. See Navigate
the User Interface on page 15 for information about the navigation buttons.
Provide power to the fixture before configuring it. If you do not provide power, the fixture will
use battery power to power the user interface.
DMX Address
Navigate:Main Menu →Address
Set the DMX address for the fixture. The default value is 001.
Info Menu
Set the Time Information
Navigate:Main Menu →Info →Time Info
Parameter Value Description
Current Time XXXX (Hours) Running time of the fixture from the last time that the
fixture was powered on, shown in hours (h). The
counter resets after the fixture is turned off.
Ttl Life Hrs XXXX (Hours) Total running time of the device, shown in hours (h).
Last Run Hrs XXXX (Hours) Running time of the fixture from the last time that the
run time value was reset, shown in hours (h).
LEDHours XXXX(Hours) Total running time of the fixture LEDs, shown in
hours (h).
Timer PIN Timer PIN XXX You must enter the Timer PIN in order to access the
Clr Last Run menu item. The default Timer PIN is 038.
Clr Last Run • ON
• OFF
This password-protected menu item resets the Last
Run Hrs value. You must enter the Timer PIN to access
this menu item.
Select ON to clear the value for the Last Run Hrs
parameter for the fixture.
LEDTime PIN LED Time PIN XXX You must enter the LED Time PIN in order to access
the Clear LED Time menu item. The default LED Time
PIN is 038.
Clear LED Time • ON
• OFF
This password-protected menu item resets the LED
Hours value. You must enter the LED Time PIN to
access this menu item.
Select ONto clear the value for the LED Hours
parameter.
View Fixture Errors
Navigate:Main Menu →Info →Error Info
Displays any current fixture errors. See Error Codes on page25 for information about the
errors.
