Honeywell H4W2PER2 User manual

PERFORMANCE SERIES IP
H4W2PER2*/H4W4PER2*/H4W8PER2*
WDR IR Dome Camera
Quick Installation Guide
(The last “*” represents V orL,and other numbers orletters)
Thank you for purchasing a Honeywell Performance Series IP
camera. Follow theinstructions inthis guide to install and log in to
your camera.
For instructions onconfiguring thecamera, refer tothe user guide
on the DVDthat came with your camera. Ifyourequire additional
assistance, call the number listed for your region ontheback cover.
Cautions and Warnings
WARNING To ensure compliance with electrical safety standards, this product is
intended for use with a Listed Power Adapter marked “Limited Power
Source” or “LPS” on the unit, output rated to 12 VDC, minimum 0.33 A,
TMA=60 deg C, or from Power over Ethernet (PoE) provided by Listed
Information Technology Equipment meeting IEEE 802.3af PoE standard.
CAUTION
The Ethernet connection is not intended to be connected to exposed
(outside plant) networks. Do not connect two power sources to the camera
at the same time.
CAUTION
Invisible LED radiation (850 nm). Avoid exposure to beam.
Important Safeguards
•Read and keep these instructions.
•Confirm the installation surface can support at least three times the weight of the
camera.
•Do not aim the camera toward a bright light source for extended periods to prevent
damage to the imager.
•Avoid operating the unit under or close to unstable light sources (may cause flickering),
or close to fluorescent lamps or objects reflecting light.
•Do not touch the camera lens.
•Do not drop the camera or subject it to physical shock.
•Do not use a strong or abrasive detergent when cleaning the camera.
•Avoid operating or storing the unit in extremely humid, dusty, hot/cold environments,
where the operating temperature is outside the recommended range of -22°F to 140°F
(–30°C to 60°C).
•Do not apply power to the camera before completing installation.
Before You Begin
Before you begin, check that you have received all of the parts listed below. If any parts are
missing or damaged, contact your dealer immediately.
•Camera
•Installation DVD
•Quick Installation Guide
•Allen Key (L-wrench)
•Self-tapping Screws (×4)
•Plastic Wall Anchors (×4)
•Mounting Template
CAUTION Installation and servicing should be performed only by qualified and experienced
technicians to conform to all local codes and to maintain your warranty.
Mounting surface
Mounting template
Anchors
Camera assembly
Self-tapping screws
Dome cover
Locking screw
Allen key
Preparing the Mounting Surface
1. Apply the mounting template to the mounting surface.
Note Observe the orientation of the cable exit notch on the bracket base. In outdoor
installations, the notch should point downward to prevent water from entering the
camera housing.
CAUTION
THIS SYMBOL INDIC ATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF
ELECTRIC SHOCK IS PRESENT
WITHIN THE UNIT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
THIS SYMBOL INDIC ATES THAT
IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS
ACCOMPANY THIS UNIT.
RISK OF ELECTRIC
SHOCK
DO NOT OPEN

© 2021 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell. The information in this publication is believed to be accurate in all respects. However, Honeywell
cannot assume responsibility for any consequences resulting from the use thereof. The information contained herein is subject to change without notice. Revisions or new additions to this publication may be issued to incorporate such changes.
2. Using the mounting template as a guide, drill three pilot holes in the mounting surface,
then hammer the supplied anchors into the holes.
3. Drill a cable entry hole in the mounting surface, then pull the required cables through the
hole.
Mounting and Aiming the Camera
1. Remove the dome cover from the camera assembly using the supplied Allenkey.
2. If you are using a microSD card with the camera, install it before continuing. See below for
details.
1. Push and
slide metal
shell to
unlock
position.
2. Open
metal
shell.
3. Insert microSD
card.
4. Close metal
shell and
slide to lock
position.
3. Connect the Ethernet cable to the RJ-45 port on thecamera.
4. If the other end of the Ethernet cable is not connected to a PoE (Power-over-Ethernet)
switchor NVR, connect the power connector of the camera to a 12 VDC power source.
5. Fix the camera assembly to the mounting surface using the supplied screws.
6. Aim the camera lens in the desired direction, then tighten the screws on the camera
assembly.
7. Reattach the dome cover.
Logging On to the Camera
If the camera is connected to the PoE port of a Honeywell Embedded NVR, it can be configured
using the NVR.
To log on remotely from a PC, install the Unified Tool from the software and documentation DVD,
find the camera on the network, and then open the web browser. The default user name is admin
(case-sensitive) and the default password is 1234.
Note

Only Internet Explorer 11 (or later) is supported.

IP address of the device is assigned automatically by DHCP server. If the DHCP server is not
available, the device will acquire 192.168.1.108 as the default IP address.
Adjusting the Zoom and Focus Settings
After you have logged on to the camera, go to Setup Camera Conditions Zoom and Focus to
fine-tune the camera’s zoom and focus settings.
Recommended Recorders
HEN*4 8/16/32/64-channel Focus 4K NVRs (H.264 and H.265)
HEN*3 4/8/16/32-channel Performance Series NVRs (H.264 and H.265)
Regulatory Statements
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Note Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Manufacturer’s Declaration of Conformance
North America The equipment supplied with this guide conforms to UL 60950-1 and CSA C22.2 No.
60950-1.
Europe The manufacturer declares that the equipment supplied is compliant with the European
Parliament and Council Directive on the restriction of the use of certain hazardous substances in
electrical and electronic equipment (2015/863/EU), the Low Voltage Directive (2014/35/EU) and the
essential requirements of the EMC directive (2014/30/EU), conforming to the requirements of standards
EN 55032 for emissions, EN 50130-4 for immunity, and EN 62368-1 for electrical equipment safety.
WEEE (Waste Electrical and Electronic Equipment)
Correct disposal of this product (applicable in the European Union and other European
countries with separate collection systems). This product should be disposed of, at the end of
its useful life, as per applicable local laws, regulations, and procedures.
North America
Europe
Middle East
715 Peachtree St. NE Atlanta,
GA 30308
Newhouse Industrial Estate
Motherwell Lanarkshire ML1 5SB
United Kingdom
Emaar Business Park, Building No. 2,
Sheikh Zayed Road
P.O. Box 232362
Dubai, United Arab Emirates
www.security.honeywell.com
Tel: [phone]
www.security.honeywell.com/uk
Tel: [phone]
www.security.honeywell.com/me
Tel: [phone]
Document 800-26630-A,03/2021
