Honeywell Ex-Or MLS2000DALIMBW Installation and operation manual

Installation and Commissioning
Instructions
Note: HP2000 required for commissioning
HC5 or HC6 required for user override
Mid-Bay: MLS2000DIMBW for DSI ballasts
MLS2000DALIMBW for DALI ballasts
Hi-Bay: MLS2000DIHBW for DSI ballasts
MLS2000DALIHBW for DALI ballasts
MLS Digital Mid-Bay & Hi-Bay Luminaire Controllers

Red - Live
Blue - Neutral
Yellow
Green
White - MLS Bus +ve
Black - MLS Bus -ve
Electrical Connections
Polarity-free
digital output
Connection to ballast only.
Do not connect to other detectors.
750mm
lead
26mm
32.5mm
6.5mm
43.5mm sq
50mm sq
Only suitably qualified personnel should install this equipment.
Installation
Snap-in to infill panel (max 0.7mm/ 22 SWG) or use any combination of fixing holes on rear. Use only No 4
type B ¼ inch self-tapping screws. Ensure that projection of screws into pilot holes does not exceed 4.5mm.
The recommended position for the detector is in the middle of the luminaire. Where this is not possible and the
detector is fitted near one end of the lamps, please ensure that the detector is at the ‘cold’ end of the lamps.
In order to achieve satisfactory light-level regulating operation, a detector must observe a substantially greater
proportion of artificial light from the luminaire(s) under its control than from neighbouring luminaires not under its
control. This is particularly important when planning the installed layout of linear luminaires that have an
integral detector positioned at one end.
To Test Luminaire Controller Operation
Once the Luminaire Controllers have been installed within the luminaires, the HC5 or HC6 may be used to
switch luminaires ON and OFF. Luminaires with regulating ballasts will also dim and brighten.
Mounting Details
C
L
Cable entry point
14.5mm
C
L
14.5mm
20.3mm
MLS Digital Mid-Bay & Hi-Bay Luminaire Controllers

Commissioning Detectors using the HP2000
It is important that the HP2000 be held perpendicular and at a distance of between 0.5m and 2m from the detector.
1. Switch on HP2000 by pressing the red power button.
2. Point HP2000 at detector and press the DOWNLOAD button. The HP2000 will confirm the product’s identity,
and call up the correct menu of parameters and their current settings. It will also show the ballast type and the
duration (shown in hours) remaining on the 100-hour burn-in.
3. Use a combination of UP, DOWN, FORWARD and BACK buttons to navigate the parameter menu, selecting
options for each shown. (See Tips below.)
4. When options for all parameters have been selected, point the HP2000 at the detector and press the UPLOAD
button. The luminaire(s) will switch off briefly during the programming process and the HP2000 shows DATA
OK to confirm operation.
5. After a short period of inactivity (default 5 minutes), the HP2000 hibernates retaining the most recent settings.
Tips
i) Where there are only two options such as ON/OFF, a double click of the OK button toggles between them.
ii) Where there are multiple options, a double click of the OK button recalls a list of all options for that parameter.
Use the UP, DOWN and OK buttons to select.
iii) Use the OK button to go forward (through the menus) without displaying help pages.
iv) Press UPLOAD at any time to transfer all current settings from the handset to the product.
Please refer to HP2000 instructions for comprehensive commissioning details.
Factory Default Settings
These are the settings to which the units have been programmed before they leave the factory:
Parameter Options Default
Power Up On / Off On
Response Auto, Manual/Bus, Manual Auto
Off Delay 1 min - 96 hrs, 10-sec (walk-test), Disabled 20 mins
On Sensitivity 0-100 100
Bus Connect Yes / No Yes
Zones 1-4 Address 1-100 -- (no zone)
Corridor 1-2: Begin 1-100 Building Address Span -- (no zone)
Corridor 1-2: End 1-100 Building Address Span -- (no zone)
Global 1-2 Rx Yes / No No
Start Lamps Max / Min Max
Entry Scene 1-6 1
Bright Out Yes / No No
Dimming Reg 50%-Reg100% Reg 100%
Lamp Max 10%-100% 100%
Fade to Off Yes / No No
When Vacant 10 Exit Scenes Off
Set-Point High 0-1023 1023
Set-Point Low 0-1023 1023
100 Hour Burn-In See Application Note: AN4028 0 hr
Additional feature accessible under Utilities:

W5101A
Technical Data
2
MLS CABLE: 1.5mm unscreened twisted pair : see Application Note AN4001
OPERATING VOLTAGE: 230V 50Hz (UK & Europe)
CAPACITY: Digital DSI - 4 ballasts max
DALI - 1 ballast max
WEIGHT: 50g
COLOUR: White bezel
MATERIAL: Flame retardant PC/ABS
IP RATING: 4X
o o
OPERATING TEMPERATURE: 0 C to 55 C
At the end of their useful life
the packaging and product
should be disposed of via a
suitable recycling centre.
Do not dispose of with normal
household waste.
Do not burn.
Ex-Or
Novar ED&S LImited
Haydock Lane, Haydock, Merseyside WA11 9UJ
Tel: [phone]
Fax: [phone]
Email: [e-mail]
www.ex-or.com
Important Additional Notes
1. Ameans for disconnection must be incorporated in the fixed wiring in accordance with the current wiring regulations.
2. Although nominally 12V, the dimming output is not SELV and therefore should be treated with the same respect as mains
with regard to wiring practice. The 0V line of the dimming output is almost at Neutral potential.
3. The dimming control output should be connected only to the control input of the ballasts - never to other detectors.
4. This equipment should be used to control only those ballasts powered from the same phase as the detector.
5. Do not connect mains to the MLS bus.
2
6. It is imperative that the MLS bus is wired with the correct type of cable; normally it should be 1.5mm unscreened twisted pair.
Please readApplication NoteAN4001 for more details.
7. Due to the fact that the photocell is on the ceiling looking down, it is not possible for measurements made with a lux meter on
the working plane to remain constant when daylight illuminates the ceiling and the working plane to a differing extent.
Therefore, products of this type should be regarded as capable of maintaining anAPPROXIMATE light level only.
8. This equipment switches lights no more frequently than would a responsible human occupant. However, manufacturers of
some particular lighting types (e.g. ‘2D’luminaires) may specify a maximum number of switching cycles in order to achieve a
predicted lamp life. Please check with the manufacturer of the luminaires to ensure that they are compatible with automatic
controls in this respect.
h
d
Mid-Bay:
MOUNTING HEIGHT: 12.0m max
RANGE: Cone-shaped detection pattern,
diameter at floor level (d) = 1.75 x mounting height (h)
Hi-Bay:
MOUNTING HEIGHT: 16.0m max
RANGE: Cone-shaped detection pattern,
diameter at floor level (d) = 1 x mounting height (h)
h
d
