MicroMAX Pro
User & Maintenance Manual

MAN-MAXPRO
REV. B.0.
OTHER LUMIDOR PRODUCTS
2
Other Lumidor Products Please visit our website at www.lumidor.com for other
products that may be applicable to your needs.
DISCLAIMER
Notwithstanding any stated, written or implied warranty that
may be associated with the sale, purchase, or use of its
products, Lumidor, 11221 Interchange Circle South, Miramar,
Florida, 33025, a subsidiary of Zellweger Analytics, will not be
responsible for any damage or injury resulting to any person or
property that may be construed as resulting from a malfunction
of any of our products if said product has not been operated or
maintained in accordance with our instructions as detailed in
instruction sheets or printed manuals, or if the product has
been tampered with, or serviced by, any other than our factory
or other authorized service agent.
Copyright Lumidor, June 2000.
Printed in U.S.A.
MAN-MAXPRO
REV: B.0

MAN-MAXPRO
REV. B.0.
CAUTIONS AND WARNINGS
3
Cautions and Warnings
WARNING
DO NOT PROCEED BEFORE READING
To ensure proper functioning and use of this product, do
not use this instrument until you read and completely
understand this operating manual. It contains operating
and maintenance procedures to ensure proper instrument
function. For your safety, you are required to calibrate this
instrument periodically. Please refer to the calibration
section of this manual
Substitution of components may impair intrinsic safety.
Use only MPRO-BPR NiMH rechargeable battery pack, or
MPRO-BPA alkaline battery holder with four each of the
following alkaline cells only: Duracell Procell-2400,
Duracell MN-2400, and Eveready E-92 or EN-92. Observe
proper polarity when installing alkaline batteries.
CAUTION
Do not change or charge batteries in a hazardous location.
The LEL (Lower Explosive Level) range of this monitor is
factory calibrated to methane. If monitoring a different
combustible gas, calibrate the combustible gas range of
the monitor to the appropriate gas.
This instrument has not been tested in atmospheres
exceeding 21% oxygen.
Calibration is required when sensors are changed or
added to the instrument.

MAN-MAXPRO
REV. B.0.
CAUTIONS AND WARNINGS
4
WARNING
Use only the approved accessories indicated in this
manual.
Do not connect the instrument to a PC in a potentially
hazardous environment.
AUSTRALIAN OR NEW ZEALAND
CUSTOMERS:
Use only supplied type approved charger when charging
from normal 240VAC outlet in Australia or New Zealand.

MAN-MAXPRO
REV. B.0.
LIFETIME WARRANTY
5
Lifetime Warranty This instrument is warranted, to the original end-user
purchaser, against defects in materials and workmanship for
the life of the product, excluding the battery and pump, which
carry a two year limited warranty. During this period Lumidor
will repair or replace defective parts on an exchange basis,
F.O.B. the factory at Miramar, Florida. The end-user purchaser
will pay freight charges to and from Lumidor. The decision to
repair or replace parts shall be determined by Lumidor.
Sensor Warranties
(1) The oxygen sensor is guaranteed to operate
satisfactorily for two years from the date of sale (i.e. the
date of shipment) and will be replaced at no charge
within that period only if it will not provide a correct
reading after calibration by authorized service
personnel. Physical or chemical damage, resulting from
exposure to improper elements, is not covered.
(2) The combustible sensor is guaranteed to operate
satisfactorily for two years from date of sale (i.e. from
date of shipment). If It will not provide a correct reading
after calibration by authorized service personnel, it will
be replaced at no charge within that period. This
guarantee is void if it has been contaminated by some
unusual substance, including but not limited to, water
and/or other liquids, oily compounds, corrosives,
silicones, lead vapors, extremely high concentrations of
combustible gases, and various particulates which may
inhibit gas flow to the sensor element.
(3) The toxic sensors are guaranteed to operate
satisfactorily for two years (18 months for CL2, CLO2
and HCN sensors, 12 months for the NH3 sensor) from
the date of sale (i.e. the date of shipment). They will be
replaced at no charge within that period only if they will
not provide a correct reading after calibration by
authorized service personnel, and only if the sensor
membranes exhibit no physical or chemical damage
resulting from exposure to improper substances.

MAN-MAXPRO
REV. B.0.
LIFETIME WARRANTY
6
Conditions and Exclusions
To maintain this warranty, purchaser must perform
maintenance and calibration as prescribed in the instrument
operation manual, including prompt replacement or repair of
defective parts and such other necessary calibration,
maintenance and repair as may be required, according to the
use of the instrument, in the reasonable judgment of Lumidor.
Normal wear and tear, and parts damaged by abuse, misuse,
negligence or accidents are specifically excluded from the
warranty.
Purchaser acknowledges that, notwithstanding any contrary
term or provision in the purchaser's purchase order or
otherwise, the only warranty extended by Lumidor is the
express warranty contained herein. Purchaser further
acknowledges that there are no other warranties expressed or
implied, including without limitation, the warranty of
merchantability or fitness for a particular purpose; that there
are no warranties which extend beyond the description of the
face hereof; that no oral warranties, representations, or
guarantees of any kind have been made by Lumidor, its
distributors or the agents of either of them, that in any way alter
the terms of this warranty; that Lumidor and its distributors
shall in no event be liable for any consequential or incidental
damages, including but not limited to injury to the person or
property of the purchaser or others, and from other losses or
expenses incurred by the purchaser arising from the use,
operation, storage or maintenance of the product covered by
the warranty; that Lumidor's liability under this warranty is
restricted to repair or replacement of defective parts at
Lumidor sole option; and that Lumidor neither assumes nor
authorizes any other person to assume for it any other
warranty. The warranty shall be void if serial numbers affixed
to the products are removed, obliterated or defaced.
Lumidor, Miramar, Florida

MAN-MAXPRO
REV. B.0.
TABLE OF CONTENTS
Section Page
7
Table of Contents
1. Preparation for Use 10
1.1 Unpacking 10
1.2 Charging 10
2. General Description 12
3. Features 14
4. Operating Instructions 18
4.1 Turn-on 19
4.2 Standard Mode Sequence 19
4.3 Testing Sensors and Alarms 20
4.4 Continuous Monitoring 22
4.5 Remote Sampling (Pretesting) 22
4.6 Alarms 23
4.7 Clearing Memory 24
4.8 Turn-off 24
5. Calibration 25
5.1 Calibration Frequency 25
5.2 Calibration Procedure (when all calibration
gases are in a single canister) 26
5.3 Calibration Procedure (when not all calibration
gases are in a single canister) 27
5.4 Zeroing 29
6. Programming 30
6.1 Programming Options 30
6.2 Selecting LEL Gas Type 31
6.3 Setting Date Format 32
6.4 Setting Date/Time 33
6.5 Selecting Data Log Frequency 34
6.6 Auto-zeroing 34
6.7 Displaying Last Calibration Date 35
6.8 Selecting Latching/Non-latching Gas Alarms 35
6.9 Setting Calibration Gas Level 36

MAN-MAXPRO
REV. B.0.
TABLE OF CONTENTS
Section Page
8
6.10 Setting High Alarm 37
6.11 Setting Low Alarm 37
6.12 Displaying Calibration Due Date 38
6.13 Choosing a Language 39
6.14 Selecting Immediate Alarm Mode/TWA Alarm
Mode 39
6.15 Restoring Factory Defaults 40
6.16 Calibration in Supervisory Mode 40
7. Data Logging 41
7.1 System Requirements 41
7.2 General Information 41
7.3 Program Installation 41
7.4 Uninstall Procedure 42
7.5 Starting the Program 42
7.6 Downloading Information from the MicroMax Pro 43
7.7 Displaying and Printing Data 45
7.7.1 Main Screen 45
7.7.2 Graph Screen 47
7.7.3 Current Calibration Records 49
7.7.4 Calibration History 51
7.7.5 Instrument Parameters 53
7.8 Editing Location 59
7.9 Editing Note 59
7.10 Uploading Information to the MicroMax Pro 59
7.11 Importing Files 60
7.12 Archiving Data 61
7.13 Recovering Data 62
7.14 Getting Help 63
7.14.1 Using MaxPro Log Help 63
7.14.2 Lumidor on the Web 63
7.14.3 Customer Support 63
7.14.4 MaxPro Log Version and Copyright 63
8. Maintenance 64
8.1 Battery Installation 64

MAN-MAXPRO
REV. B.0.
TABLE OF CONTENTS
Section Page
9
8.2 Alkaline Battery Pack Installation 64
8.3 NiMH Battery Pack Installation 65
8.4 NiMH Battery Pack – General Information 66
8.5 Sensor Replacement 66
8.6 Removing and Adding a Sensor 67
8.7 Cleaning 67
8.8 Pump Inlet Filter Replacement 67
8.9 Sampling Hose Maintenance 68
8.10 Storage 68
8.11 Sensor and Battery Disposal 68
9. TroubleShooting 70
9.1 Sensor Not Recognized (“XXX” Displayed) 70
9.2 “LEL FAIL” Message 70
9.3 Low Flow Alarm When Sampling Hose Attached 71
9.4 “Calibration Fail” Message 71
9.5 Instrument Will Not Turn On 71
9.6 Instrument is in Diffusion Mode but Pump
ComesOnWhenCalibrating 71
Appendix A Specifications 72
Appendix B Turn-on Sequence 84
Appendix C Mode Sequence, Standard Mode 87
Appendix D Mode Sequence, User Set-up Mode 88
Appendix E Alarm Modes 92
Appendix F Charging Screens 94
Appendix G Calibration Kits 95
Appendix H Optional Accessories 96
Appendix I Replacement Parts 97
Appendix J Calibrating with Multiple Canisters 99
Appendix K Calibration Gases 101

MAN-MAXPRO
REV. B.0.
1. PREPARATION FOR USE
10
1. PREPARATION FOR USE
1.1 UNPACKING
Check for these items:
•Packaging (retain for possible future use)
•Instrument with internal rechargeable battery pack
•Calibration certificate
•Standard accessories:
–AC battery charger
–Alkaline battery holder
–Dust filter
–10-foot sampling hose with filter and water trap
–Rubber boot with belt clip and neck strap
–Instruction manual
1.2 CHARGING
CAUTION
Do not change or charge batteries in a hazardous location.
Do not try to turn on or otherwise operate this instrument
until it is fully charged.
Use only the MPRO-1 A.C.charger, the MPRO-2 220 volt
AC charger, or the MPRO-6 vehicular charger. Use of any
other charger may cause permanent instrument damage
and will void any warranties. The charge period is
dependent on the condition of the batteries, but should not
exceed about 4 hours for a completely depleted battery
pack. Partially depleted packs will be charged in a much
shorter period of time.

MAN-MAXPRO
REV. B.0.
1. PREPARATION FOR USE
11
To commence charging with the charger supplied with
AC power, connect the charger plug to the instrument port
(See Figure 1) and instrument display should read
“CHARGING BATTERY”. When charging is completed,
“CHARGE COMPLETE” is displayed. The instrument is now fully
charged and ready for use.
If charging is attempted without the rechargeable battery, or
with alkaline batteries, “CHECK BATTERY” is displayed.
Figure 1 Charging the MicroMax Pro

MAN-MAXPRO
REV. B.0.
2. GENERAL DESCRIPTION
12
2. GENERAL DESCRIPTION
The MicroMax Pro is a programmable instrument that can
monitor one, two, three, four, or with Combo-Tox sensor, up to
five gases. It combines proven sensor performance and
electronics in a small, lightweight, and easy to use monitor. It
consists of the monitor, NiMH rechargeable battery pack,
battery charger, alkaline battery holder, rubber boot with neck
strap and belt clip, dust filter, 10-foot sampling hose with filter
and water trap, calibration certificate and instruction manual.
Prior to shipment, the monitor was configured with default
alarms and other settings, tested and calibrated. After
charging, it is ready for use.

MAN-MAXPRO
REV. B.0.
2. GENERAL DESCRIPTION
13
Figure 2 MicroMax Pro
Port
Battery Compartment
Large Alarm LED Bar
Rear View
Inlet ON/OFF
Switch
MODE
Switch

MAN-MAXPRO
REV. B.0.
3. FEATURES
14
3. FEATURES (1) Liquid Crystal Display
High contrast 4 lines by 16 character alphanumeric
display that indicates gas concentration of up to four
gases simultaneously.
(2) Display Backlighting
Automatic fiber-optic backlight provides display
readability in dim or dark environments.
(3) Automatic Toxic Sensor Recognition
Microprocessor automatically recognizes toxic sensors
when plugged in. Monitor displays corresponding gas,
sets gain, corrects alarm levels and initializes
temperature compensation.
(4) User Selectable Power Source
User has an option of powering instrument either with
the supplied NiMH rechargeable battery pack or with
four “AAA” alkaline cells (use only the cells that are
approved for use), mounted in the supplied battery
holder.
(5) User Friendly Interface
User friendly interface is intuitive for ease of use and
simplicity of operation.
(6) Extensive Programming Options
There are many programming options to custom-
configure the instrument.
(7) Programmable Gas Alarms
High and low alarm levels, TWA mode for toxics,
latching or non-latching, are all user programmable.
(8) Fully Automatic Calibration
Fast, easy, accurate calibration that requires no user
adjustments or tools.
(9) Confidence Beep
User selectable confidence beep provides a visible flash
and audible beep about every 20 seconds to confirm
instrument operation.

MAN-MAXPRO
REV. B.0.
3. FEATURES
15
(10) Voice and Display Messaging
User may select English, Spanish, French or German
for voice and display messaging.
(11) Battery Gauge
This consists of B (for battery) and a maximum of 6 bars,
as illustrated. Six bars represent full charge, while fewer
bars indicate various stages of charge. When all bars
are depleted, the instrument will run for more than an
hour, after which time a low battery alarm is indicated by
two beeps every 15 seconds. Low battery alarm will
continue for at least half an hour, after which instrument
will beep continuously and shut down. If alkaline
batteries power instrument, battery condition is
indicated on the display, not by bars, but by battery
voltage. A fresh alkaline pack will read about 5.8 volts,
and low battery warning commence anywhere from 4.0
to 4.2 volts, model dependent, while shut-off occurs
between 3.68 and 3.95 volts, model dependent.
(12) Pump or Diffusion Mode of Operation
User may choose between pump and diffusion mode of
operation. If pump is selected, ‘P’ is displayed in the
lower left corner of display and all the benefits of internal
pump operation are available. In diffusion mode, ‘D’ is
displayed. If pump mode is selected and pump fails,
instrument automatically switches to diffusion mode for
continuous operation and protection.
(13) Real Time Clock
User adjustable real time clock provides continuous
time display. If daylight savings time is selected, the
time will be automatically updated.
(14) User Selectable Calibration Gas Concentration
This feature allows the user to select the desired
calibration gas concentration, within specified limits, for
all sensors except oxygen.
B

MAN-MAXPRO
REV. B.0.
3. FEATURES
16
(15) User Selectable LEL Conversion Factors
This feature allows instrument to accurately indicate the
LEL level for a wide range of hydrocarbons after
calibrating with the methane gas.
(16) Multiple Gas Alarm Indicators
Audible and visual alarms alert user of unsafe gas
levels.
(17) Low Flow Alarm
In pump mode, a steady audible alarm is accompanied
by a visual alarm and the display indicates “LOW FLOW”.
If alarm persists, instrument will indicate “PUMP FAIL”
and switch to diffusion mode of operation.
(18) RFI Resistant Design
High resistance to RFI (radio frequency interference)
minimizes false alarms.
(19) Charge Status Recognition
The instrument automatically shuts off if charger is
connected while monitor is on. This prevents the charger
from being used as a power source, which is not
intrinsically safe. Soon after charger is connected,
display indicates “CHARGING BATTERY”.
(20) Calibration Record
The date the instrument is last calibrated and the date
that the instrument is due for the next calibration can be
displayed on the start-up under “LAST CALIBRATED”
and “CALIBRATION DUE”.
(21) Peak, STEL and TWA
The MODE button enables display of peak reading
(highest toxic or combustible and lowest oxygen levels),
STEL (15-minute accumulated short-term exposure
level), and TWA (8-hour time weighted average) since
instrument was last turned on. The STEL and TWA will
be indicated only if “ALARM TYPE” is set to “TWA ON”.

MAN-MAXPRO
REV. B.0.
3. FEATURES
17
(22) Low Battery Warning
Low battery warning is indicated by dual beep every
15 seconds, 30 minutes prior to shutdown. With alkaline
batteries, low battery warning occurs between 4.0 and
4.2 volts.
(23) Data Logging
The MicroMax Pro is supplied with data logging
capabilities and all necessary hardware, cables and
software. There are 2400 data points for storage of up
to 200 hours of data.
(24) Approvals
Intrinsic Safety:
•MPRO (Standard MicroMax Pro)
UL Classified ‘Class I, Divisions 1 & 2, Groups A, B,
C & D, Class II, Groups E, F & G’
•MPRO-A (Australian version)
SAA Certified Ex ia s Zone 0 IIB T3
•MPRO-M (MSHA version)
MSHA approved for intrinsic safety (Methane-Air
mixtures only)
•China ‘PATTERN APPROVAL CERTIFICATE’
EMC Standards: (Third Party Certified)
•EN 50270:1999
•EN 55011:1998

MAN-MAXPRO
REV. B.0.
4. OPERATING INSTRUCTIONS
18
4. OPERATING INSTRUCTIONS
Figure 3 Default Turn-on Sequence
MICROMAX PRO
VER 5.0
ON
TESTING
PLEASE WAIT
ZEROING
PLEASE WAIT
OX LEL CO H2S
19.5 10 25 10
LOW ALARM
OX LEL CO H2S
23.5 20 35 20
HIGH ALARM
VOICE ON
READY
OX LEL CO H2S
20.9 0 0 0
P 11:52 B

MAN-MAXPRO
REV. B.0.
4. OPERATING INSTRUCTIONS
19
4.1 TURN-ON
After charging the instrument, or installing fresh alkaline
batteries, turn instrument on in clean air, by depressing the
ON/OFF button until a confirming beep is heard. Release the
ON/OFF button and instrument will display the firmware
version number and “ON” before cycling through its turn-on
sequence (See Figure 3 Default Turn-on Sequence). Then
the instrument goes through “TESTING” and “ZEROING”
cycles, displays low alarm levels and high alarm levels,
indicates “VOICE ON” and “READY” and goes into normal
operating mode. In normal operating mode, gas types and
levels occupy the top two lines, the third line is blank and
available for messaging, while on the fourth line is the letter “P”
or “D”, for pump or diffusion mode of operation respectively,
the current time in 24-hour format and the battery gauge. If
alkaline batteries power instrument, battery condition is
indicated by display of battery voltage. With alkaline batteries,
voltage should be about 5.8 volts with fresh batteries, with low
battery warning occurring at between 4.0 and 4.2 volts,
depending on sensor configuration.
4.2 STANDARD MODE SEQUENCE
Figure 4 Default Standard Mode Sequence
OX LEL CO H2S
20.1 0 16 9
PEAK READING
LEL CO H2S
USER SETUP NO
OX LEL CO H2S
20.9 0 0 0
P 08:49 B

MAN-MAXPRO
REV. B.0.
4. OPERATING INSTRUCTIONS
20
Each standard mode option is available by depressing the
MODE button sequentially.
PEAK READING. The highest toxic and combustible gas
levels and the lowest oxygen levels. Depressing the ON/OFF
button while in this mode clears peak values.
USER SETUP. User setup mode allows pump, voice and
confidence beep to be turned on or off as desired. It is also
here that calibration is usually done, and memory cleared (See
Section 4.7 Clearing Memory). To enter the user setup mode,
keep depressing the MODE button until line 3 of display
indicates “USER SETUP”. Press the ON/OFF button to enter
user setup mode, to bypass each setting depress the MODE
button. To change any setting, depress the ON/OFF button.
For example, to change pump, voice, or confidence beep from
“ON” to “OFF” or vice versa, depress the ON/OFF button when
the appropriate menu item is displayed. To enter calibration
mode, depress the ON/OFF button when “CALIBRATE?” is
displayed(SeeSection5Calibration).
4.3 TESTING SENSORS AND ALARMS
It is recommended that proper alarm function be verified prior
to use by applying calibration or alarm check gas. Alarm check
gas (Test 1A) should be used only for instruments that contain
one or more of the 4 standard sensors (O2, LEL, CO or H2S).
For other configurations, use calibration gas with instrument in
normal operating mode. After testing, remember to clear the
peak values, or if “ALARM TYPE” is set to “TWA ON”, clear
memory. Test low flow alarm by placing finger over inlet when
in pump mode. If instrument does not go into low flow alarm
when inlet is blocked, instrument should be operated in
diffusion mode after entering the “USER SETUP” mode and
changing the pump status configuration to “PUMP OFF”.
Instrument should be serviced as soon as possible to fix the
problem.
