1
Introduction
Product Overview
The MS5145 Eclipseis a single-line, hand-held laser scanner.
Equipped with Honeywell’s patented CodeGate®technology, Eclipse can be
used in a wide variety of applications. CodeGate technology allows the user to
easily target the desired bar code and complete the data transmission with a
simple press of a button. This combination makes Eclipse a perfect selection for
menu scanning, point-of-sale, document processing and inventory control.
With state-of-the-art scanning technology embedded inside, the MS5145 Eclipse
has a longer working range and a wider scan field than a typical CCD. The width
of the scan line grows as the scanner moves further away from bar codes. In
addition, the laser beam pulses, making lining up bar codes easy and when the
scanner senses a bar code (CodeSense®Mode), the laser beam automatically
switches to scan mode and activates CodeGate to ensure high-speed scanning
and accuracy.
Many standard features are included such as: user configurable Flash ROM,
PowerLink user-replaceable cables, MetroSet®2 and MetroSelect®configuration,
and data editing (parsing).
Model Number Interface
MS5145 – 00 Laser Emulation
MS5145 – 11 RS485, RS232-TXD, RXD, RTS, CTS
MS5145 – 14 RS232 - TXD, RXD, RTS, CTS, DTR, DSR
MS5145 – 38 TTL RS232 Low Speed USB,
Keyboard Emulation or Serial Emulation*
MS5145 – 40 Full Speed USB
MS5145 – 41 RS232/Light Pen Emulation
MS5145 – 47 Keyboard Wedge, Stand Alone Keyboard and TTL RS232
Transmit/Receive
* Configurable for Keyboard Emulation Mode or Serial Emulation Mode. The default
setting is Keyboard Emulation Mode.
Applicable for IBM®Host applications.

2
Basic Kit Components
Part # Description
MS5145 Eclipse Scanner
00-02544 MetroSelect Single-Line Configuration Guide*
70-79016 MS5100 Eclipse Series Installation and User’s Guide*
* Manuals are available for download from www.honeywellaidc.com.
Optional Accessories
Part # Description
AC to DC Power Transformer- Regulated 5.2VDC @ 1A output.
46-00525 90VAC to 255VAC, United States, Canada and Japan
46-00526 90VAC to 255VAC, Continental European
46-00527 90VAC to 255VAC, United Kingdom
46-00528 90VAC to 255VAC, Australia
46-00529 90VAC to 255VAC, China
46-00530 90VAC to 255VAC, India
Other items may be ordered for the specific protocol being used. To order additional items,
contact the dealer, distributor, or customer service. See page 45 for contact information.

3
Part # Description
55-55000x-3 RS232 PowerLink Cable with Built-in Power Jack
straight cord, long strain relief, black
55-55002x-3 Keyboard Wedge PowerLink Cable with Adapter
straight cord, long strain relief, black
55-55020x-3 Stand Alone Keyboard PowerLink Cable,
straight cord, long strain relief, black
55-55235x-N-3 USB Low Speed Communication Cable, Type A
straight cord, long strain relief, black
55-55200x-N-3
USB Full Speed Cable, Locking Plus-Power™ Type A
straight cord, long strain relief, black
Note: This cable is for use with full speed USB (-40)
interface only.
MVC** RS485 Applications,
MVC Cable, ±12VDC to +5.2VDC
** Contact a customer service representative for additional information on the MVC
cable series and the host connections available.
46-46633 Countertop Stand
Other items may be ordered for the specific protocol being used. To order additional items,
contact the dealer, distributor, or customer service. See page 45 for contact information.

MS5145 Components
Item No. Description
1 Mode Select Button/CodeGate Button (see page 13)
2 Red LED (see page 15)
3 Green LED (see page 15)
4 Pin Hole for Cable Release (see page 6)
5 Red Output Window (Laser Aperture)
6 Speaker (see page 14)
7 10-Pin RJ45, Female Socket (see page 31)
Figure 1. Scanner Components
Maintenance
Smudges and dirt on the unit’s window can interfere with the unit’s performance.
If the window requires cleaning, use only a mild glass cleaner containing no
ammonia. When cleaning the window, spray the cleaner onto a lint free, non-
abrasive cleaning cloth then gently wipe the window clean.
If the unit’s case requires cleaning, use a mild cleaning agent that does not
contain strong oxidizing chemicals. Strong cleaning agents may discolor or
damage the unit’s exterior.
4

Caution and Serial Number Labels
Figure 2. Label Location on the Bottom of the Scanner with Example
Caution: To maintain compliance with applicable standards, all circuits connected to
the imager must meet the requirements for SELV (Safety Extra Low Voltage)
according to EN/IEC 60950-1.
5
To maintain compliance with standard CSA C22.2 No. 60950-1/UL 60950-1
and norm EN/IEC 60950-1, the power source should meet applicable
performance requirements for a limited power source.

Cable Installation and Removal
Installation
1. Insert the cable’s modular connector into the socket on the scanner.
2. Pull gently on the cable strain relief to ensure the cable is installed.
Note: If the PowerLink cable is not fully latched, the unit can power
intermittently.
Figure 3.
Removal
Disconnect the power supply from the PowerLink cable and turn off power to the
host system before removing the cable from the scanner.
1. Locate the small ‘pin-hole’ on the front
side of the scanner near the end of the
handle.
2. Bend an ordinary paperclip into the shape
shown.
3. Insert the paperclip (or other small metallic
pin) into the small ‘pin-hole’. There will be
a faint ‘click’ when the connector’s lock
releases.
4. Pull gently on the cable’s strain-relief to
remove the cable.
Figure 4.
6

Installation
RS232, Light Pen or Laser Emulation
1. Turn off the host system.
2. Plug the male, 10-pin RJ45 end of the
PowerLink cable into the 10-pin socket
on the MS5145.
3. Connect the 9-pin female end of the
PowerLink cable to the appropriate
communication port on the host device.
4. Plug the external power supply into the
power jack on the PowerLink cable.
5. Check the AC input requirements of the
power supply to make sure eth voltage
matches the AC outlet. The outlet must
be located near the equipment.
6. Connect AC power to the transformer.
7. Turn on the host system.
Figure 5. RS232, Light Pen, or
Laser Emulation
Installation Notes
Plugging the scanner into the serial port of the PC does not guarantee
that scanned information will appear at the PC. A software driver and
correct configuration settings are also required for proper
communications to occur.
Powering the MS5145 directly from the host device can sometimes
cause interference with the operation of the scanner or the computer.
Not all computers supply the same current. For this reason, using an
external power supply is recommended. For additional information,
contact a customer service representative.
All MS5145-00 scanners leave the factory with the Laser Emulation
Mode enabled. If recall defaults is scanned while re-configuring the
scanner the Laser Emulation Mode will no longer be enabled. Refer to
the MS5145-00 Laser Emulation Mode section of the MetroSelect
Single-Line Configuration Guide for information on enabling the Laser
Emulation Mode.
See caution on page 5.
7

RS485
1. Turn off the host system.
2. Plug the male 10-pin RJ45 end of the
MVC cable into the 10-pin socket on the
MS5145.
3. Connect the other end of the MVC cable
to Port 9 of the host device.
4. Turn on the host device
Figure 6. RS485
See caution on page 5.
8

Keyboard Wedge
1. Turn off the host system.
2. Plug the male, 10-pin RJ45 end of the
PowerLink cable into the 10-pin
socket on the MS5145.
3. Disconnect the keyboard from the
host/PC.
4. Connect the Y ends of the PowerLink
cable to the keyboard and the host’s
keyboard port. If necessary, use the
supplied adapter cable to make the
connections.
5. Plug the external power supply into
the power jack on the PowerLink
cable.
6. Check the AC input requirements of
the power supply to make sure the
voltage matches the AC outlet. The
outlet must be located near the
equipment Figure 7. Keyboard Wedge
7. Connect AC power to the transformer.
8. Turn on the host system.
Installation Note
Powering the MS5145-47 directly from the computer can sometimes cause
interference with the operation of the scanner or the computer. Not all computers
supply the same current through the keyboard port, explaining why a scanner
may work on one computer and not another. Contact a customer service
representative if an external power supply is required.
See caution on page 5.
9

Stand-Alone Keyboard
1. Turn off the host system.
2. Connect the 10-pin RJ45 male
connector into the jack on the Eclipse.
There will be a ‘click’ when the
connection is made.
3. Connect the L-shaped plug of the
power supply into the power jack on
the PowerLink cable.
4. Make sure the AC input requirements
of the power supply match the AC
outlet. Connect the power supply into
an AC outlet. The outlet should be
near the equipment and easily
accessible.
5. Connect the PowerLink cable to the
keyboard port on the host system.
6. Turn on the host system.
Figure 8. Stand-Alone Keyboard
Installation Note
Powering the MS5145-47 directly from the computer can sometimes cause
interference with the operation of the scanner or the computer. Not all computers
supply the same current through the keyboard port, explaining why a scanner
may work on one computer and not another. Contact a customer service
representative if an external power supply is required.
See caution on page 5.
10

USB: Low Speed USB (-38)
Full Speed USB (-40)
1. Turn off the host system.
2. Connect the 10-pin RJ45 male
connector of the USB cable into the
jack on the Eclipse. There will be a
‘click’ when the connection is made.
3. Connect the other end of the USB
cable to the host USB port.
4. Turn on the host system.
Figure 9. USB
Installation Notes
As a default, the MS5145-38 leaves the factory with USB Keyboard
Emulation Mode enabled.
For information on configuring the MS5145-38 for USB Serial Emulation
Mode, please refer to the USB section of the MetroSelect Single-Line
Configuration Guide..
Plugging the scanner into a port on the host system does not guarantee
that scanned information will be communicated properly to the host
system. All Eclipse’s are shipped already configured with a set of
factory defaults. Please refer to the MetroSelect Single-Line
Configuration Guide or MetroSet2’s help files for instructions on
changing the scanner’s factory default configuration. The scanner and
host system must use the same communication protocols.
See caution on page 5.
11

12

Scanner Operation
Modes of Operation
CodeGate®, Out-of-Stand
CodeGate activates when removed from the stand
Bar code data is transmitted when the button is pressed
Manual Activation Mode*, Out-of-Stand
Button activates laser
Bar code data is scanned and transmitted while button is held down
CodeGate Manual Activation Mode*
* This feature is not a default
setting. Refer to the MetroSelect
Configuration Guide for
instructions on enabling the
Manual Activation Mode.
Figure 10. CodeGate Enabled Figure 11. Manual Activation Mode
13

14
Audible Indicators
When the MS5145 scanner is operational, the scanner provides audible
feedback to indicate the status of the scanner and the last scan. Eight settings
are available for the tone of the beep (normal, six alternate tones and no tone).
For instructions on how to change the tone of the beeper, refer to the Single-Line
MetroSelect Configuration Guide.
One Beep – On Power Up
The green LED will turn on, then the red LED will flash and the scanner will beep
once. The red LED will remain on for the duration of the beep. The scanner is
now ready to scan.
One Beep – During Operation
When the scanner successfully reads a bar code, the red LED will flash and the
scanner will beep once (if programmed to do so). If the scanner does not beep
once and the red light does not flash, then the bar code has not been
successfully read.
Three Beeps – During Operation
When entering the configuration mode, the red LED will flash while the scanner
simultaneously beeps three times. The red LED will continue to flash until the
unit exits configuration mode. Upon exiting configuration mode, the scanner will
beep three times and the red LED will stop flashing.
When configured for communication timeout, three beeps during operation will
indicate that a communication timeout has occurred.
Three Beeps – On Power Up
This is a failure indicator. Refer to the Failure Modes section of this guide on
page 16.
Razzberry Tone
This is a failure indicator or an invalid code read during configuration mode.
Refer to the Failure Modes section of this guide on page 16.

Visual Indicators
The MS5145 is equipped with a red LED and green LED, which indicate the
scanner’s state and the status of the current scan when the unit is in operation.
Figure 12. LED Color and Location
Green and Red LEDs Are Off
The LEDs will not be illuminated if the scanner is not receiving power from the
host or transformer.
Steady Green
Indicates normal pulse or continuous laser operation. Accompanied by a
razzberry tone, it indicates that an invalid bar code has been scanned.
Flashing Green
After a period of inactivity, the ON time of the pulsing laser will be shortened.
During this time the green LED will flash. This indicates that the scanner is in a
power saver mode. When a bar code enters the laser field, the scanner will
wake up and return to normal pulse mode.
Steady Green and Single Red Flash
When the scanner successfully reads a bar code, the red LED will flash and the
scanner will beep. If the red LED does not flash and the scanner does not beep,
then the bar code has not been successfully read.
Steady Green and Steady Red
After a successful read, the scanner transmits the data to the host device. Some
communication modes require that the host inform the scanner when data is
ready to be received. If the host is not ready to accept the information, the
scanner’s red LED will remain on until the data can be transmitted.
Steady Green and Continuous Flashing Red
When entering the configuration mode, the red LED will flash, the green LED will
turn on and the scanner will beep three times. The red LED will continue to flash
and the green LED will stay on until the unit exits the configuration mode.
15

16
Failure Modes
One Razzberry Tone – On Power Up
This indicates the scanner has experienced a laser or flipper subsystem failure.
Return the unit for repair to an Authorized Service Center.
Continuous Razzberry Tone with no LEDs
If, upon power up, the scanner emits a continuous razzberry tone, then the
scanner has an experienced an electronic failure. Return the unit for repair to an
Authorized Service Center.
Three Beeps – On Power Up
If the scanner beeps three times on power up, then the non-volatile memory
(NovRAM) that holds the scanner configuration has failed. Return the unit for
repair to an Authorized Service Center.
