Clevertronics LP CBS2N Series Technical specifications

1948770 V1.5 January 2018
Clevertronics Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or Red
flashing for a period up to 2 minutes.
Zoneworks and DATA Monitored Options
Fittings with part numbers CBS2N-ZW, CBS2N-DATA are fitted with Zoneworks communications modules
(nodes).These fittings are monitored using either Powerline Carrier Technology that utilizes the power
cable to provide data communication or a dedicated data cable to/from data routers installed on a
dedicated data trunk connected to a central Server (can also be connected via Ethernet/Internet/Fibre).
Zoneworks software on the server is used to monitor, coordinate testing and collate test data from each
fitting. Zoneworks fittings can be commissioned by a single push of the test switch, or scanning of the
supplied barcode. The LED Test Switch indicator provides a multifunction indication of the status of the
Lifelight during testing and normal operation:
State
LED Operation
Commissioned
LED on Solid (Green)
Un-commissioned
LED flashes at 0.5Hz (0.5s Green, 0.5s Yellow)
Emergency Light Test In Progress
LED flashes at 3s On (Yellow) & 0.5s Off
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl. DATA
version)
DALI EM Option
Fittings with part numbers CBS2N-DALI are fitted with DALI modules (nodes) that facilitate connection
and integration to 3rd Party Lighting Control Systems. Before installing the CBS2N -DALI please confirm
that the Lighting Control System has the capability to monitor DALI Emergency Luminaires. The CBS2N
-DALI will be addressed and configured into the control system by the Lighting Control System
Commissioning Technicians and not Clevertronics.
State
LED Operation
Commissioned/ Un-commissioned
LED on Solid (Green)
Emergency Light Test in progress
LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND”
Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network OR a 5/6way
“structured wiring system” lead and plug facilitating the power and DALI connection. DALI connections
are marked as Da Da.
.
LP™ LED Non-Maintained Batten
Surface Mount Emergency Luminaire
Installation & Maintenance Instruction Leaflet
Designed in Australia to comply with the
requirements of AS2293.3: 2005 and AS/NZS
CISPR15: 2011.
NOTE: Standard product codes with this
symbol are enabled with Clevertest Plus
capability. Please refer to the operation guide
supplied with the product for details.
Victoria (Head Office & Manufacturing)
195 Chesterville Rd Moorabbin VIC 3189
Phone: [phone]
Fax: [phone]
News South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Models: CBS2N-xx-yy
Testing
:
Options:
Manual Test
xx = Blank
Black Colour
yy = BLK
Zoneworks
xx = ZW
Zoneworks DATA
xx = DATA
DALI Compatible
xx = DALI
Clevertest
xx = CT (NOTE: Products supplied with the Clevertest Plus Symbol are
activated with Clevertest PLUS capability. Please refer to the operation
guide supplied with the product for details).
Spare Parts:
1550010
Battery, LP 3.2V 3.2Ahr, 200mm Lead Bracket
1100930
CLIFE LED Head Assembly - White
CLIFE-CKIT-NP
Lifelight, Control Gear Only, LP Lithium
Important:
It is illegalfor anyone, except for a licensed electrician toinstall ormaintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1948770 V1.5 January 2018
Installation:
This CBS2N Surface mount non-maintained Emergency Luminaire can be installed on solid surface or
used to replace an existing unit.
•Locate the installation position.
•Refer Images and Dimensions below for the Cut-out Hole and other dimensions.
•Pre-drill mounting holes
•Mount base plate and use suitable fixings to secure the base plate into the pilot holes
•Bring in supply cables via the rear entry hole or via the end of the base plate (surface mount
conduit entry)
•Terminate the supply cables to the L, N & E terminals (in the case of the –DALI or –DATA fittings
terminate the DALI or DATA cable to the terminals marked Da Da or DATA).
•Install the top cover, containing the control gear, ensuring to reconnect the control gear assembly
to the connector from the supply terminal block
•Ensure the Battery is connected
•Screw the cover to the base plate and, in the case of side/conduit entry remove the knock-out at
the end of the cover to go cover the conduit
•If the CTP capabilities are activated, please affix the CTP Status Label to a visible surface.
Networking:
When installing the product on a monitored network, (ZONEWORKS, DATA, DALI) simply insert the
relevant Smart Node PCA.
Images and Dimensions:
Initial Testing:
When the CBS2N unit is connected to the un-switched active, it must be allowed to charge the battery
for at least 24 hours. The emergency lamp only illuminates during a power failure. Conduct the following
tests:
•During the first commissioning test the emergency lamp must illuminate for at least 2 hours after
disconnection from the main supply. The results of all tests are required to be recorded in a service
logbook, which is to be kept on-site at all times. If the unit fails to illuminate for the requisite time,
remedial action must be taken to repair the situation and once completed, the unit must pass a
subsequent test.
•Press and hold Test Button for each LED head or switch Off Mains Supply, check that the
emergency lamps are On.
•Release the Test Button or Switch on Mains Supply, check that the emergency lamp is Off (Non-
maintained operation).
Below are a list of common problems and their possible causes:
Fault: The Green LED indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected.
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1 (refer
to spacing tables for installation positions):
C0=D40 C90=D40
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any fittings, on these circuits, will have their batteries discharged or “cycled”.
The Li-ion battery in the fitting has been selected to give excellent long life performance in a controlled
IEC 60598-2-22 testing environment. Excessive battery cycling will reduce through-life performance and
may lead to premature battery failure. Battery warranty claims, as a result of such abuse, are specifically
EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
Cable entry points
End view
Chain suspension points
Surface suspension points
