Honeywell X Series User manual

X-Series Smoke and Heat Alarms *E*nrN*yrrueE3
Battery Powered Smoke and Heat Alarms
xs100T
xH100 xs100
%
W

The dangers of fire
;, ,'1:,Eve*y year there are an average of 3 billion fires across the world. These range
,'.-r.,,,ln,seyerity and causes, but each one incurs either financial or personal losses,
;,;,:r.'.'.:On average! more than 23,000 people die from fires across the world each year,
and 230,000 people are injured.
rlhe UK alone, deaths from fires have fallen by more than 60% since the
of smoke and heat alarms in the mid 1990's, Homes with a working
or heat alarm have been found to have a death rate that is 50% lower
i+iorneS witfrout one. The longer people spend inside a burning building, the
iti*ir.ctranee of survival is as they begin to suffer from smoke inhalation and
tr.apped. Smoke and heat alarms give that vital extra time before
occur, and give you the advised three minutes to get out of a
burning building.r
Smoke and heat alarms offer an early warning
system that works. Research has found that
for every e1 spent on an alarm, more than
150 is saved in fire related costs,2
Who is at risk?
Without proper and adequate warning,
:l everyone is at risk of injury or death from a
i,i";,..iirq; especially when you are asleep as your
;lieanse of smell does not work. Children are
at risk as they often don't react
;:SuiCkly enough to the dangers of fire.
on principles
:i;*ilre can be detected using various different
; however, the priority is always
maximize the detection speed, whilst
false alarms. Using multi criterla
ensures accuracy and speed in
rates to a broader range of fires
Qalifornia State Fire Deparlment
Child Safety Alliance: for every €1
an an alarm, €69 rs saved in fire related
Fire Safety in Residential
a:i4:r? 14*t*:
L
1
j
7
7
.&

Regulations
ln England and Wales, a house built after 1992 must have a
mains operated smoke or heat alarm alarm on every level of the
building. Landlords and their agents have a duty of care to their
tenants to ensure the property is safe. ln older houses it is advisable
to install smoke or heat alarms,s
ln Scotland, a house must have at least one smoke or heat alarm,
preferably optical, installed in the principal habitable room (normally
the lounge / living room) and in circulation spaces such as hallways
and landings, and at least one heat alarm in the kitchen, all must
be interconnected.
ln Northern lreland, there must be a smoke or heat alarm in the
princlpal habitable room (normally the lounge/living room) and a heat
alarm in each kitchen.
3 Source: UK government
Honeywell's expertise
Honeywell is one of the biggest manufacturers of commercial
fire protection systems. Worldwide, more than 20 million
commercial fire alarms are sold under Honeywell's brands
Esser, Gent, Notifier and others, These commercial systems
are typically being used in larger public and private buildings,
for example hotels and offices. Honeywell has more than
50 years experience in this area. This experience has
been used to develop highly reliable smoke and heat alarms
for the residential area.
+
*' \
\\\
*HIF4*kfll lt$$eXq,h
E&* *- a
-*{.1: l.{*4:.1 *--ti::: :
" "'}-',
re
i Power
,F,6.?=.i:Ecreased'prote,etis'ni,afl: 'ean'hd.uBgrade,q rclesE

Honeywell smoke and heat alarms have been optimised for
use by professionals dealing with residential fire protection,
Offering simple installation and maintenance they have
been designed to meet the needs of housing associations
and larger private households,
((
0333
u0P-RSA002
DOP.RSAOO3
EN 1460412005/AC:
bsi.
KITEMARK"
KM 634563
8S EN 14604r2005
bsi.
KITEMARK"
KM 630857
BS 5446 2:2003
. Self-locking mounting plate. X-Series can only be
removed with an appropriate tool
. On/off only by installing/removing from mouniing plate
Designed for residential environmrents
o Unobtrusive, low profile design
. lntegrates well into residential environment
Low total esst of ownership
. Ten year warranty
o Maintenance free - no pafis to change
Easy to operate and urse by the end-user
r Clearly visible status indication LEDs: Power,
Alarm, Fault
. Loud 85dB audible alarm , with reduced volume test
mode
. Large button - can be pressed with a broom stick
. Alarm hush
. Fault hush
r Clean, intuitive user interface
Easy to install
. One or two hole installation/flexible hole positions
o Switches on when slid onto mounting plate
from 08:30 to 17:00
be contacted on
General description
X-Series High Reliability
r Multi-criteria detection: lntelligent algorithm combines optical
and heat detection for increased detection speed across a
broad range of fires, producing less false alarms (XS1 00T)
. Optical detection: Accurate and rapid detection of fires using
responsive optical sensors (XS1 00)
o Heat detection: Combines fast response time and minimum
false alarms in areas with high levels of dust or fumes likes
kitchens (XH100)
o BSito BS EN 14604:2005/AC:2008 Part 2 United Kingdom
(xH100)
. Q Label - an independent quality mark for high-quality
smoke alarm detectors, which have been tested especially
for long-term use
. Sealed housing to protect from adverse environmental conditions
. Automaticself-checks
o Dirt Compensation
Tamper-proof
r Sealed in battery lasts for ten years
Dedicated local support
Honeywell provides a UK based Customer Support Centre, which is available Monday to Thursday
and Friday from 08:30 to 15:30. Our team is happy to answer any queries on our products and can
[phone].
.Xt{i'oO;'XS 100r 1 66+ " =-='"''= """ -'==
-.'. F6
"t
n
i
*
.\#
5
s
e
',"-i
., "l
,t,'
::
:.,
+
t;
+h\ .l-
!j!! E
E
F
f
*

Technical specification
Detection principle
Approvals
Battery
Heat ALarm
Battery
Optca Smoke
A arrn
Accurate heEt deteclor
t#*''*'n'o'
Separate indicator$
lor sach unit state .
. 360'visual Alarm
. Power (0ptional LED
deactivation for les$
disturbance at flight)
" Fauit
3 Udireless
iif separately sold XW'100
module is installed)
Loud sounder output
Big, easy to
press button
r Fault hush
n Alarm hush
. Reduced sound level test
XSI 00T - [/u t -cr teria: Opt ca and Therma
XS100 Optca1
\l--00 - herra
XH 1 00 - BS Kite mark (BS 5446-2:2003), CE
XSI 00 and XS1 00T BS Klte lVark (BS EN 1 460412005)
CE E\ 1 a60a:2005/AC.2008
RoHS, REACH, R&TTE, EIVC
Yes
1 0y/1 0y
10"C +55'C
25 95% Relat ve Humidity (non condensing)
IPX2D
Long-life Lithium Battery, 3V Sealed-in
Powert Green LED optiona deactivat on
Alarm Red LED large surface
Fault: Yellow LED
>B5dB @ 3rn, Distinct "Flre" alarm sound
Test with reduced sound evel
A arm hush
Fau t hush (24h)
0116x42mm
l85 g
Cafton box with euro ho e
119 x 119 x 55 mm
Unit
N/ount ng kt: Screws + plugs
Temperature
Humidity
lP rating
Visual indicator
Audible
Butlon
Separate indicators
for each unit stale
n 360" visual Alarm
. Power (0ptional LED
deactivation for Iess
disturbance at night)
. Fauit
. Wireless
(if separateiy sold XWl00
module is installed)
Loud $ounder output
Big, easy to
pres$ button
. Fault hush
. Alarm hush
. Reduced sound level test
Type
Dimensions
Scope of supply
User/ nstaller manual
Low profile shape
Separate indicators
for cach unit $late
. 360" visual Alarm
. Power (0ptional LED
deactivation for less
drsturbance at nierht)
. Fault
. Wireless
(if $Bparately sold
module is installed)
Loud sounder outpui
Big, easy tc
press button
. Fault hush
. Alarm hush
Order information
Eng ish
Engl sh
Multi criteria, heat and 0plical detecti0n
n lncreased response speed
n Broader range of lire iypes deiected quickly
" Reduced faise alarms
0ptica Thermal
Smoke A arm
. Reduced sound level test
Opt ca
Power
.l
Part No' Barcode ffi Mirimum
&derQuanE'ty
Available
Languages
Hoduct
Description
xH100-EN
xst00-EN
XSlOOT.EN

*t*i*i
lnstallation
X-Series smoke alarms don't need wiring
when installing them; simply install the
mounting plate first using supplied plugs
and screws, then slide the alarm onto it
which automatically activates the alarm.
X-Series smoke alarms can either be
mounted on the ceiling or on walls.
Mounting options:
Screw, two holes, or
Screw, one center hole
Tamper proof
locking clip (optional)
Clip with a breakable part
*.\
Switch on operation
E
E:
"@:;..
ffi-,t:..
w-:-
E5-'
Locking/release
tab (removable)
,W:h'ef€1,6': . lgener.at',rciom,m*6:6ti6 :'Lp, 6y11 ion€ywe I l)

Smoke and heat Alarms
Multi-Criteria Detection
Optical smoke alarms use an optical chamber to "see" the smoke.
Certain fire types are recognized with some delays only. Multi-criteria detection
therefore ads a thermal sensor and use an intelligent algorithm to improve
reaction speed, and reduce the number of false alarms.
Low Profile Design
Honeywell's low profile design utilising rounded corners, sleek round design
and low profile height make the unit seem a lot smaller than it really is.
Honeyruell have employed design agencies and end user market research to
select the best suitable concept.
Full Ten Year Lifespan and Warranty
Honeywell's full product lifespan warranty is one of the most comprehensive in
the industry This is backed up with more than 50 years of fire alarm experience
producing some of the most reliable alarms in the market. Honeyvvell is one of
the few companies in the market to offer a full ten year lifespan and ten year
warranty on its smoke and heat alarms.
lndependent 3rd Party Certification and Q-Label
All residential smoke alarms being sold in the EU must be cedified by a 3rd
party, for example VdS, against EN14604 which is the standard for residential
smoke alarms. This sets the minimum requirements for smoke alarms to be
sold, whether it is for DIY or professional use. The Q-Label is a voluntary
additional 3rd party certification, which is granted to high quality smoke
alarms. Smoke alarms with the Q-Label are tested for long-life, minimised false
alarms, increased protection against adverse environmental conditions and
have a sealed battery with at least 10 years lifetime.
CE Mark
The CE mark affixed to this product confirms its compliance with the European
Directives which apply to the product and, in particular, its compliance with
the harmonised specifications of standard EN 14604 relating to Construction
Products Directive 89/1 06/EEC.
BSI Kitemark
The BSI Kitemark is a product or service certification mark that shows it has
been tested independently and audited to ensure it meets the appropriate
standards of quality and safety.
NF Mark
The NF - Smoke Alarm Devices mark provides assurance as to safety and
consistent quality inspected by experts. Through its rigorous and exhaustive
inspections (holdels quality management system, product inspections,
audits and monitoring tests, etc.), the NF mark represents a comprehensive
guarantee for consumers that the certified products are compliant. The
NF - Smoke Alarm Devices mark confirms the product's compliance with
certification rules NF 292.
Automatic Self-adiustment / Self Checks
Honeywell's smoke and heat alarms have been fitted with an automatic self test
function which ensures the unit is functioning properly. Every ten seconds, the
unit tests critical systems to ensure accurate alerts are delivered rapidly once a
fire is detected.
Clearly Visible Alarms
Honeywell have integrated a set of clearly visible LED lights into the perimeter
of the unit, ensuring the alarm can be seen from all angles- This feature greatly
helps people who have hearing troubles so may not hear the alarm.
Heat Alarms
Combining fast levels of detection with minimum false alarms, the Honeywell
XH100 Heat Alarm is best suited to areas with high levels of dust or fumes,
such as kitchens and garages.
Dirt Compensation
Honeywell's unique dirt compensation ensures that nuisance alarms are kept to a
minimum. By not confusing dust with smoke, the X-Series smoke and heat alarms
only sound when a hazard is detected.
X-Series Alarms
Sealed Housing
Honeywell's X-Series alarms all have sealed housings. lt protects the
electronics from adverse environmental conditions like humidity, and
improves reliability and lifetime. We have been successfully using this
technology for many years in our commercial smoke alarms, which are
being used in harsh conditions like warehouses.
Alarm Hush
There might be situations where the unit is in full alarm, and you want
to mute the 85dB loud alarm sounder, e.g. when the situation is under
control. Pressing the button on the unit will mute the sounder for 5
minutes, whilst the alarm light will keep on flashing as long as the alarm
detects a threat.
Fault Hush
A typical fault occurs when the alarm warns of an almost depleted
battery. The alarm will start to bleep once per minute accompanied by
a flashing fault light. The Fault Hush allows you to mute the sounder for
24 hours, giving you time to address the fault. lf you wish to restart the
24 hour timer in the morning, you can press the button a second time.
Reduced Sound Level Test
Alarms need to be tested regularly, to ensure they are working properly.
After pressing the button, the alarm will start its internal self-test, flash all
lights and sounding the buzzer. Honeywell has reduced the sound level
for this test function considerably from the full alarm level of 85dB. lt still
tests the alarm, but your ears are being protected. BTW: By pressing the
alarm for more than 3 seconds, the full alarm level will sound.
Tamper-Proof
Many professional landlords want to ensure that installed alarms cannot
be stopped from normal operation by the end-user. ln the past, tenants
have often removed the batteries to use them for instance in TV remote
controls. Honeywell's X-Series alarms all have sealed batteries, which
cannot be removed by the end-user. Also, once installed, a tool like a
screwdriver is required to switch the unit off or remove it.
Maintenance Free Operation
All Honeywell X-Series alarms have batteries, which last the whole
lifetime of the alarms. No additional cost for batteries or labour cost to
replace them occur. The same applies for the CO sensor: lt lasts the
whole lifetime of up to 10 years. The only required maintenance is the
occasional cleaning of the product.
lnterlink
Interlink means the connection of several alarms to an alarm system. So if
one unit goes into alarm, all other units will sound as well. This improves
considerably the safety especially in larger accommodations like multi-
story houses. All X-Series alarms can be upgraded, to connect wirelessly.
All mains powered Honeywell X-Series alarms can be linked by wire.
Battery Back-up
l\/lains powered alarms can be effected by power outages. Therefore,
all Honeywell mains powered X-Series alarms are fitted with a battery
backup.
t-i,*
c7
How we add value

&un l{ome Safety Product Ramge
'{;
Hf5*il l-la:"d-Hlir*d
Flamma*ie
Gas Alarrnr
ezscn$* *attery
Flar-nmrabl*
Gas Aianrrr
Sf34* $eri**
Hard-WirCIei
Cmrb*n lM*n*xiC*
Alarm
X-S*ri*s
ffiattery F]*w*red
earb*n hrlcn*xii*
Alerrns
tlwls<+
:.:;.a...:'.: :.
&ffi.-.--*.'
ezsense is the most convenient
way to detect Natural Gas,
Propane, Butane, LPG and LNG
it is compact and light on the
pocket in more ways than one.
1t.
Our X-Series battery porrrered CO
alarm range offers a seven or ten
year maintenance{ree lifetime.
Three models provide different
display options designed to
enhance safety in critical situations
including a patent pending alarm
evacuate visual inCication.
The HF500 alarms are'designed
to deliver a complete solution for
the detection of LPG (Liquefied
Petroleum Gas) and Natural
Gas/Methane. Optimised for use
by professionals dealing with
flammable leak detection, HF500
is ideally suited for use in private
or social housing as well as other
forrns of residential care.
The SF340 Series is a range
of reliable, hard-wired Carbon
Monoxide aiarms with battery
back-up. They are designed for
use in all domestic and light
commerciai environments.
Find out more
www. homesafety. honeywell,com
www. honeywellanaly.tics.com
Gontact us:
UK Customer $ervice Centre:
Honeywell Anaiy.tics Ltd.
4 Stinsford Hoad
Nuffield lndustrial Estate
Poole. Dorset BHl7 ORZ
Tal: +44 {O}12O2 645577
Fax: [phone]
[email protected]
Acts for and on behalf of Life Safety Distribution
AG, Javastrasse 2, 8604 Hegnau, Switzerland
by its Authorised Bepresentative Honeywell inc
All Honeywell X-Series alarms can
be wirelessiy inlerconnected r:sing
the XW100 plug-in module.
This means that if one X-Series
Carbon Monoxide, smoke or
heat alarm triggers an alarm,
ail interconnected units will give
an audible alarm as we!1. This is
especially usetul, when living in a
large or muiti-story dwelling where
the alarm may be kiggered in
another pad of the buildinq.
Please Note;
Vy'htle every eflsrt has been matle lo ensure accuracy if ihis publication, n0 resp0fsibllity can ile accepted l0r ercis 0r
0missions. Dala may change, as we I as legislaUon, and you are str0ngly advls€d i0 oblaln copies 0f the m0s1 recenily
issued regllations, standarrls, and guidelines. This publlcati0n is not intended t0 f0rm the basis 0i a c0ntract.
'13474 _H X'Serios Battery F re Alarms'DSCI 1 54_V1_El\lEA
0B/1 5
O 2015 Hone\,ryell Anaiytlcs Honeywell
