Honeywell RXSW100A3CULH User manual

Owner’s Manual
For
Automatic Transfer Switch
100 & 200 Amp, Service Entrance, CSA
Model Number
RXSW100A3CULH
RXSW200A3CULH
SERIAL NUMBER: _________________________
DATE PURCHASED:________________________
WWW.HONEYWELLGENERATORS.COM
855-436-4636
Para español, visita: http://www.honeywellgenerators.com/service-support/owner-support
Pour le français, visiter : http://www.honeywellgenerators.com/service-support/owner-support
SAVE THIS MANUAL FOR FUTURE REFERENCE

ii Automatic Transfer Switch Owner’s Manual
(000393)
WARNING
Operating, servicing and maintaining this
equipment can expose you to chemicals
including engine exhaust, carbon monoxide,
phthalates, and lead, which are known to the
State of California to cause cancer and birth
defects or other reproductive harm. To
minimize exposure, avoid breathing exhaust,
do not idle the engine except as necessary,
service your equipment in a well-ventilated
area and wear gloves or wash your hands
frequently when servicing your equipment.
For more information go to
www.P65Warnings.ca.gov.

Automatic Transfer Switch Owner’s Manual iii
Section 1: Safety
Introduction ..........................................................1
Safety Rules .........................................................1
Safety Symbols and Meanings ...........................1
Electrical Hazards ................................................2
General Hazards ..................................................3
Section 2: General Information
Unpacking ............................................................5
Equipment Description .......................................5
Transfer Switch Mechanism ........................................5
Utility Service Circuit Breaker ......................................6
Transfer Switch Data Decal ................................6
Transfer Switch Enclosure .................................6
Safe Use of Transfer Switch ...............................6
Load Management Options .................................6
Smart A/C Module (SACM) .........................................7
Smart Management Module (SMM) ............................7
Application Considerations ..........................................7
Section 3: Installation
Introduction to Installation .................................9
Mounting ...............................................................9
Open Enclosure ...................................................9
Connecting Power Source and Generator Power
Supply ..........................................................10
Connecting Start Circuit Wires .........................11
Connecting SACM .............................................11
Control of Air Conditioner Load .................................11
Auxiliary Contact ...............................................13
Fault Current Label ............................................13
Section 4: Operation
Functional Tests and Adjustments .................. 15
Manual Operation .............................................. 15
Close to Utility Source Side .......................................15
Close to Generator Source Side ...............................16
Return to Utility Source Side .....................................16
Voltage Checks .................................................. 16
Utility Voltage Checks ...............................................16
Generator Voltage Checks ........................................16
Generator Tests Under Load ............................ 16
Checking Automatic Operation ........................ 17
Installation Summary ........................................ 17
Shutting Generator Down While Under Load
Or During A Utility Outage ......................... 17
Preparing for Maintenance ............................... 18
Testing The SACM ............................................. 18
SACM Fuse Service ........................................... 18
Testing The SMM ............................................... 18
Section 5: Drawings and Diagrams
Installation Drawing .......................................... 19
No. 10000027062 ......................................................19
Interconnection Drawing .................................. 20
No. 10000027057—page 1 of 2 ................................20
No. 10000027057—page 2 of 2 ................................21
Table of Contents

iv Automatic Transfer Switch Owner’s Manual
This page intentionally left blank.

Safety
Automatic Transfer Switch Owner’s Manual 1
Section 1: Safety
Introduction
Thank you for purchasing a Honeywell, Inc. product. This
unit has been designed to provide high performance,
efficient operation, and years of use when maintained
properly.
Read this manual thoroughly and understand all of the
instructions, cautions, and warnings before using this
equipment. If any section of the manual is not understood,
contact your nearest Independent Authorized Service
Dealer (IASD). To locate the nearest IASD, visit the dealer
locator at
www.honeywellgenerators.com/find-a-dealer,
or call 855-436-4636 with any questions or concerns.
The owner is responsible for proper maintenance an d
safe use of the equipment. Before operating or servicing
this transfer switch:The owner is responsible for proper
maintenance and safe use of the equipment. Before
operating or servicing this transfer switch:
•Study all warnings in this manual and on the
product carefully.
•Become familiar with this manual and the unit
before use.
•Refer to the installation sections of the manual for
instructions on final assembly procedures. Follow
the instructions completely.
Save these instructions for future reference. ALWAYS
supply this manual to any individual that will use this
equipment.
The information in this manual is accurate based on
products produced at the time of publication. The
manufacturer reserves the right to make technical
updates, corrections, and product revisions at any time
without notice.
Safety Rules
The manufacturer cannot anticipate every possible
circumstance that might involve a hazard. The warnings
in this manual, and on tags and decals affixed to the unit
are, therefore, not all inclusive. If using a procedure, work
method or operating technique that the manufacturer
does not specifically recommend, verify that it is safe for
others. Also make sure the procedure, work method or
operating technique utilized does not render the
equipment unsafe.
Safety Symbols and Meanings
Throughout this publication, and on tags and decals
affixed to the transfer switch, DANGER, WARNING,
CAUTION and NOTE blocks are used to alert personnel
to special instructions about a particular operation that
may be hazardous if performed incorrectly or carelessly.
Observe them carefully. Their definitions are as follows:
NOTE: Notes contain additional information important to
a procedure and will be found within the regular text of
this manual.
These safety alerts cannot eliminate the hazards that
they indicate. Common sense and strict compliance with
the special instructions while performing the action or
service are essential to preventing accidents.
(000100a)
WARNING
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
(000001)
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
(000002)
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
(000003)
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.

Safety
2Automatic Transfer Switch Owner’s Manual
Electrical Hazards
(000129)
DANGER
Electrocution. High voltage is present at
transfer switch and terminals. Contact with live
terminals will result in death or serious injury.
(000104)
DANGER
Electrocution. Water contact with a power
source, if not avoided, will result in death
or serious injury.
(000145)
DANGER
Electrocution. In the event of electrical accident,
immediately shut power OFF. Use non-conductive
implements to free victim from live conductor. Apply
first aid and get medical help. Failure to do so will
result in death or serious injury.
(000237)
DANGER
Electrical backfeed. Use only approved switchgear to
isolate generator from the normal power source.
Failure to do so will result in death, serious injury,
and equipment damage.
(000195)
DANGER
Electrocution, equipment and property damage.
Handle transfer switches carefully when installing.
Never install a damaged transfer switch. Doing so
could result in death or serious injury, equipment
and property damage.
(000123)
DANGER
Electrocution. Turn utility supply OFF before
working on utility connections of the transfer
switch. Failure to do so will result in death or
serious injury.
(000157)
DANGER
Electrocution. Do not disable or modify the
connection box door safety switch. Doing so
will result in death or serious injury.
Automatic start-up. Disconnect utility power and
render unit inoperable before working on unit.
Failure to do so will result in death or serious injury.
(000191)
DANGER
(000119)
Equipment malfunction. Installing a dirty or damaged
transfer switch will cause equipment malfunction and
will result in death or serious injury.
DANGER
(000155a)
WARNING
Electric shock. Only a trained and licensed electrician
should perform wiring and connections to unit. Failure
to follow proper installation requirements could result in
death, serious injury, and equipment or property damage.
(000120)
CAUTION
Equipment damage. Verify all conductors are tightened
to the factory specified torque value. Failure to do so
could result in damage to the switch base.
(000121)
CAUTION
Equipment damage. Perform functional tests in the
exact order they are presented in the manual.
Failure to do so could result in equipment damage.
(000134a)
CAUTION
Equipment damage. Exceeding rated voltage and
current will damage the auxiliary contacts. Verify
that voltage and current are within specification
before energizing this equipment.

Safety
Automatic Transfer Switch Owner’s Manual 3
General Hazards
•Competent, qualified personnel should install,
operate and service this equipment. Adhere strictly
to local, state and national electrical and building
codes. When using this equipment, comply with
regulations established by the National Electrical
Code (NEC), Canadian Electrical Code (CE/CSA
C22.1), CSA Standard; the Occupational Safety
and Health Administration (OSHA), or the local
agency for workplace health and safety.
•If working on this equipment while standing on
metal or concrete, place insulative mats over a dry
wood platform. Work on this equipment only while
standing on such insulative mats.
•Never work on this equipment while physically or
mentally fatigued.
•Any voltage measurements should be performed
with a meter that meets UL/CUL3111 safety
standards, and meets or exceeds overvoltage
class CAT III.
(000237)
DANGER
Electrical backfeed. Use only approved switchgear to
isolate generator from the normal power source.
Failure to do so will result in death, serious injury,
and equipment damage.
(000129)
DANGER
Electrocution. High voltage is present at
transfer switch and terminals. Contact with live
terminals will result in death or serious injury.
(000123)
DANGER
Electrocution. Turn utility supply OFF before
working on utility connections of the transfer
switch. Failure to do so will result in death or
serious injury.
(000104)
DANGER
Electrocution. Water contact with a power
source, if not avoided, will result in death
or serious injury.
(000188)
DANGER
Electrocution. Do not wear jewelry while
working on this equipment. Doing so will
result in death or serious injury.
(000213)
DANGER
Electrocution. Only authorized personnel should
access transfer switch interior. Transfer switch
doors should be kept closed and locked. Failure to
do so will result in death or serious injury.
Automatic start-up. Disconnect utility power and
render unit inoperable before working on unit.
Failure to do so will result in death or serious injury.
(000191)
DANGER
(000145)
DANGER
Electrocution. In the event of electrical accident,
immediately shut power OFF. Use non-conductive
implements to free victim from live conductor. Apply
first aid and get medical help. Failure to do so will
result in death or serious injury.
(000209b)
WARNING
Loss of life. This product is not intended to
be used in a critical life support application.
Failure to adhere to this warning could result
in death or serious injury.
WARNING
Equipment damage. This unit is not intended for use as a
prime power source. It is intended for use as an intermediate
power supply in the event of temporary power outage only.
Doing so could result in death, serious injury, and
equipment damage. (000247a)

Safety
4Automatic Transfer Switch Owner’s Manual
This page intentionally left blank.

General Information
Automatic Transfer Switch Owner’s Manual 5
Section 2: General Information
Unpacking
Carefully unpack the transfer switch. Inspect closely for
any damage that might have occurred during shipment.
The purchaser must file with the carrier any claims for
loss or damage incurred while in transit.
Check that all packing material is completely removed
from the switch prior to installation.
Equipment Description
This automatic transfer switch is used for transferring
electrical load from a utility (normal) power source to a
generator (standby) power source. Transfer of electrical
loads occurs automatically when the utility power source
has failed or is substantially reduced and the generator
source voltage and frequency have reached an
acceptable level. The transfer switch prevents electrical
feedback between two different power sources (such as
the utility and generator sources) and, for that reason,
codes require it in all standby electric system installations.
The transfer switch consists of a transfer mechanism,
utility service disconnect circuit breaker (if equipped), and
a Smart A/C module incorporating fuses and two terminal
blocks for transfer switch connections.
This UL/CUL listed transfer switch has locking provisions
for the utility entry cabinet. In addition, it has a lockout/
tagout provision for the service entrance circuit breaker.
Transfer Switch Mechanism
See Figure 2-1. This switch is used with a single-phase
system when the single-phase neutral line is to be
connected to a neutral lug and is not to be switched.
Solderless, screw-type terminal lugs are standard.
The conductor size range is as follows:
This transfer switch is suitable for control of motors, electric
discharge lamps, tungsten filament and electric heating
equipment where the sum of motor full load ampere ratings
and the ampere ratings of other loads do not exceed the
ampere rating of the switch and the tungsten load does not
exceed 30 percent of the switch rating.
This UL/CUL listed transfer switch is for use in optional
standby systems only.
A 100A rated switch is suitable for use on circuits capable
of delivering not more than 10,000 RMS symmetrical
amperes, 250 VAC maximum, when protected by a 100A
maximum circuit breaker (Siemens types QP or BQ) or
150A maximum circuit breaker (Square D Q2,
Westinghouse CA-CAH, General Electric TQ2 and
Siemens QJ2).
A 200A rated switch is suitable for use on a circuit
capable of 22,000 RMS symmetrical amperes, 240 VAC
when protected by a circuit breaker without an adjustable
short time response or by fuses.
Figure 2-1. Typical Single-Phase ATS Transfer
Mechanism
Switch
Rating Wire Range Conductor Tightening Torque
100A #14-1/0 AWG (Cu/Al) 50 in-lbs (5.6 Nm)
200A #6-250 MCM (Cu/Al) 275 in-lbs (31 Nm) A Utility Closing Coil
B Generator Closing Coil
C Utility Lugs (N1 & N2)
D Generator Lugs (E1 & E2)
E Load Lugs (T1 & T2)
000219
A
B
C
D
E

General Information
6Automatic Transfer Switch Owner’s Manual
Utility Service Circuit Breaker
The utility service and generator disconnect circuit
breakers for 100 amp models are:
•Type BQ, 2-pole
•10,000 A/C
•120/240VAC, 100A
•50/60 Hertz
•Wire range: #1 - #8 AWG (Cu/Al)
•The conductor tightening torque is 50 in-lbs. (5.6
Nm).
The utility service circuit breakers for 200 amp models
are:
•Type 225AF, 2-pole
•22,000 A/C
•120/240VAC, 200A
•50/60 Hertz
•Wire range:
– Line: 300 MCM - 6 STR (Cu/Al)
– Load - ATS: 250 MCM - 6 STR (Cu/Al)
•The conductor tightening torque is:
– Line: 375 in-lbs (42.4 Nm)
– Load - ATS: 275 in-lbs. (31 Nm)
Transfer Switch Data Decal
See Figure 2-2 . A data decal is permanently affixed to the
transfer switch enclosure. Use this transfer switch only
with the specific limits shown on the data decal and on
other decals and labels that may be affixed to the switch.
This will prevent damage to equipment and property.
When requesting information or ordering parts for this
equipment, make sure to include all information from the
data decal.
For future reference, record the Model and Serial numbers
in the space provided on the front cover of this manual.
Figure 2-2. Data Decal Location
Transfer Switch Enclosure
The standard switch enclosure is a National Electrical
Manufacturer’s Association (NEMA) and UL/CUL 3R
type. UL/CUL and NEMA 3R (indoor/outdoor rated) type
enclosures primarily provide a degree of protection
against falling rain and sleet; are undamaged by the
formation of ice on the enclosure.
Safe Use of Transfer Switch
Before installing, operating or servicing this equipment,
read the Safety Rules carefully. Comply strictly with all
Safety Rules to prevent accidents and/or damage to the
equipment. The manufacturer recommends that a copy
of the Safety Rules be posted near the transfer switch.
Also, be sure to read all instructions and information
found on tags, labels and decals affixed to the
equipment.
Two publications that outline the safe use of transfer
switches are the following:
•Canadian Electrical Code CE; CSA C22.1
•NFPA 70E: Standard for Electrical Safety In The
Workplace
•UL/CUL 1008: Standard for Safety—Automatic
Transfer Switches
NOTE: It is essential to use the latest version of any
standard to guarantee correct and current information.
Load Management Options
Load management systems are designed to work
together to prevent a generator from being overloaded by
large appliance loads. A Smart A/C Module (SACM) is
provided as standard equipment with this switch. An
optional Smart Management Module (SMM) is also
available.
006487
(000100a)
WARNING
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.

General Information
Automatic Transfer Switch Owner’s Manual 7
Smart A/C Module (SACM)
Up to four air conditioner loads can be managed by the
SACM. The SACM manages the loads by “shedding” the
connected loads in the event of a drop in generator
frequency (overload). Loads to be “shed” are in 4 priority
levels on the module.
See Figure 2-3. Priorities A/C 1-4 (A) have connections
for an air conditioner. To control an air conditioner, no
additional equipment is required. Internal normally closed
relays interrupt the 24 VAC thermostat control signal to
disable the air conditioner load.
Four LEDs, located on the SACM (B), illuminate when a
load is connected and powered.
See Figure 2-3. The SACM has a test button (C) used to
simulate an overload condition. This button operates
even when the transfer signal is inactive. The Generator
Control Wiring is connected to terminals (D).
Figure 2-3. Smart A/C Module (SACM)
Smart Management Module (SMM)
(sold separately)
Any loads, including central air conditioners, can be
managed using a Smart Management Module (SMM).
The system can accommodate up to eight individual
SMMs.
NOTE: SMMs are self-contained and have individual
built-in controllers.
Figure 2-4. Smart Management Module (SMM)
Application Considerations
Generator overload condition is determined by generator
frequency. Loads are shed when frequency is less than
58 Hz for three seconds or less than 50 Hz for ½ second
(for 60 Hz systems).
The SACM can be used in conjunction with individual
SMMs to manage a combined total of eight loads.
•Use Priorities A/C 1-4 on the SACM as the top
priorities, then up to four SMMs as Priorities 5-8.
•Use only select A/C priorities on the SACM as the top
priorities, then use additional SMMs as the remaining
priorities.
•A SMM can share a priority with an A/C priority on
the SACM provided the generator is sized to handle
the combined surge load from both appliances.
Sharing priorities can allow up to 12 loads to be
managed in a properly sized system.
In any combination of modules, the recovery times after a
loss of utility power or shutdown due to overload are
shown in Table 1: Priority Settings.
Refer to the SMM Owner’s/Installation Manual for
detailed characteristics and specifications of that product.
1
1
1
1
2
2
2
2
T1N1N2
0 DC GROUND
194 +12 VDC
N1
N2
T1
23 TRANSFER
Replace with Littelfuse 021606.3XHP,
Optifuse FCD-6.3A or
Generac 10000005117 250 vac, 6.3A
®
®
A
B
C
D
004436
Table 1. Priority Settings
Priority Recovery Time SACM SSMM
1 5 minutes Yes Yes
2 5 minutes 15 seconds Yes Yes
3 5 minutes 30 seconds Yes Yes
4 5 minutes 45 seconds Yes Yes
5 6 minutes NA Yes
6 6 minutes 15 seconds NA Yes
7 6 minutes 30 seconds NA Yes
8 6 minutes 45 seconds NA Yes
000106

General Information
8Automatic Transfer Switch Owner’s Manual
This page intentionally left blank.

Installation
Automatic Transfer Switch Owner’s Manual 9
Section 3: Installation
Introduction to Installation
This equipment has been wired and tested at the factory.
Installing the switch includes the following procedures:
•Mounting the enclosure.
•Connecting power source and load leads.
•Connecting the generator start and sensing circuit.
•Connecting any auxiliary contact (if needed).
•Testing functions.
Mounting
Mounting dimensions for the transfer switch enclosure
are in this manual. Enclosures are typically wall-
mounted. See Drawings and Diagrams.
This transfer switch is mounted in a UL/CUL type 3R
enclosure. It can be mounted outside or inside and should
be based on the layout of installation, convenience and
proximity to the utility supply and load center.
Install the transfer switch as close as possible to the
electrical loads that are to be connected to it. Mount the
switch vertically to a rigid supporting structure. To prevent
switch distortion, level all mounting points. If necessary,
use washers behind mounting holes to level the unit.
Open Enclosure
See Figure 3-1. First, remove outer cover (A):
1. Remove thumb screw (B).
2. Slide slot (C) over retention tab.
3. Lower outer cover until clear of top flange (D), and
pull away from enclosure.
Remove inner panel (E):
4. Loosen nut (F) until it clears t-slot (H) in inner
panel.
5. Grasp inner panel at two cutouts (G—left and
right). Tilt inner panel as shown, passing nut
through t-slot.
6. Lower inner panel until tabs (J) clear upper panel,
and pull away from enclosure.
7. Remove screw (K). Lower upper panel (L) until
clear of two retention slots in top flange, and pull
away from enclosure.
Figure 3-1. Open Enclosure
(000119)
Equipment malfunction. Installing a dirty or damaged
transfer switch will cause equipment malfunction and
will result in death or serious injury.
DANGER
006146
B
AC
E
F
D
J
G
H
K
L

Installation
10 Automatic Transfer Switch Owner’s Manual
Connecting Power Source and
Generator Power Supply
Installation and interconnection diagrams are provided in
this manual.
NOTE: All installations must comply with national, state
and local codes. It is the responsibility of the installer to
perform an installation that will pass the final electrical
inspection.
1. Connect utility supply at the utility service
disconnect circuit breaker terminals N1 and N2.
Follow torque specifications listed on the circuit
breaker.
2. See Figure 3-2. Connect utility neutral and ground
to the Upper Neutral and Ground terminals. Neutral
and Ground terminals are bonded to each other
with a jumper wire (A).
NOTE: Neutral to Ground jumper wire (A) is provided for
use if required by local codes.
3. Connect generator to the generator terminals (E1
and E2) on the transfer mechanism.
4. Connect the generator neutral wire to the lower
neutral lug.
IMPORTANT NOTE: A jumper wire (B) bonds the
upper and lower Neutral lugs. NEVER remove this
wire.
5. Connect a subpanel supply to lower T1 and T2
Terminals. Connect subpanel Neutral and Ground
to lower Neutral and Ground bars.
Conductor sizes must be adequate to handle the
maximum current to which they will be subjected, based
on the 75°C column of tables, charts, etc. used to size
conductors. The installation must comply fully with all
applicable codes, standards and regulations.
Knockouts into the transfer switch can be made in the
field as needed for entry of power cables and conduit.
Conduit entry shall maintain the proper wire bending
spaces required by CSA C22.1. A barrier provides
separation between the Utility and Generator supply
conductors inside the enclosure.
NOTE: The upper panel has a provision for a utility lock
or tag after installation is complete. The service entrance
circuit breaker also has a provision for a locking device.
NOTE: If aluminum conductors are used, apply corrosion
inhibitor to conductors. After tightening terminal lugs,
carefully wipe away any excess corrosion inhibitor.
Figure 3-2. Wiring Connections
Tighten terminal lugs to the torque values as noted on the
decal located on the inside of the door. After tightening
terminal lugs, carefully wipe away any excess corrosion
inhibitor.
Electrocution. Turn utility and emergency
power supplies to OFF before connecting
power source and load lines. Failure to do so
will result in death or serious injury. (000116)
DANGER
006147
N2
E2
T2
A
T1
N1
E1
B
(000120)
CAUTION
Equipment damage. Verify all conductors are tightened
to the factory specified torque value. Failure to do so
could result in damage to the switch base.

Installation
Automatic Transfer Switch Owner’s Manual 11
Connecting Start Circuit Wires
Control system interconnections consist of N1, N2, and
T1, and leads 23, 0, and 194 (see Figure 3-3). The
generator control wiring is a Class 1 signaling circuit.
Reference instruction manual of specific engine
generator for wiring connection details. Screw heads are
straight bladed and cross-bladed, and should be
tightened to 3.5 in-lb (0.4 Nm).
Recommended wire gauge sizes depend on wire length
as specified in the following chart: Consult factory if you
are operating more than one transfer switch and SACM.
Exception: Conductors of AC and DC circuits, rated
1000 volts nominal, or less, shall be permitted to occupy
the same equipment, cable, or conduit. All conductors
shall have an insulation rating equal to at least the
maximum circuit voltage applied to any conductor within
the equipment, cable, or conduit.
Connecting SACM
See Figure 3-3. The SACM can control an air conditioner
(24 VAC) directly.
Control of Air Conditioner Load
1. Route the thermostat cable (from the furnace/
thermostat to the outdoor air conditioner unit) to the
transfer switch.
2. Connect the wire to the terminal strip terminals
(A/C 1) on the SACM as shown in Figure 3-3.
These are normally closed contacts which open
upon load shed conditions. Route thermostat wire
away from high voltage wires.
3. If required, connect additional air conditioners to
the terminal strip terminals (A/C 2-4).
NOTE: These instructions are for a typical air conditioner
installation. Control of certain heat pumps and 2-stage air
conditioners may require special connections or the use
of SMMs to control the loads.
Recommended
Wire Size
Maximum Wire Length
( O n e t r a n s f e r s w i t c h
and load shed module)
No. 18 AWG 1–115 ft (0.3–35 m)
No. 16 AWG 116–185 ft (36–56 m)
No. 14 AWG 186–295 ft (57–89 m)
No. 12 AWG 296–460 ft (90–140 m)
Contact Ratings
A/C 1-4 24 VAC, 1.0 Amp Max

Installation
12 Automatic Transfer Switch Owner’s Manual
Figure 3-3. Typical SACM Connections
A
Thermostat 1
B
Air Conditioner 1
C
Thermostat 2
D
Air Conditioner 2
E
Thermostat 3
F
Air Conditioner 3
G
Thermostat 4
H
Air Conditioner 4
T1 (fused)
Battery Charge
N1 (fused)
Utility Sense
N2 (fused)
Utility Sense
0
Ground
194
+ 12 VDC
23
Transfer Control
J
240 VAC, 6.3A
Fuses
A
B
G
H
C
D
E
F
T1
1
1
1
1
2
2
2
2
T1N1N2
0 DC GROUND
194 +12 VDC
N1
N2
T1
23 TRANSFER
Replace with Littelfuse 021606.3XHP,
Optifuse FCD-6.3A or
Generac 10000005117 250 vac, 6.3A
®
®
J
T1
N2
0
194
23
N1
006244

Installation
Automatic Transfer Switch Owner’s Manual 13
Auxiliary Contact
See Figure 3-4 . If desired, there is one normally-closed
Auxiliary Contact (A) on the transfer switch to operate
customer accessories, remote advisory lights, or remote
annunciator devices. A suitable power source must be
connected to the common terminal. If needed, an extra
auxiliary contact can be added.
Figure 3-4. Auxiliary Contact
The auxiliary contact is normally closed when the transfer
switch is in utility mode. The contacts will open when the
transfer switch is in the standby power mode.
NOTE: Auxiliary Contact is rated 10 amps at 125 or 250
volts AC, and 0.6 amps at 125 volts DC.
Fault Current Label
See Figure 3-5 . A Fault Current Identification Label is
provided in the bag containing the unit Owner’s Manual and
transfer switch manual operating handle. The 2017 NEC
requires that the short-circuit current rating of the transfer
equipment, based on the type of overcurrent protective
device protecting the transfer equipment, be field marked on
the exterior of the transfer equipment. For NEC compliance,
verify the required short-circuit current rating of the transfer
switch before installation.The completed label provides the
local AHJ (Authority Having Jurisdiction) with the information
he or she may require during inspection.
Apply the label to the exterior of the transfer switch
enclosure. Use a pen to fill in the required information, and
then cover the label with the clear protective decal.
Figure 3-5. Fault Current Label
003626
A
(000134a)
CAUTION
Equipment damage. Exceeding rated voltage and
current will damage the auxiliary contacts. Verify
that voltage and current are within specification
before energizing this equipment.
004496

Installation
14 Automatic Transfer Switch Owner’s Manual
This page intentionally left blank.

Operation
Automatic Transfer Switch Owner’s Manual 15
Section 4: Operation
Functional Tests and Adjustments
Following transfer switch installation and interconnection,
inspect the entire installation carefully. A competent,
qualified electrician should inspect it. The installation
should comply strictly with all applicable codes,
standards, and regulations. When absolutely certain the
installation is proper and correct, complete a functional
test of the system.
IMPORTANT: Before proceeding with functional tests,
read and make sure all instructions and information in
this section is understood. Also read the information and
instructions of labels and decals affixed to the switch.
Note any options or accessories that might be installed
and review their operation.
Manual Operation
See Figure 4-1. A manual handle (B) is shipped with the
transfer switch manual. Manual operation must be
checked BEFORE the transfer switch is operated
electrically. To check manual operation, proceed as
follows:
1. Verify the generator is in the OFF mode.
2. Turn OFF both utility (service disconnect circuit
breaker) and emergency (generator main line
circuit breaker) power supplies to the transfer
switch.
3. Note position of transfer mechanism main contacts
(A) by observing the movable contact carrier arm.
This can be viewed through the long narrow slot in
the inside cover. The top of the movable contact
carrier arm is yellow to be easily identified.
•Manual operation handle in the UP position—LOAD
terminals (T1, T2) are connected to utility terminals
(N1, N2).
•Manual operation handle in the DOWN position—
LOAD terminals (T1, T2) are connected to
EMERGENCY terminals (E1, E2).
Close to Utility Source Side
Before proceeding, verify the position of the switch by
observing the position of manual operation handle in
Figure 4-1. If the handle is UP, the contacts are closed in
the utility (normal) position, no further action is required.
If the handle is DOWN, proceed with Step 1.
1. With the handle inserted into the movable contact
carrier arm, move handle UP. Be sure to hold on to
the handle as it will move quickly after the center of
travel.
2. Remove manual operating handle from movable
contact carrier arm. Return handle to storage
bracket.
Figure 4-1. Manual Operation
(000121)
CAUTION
Equipment damage. Perform functional tests in the
exact order they are presented in the manual.
Failure to do so could result in equipment damage.
(000132)
DANGER
Electrocution. Do not manually transfer under load.
Disconnect transfer switch from all power sources
prior to manual transfer. Failure to do so will result
in death or serious injury, and equipment damage.
(000122)
CAUTION
Equipment damage. Do not use excessive force while
manually operating the transfer switch. Doing so could
result in equipment damage.
006148
A
B
B

Operation
16 Automatic Transfer Switch Owner’s Manual
Close to Generator Source Side
Before proceeding, verify the position of the switch by
observing the position of the manual operation handle in
Figure 4-1 . If the handle is DOWN, the contacts are
closed in the generator (standby) position. No further
action is required. If the handle is UP, proceed with Step 1.
1. With the handle inserted into the movable contact
carrier arm, move the handle DOWN. Be sure to
hold on to the handle as it will move quickly after
the center of travel.
2. Remove manual operating handle from movable
contact carrier arm. Return handle to storage
bracket.
Return to Utility Source Side
1. Manually actuate switch to return manual operating
handle to the UP position.
2. Remove manual operating handle from movable
contact carrier arm. Return handle to storage
bracket.
Voltage Checks
NOTE: Use the Digital Multimeter (DMM) LowZ low input
impedance setting to collect accurate voltage
measurements. LowZ eliminates the possibility of
inaccurate ghost voltage readings, also known as
phantom voltage or stray voltage readings. Refer to the
DMM manufacturer’s literature for additional information.
Utility Voltage Checks
1. Turn ON the utility power supply to the transfer
switch using the utility service disconnect circuit
breaker.
2. With an accurate AC voltmeter, check for correct
voltage. Measure across ATS terminal lugs N1 and
N2; N1 to NEUTRAL and N2 to NEUTRAL.
Generator Voltage Checks
1. On the generator panel, select the MANUAL mode
of operation. The generator should crank and start.
2. Let the generator stabilize and warm up at no-load
for at least five minutes.
3. Set the generator's main circuit breaker (CB1) to its
ON or CLOSED position.
4. With an accurate AC voltmeter and frequency
meter, check the no-load, voltage and frequency.
Measure across ATS terminal lugs E1 to E2; E1 to
NEUTRAL and E2 to NEUTRAL.
5. When certain that generator supply voltage is
correct and compatible with transfer switch ratings,
turn OFF the generator supply to the transfer switch.
6. Set the generator main circuit breaker (CB1) to
OFF or OPEN.
7. On the generator panel, select the OFF mode to
shut down the generator.
NOTE: Do NOT proceed until generator AC output
voltage and frequency are correct and within stated
limits.
Generator Tests Under Load
1. Set the generator main circuit breaker to OFF or
OPEN.
2. Set the utility service disconnect circuit breaker of
the transfer switch to OFF or OPEN, and turn OFF
or OPEN all load circuit breakers.
3. Manually actuate transfer switch main contacts to
the emergency (standby) position. See Manual
Operation.
4. To start the generator, select the MANUAL mode of
operation. When engine starts, let it stabilize for a
few minutes, and close lid (if applicable).
(000129)
DANGER
Electrocution. High voltage is present at
transfer switch and terminals. Contact with live
terminals will result in death or serious injury.
(000123)
DANGER
Electrocution. Turn utility supply OFF before
working on utility connections of the transfer
switch. Failure to do so will result in death or
serious injury.
Frequency 60–62 Hz
Terminals E1 to E2 240–246 VAC
Terminals E1 to NEUTRAL 120–123 VAC
Terminals E2 to NEUTRAL 120–123 VAC
(000129)
DANGER
Electrocution. High voltage is present at
transfer switch and terminals. Contact with live
terminals will result in death or serious injury.
