Honeywell H2W2PRV3 User manual

Document 800-22215 – Rev. A – 06/2016
H2W2PRV3/H2W4PRV3 WDR IR
Rugged Micro Dome IP Camera
Quick Installation Guide
Document 800-22215 – Rev A – 06/2016
Thank you for purchasing an H2W2PRV3/
H2W4PRV3 camera. Follow the instructions in this
guide to install and log in to your camera. For
instructions on configuring the camera, refer to the
Performance Series IP Cameras User Guide on the
installation CD that came with your camera.
If you require additional assistance, contact Tech
Support (contact info is listed on the back page).
Cautions and Warnings
WARNING To ensure compliance with electrical safety standards, this product
is intended for use with a Listed Power Adapter marked “Limited Power Source”
or “LPS” on the unit, output rated to 12 VDC, minimum 0.33 A, TMA=60 deg C, or
from Power over Ethernet (PoE) provided by Listed Information Technology
Equipment meeting IEEE 802.3af PoE standard.
The Ethernet connection is not intended to be connected to exposed (outside plant)
networks. Do not connect two power sources to the camera at the same time.
CAUTION Invisible LED radiation (850 nm). Avoid exposure to beam.
Regulatory Statements
Information to the User: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
Note Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
Important Safeguards
•Read and keep these instructions.
•Do not aim the camera toward a bright light source for extended periods to
prevent damage to the imager. Avoid operating the unit under or close to
unstable light sources (may cause flickering), or close to fluorescent lamps or
objects reflecting light.
•Do not touch the camera lens.
•Do not drop the camera or subject it to physical shock.
•Do not use a strong or abrasive detergent when cleaning the camera.
•Avoid operating or storing the unit in extremely humid, dusty, hot/cold
environments, where the operating temperature is outside the recommended
range of -4°F to 140°F (–20°C to 60°C).
Note Do not apply power to the camera before completing installation.
Note Ensure that the installation surface can support at least three times the
weight of the camera.
CAUTION
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF
ELECTRIC SHOCK IS PRESENT
WITHIN THE UNIT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
THIS SYMBOL INDICATES THAT
IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS
ACCOMPANY THIS UNIT.
RISK OF ELECTRIC
SHOCK
DO NOT OPEN

© 2016 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell. The information in this publication is believed to be accurate in all
respects. However, Honeywell cannot assume responsibility for any consequences resulting from the use thereof. The information contained herein is subject to change without notice. Revisions or new additions to this publication
may be issued to incorporate such changes.
MicroSD card slot
Figure 2-1
Figure 2-2 Figure 2-3
Before You Begin
Before you begin, check that you have received all of the parts listed below. If any
parts are missing or damaged, contact your dealer immediately.
•Camera
•Installation CD
•Quick installation guide
•Allen key (L-wrench)
•Self-tapping screws (×4)
•Plastic wall anchors (×4)
•Mounting template
Required tools
•Phillips screwdriver
•Drill with appropriate bit for pre-drilling wall anchor holes
CAUTION Installation and servicing should be performed only by qualified and
experienced technicians to conform to all local codes and to maintain your warranty.
Preparing the Mounting Surface
1. Inspect the site where you want to install the camera. The mounting surface
must be flat and capable of supporting at least three times the weight of the
camera.
2. Remove the backing from the mounting template sticker and affix the sticker to
the mounting surface.
Note If you are using the side exit for the cable, note
the orientation of the cable exit notch. In outdoor
installations the notch should point downwards to
prevent water from entering the camera housing.
3. Drill three screw holes at the locations indicated on
the mounting template sticker and insert the three
supplied plastic anchors in the holes.
4. If you are flush mounting the camera and want to
store the cables inside the wall or ceiling, drill a
hole at the cable exit position on the mounting
template and then pull the cables through the hole.
Mounting the Camera
1. Use the supplied Allen key to remove the dome cover from the camera assembly
and set it aside.
2. If local storage is needed, insert a microSD card into the microSD card slot as
shown in Figure 2-1.
3. Connect one end of the Ethernet cable to the RJ-45 port on the camera.
4. If the other end of the Ethernet cable is NOT connected to a PoE switch or NVR,
connect the power connector of the camera to a 12 VDC power source.
5. Attach the camera assembly to the mounting surface using the supplied screws.
Aiming the Camera and Logging On to the Camera
1. Aim the camera lens in the desired direction as shown in Figure 2-2 and Figure 2-3.
Note Lens adjustment can be divided into left/right and up/down adjustment.
Left/right adjustment can be done manually as shown in Figure 2-2. For up/down
adjustment, you must insert the L-wrench into the hole on the lens and turn it as
shown in Figure 2-3.
2. Tighten the adjustment screws to secure the camera lens in place.
3. Reattach the dome cover.
4. If the camera is connected to the PoE port of a Honeywell Embedded NVR, you
can log on to the camera directly from the NVR. To log on from a PC:
a. Install the Honeywell Config Tool from the installation CD.
b. Use the Config Tool to discover the camera and open the camera’s
webpage.
c. Log on to the camera as the admin user. The default user name is admin
(case-sensitive) and the default password is 1234.
Note Only Internet Explorer 11 and Firefox 46.0.1 (or later) browsers are supported.
www.honeywell.com/security
[phone]
(North America only)
www.honeywell.com/security/uk
[phone]
(Europe only)
www.asia.security.honeywell.com
[phone]
(Asia Pacific only)
Document 800-22215 – Rev A – 06/2016
