Honeywell Chronotherm CM67 User manual

Installation
42009636-005 R3
1
honeywell
Chronotherm
Parameters
Optimisation
Minimum ON Time
AM-PM / 24hr Display
Accessory Module Type
RESET Time / Temperature
Program
Heat / Cool Operation
Electric Heat
Pump Exercise
Cycle Rate
Second Temperature
Sensor
Upper Temperature Limit
Lower Temperature Limit
Temperature Offset
Pressure Offset
(needed for Weatherstation
accessory only)
Proportional Band Width
Return all Set-Up Features
to Factory Settings
Installer Set-Up Mode - SettingsTable
You must now press the PROG 2 key to enter the next section
Installer Set-Up
Number /
Abbreviation
(Press + or -
key to change)
1:0P
2:0t
3:Cl
4:At
5:rP
6:HC
7:Eh
8:PE
9:Cr
10:SS
11:UL
12:LL
13:tO
14:PO
15:Pb
16:FS
Display
0
1
0
0
1
1
0
0
6
0
30
5
0
0
1.5
1
Factory Setting
Description
Optimisation disabled
1 minute minimum ON time
24 hr clock display
No accessory module
plugged in
Time / Temperature profile
set to factory default
Changes to 0 when one of the
time/temp profiles are changed
Heating Operation
Applications < 3A
Pump Exercise Disabled
6 cycles per hour (cph) for
gas boilers, zone valves and
fan-coil
No sensor fitted
30°C Upper Temp. Limit
5°C Lower Temp. Limit
No offset
No offset
1.5°C Proportional Band
All settings held are the
factory defaults. Changes to
0 when one of the parameter
values are changed
Display/Setting
1
2 to 5
1
1, 2
0
1
0
1
1
3, 9, 12
1, 2
21 to 29
6 to 16
-3 to +3
-99 to +99
1.6 to 3.0
0
1
Optional Setting
Description
Optimisation enabled
2 - 2 minutes
3 - 3 minutes
4 - 4 minutes
5 - 5 minutes
12 hr AM / PM clock display
1 - Auto Time Setting Module
2 - Weatherstation Module
Time / Temperature are as
programmed
To restore the factory profile
set to 1
Cooling Operation
Applications 3 - 8A
Pump Exercise Enabled
3 - 3 cph
9 - 9cph
12 - 12 cph
1 - Outside Temperature
Sensor fitted
2 -Remote Temp. Sensor fitted
21°C to 29°C adjustment in
1°C steps
6°C to 16°C adjustment in 1°C
steps
-3°C to +3°C adjustment in
0.1°C steps
-99 mbar to +99 mbar
adjustment in 1 mbar steps
1.6°C to 3.0°C adjustment in
0.1°C steps
Settings are as modified
above
To restore the factory profile
set to 1
Installer Set-Up
Category
(Press keys PROG 1
or 2 to select)
1 2
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
Notes
1) When the Installer Set-Up Mode is initiated, only Category 1 (1) Set-Up Features
are accessible.
Category 2 (2) Set-Up Features are accessed by pressing the PROG. 2 key.
2) Remember to always press the INFO button to confirm that you want to store your new
Installer Set-Up setting.
3) To exit the Installer Set-Up Mode move the slider to the AUTOmatic or MANual position.
2
34 a4 b
4 c5
6
1.0-2.5mm²
honeywell
Home Comfort & Systems
Honeywell Control Systems Ltd.
Newhouse Industrial Estate
Motherwell, ML1 5SB
Scotland
http://europe.hbc.honeywell.com
3mm
max.
3mm
max.
This product has been designed with your
environment in mind! Please respect this by
disposing of all packaging, used parts and
eventually the product itself in an environ-
mentally friendly manner.

8 9
10 11
You have now installed the Chronotherm. For gas boiler applications, the factory system
settings will not need to be changed (for other applications see below).You can now use
the USER GUIDE to program the unit and demonstrate how it works to the homeowner.
Special Features
Optimisation (Variable
Start Time)
AM-PM/ 24hr Display
Pump Exercise
Upper Temperature Limit
Lower Temperature Limit
Temperature Offset
Proportional Band Width
What do I need to do if I wish
this feature?
Set parameter n.1 in the installer
set-up mode to 1
Set parameter n.3 in the installer
set-up mode to 1
Set parameter n.8 in the installer
set-up mode to 1
Set parameter n.11 in the installer
set-up mode to the desired limit
Set parameter n.12 in the installer
set-up mode to the desired limit
Set parameter n.13 in the installer
set-up mode to the desired offset
value.
Set parameter n.15 in the installer
set-up mode to the desired value
Description
The Chronotherm will adjust the start time in the morning/afternoon so the
desired temperature is reached by the start of the program period e.g.Time
7:00, Temp 21°C.The system will restrict the start time to a max of 3 hours
The end user can have a different clock format display
The circulating pump on hydronic systems can be exercised once a day for 1
minute at mid-day.Useful to prevent the pump from sticking after the summer
The normal upper temperature limit of 30°C can be reduced down to 21°C to
save the homeowner energy.
The normal lower temperature limit of 5°C can be increased up to 16°C to
protect the inhabitants from cold. Useful if the inhabitants include the elderly,
children or disabled
If the Chronotherm is located in a particularly hot/cold location and cannot
be moved because of wiring then the measured/displayed temperature can
be adjusted by +/- 3°C. Useful if the homeowner wants the reading to match
another appliance temperature display
Can be adjusted up to 3°C (default is 1.5°C) to provide better temperature
control (less overshoot). Useful for:
a. Well insulated homes with over-sized heating systems
b. Air systems with fast response
Optional
Accessories
Outside Temperature
Sensor
Remote Temperature
Sensor
Automatic Time Setting
(ATS) Module
What do I need to do if I wish
this feature?
1. Fit the sensor (instructions
included in the sensor package)
2. Set parameter n.10 in the
installer set-up mode to 1
1. Fit the sensor (instructions
included in the sensor package)
2. Set parameter n.10 in the
installer set-up mode to 2
1. Fit the ATS module
2. Set parameter n. 4 in the
installer set-up mode to 1
Description
An Outside Temperature Sensor can be fitted to your CM67 to allow the
homeowner to display the outside temperature on the Chronotherm display
by using the INFO button.
A Remote Temperature Sensor can be fitted to your CM67 to allow the
Chronotherm to control the temperature from another room e.g. in a
commercial premises where the public may adjust keys.
The ATS module picks up a time signal daily from a European transmitter, so
you never need to set or adjust the time.
Move the slider to
the OFF position.
Press and hold
INFO button and
press PROG 3,4
together.
Press TEMP or to change factory setting.
The display will flash indicating that a change has
been made.
Press INFO button to confirm the change is ok.
The display will stop flashing indicating that the new
value has been stored.
Adjust other settings using the Installer Set-
Up Mode - SettingsTable on the next page.
To exit the Installer Set-Up Mode move the
slider to the AUTOmatic or MANual position.
12
34
5 6
7
7
1
Installer Set-Up Number
(Press + or - to change)
e.g. 1 = Optimisation
Abbreviated Set-Up Description
e.g.
0 P = Optimisation
Factory Setting or New Choice
(PressTemp or to change)
e.g. 0 = Optimisation disabled
e.g. 1 = Optimisation enabled
Installer Set-Up Mode
Selected
Category 1 Installer Set-Ups
1
Once you have inserted the battery cartridge,
after a pause the unit will display information.
If this does not happen or the display shows
the symbol please refer to the‘trouble
shooting’ section in the CM67 user guide.
What else will the Chronotherm do?
Cover Specific Applications
Perform Special Features
Support Optional Accessories Installer Set-Up Mode
1
Press + or - to go to the next parameter and follow
steps 3 & 4 to make changes.
1
Specific Application
Heating
Air-
conditioning
What do I need to change?
Note:
a. To change Cycle/Hour, please go to parameter n. 9 in the installer
set-up mode.
b. To change Minimum ON Time, please go to parameter n. 2 in the
installer set-up mode
No action required
1. Set Minimum ON Time to 4 minutes.
2. Set Cycle/Hour to 3.
Set Cycle/Hour to 12.
No action required
1. Configure the Chronotherm for electric heating (set parameter n.7
in the installer set up mode to 1)
2. Set Cycle/Hour to 12
1. For cooling application only, set the Chronotherm to cooling (set
parameter n.6 in the installer set-up mode to 0)
2. For heat/cool application, set the Chronotherm accordingly to
required mode of operation by changing parameter n.6 in the
installer set-up mode.
winter = heating summer = cooling
Explain to the end-user how to implement the change-over and ensure that the
appropriate time and temperature profile is established for heating and cooling
1. Set Minimum ON Time to 4 minutes.
2. Set Cycle/Hour to 3.
No action required
Setting
Cycle/ Minimum
Hour ON Time
61
34
12 1
61
12 1
34
61
Gas Boilers
(<30KW)
Oil Boiler
Thermal Actuator
Zone Valve
Electric Heating
(for applications
<8A)
Heat Pump/Air
conditioner
Fan Coil
