Honeywell 272630D User manual

272630D
Position Feedback and
Auxiliary Switch Accessory
For ML6984 and ML7984
INSTALLATION INSTRUCTIONS
APPLICATION
The 272630D auxiliary board is an optional
circuit board that is used in conjunction with
Series 4000 ML6984 and ML7984 globe valve
actuators. This auxiliary board combines the
function of an adjustable low voltage SPDT
auxiliary switch with a 2-10 Vdc or 4-20 mA
position feedback signal. It has a 4-pin keyed
connectorforcommunicationsfromthemother
circuit board.
SPECIFICATIONS
Feedback: 2-10 Vdc (10-2 V reverse acting)
into minimum impedance 500 Ω.
Maximum output current is
20 mA dc.
Auxiliary Switch: SPDT, 24 V, 50/60Hz, 1 A
inductive. Fixed differential
(3% of stroke), adjustable
operating point from 0 to
100% of stroke.
2005.04 RJ Printed in Canada Form No. 95C-10941

272630D Auxiliary Board
INSTALLATION
When installing this product...
1. Read these instructions carefully. Failure to
follow them could damage the product or
cause a hazardous condition.
2. Check ratings given in instructions and on
theproducttoensure the product is suitable
for your application.
3. Installer must be a trained, experienced
service technician.
4. After installation in complete, check out
product operation as provided in these
instructions.
! CAUTION:
1. Disconnect power supply before beginning
installation to prevent electric shock and
equipment damage.
2. All wiring must comply with applicable local
electricalcodes,ordinancesandregulations.
3. DO NOT electrically operate the ML6-7984
actuator before assembly to the valve
becausedamagenotapparenttothe installer
may occur. Mount the actuator to the valve
before connecting to power.
Assembly
1. Remove plastic cover from the ML6-7984
by loosening the two screws located on the
top. (Note: These screws are captive.
Rotate three complete revolutions to
remove cover).
2. Slide the auxiliary board into the two slots
at the bottom of the bridge. Push back and
snap the board into the fingers. (See Fig. 1)
3. Connect one end of the 4-pin connector to
the main board and the other end to the
auxiliary board if it is not already connected.
The connectors are keyed and only install
one way.
4. Mount the actuator onto the valve body and
connect wiring.
5. Reinstall cover after operational check.
Fingers Bridge
Slots
1. Install
circuit
board
Fig. 1 - Installation of auxiliary board
OPERATION
The first time the valve is powered, the
microprocessor will automatically cycle the
valve through a full stoke to calibrate its
position.Anystroke between1/2" (13 mm) and
1" (25 mm) will be divided into 30 equal steps.
Run time will be proportional to stroke length.
(For example: nominal timing for 3/4" stroke
is 63 seconds. For 1/2" stroke this would be
42 seconds). The LED lights up when
terminals T5-T6 are powered, and flash when
the actuator is in motion.
NOTE: 272630D requires that the actuator be
continuously powered, so ML6984 must be
wired in "5-wire" configuration.
C-NC contact C-NO contact
CLOSED CLOSED 2-10 V,
when valve when valve (4-20 mA
position is position is into
below trim pot above trim pot 500 Ω)
setting (direct setting (direct feedback
acting). acting). output COM
Trim pot
J1
LED
+FBNC C NO
RLY1
-COM
Connect to main
board for position
feedback.
Fig. 2 - Wiring and operation of auxiliary
board 272630D
2

The 272630D provides:
1. A2-10 Vdc voltage proportional to the valve
stem position. This output is capable of
sourcing up to 20 mA dc drive current.
2. An isolated "Form C" relay contact closure
that energizes when the valve is open more
thanthesettingof the trimmer potentiometer
("trim pot").
Position feedback voltage mirrors the control
signal. For ML6984 and direct acting ML7984
operation, see Fig. 3. For reverse acting
ML7984, see Fig. 4.
1.75V 2.5V 9.5V 10.25V
FEEDBACK VOLTAGE
LOWER
SEAT
UPPER
SEAT
STROKE
28 steps @
0.25V per step
First and last steps
are @ 0.75V per step
Fig. 3 - Feedback voltage reponse for
ML6984 and direct acting ML7984
STROKE
10.25V9.5V2.5V1.75V
FEEDBACK VOLTAGE
LOWER
SEAT
UPPER
SEAT
28 steps @
0.25V per step
First and last steps
are @ 0.75V per step
Fig. 4 - Feedback voltage response for
reverse acting ML7984
Auxiliary Switch Setup
1. Drive actuator to desired position.
2. Adjusttrimmerpotentiometer ("trimpot")until
relayisenergized.(On-boardLEDwilllight).
3

Automatic and Control Solutions
Honeywell International Inc. Honeywell Limited-Honeywell Limitee
1985 Douglas Drive North 35 Dynamic Drive
Golden Valley, MN Scarborough, Ontario
55422 M1V 4Z9
