Honeywell P7650A Series User manual

INSTALLATION INSTRUCTIONS
31-00138-02
50
P7650A/B/U
DIFFERENTIAL PRESSURE TRANSDUCER, DRY MEDIA
APPLICATION
The P7650A/B/U Differential Pressure Sensor measures
static and differential air pressure in duct and panel
applications. It can also measure air velocity using
pressure-velocity pick up tubes P7650L6, P7650L8,
P7650L10, P7650L12, or P7650L14. P7650A/B/U can be
ordered in duct or panel versions and in 0 to 1 in. (0 to
250 Pa) or 0 to 10 in. (0 to 2500 Pa) pressure ranges.
Universal models can be configured for duct or panel and
for 0 to 1 in. (0 to 250 Pa) or 0 to 10 in. (0 to 2500 Pa)
pressure ranges. All variants are available with and
without LCD display. The P7650A/B/U has an
IP65/NEMA 4 environmental rating and a 5-year limited
warranty.
IMPORTANT
• This product is not intended for life or safety
applications.
• Do not install this product in hazardous or classified
locations.
• Read and understand the instructions before installing
this product.
• Turn off all power supplying equipment before working
on it.
• The installer is responsible for conformance to all
applicable codes.
• If this product is used in a manner not specified by the
manufacturer, the protection provided by the product
may be impaired. No responsibility is assumed by the
manufacturer for any consequences arising out of the
use of this material.
PRODUCT IDENTIFICATION
New Part Number Mounting
Selectable w.c. Pressure Range,
Uni or Bi-Directional Velocity Mode Display Output
Supply
Voltage
P7650A1000
Panel
+/-0-.1", 0-.25", 0-.5", 0-1" w.c. or
+/-25, 50, 100, 250 Pa Selectable
500/1,000/2,000/
3,000 FPM
2.5/5/10/15MS
Yes
0-10Vdc, 0-5Vdc, and
4-20mA Selectable
12-30Vdc or
24Vac
P7650A1018 No
P7650A1026 +/-0-1", 0-2", 0-5", 0-10" or
+/-0.250, 0.500, 1.00, 2.50 kPa
Selectable
3,000/4,000/5,000/
6,000 FPM
15/20/25/30MS
Yes
P7650A1034 No
P7650B1008
Duct
+/-0-.1", 0-.25", 0-.5", 0-1" w.c. or
+/-25, 50, 100, 250 Pa Selectable
500/1,000/2,000/
3,000 FPM
2.5/5/10/15MS
Yes
P7650B1016 No
P7650B1024 +/-0-1", 0-2", 0-5", 0-10" or
+/-0.250, 0.500, 1.00, 2.50 kPa
Selectable
3,000/4,000/5,000/
6,000 FPM
15/20/25/30MS
Yes
P7650B1032 No
P7650U1040
Universal
+/-0-.1", 0-.25", 0-.5", 0-1", 0-2",
0-5", 0-10" in. w.c. or
+/-0.25, 0.5, 1.0, 2.5 kPa; or
+/-25, 50, 100, 250 Pa Selectable
500/1,000/2,000/
3,000/4,000/5,000/
6,000/7,000 FPM
2.5/5/10/15/20/
25/30/35 MS
No
P7650U1052 Yes

P7650A/B/U
31-00138—02 2
DIMENSIONS
Fig. 1.
SPECIFICATIONS
Media Compatibility:
Dry air or inert gas
Input Power:
Three-wire Volt mode: 24 Vac or 12-30 Vdc*
Two-wire mA mode: 12-30 Vdc*
Output Power Field-selectable:
2-wire, loop-powered 4-20 mA**
(DC only, clipped and capped), 24 Vac/dc or 3-wire 0-
5V/0-10V***
Response Time:
Standard: T95 in 20 sec, Fast: T95 in 2 sec, DIP switch
selectable
Pressure Mode:
Selectable unidirectional or bidirectional (example: uni-
directional 0 to 1 inch w.c., or bi-directional -1 to 1 inch
w.c.), DIP switch selectable
Velocity Mode:
Velocity is set up in Feet/Minute or Meters/second
Display (Option):
Pressure mode: Signed 3-1/2 digit LCD, indicates
pressure, overrange indicator
Velocity mode: Signed 4-1/2 digit LCD, indicates velocity,
overrange indicator
Proof Pressure:
3psid(20.6kPa)
Burst Pressure:
5psid(34.5kPa)
Pressure Mode Accuracy:
±1% F.S. (combined linearity and hysteresis)
Velocity Mode Accuracy:
±90 FPM (±0.45 MS) plus 5% of measured value****
Temperature Effect:
1” (250 Pa) models: 0.05%/°C; 10” (2.5 kPa)
models: 0.01%/°C
— (Relative to 25 °C) 0 to 50 °C (32 to 122 °F)
Zero Drift (1-year):
1” (250 Pa) models: 2.0% max.; 10” (2.5 kPa)
models: 0.5% max.
Zero Adjust:
Pushbutton auto-zero and digital input (2-pos terminal
block)
Operating Environment:
0 to 60 °C (32 to 140 °F)
Altitude of Operation:
0 to 3000 m
Pollution Degree:
2
Humidity Range:
100% RH, non-condensing
Mounting Location:
For indoor use only.
Fittings:
Brass barb; 0.24” (6.1 mm) o.d.
Limited Warranty:
5 years
Environmental Rating:
IP65, NEMA 4
Flammability Rating:
Plastic enclosure is UL 94 5VA fire retardant ABS
Accessories:
32003169-001 4 in. Duct Pressure Pick-up Probe.
P7650L6, P7650L8, P7650L10, P7650L12, or P7650L14,
Velocity Pick-up Probes. (Last number is probe length,
i.e., P7650L6 has 6 inch probe, etc)
EMC Conformance: EN 61000-6-3:2007 and A1:2011 Class B, EN
61000-6-1:2007
* Class 2 power source.
** Minimum input voltage for 4 to 20 mA operation: 250 Ωloop =
12 Vdc; 500 Ωloop = 19 Vdc.
*** Minimum load resistance for Volt operation: 5 kΩ.
**** For measured values between 200 and 7000 FPM (1 and
35 MS).
1-19/32
(42)
3-1/2 (88)
4-13/32
(112)
7-13/32 (188)
19/64
(7)
3-3/32
(78)
M37264

P7650A/B/U
331-00138—02
INSTALLATION, WIRING & CONFIGURATION
1. Plan the installation. Panel or duct mount?
Fig. 2.
NOTE: Velocity measurement, shown below, requires the use of a pressure-velocity pick up tube, part P7650L6,
P7650L8, P7650L10, P7650L12, or P7650L14. Length is the number after L in inches, so P7650L6 is 6 inch,
etc. See form 31-00149 for details on installing and configuring the P7650L velocity pick up probes.
Fig. 3.
2. For duct mount applications, thread the probe into
the back of the device housing, as shown in the
dimensional drawing.
3. Configure the internal tubing for the selected instal-
lation method as described below.
Duct mount tubing configuration:
a. Connect the right-side tube to the rear brass
barb marked as “-” on the underside of the device
housing.
b. Connect the left-side tube to the probe in the
back of the device housing.
Panel mount tubing configuration:
a. Connect the right-side tube to the rear brass
barb marked as “-” on the underside of the device
housing.
b. Connect the left-side tube to the front brass barb
marked as “+” on the underside of the device
housing.
Fig. 4.
4. Mount the transducer (see the screw hole diagram
below).
Fig. 5.
AIR FLOW
FILTER
LOW
HIGH
STATIC PRESSURE DIFFERENTIAL PRESSURE
PANEL
INSTALLATIONS
DUCT
INSTALLATIONS
M37265
AIR FLOW AIR FLOW
AIR FLOW
VELOCITY WITH P7650L PROBE
AIR FLOW
M37453
TUBING FOR DUCT MOUNT TUBING FOR PANEL MOUNT
M37267
2-19/64 (59)
CTR-CTR
3-19/64 (83)
CTR-CTR
2-1/2 (62)
TO P/U
TUBE
1-13/32
(35)
TO P/U
TUBE
1/2
(13)
3-13/64
(81)
IN. (MM)
M37268

P7650A/B/U
31-00138—02 4
5. For applications using conduit, remove the cable
gland nut on the bottom of the unit. Thread a stan-
dard 1/2-inch NPT female threaded coupler onto
the body of the cable gland. Connect the opposite
end of the coupler to the conduit.
Fig. 6.
6. Set DIP switches to desired settings.
Table 1.
*Velocity mode is unidirectional regardless of DIP switch
setting.
Table 2. DIP Switch Settings.
7. Set rotary switch to the desired setting. Align the
arrow (not the slot) on the rotary switch to the
desired full-scale range. LCD models momentarily
indicate the selected range.
Rotary Switch Settings
Table 3. 0-1 Inch Range Models, Field Selectable
(WC/FPM or Pa/MS).
Table 4. 0-10 Inch Range Models, Field Selectable
(WC/FPM or Pa/MS).
DIP Switch Setting
DIP Switch 1: Scale ON = Pascal/MPS
OFF = In. WC/FPM
DIP Switch 2: Mode ON = Velocity
OFF = Pressure
DIP Switch 3: Direction* ON = Unidirectional
OFF = Bidirectional
DIP Switch 4: Response ON = Slow
OFF = Fast
DIP Switch 5: Output ON = 4-20 mA
OFF = Voltage
DIP Switch 6:
Volt Scale
ON = 0-5 Vdc
OFF = 0-10 Vdc
DIP Switch 7 Unused
DIP Switch 8 Unused
1/2-INCH NPT FEMALE
THREADED COUPLER
M37460
Scale Mode Direction Response
ON Pascal/MPS Velocity Uni Slow
OFF In. WC/FPM Pressure Bi Fast
1234
Output Volt Scale Unused Unused
ON mA 5V Unused Unused
OFF Volt 10V Unused Unused
5678
WC / FPM Pa / MS
0 0 to 0.1 in. WC 0 0 to 25 Pa
1 0 to 0.25 in. WC 1 0 to 50 Pa
2 0 to 0.5 in. WC 2 0 to 100 Pa
3 0 to 1 in. WC 3 0 to 250 Pa
4 0 to 500 FPM 4 0 to 2.5 ms
5 0 to 1000 FPM 5 0 to 5 ms
6 0 to 2000 FPM 6 0 to 10 ms
7 0 to 3000 FPM 7 0 to 15 ms
WC / FPM Pa / MS
0 0 to 1 in. WC 0 0 to 250 Pa
1 0 to 2.5 in. WC 1 0 to 500 Pa
2 0 to 5 in. WC 2 0 to 1000 Pa
3 0 to 10 in. WC 3 0 to 2500 Pa
4 0 to 3000 FPM 4 0 to 15 ms
5 0 to 4000 FPM 5 0 to 20 ms
6 0 to 5000 FPM 6 0 to 25 ms
7 0 to 6000 FPM 7 0 to 30 ms

P7650A/B/U
531-00138—02
Table 5. P7640U Universal Model, Field Selectable (P)
Pressure or (V) Velocity Mode, Field Selectable
(WC/FPM or Pa/MS).
8. Connect the transmitter to the control system and
power supply as indicated below. Optional: Connect
the ZERO terminals to the digital output (contact
closure) of the control system.
Fig. 7. 2-wire, 4-20 mA Current Loop Output.
Fig. 8. 3-wire, 0-5 V/0-10 V Voltage Output.
9. Wait five seconds, then press and hold the ZERO
pushbutton for two seconds or provide contact clo-
sure on the AUX ZERO terminal. This will reset the
output and display to zero pressure. For best accu-
racy, press the ZERO button while both ports are
open to atmospheric pressure. To protect the unit
from accidental zero, this feature is enabled only
when the detected pressure is within about 0.1 in.
WC (25 Pa) of factory calibration.
10. Connect desired external tubing to the P7650A/B/U.
P7650A/B/U Series devices employ high performance
sensors and sophisticated temperature compensation
circuitry. The sensor achieves its best accuracy after an
initial warm-up period. During the first few minutes of
operation, readings at zero pressure and the lowest
pressure ranges appear erroneous. Following this initial
warm-up period, the P7650A/B/U device maintains its
specified accuracy and stability.
The LCD momentarily indicates range ‘SET’ when a
selection is made. Pressure is normally indicated on the
display. Units are in inches water column (in. WC),
Pascals (Pa) or kilopascals (kPa) as indicated on the
display. The display shows ‘OVER’ when the pressure is
over range.
(P) Pressure Mode (V) Velocity Mode
0 0 to 0.1 in. WC
(0 to 25 Pa)
00to500FPM
(0 to 2.5 MS)
1 0 to 0.25 in. WC
(0 to 50 Pa)
1 0 to 1000 FPM
(0 to 5 MS)
2 0 to 0.5 in. WC
(0 to 100 Pa)
2 0 to 2000 FPM
(0 to 10 MS)
3 0 to 1 in. WC
(0 to 250 Pa)
3 0 to 3000 FPM
(0 to 15 MS)
4 0 to 2.5 in. WC
(0 to 500 Pa)
4 0 to 4000 FPM
(0 to 20 MS)
5 0 to 5 in. WC
(0 to 1000 Pa)
5 0 to 5000 FPM
(0 to 25 MS)
60to10in.WC
(0 to 2500 Pa)
6 0 to 6000 FPM
(0 to 30 MS)
70to10in.WC
(0 to 2500 Pa)
7 0 to 7000 FPM
(0 to 35 MS)
M37262
DIGITAL
CONTROL
DIGITAL
OUTPUT
RETURN
V+
1.000
0
1
2
3
4
5
6
7
PWR
mA RTN
{
RMT.
ZERO
ZERO
1.000
0
1
2
3
4
5
6
7
{
RMT. ZERO
ZERO
DIGITAL
CONTROL
DIGITAL
OUTPUT
V IN
–
POWER
SOURCE
24 VAC/DC
+
V+/PWR
V–/GND
VOUT
–
M37263

P7650A/B/U
31-00138—02 6
CHINA ROHS COMPLIANCE INFORMATION
ENVIRONMENT-FRIENDLY USE PERIOD (EFUP) TABLE
󴉆󸀮󴏵󱡽󳮹SJ/T11364󵵙󸊿󲷢󶴹󱳷
O: 󸀮󶆺󸛋󴈄󲸓󵙀󸢹󲔩󸛋󸽩󱝾󳧟󴈄󲕓󸢹󴉿󳾒󱙆󵵙󲀯󹄡󲕓󲔩GB/T 26572󸊿󲷢󵵙󹢔󹄡󸉔󴭁󱝥󱘕
X: 󸀮󶆺󸛋󴈄󲸓󵙀󸢹󷋼󲻒󲔩󸛋󸽩󱝾󵵙󴍅󱘈󲕓󸢹󴉿󳾒󱙆󵵙󲀯󹄡󸤥󱲡GB/T 26572󸊿󲷢󵵙󹢔󹄡󸉔󴭁
󽘘󱞒󱘭󱿔󲔩󴦝󲠦󽘜󴏰󳮹󲷫󹢃󳜵󱰤󲺧󱘔󸀮󱙆󳨈 󵵙󳩏󴉊󱽓󲒵󸴔󸀅󸴔󱘈󴦠󸛚󴁩󽘙
This table is made according to SJ/T 11364.
O: Indicates that the concentration of hazardous substance in all of the homogeneous materials for this part is below the
limit as stipulated in GB/T 26572.
X: Indicates that concentration of hazardous substance in at least one of the homogeneous materials used for this part is
above the limit as stipulated in GB/T 26572.
REGULATORY INFORMATION
FCC REGULATIONS
§ 15.19 (a)(3)
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
IC REGULATIONS
RSS-GEN
This device complies with Industry Canada’s license-
exempt RSSs.
Operation is subject to the following two conditions:
1. This device may not cause interference; and
2. This device must accept any interference, including
interference that may cause undesired operation of
the device.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions
suivantes :
1. l’appareil ne doit pas produire de brouillage;
2. l’utilisateur de l’appareil doit accepter tout brouil-
lage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
FCC Warning (Part 15.21) (USA
only)
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
󸽩󱝾󱿽󶌇 󴈄󲸓󵙀󸢹 - Hazardous Substances
Part Name 󹚮(Pb) 󴭰(Hg) 󹜲(Cd) 󱮺󱞀󹛕 (Cr (VI)) 󲡕󴼤󶾌󷔦 (PBB)
󲡕󴼤󱛔󷔦󹂮
(PBDE)
歏㶩⟝
Electronic
XOOOOO

P7650A/B/U
731-00138—02

P7650A/B/U
Home and Building Technologies
In the U.S.:
Honeywell
715 Peachtree Street NE
Atlanta, GA 30308
customer.honeywell.com
® U.S. Registered Trademark
© 2018 Honeywell International Inc.
31-00138—02 M.S. Rev. 05-18
Printed in United States
By using this Honeywell literature, you agree that Honeywell will have no liability for any damages arising out of your use or
modification to, the literature. You will defend and indemnify Honeywell, its affiliates and subsidiaries, from and against any
liability, cost, or damages, including attorneys’ fees, arising out of, or resulting from, any modification to the literature by you.
