TRUE DAY/NIGHT HIGH RESOLUTION COLOUR CAMERA
HCD484LX
The Honeywell HCD484LX colour camera is ideally suited for use in 24/7
surveillance applications. The HCD484LX adapts to varying lighting conditions to
ensure the highest quality picture even in very low light. When the light level
drops too low for accurate video identification in colour, the camera automatically
moves the IR cut filter out of the optical path and then switches to black and
white video to capture more detail using the increased sensitivity of the CCD to
IR light. The camera uses internal logic or RS485 communication to control the
switchover from colour to black and white. This improves the reliability of the
operation of the camera in difficult installations or lighting conditions.
An on-screen text menu simplifies all setup and adjustment options. Menu
navigation is simple and picture adjustments can be made in a matter of seconds
with easy-to-use pushbuttons on the back of the camera.
The HCD484LX includes an automatic electronic shutter for changes in light level,
and three zones of automatic backlight compensation option for viewing backlit
scenes. The HCD484LX produces 480 TV lines of resolution for applications
requiring the highest level of sharpness in video quality as well as providing
reliable video quality even in low light conditions down to 0.1 lux.
Market Opportunities
The Honeywell HCD484LX is designed for high resolution 24/7 surveillance
applications, including those using infrared illumination. This includes general
indoor surveillance applications in retail, financial, and other commercial markets.
Combined with the AVH environmental housing, the HCD484LX can be used as a
solution for outdoor applications such as car parks, building entranceways, and
driveways.
Features
• 1/3" colour CCD with DSP
• 480 TV lines of resolution
• True Day/Night low light performance
down to 0.1 lux (F1.2)
• Manual Exposure Mode for setting
shutter speed
• Automatic Electronic Shutter (AES)
• 3 Zone Automatic Backlight
Compensation (BLC)
• 12 VDC/24 VAC with line lock,
phase adjustable
• DC, Video and Manual Iris
lens support
• Phase adjustable line lock
• Improved low light sensitivity using
external IR illumination

SPECIFICATIONS
HCD484LX
Operational
Video Standard PAL
Scanning System 625/50 TVL (PAL)
Image Sensor 1/3" Interline Transfer CCD
Number of Pixels
(H x V) 752 x 582 (PAL)
Minimum Illumination 0.1 lux @ F1.2
Horizontal Resolution 480 TVL
Video Output 1.0 Vp-p @ 75 Ohms
Sync System 12 VDC: Internal
24 VAC: Line lock
S/N Ratio >50 dB
Auto Gain Control Off 10 db-38 db
ALC Variable Iris control for DC drive lenses
Automatic Electronic
Shutter 1/50 – 1/100,000 sec (PAL)
Manual Electronic
Shutter 1/50 – 1/10,000 sec (PAL)
Lens Iris Control DC drive/Video drive
BLC 3 zones - High, Middle, Low, Off
Line Lock Phase
Adjustment Adjustable AC line lock
White Balance ATW/AWB/Manual/Fixed
OSD Camera title setting/Menu control
Remote Control RS485
Electrical
Input Voltage 12 VDC/24 VAC
Input Range 11 - 16 VDC, 17 - 28 VAC
Surge Suppression 1.5 kW transient
Power Consumption 3.5 W
Ordering
HCD484LX 1/3" CCD High Resolution True Day/Night Camera with DSP, 480 TVL, 0.1 lux, 12 VDC/24 VAC, RS485, PAL
NOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications.
Mechanical
Dimensions
(W x H x D) 68 mm x 56 mm x 120 mm
Weight 0.38 kg camera only
Construction Housing: Aluminium
Finish: Cool grey powder coat
Camera Mount 1/4 – 20 UNC mounting shoe
Lens Mount C/CS adjustable mounting ring
Connector
Video output: BNC connector
Lens: 4-pin connector
Power Input: Screw terminal block
Power Indicator Green LED indicates Power On
Accessories:
Recommended Lens Options
HLD29V8DNL 2.9 - 8 mm, F0.95, DC Auto Iris, IR corrected
HLD27V13DNL 2.7 - 13.5 mm, F1.3, DC Auto Iris, IR corrected
HLD5V50DNL 5.0 - 50 mm, F1.6, DC Auto Iris, IR corrected
Environmental
Temperature Operating: -10°C to 50°C
Storage: -20°C to 70°C
Relative
Humidity 20% to 80%, non-condensing
Regulatory
Emissions FCC, CE (EN55013)
Immunity CE (EN50130-4)
Safety EU: 73/23/EEC LVD
+
VIDEO
DOWN
MENU
UP
-
DC
VSD
REMOTE
PWR
Front View Rear View
Side View
Housing and Mounts
AVH530SH4 Housing - 12-24V, Aluminium, no shield
AVH530SH5 Housing - 110-240VAC, Aluminium,
sunshield
AVH500WMB Wall bracket - standard
sunshield
AVH500CMB Wall bracket -cable management
Power Supplies
HPTV2401D 240V/24VAC 1A Output for
internal use
HPTV2408-1D 230V/24VAC 8 individually fused
1A outputs for internal use
