Honeywell Satellite Receiver User manual

RedLINK™Wireless Accessories
Remote control • Outdoor air sensor
® U.S. Registered Trademark.
Copyright © 2008 Honeywell International Inc.
All rights reserved.
Español: vea la página 7 • Français : voir la page 13
Thermostat
Outdoor
air sensor
Remote
control
Equipment interface module (or
TrueZONE™panel with wireless adapter)
Installation procedure
Install batteries in wireless devices ................................Page 2
Link devices to wireless network................................Pages 2-3
Mount outdoor sensor ......................................................Page 4
To replace system components if needed, see page 5
3
2
1
HVAC
equipment
If there is more than one Equipment Interface Module (EIM) or zone panel:
Wireless devices must be linked separately to each EIM or zone panel.
Installation
Guide

Install batteries in wireless devices
1
Make sure batteries are inserted properly (see polarity marks on illustrations
below).
Link devices to wireless network
2
Press the CONNECT button at the EIM or
wireless adapter and wait for green
flashing light to begin linking devices to
the wireless network (see page 3).
If the light stops flashing before you
have linked all devices, press CONNECT
again.
Press CONNECT
Remote control Outdoor air sensor
Install 3 fresh AA
batteries
Install 2 fresh AA
lithium batteries
Flashing status light times out after 15
minutes of inactivity. Press CONNECT again if
necessary.
Continued on next page >>
RedLINK™ Installation Guide (Wireless Accessories)
2
If light does not flash, another EIM/wireless
adapter may be in wireless setup mode. Exit
wireless setup at the other EIM/wireless
adapter.

3
Español: vea la página 7 • Français : voir la page 13
Link remote control to wireless network
1Make sure the Connected light on the
EIM or wireless adapter is flashing
(see page 2).
2Press CONNECT at the remote. There will
be a short delay as the remote seeks
a signal from the wireless network.
3When the screen displays
“Connected,” press DONE.
4Press NO at the next screen to save and
exit. (Or press YES and repeat steps 1-4
to link another EIM/zone panel.)
Link outdoor sensor to wireless network
1Make sure the Connected light on the
EIM or wireless adapter is flashing
(see page 2).
2Press the CONNECT button on the back
of the sensor.
3Check thermostat to verify that the
outdoor sensor is working. After
about 15 seconds, the thermostat
should display outdoor temperature
and humidity.
(If there is more than one EIM/zone
panel, repeat steps 1-3 for each.)
Press and release
If E1 appears, see error codes on page 5.
WIRELESS SETUP
CONNECT
YES NO
CONNECT MORE? The linking procedure may time out if there is
no keypress within 30 minutes. To begin again,
press and hold the blank space (or arrow if
present) in the lower right corner of the screen
until the display changes (about 3 seconds)
Press to link another
EIM or zone panel
Press to save
and exit

Place sensor securely
in bracket, facing
away from wall
Mount the sensor on a
vertical exterior wall, at
least 6 inches below
any overhang. Choose
a location protected
from direct sunlight.
Mount outdoor sensor
3
4
RedLINK™ Installation Guide (Wireless Accessories)
To check location before mounting: Restore
thermostat Home screen, then hold the sensor
where you intend to install it and press the CONNECT
button. If sensor is working properly, thermostat will
switch to display outdoor temperature and humidity.
Press and release

5
Español: vea la página 7 • Français : voir la page 13
Error codes (remote control)
If E1 appears during setup, check error code number:
29 You are attempting to connect a remote control to an incompatible device.
34 Low signal strength. Move remote control to a different location and try again.
38 Make sure Connected light is flashing and you are 2+ feet away from EIM or
wireless adapter.
Replacing system components
Remote control or outdoor sensor
To replace a remote control or outdoor air sensor, install batteries in the
new component and follow the procedure on pages 2-3 to link it to the
wireless network.
EIM or zone panel
After installing a new EIM or zone panel, you must re-set the remote
control to communicate with the new equipment, as described below.
At the remote control:
1 Press and hold the blank space (or arrow if present) in the lower right
corner of the screen until the display changes (about 3 seconds).
2 Press REMOVE , then YES to disconnect from old equipment.
3 Follow the procedure on pages 2-3 to link to new equipment.
Press and hold for
about 3 seconds

RedLINK™ Installation Guide (Wireless Accessories)
6
Regulatory information
FCC Compliance Statement (Part 15.19) (USA only)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1 This device may not cause harmful interference, and
2 This device must accept any interference received, including interference that may cause
undesired operation.
FCC Warning (Part 15.21) (USA only)
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC Interference Statement (Part 15.105 (b)) (USA only)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Outdoor sensor
To comply with FCC and Industry Canada RF exposure limits for general population/ uncon-
trolled exposure, the antenna(s) used for these transmitters must be installed to provide a
separation distance of at least 20 cm from all persons and must not be co-located or operating
in conjunction with any other antenna or transmitter.
Remote control
This portable transmitter with its antenna complies with FCC and Industry Canada RF
exposure limits for general population/uncontrolled exposure.
Section 7.1.5 of RSS-GEN
Operation is subject to the following two conditions:
1 this device may not cause interference, and
2 this device must accept any interference, including interference that may cause undesired
operation of the device.
