OWNER’S GUIDE
62-3071—2
TB8220U Commercial
Programmable Thermostat

2 62-3071—2
CONTENTS
Features ..................................................................................................................... 3
Main Screen Selections .............................................................................................. 4
Programming Heating and Cooling Schedule ............................................................ 6
Operating the Thermostat .......................................................................................... 10
Replacing Batteries .................................................................................................... 15
Cleaning Thermostat Screen ...................................................................................... 18
Reading Outdoor Temperature ................................................................................... 20
Reading Remote Indoor Temperature ........................................................................ 19
Advanced Settings ..................................................................................................... 26
Frequently Asked Questions and Answers ................................................................ 30
Limited Five-Year Warranty ........................................................................................ 31
Customer Assistance ................................................................................................. 32
IMPORTANT
The thermostat has a touch screen interface. Touch keys appear, as necessary, to
complete tasks. Always press the screen with a fingertip. Sharp instruments like a
pen or pencil point can damage the thermostat.

3 62-3071—2
FEATURES
• Large, Clear Display with Backlighting—current temperature, set temperature and
time are easy-to-read and all are displayed on the main screen.
• Menu Driven Programming—Provides guidance through the scheduling process,
showing only necessary information and choices on each screen.
• Ability to Select Multiple Days—allows easy customizing for unique schedules.
• Real-Time Clock—keeps time during power failure; automatically updates for
daylight savings.
• Armchair Programming—can remove thermostat from wall to set the schedule.
• Precise Temperature Control (±1°F)—reliable, consistent comfort.
• Multiple OVERRIDE options—can modify schedule indefinitely or for a specific
period of time.
• Programmable Fan—increases indoor air quality when combined with air
cleaning equipment.
• Outdoor Temperature Indication—displays current outdoor temperature to help
plan outdoor activities.
NOTE: The main screen can differ slightly, depending on the heating, ventilation and air
conditioning (HVAC) system and the thermostat settings for the system type.

4 62-3071—2
Main Screen Selections
SCHEDULE HOLIDAY CLOCK SCREEN OVERRIDE
TUE
AM
FAN
AUTO
SYSTEM
HEAT
Following
Schedule
Inside
M22748A
FAN
SELECTS
ON/AUTO
SYSTEM
SELECTS
HEAT/OFF/
COOL/AUTO
SCHEDULE
ENTERS
SCHEDULING MODE
HOLIDAY
CHANGES TEMPERATURE
SETTING FOR DESIGNATED
NUMBER OF DAYS
SCREEN
LOCKS OUT THE SCREEN TO
ALLOW FOR CLEANING
CLOCK
SETS THE TIME FORWARD OR BACK
UP ARROW
RAISES
TEMPERATURE
SETTING
DOWN ARROW
LOWERS
TEMPERATURE
SETTING
OVERRIDE
SET TEMPORARY
OVERRIDE

5 62-3071—2
Main Screen Display
SCHEDULE HOLIDAY CLOCK SCREEN OVERRIDE
TUE
AM
FAN
AUTO
SYSTEM
HEAT
Following
Schedule
Inside
M22749
FAN
SHOWS FAN
SETTING
TUE
SHOWS CURRENT
DAY OF THE WEEK
SYSTEM
SHOWS CURRENT
SYSTEM POSITION
TIME
DISPLAY CURRENT
TIME OF DAY, HOLD
TIME REMAINING
OR NUMBER OF
HOLIDAY DAYS
REMAINING
INSIDE TEMPERATURE
SHOWS THE CURRENT INSIDE TEMPERATURE
SET TO
TEMPERATURE
SHOWS THE
CURRENT
SET
TEMPERATURE
FOLLOWING
SCHEDULE
SHOWS THE
THERMOSTAT IS
FOLLOWING THE
PROGRAMMED
SCHEDULE
Occupied

6 62-3071—2
Programming Heating and Cooling Schedule
The thermostat can control up to four different schedule periods per day:
OCC 1—Work arrival time. Period to keep space at a comfortable temperature.
UNOCC1—Work exit time. Period to keep space at an energy-saving temperature.
OCC 2—Second occupied period.
UNOCC2—Second unoccupied period.
NOTE: Available schedule times are at 15-minute intervals.
Editing Schedule
1. Press SCHEDULE.
2. Press EDIT.
NOTES:
— The first time a change is
made, the screen appears
mostly blank.
— Multiple days can be selected.
3. Select any combination of days to
edit.
NOTE: Checkmarks appear next to
selected days. These are
scheduled with identical times and temperatures.
CANCEL
MON TUE WED THU FRI SAT SUN
OK TO PICK MULTIPLE DAYS
M19954

7 62-3071—2
4. Press OCC 1. Once pressed, OCC 1 flashes to show it is selected.
5. Press Up and Down to modify time
and temperatures from this screen.
NOTE: Fan settings for the selected
period can be programmed for
ON or AUTO. See Fan Schedule
section for more information.
6. Press UNOCC1 and repeat step 5.
NOTE: With default settings, only
OCC 1 and UNOCC1 can
be configured. To use
OCC 2 and UNOCC2, enter
the Installer Setup and
change the appropriate
parameter.
7. Press OCC 2 and repeat step 5.
8. Press UNOCC2 and repeat step 5.
DONE OCC 1 UNOCC1 OCC 2 UNOCC2 CANCEL
MON TUE WED THU FRI SAT SUN
AM
FAN
ON
AUTO
CANCEL
PERIOD
HEAT
COOL
OK TO PICK MULTIPLE DAYS
M22750

8 62-3071—2
9. When complete, press DONE.
SAVING CHANGES appears on the
screen to indicate changes are being
saved to the day(s) modified.
NOTE: To schedule the remaining days
of the week, repeat steps 1-9.
10. To exit schedule without saving
changes, press CANCEL any time.
Cancelling a Schedule Period
NOTE: To accommodate special needs,
a period can be cancelled.
For example, if the space is always unoccupied during the weekend, cancel all
Saturday and Sunday (occupied and unoccupied) periods. The thermostat then
controls to the final Friday UNNOC temperature until the Monday OCC 1 period.
1. Press SCHEDULE.
2. Press EDIT.
3. Select the Day(s) of the week desired.
4. Press the schedule period to cancel (OCC 1, UNOCC1, OCC 2 or UNOCC2). Once
selected, the period flashes.
MON TUE WED THU FRI
SAVING
CHANGES
M22751

9 62-3071—2
5. Press CANCEL PERIOD. The time,
temperature(s) and fan setting
disappear. The bar above the
selected period is removed,
indicating the scheduled period
was cancelled.
NOTE: To reinstate a schedule period,
press an arrow to set desired time
and temperatures.
6. Press DONE.
DONE OCC1 UNOCC1 OCC2 UNOCC2 CANCEL
MON TUE WED THU FRI SAT SUN
FAN
HEAT
COOL
OK TO PICK MULTIPLE DAYS
M22752

10 62-3071—2
Setting Time
1. Press CLOCK.
2. Use arrows to set current time.
3. Press DONE.
IMPORTANT
The current day of the week
should already be set correctly.
If not, see the Advanced Settings
section to set the day.
Operating the Thermostat
Setting Fan and System
SETTING FAN
Fan selections vary based on the HVAC system type.
ON—fan runs continuously. Use this setting for improved air circulation or for more efficient
central air cleaning.
AUTO—fan follows fan program schedule. See Fan Schedule section for more information.
DONE CANCEL
TUE
A
M
M19958

11 62-3071—2
SETTING SYSTEM
The System selections vary based on the HVAC system type.
HEAT — thermostat controls the heating system.
OFF — both heating and cooling systems are off.
COOL — thermostat controls the cooling system.
AUTO — thermostat controls both the heating and cooling systems based on temperature.
Setting Temperature Overrides
There are three temperature override options:
— Hold Temperature Until
— Override, and
— Holiday.
HOLD TEMPERATURE UNTIL
Holds the temperature temporarily until the time set by the user, or the next scheduled
period time.
1. Press the Up or Down arrow next to the temperature to adjust. The Hold Temperature
Until time appears on the screen. The time defaults to the next scheduled period start
time.
NOTE: Time Up and Down arrows are shown for approximately seven seconds.
Pressing the screen time (where the “Hold Temperature Until” time displays)
causes the arrows to reappear.

12 62-3071—2
2. Press Up or Down arrow next to the
hold time to set desired time for the
thermostat to resume schedule.
NOTE: The installer setup can limit
the length of time for an
override to 1, 2, 3, or 4
hours beyond the current
time.
3. Press CANCEL or SCHEDULE to
cancel “Hold Temperature Until” and
resume the schedule.
NOTE: Once the Hold Temperature Until
time is reached, the thermostat
displays “Following Schedule” to indicate that the Hold (Override) has ended.
OVERRIDE
Changes temperature setting until the next period takes effect. For use during Unoccupied
periods.
1. Press OVERRIDE. The settings change by default to the next Occupied period.
NOTE: Changes are limited to those allowed by the lockout level.
2. Press Up or Down arrow to change the override time and temperature.
SCHEDULE HOLIDAY CLOCK SCREEN
CANCEL
TUE
PM
FAN
AUTO
SYSTEM
HEAT
Inside
Hold Temperature
Until
Set
M22753
Occupied

13 62-3071—2
HOLIDAY
Changes temperature setting for a
designated number of days.
1. Press HOLIDAY. The screen shows
“Hold Temperature Until 1 DAYS”.
2. Press Up or Down arrow to change
the number of days desired for the
thermostat to override the schedule.
3. Press the Up or Down arrow to
change the desired temperature
for the duration of the holiday.
NOTE: The DAYS Up and Down arrows
appear for approximately seven
seconds. Pressing the screen just
below Hold Temperature Until
allows the DAYS Up and Down
arrows to reappear.
4. To cancel the Holiday Override early, press CANCEL.
NOTE: When the number of Holiday Override days expires, the screen shows
“Following Schedule” to indicate that the Holiday Override has ended.
SCHEDULE CLOCK SCREEN
CANCEL
THU
FAN
AUTO
SYSTEM
HEAT
Inside
DAYS
Hold Temperature
Until
Set To
M22754
DONE
Unoccupied

14 62-3071—2
Fan Schedule
Press FAN while in the SCHEDULE screen to program the system fan. Choices available
from the SCHEDULE screen:
AUTO (default position)—fan runs with equipment. Programmable for all SCHEDULE
periods (OCC 1, UNOCC1, OCC 2 and UNOCC2).
ON—fan runs continuously (programmable for all SCHEDULE periods).
Fan Status Displayed on Main Screen
If the fan program is scheduled, the scheduled mode (AUTO or ON) appears. When the
thermostat is running the fan, the fan blade symbol appears next to FAN to indicate the
thermostat has the fan on.
NOTE: If the thermostat is not controlling the fan—typical for many gas, forced-air heating
systems—the fan blade symbol will not appear even though the fan may be
running.
Manual Override of Fan Schedule
AUTO—fan is automatically following the FAN schedule (choices are AUTO and ON).
ON—overrides FAN schedule. The fan is continuously on.

15 62-3071—2
Replacing Batteries
Not all thermostat models require batteries.
If the thermostat has batteries, a low
battery warning flashes on the main screen
for approximately 30 days.
NOTES:
— If batteries are not replaced
when the Low Battery warning
is flashing, the LO batt screen
displays continuously and the
thermostat stops operating
until batteries are replaced.
— The thermostat has a low
battery indicator. However, it is
recommended that you
replace the batteries once
each year. Do this to prevent leakage and prevent the thermostat and
HVAC system from shutting down due to lack of thermostat battery power.
M22755

16 62-3071—2
Replace the batteries as follows:
1. Remove the thermostat
from the base by pulling
it straight out.
2. Install three new AAA
alkaline batteries with
proper polarization.
NOTES:
— Always use AAA
alkaline batteries.
— All programming
(Schedule, Date
and Time) infor-
mation is retained
during battery
replacement.
WALL
M19919
REMOVE DURING
INSTALLATION

17 62-3071—2
3. Place the thermostat back on its
base by aligning the terminal screw
blocks with the pins on the back of
the thermostat.
4. Push the thermostat straight onto
the base.
M19918
BATTERIES (3)

18 62-3071—2
Cleaning Thermostat Screen
The thermostat has a touch screen interface. Follow these steps to clean the screen
without making thermostat changes:
1. Press SCREEN. Thermostat locks
out the keypad for 30 seconds to
allow for cleaning.
IMPORTANT
Do not spray any liquid directly on
the screen. If using household
glass cleaner, spray cleaner on
cloth. Then use the cloth wipe the
screen clean.
2. Use damp cloth slightly moistened
with water or household glass
cleaner to clean the screen.
3. Repeat above steps, as necessary.
4. Press DONE to return to the main
screen and normal operation.
NOTE: If no button is pressed for two minutes, the device automatically returns to the
main screen.
OK TO
CLEAN
M22756

19 62-3071—2
Reading Remote Indoor Temperature
If connected to an installed remote indoor
temperature sensor, the thermostat
displays the indoor temperature from the
remote sensor(s).
NOTE: When connected to an installed
remote indoor temperature
sensor, the thermostat internal
sensor is not used.
ONE REMOTE INDOOR SENSOR INSTALLED
If one remote indoor temperature sensor is
used, the screen showing the Inside
temperature reading displays the
temperature at the indoor remote sensor
location.
MULTIPLE REMOTE INDOOR SENSORS INSTALLED
If more than one remote indoor sensor is used, the screen showing the Inside temperature
reading displays the average of all the remote indoor sensors.
Heat On
SCHEDULE HOLIDAY CLOCK SCREEN OVERRIDE
MON
MON
TUE WED
WED
THU
THU
FRI
FRI
S
S
A
A
SUN
AM
FAN
AUTO
SYSTEM
HEAT
Following
Schedule
Inside Set
OK TO PICK MULTIPLE DAYS SCREEN LOCKED
M22758

20 62-3071—2
Reading Outdoor Temperature
If connected to an outdoor sensor, the thermostat displays the Outside temperature.
VIEW OUTSIDE TEMPERATURE
The Outside temperature is located in the
lower right corner of the main screen. If it is
not on the main screen, view the outdoor
temperature by pressing MORE until the
outside temperature shows.
Heat On
SCHEDULE HOLIDAY CLOCK SCREEN MORE
MON
MON
TUE WED
WED
THU
THU
FRI
FRI
S
S
A
A
SUN
AM
FAN
AUTO
SYSTEM
HEAT
CHANGE FILTER UV LAMP HUMIDIFIER PAD
Following
Schedule
Outside
Set
OK TO PICK MULTIPLE DAYS SCREEN LOCKED
OVERRIDE
M22757
