Honeywell PX2 Series User manual

Installation Instructions for the
PX2 Series Heavy Duty Transducers Issue 8
50052336
Sensing and Control
CAUTION
PRODUCT DAMAGE
•Ensure torque specications are determined for the specic
application. Values provided are for reference only. NPT ports
are not specied with torque values. Correct installation
is based on the number of Turns From Finger Tight (TFFT).
(Mating materials and thread sealants can result in
signicantly different torque values from one application to
the next.)
• When using NPT ports in stainless steel manifolds, use
a thread sealant with anti-seize properties to prevent thread
galling. Ensure the sealant is rated for the application.
• Use appropriate tools (such as an open ended wrench or
deep well socket) to install transducers.
• Always hand-start transducers into the hole to prevent cross
threading and damage.
• Do not subject the transducer to high temperatures from
soldering, brazing, or welding of the system plumbing
Failure to comply with these instructions may result in
product damage.
Ratiometric voltage devices require either a regulated 3.3 Vdc (AA
and AB) or a regulated 5.0 Vdc supply (AC and AD), (see Table 2).
All other versions can use an unregulated supply within the ranges
noted under the excitation specications. Ensure the power supply
is off while wiring.
ELECTROMAGNETIC ENERGY/NOISE
CAUTION
PRODUCT DAMAGE/ERRATIC OPERATION
• Do not use in areas where electromagnetic energy may affect
transducer operation.
Failure to comply with these instructions may result in
product damage.
The PX2 Series has been rated for high immunity to electrical
noise; however, care should be taken when used around high
voltage sources that emit high levels of radiated electromagnetic
energy like variable frequency motor drives, solenoids, radio
transmitters and engine ignition systems. The use of shielded
cable and grounding of pressure port is also recommended.
FUNCTIONAL TEST
1. Connect the transducer to a dc voltage supply (off). The supply
voltage should be set within the range specied for the model.
2. Based on the transducer’s specied output, connect the output
lead(s) to a digital dc or mA meter.
3. With no pressure on the transducer, turn on the power supply
and read the output signal on the voltmeter. The reading
should correspond to the specication indicated for null offset.
If not, check the connections, wire color code and the setting
of the power supply.
GENERAL INFORMATION
Honeywell’s PX2 Series Heavy Duty Pressure Transducer is
a portfolio of highly congurable pressure sensors that use
piezoresistive sensing technology with ASIC (Application Specic
Integrated Circuit) signal conditioning in a stainless steel housing.
The PX2 Series is fully calibrated and compensated for offset,
sensitivity, temperature effects and non-linearity using the on-
board ASIC.
OVERPRESSURE
CAUTION
PRODUCT DAMAGE
•Do not exceed the overpressure.
Failure to comply with these instructions may result in
product damage.
If the overpressure rating is exceeded, the life of the PX2 Series
may be reduced and electrical failure may occur. Both static
and dynamic overpressure must be considered, particularly in
hydraulic system applications. Hydraulic pressure uctuations
can have very high and very fast peak pressures, as in a water
hammer effect.
An oscilloscope is recommended for determining if high-pressure
transients exist in a system. If system pressure pulses are
expected, choose a transducer with a pressure rating high enough
to allow continuous operation at the highest expected pressure
spikes.
A pressure ‘snubber’ may be used to reduce the peak pressure
applied to the transducer.
MEDIA COMPATIBILTY
CAUTION
PRODUCT DAMAGE
• Use non-abrasive, chemically compatible media to prevent
damage to diaphragm or port materials.
Failure to comply with these instructions may result in
product damage.
The PX2 Series uid path is an assembly of 304 stainless steel,
epoxy, alumina, glass, and silicon.
•
INSTALLATION
Table 1. Compatible Media
Refrigerants Other Media
R410A
R134A
R123ZE
mixture of R245Fa and transdichloroethylene
engine oil 10W30
brake uid DOT3
hydraulic uid
tap water
compressed air

2 Honeywell Sensing and Control
PX2 Series Heavy Duty Presssure Transducers ISSUE 8
50052336
NOTICE
• To ensure proper environmental sealing and electrical
connections when using a connector, follow the connector
manufacturer’s installation guidelines.
• All terminal cavities must be sealed using the correct wire
gauge and seal combination.
• If only two leads are used, any additional terminal cavities
should be sealed per the connector manufacturer’s
installation guide.
• Honeywell recommends using a crimping tool for crimping
wires to the connector terminals.
• Contact the individual connector manufacturer for connector
wiring.
Table 2. Electrical Specications
Characteristic
Ratiometric Output Current
Output Regulated Output
Output Transfer Function Order Code1
AA AB AC AD CH BC BD BE BG
Output transfer function1:
null output value
full scale output value
full scale span (FSS)
operating supply voltage, min.(Vs)2
operating supply voltage, typ. (Vs)2
operating supply voltage, max. (Vs)2
10% of Vs
90% of Vs
80% of Vs
4.75 V
5 V
5.25 V
5% of Vs
95% of Vs
90% of Vs
4.5 V
5 V
5.5 V
10% of Vs
90% of Vs
80% of Vs
3.135 V
3.3 V
3.465 V
5% of Vs
95% of Vs
90% of Vs
3.135 V
3.3 V
3.465 V
4 mA
4 mA
16 mA
8 V
—
30 V4
1 V
6 V
5 V
9 V
—
30 V3
0.25 V
10.25 V
10 V
13 V
—
30 V3
0.5 V
4.5 V
4 V
8 V
—
30 V3
1 V
5 V
4 V
8 V
—
30 V3
Supply current (typ.) 5 mA 4 mA — 5.5 mA
Output load (pull up or down)
minimum
maximum
2 kOhm
—
—
(Vs - 8) x
50 Ohm4
2 kOhm
—
Absolute voltage ratings5:
minimum6
maximum6
maximum applied to output pin
(short circuit protection)7
-16 V
16 V
Vs
-16 V
30 V
—
-16 V
30 V
12 V
EMC rating8:
CE compliance:
electrostatic discharge
radiated immunity
fast transient burst
immunity to conducted disturbances
radiated emissions
±4 kV contact, ±8 kV air per IEC 61000-4-2
10 V/m (80 MHz to 1000 MHz) per IEC 61000-4-3
±1 kV per IEC61000-4-4
3 V per IEC61000-4-6
40 dB 30 MHz to 230 MHz; 47 dB 230 MHz to 1000 MHz per CISPR 11
ISO 11452-2:
radiated immunity 100 V/m 200 MHz to 2 GHz 20 V/m 200 MHz to 2 GHz
Notes:
1. The Output Transfer Function order code in the catalog listing appears as the last two digits before the nal “X”. For example, the “AA” in the
following catalog listing is the transfer function code: PX2BN1XX100PSAAX.
2. Transducer will not produce valid output when supply voltage is outside of operating range.
3. Applies at 25 °C. See Figure 2 for Regulated Output Supply Voltage.
4. Applies at 25 °C. See Figure 3 for Current Output Supply Voltage.
5. Absolute maximum ratings are the extreme limits the device can withstand without damage to the product. Voltages above these ratings may
cause permanent damage. Exposure to absolute maximum conditions for extended periods may degrade device reliability.
6. Absolute voltage applies to potential across power and ground terminals.
7. Short circuit protection between output pin and ground, and output pin and supply pin.
8. All EMC ratings veried with the Delphi Metri-Pack 150 electrical connector type.
WIRING INSTRUCTIONS
The wiring code for electrical connection is shown in Figure 3.

Honeywell Sensing and Control 3
PX2 Series Heavy Duty Pressure Transducers ISSUE 8
50052336
Figure 1. Regulated Output Supply Voltage Figure 2. Current Output Supply Voltage
Table 3. Performance Specications1
Characteristic Parameter
Operating temperature range2-40 °C to 125 °C [-40 °F to 257 °F]
Storage temperature range3-40 °C to 125 °C [-40 °F to 257 °F]
Compensated temperature range4-40 °C to 125 °C [-40 °F to 257 °F]
Overpressure minimum rating5(See Table 4.)
Burst pressure minimum rating6(See Table 4.)
Long term stability ±0.5 %FSS9 (1000 hr at 25 °C [77 °F])
Accuracy7±0.25 %FSS9
Offset error8±1 %FSS9
Total Error Band10 ±2 %FSS9(-40 °C to 125 °C [-40°F to 257 °F])
Response time11 <2 ms
Turn on time12 <7 ms
Life13 min. of 10 million cycles to operating pressure
Notes:
1. All specications apply at 25 °C and under operating conditions unless otherwise noted.
2. Operating Temperature Range: The temperature range over which the product will produce an output proportional to pressure but may not remain
within the specied performance limits.
3. Storage Temperature Range: The temperature range over which the product may safely be exposed without excitation or pressure applied. Under
these conditions the product will remain in specication after excursion to any temperatures within this range. Exposure to temperatures outside
this range may cause permanent damage to the product.
4. Compensated Temperature Range: The temperature range (or ranges) over which the product will produce an output proportional to pressure
within the specied performance limits.
5. Overpressure: The absolute maximum rating for pressure which may be safely applied to the product for it to remain in specication once pressure
is returned to the operating pressure range. Exposure to higher pressure may cause permanent damage to the product.
6. Burst Pressure: The maximum pressure that may be applied to the product without causing escape of the pressure media. The product should not
be expected to function after exposure to any pressure beyond the rated burst pressure. This rating is also the case burst rating of the product.
7. Accuracy: The maximum deviation in output from a Best Fit Straight Line (BFSL) tted to the output measured over the pressure range at 25 °C.
Includes all errors due to pressure non-linearity, pressure hysteresis, and non-repeatability.
8. Offset Error: the maximum deviation in the output signal obtained when the reference pressure is applied at 25 °C relative to the ideal transfer
function.
9. Full Scale Span (FSS): The algebraic difference between the output signal measured at the maximum (Pmax.) and minimum (Pmin.) limits of the
pressure range.
10. Total Error Band: The maximum deviation from the ideal transfer function over the entire compensated temperature and pressure range. Includes
all errors due to offset, full scale span, pressure non-linearity, pressure hysteresis, repeatability, thermal effect on offset, thermal effect on span,
and thermal hysteresis.
11. Response Time: The response time of the transducer is the maximum amount of time that the transducer will take for the transducer to output a
change from 10% to 90% of full scale in response to a 0% to 100% full scale step input pressure range.
12. Turn On Time: Duration from power applied until rst valid output.
13. Life may vary depending on the application in which transducer is used. Contact Honeywell Sales and Service for Mean Time to Failure (MTTF)
data based on customer-specic usage prole.

4 Honeywell Sensing and Control
PX2 Series Heavy Duty Presssure Transducers ISSUE 8
50052336
Table 4. Pressure Ratings
bar kPa MPa psi
Operating
Pressure
Over-
pressure
Burst
Pressure
Operating
Pressure
Over-
pressure
Burst
Pressure
Operating
Pressure
Over-
pressure
Burst
Pressure
Operating
Pressure
Over-
pressure
Burst
Pressure
158100 500 800 1 3.1 5.1 15 70 115
1. 6 5 8 160 1000 1700 1. 6 5.2 8.6 30 150 250
210 17 250 1000 1700 2.5 6.9 10.3 50 250 400
2.5 10 17 400 1700 2700 4 6.9 10.3 100 450 750
417 27 600 3100 5100 4.6 6.9 10.3 150 450 750
6 31 51 — — — 6 13.8 20.6 200 750 1250
8 31 51 — — — 7 13.8 20.6 250 750 1250
10 31 51 — — — — — — 300 1000 1500
16 52 86 — — — — — — 500 1000 1500
25 69 103 — — — — — — 600 1000 1500
34 69 103 — — — — — — 667 1000 1500
40 69 103 — — — — — — 750 1500 2250
46 69 103 — — — — — — 800 1500 2250
60 138 206 — — — — — — 850 2000 3000
70 138 206 — — — — — — 1000 2000 3000
Table 6. Mechanical Characteristics
Characteristic Parameter
Mechanical shock 100 G per MIL-STD-202F, Method 213B, Cond. F (at 25 °C)
Vibration 20 G sweep, 10 Hz to 2000 Hz (at 25 °C)
Enclosure rating per electrical connector type selection (See Figure 3.)
Wetted materials:
port
substrate
adhesives
electronics
304 stainless steel
alumina ceramic
epoxy
glass, silicon
External materials:
housing
connector:
UL 94 HB (standard)
UL 94 V-0 (optional)
cable jacket
304 stainless steel
PBT 30% GF, black
PBT 30% GF, natural (beige)
TPE
Installation torque per pressure port type (See Figure 4.)
Table 5. Pressure Reference Types
Pressure Reference Description
Absolute Output is proportional to the difference between applied pressure and a built-in xed reference to vacuum (zero pres-
sure), where the minimum operating pressure is set to absolute zero pressure (perfect vacuum).
Sealed gage1Output is proportional to the difference between applied pressure and a built-in xed reference to 1 atmA, where the
minimum operating pressure is set to 14.7 psiA (1 atmA).
Vented gage2Sensor measures pressure relative to ambient pressure. Output is proportional to the difference between applied pressure
and atmospheric (ambient) pressure, where the minimum operating pressure is set to atmospheric pressure.
Notes:
1. Sealed gage option only available in pressure ranges at or above 100 psi.
2. Vented gage option only available in pressure ranges between 100 psi and 667 psi (not available on cable harness congurations).

Honeywell Sensing and Control 5
PX2 Series Heavy Duty Pressure Transducers ISSUE 8
50052336
Figure 3. Electrical Connector Type Dimensions (For reference only: mm/[in].)
A
Delphi Metri-Pack 150, Standard
(UL 94 HB)
J
Delphi Metri-Pack 150
(UL 94 V-0)
B
Micro M12
(IEC 61076-2)
C
DIN
(EN 175301-803C)
Connector: DELPHI 12078088
Mating Connector: DELPHI 12110192
IP Rating
1
: IP65 (all versions)
Connector: IEC 61076-2-101
Mating Connector: 4 POS TYPE D
IP Rating
1
: IP65/IP67 (absolute, sealed gage
versions)
IP65 (vented gage versions)
Connector: EN 175301-803C
Mating Connector: EN 175301-803C DIN
43650C 8MM
IP Rating
1
: IP65 (all versions)
Pin Voltage
Output
Current
Output Pin Voltage Output
Current
Output Pin Voltage Output
Current
Output
AGND RTN 1 V+ supply 1 GND RTN
B V+ supply 3 GND RTN 2 V+ supply
C Vout NC 4 Vout NC
3 Vout NC
PE NC NC
1
IP rating is determined by the electrical connector type chosen.
Hole
(vented gage
versions only)
Hole
(vented gage
versions only)
Hole
(vented gage
versions onl
y)

6 Honeywell Sensing and Control
PX2 Series Heavy Duty Presssure Transducers ISSUE 8
50052336
Figure 3. Electrical Connector Type Dimensions (continued)
D
Deutsch
(DTM04-3P)
ECable Harness, 1 Meter2
FCable Harness, 2 Meter2
GCable Harness, 3 Meter2, 3
HCable Harness, 5 Meter2, 3
Connector: Deutsch DTM04-3P
Mating Connector: DTM06-3S
IP Rating1: IP65, IP67, IP69K (absolute,
sealed gage versions)
IP65 (vented gage versions)
Connector: 24 AWG with TPE jacket
Mating Connector: Flying leads
IP Rating1: IP65, IP67, IP69K (absolute, sealed gage versions)
Pin Voltage
Output
Current
Output Wire Color Voltage Output Wire Color Current Output
1 GND RTN red V+ red supply
2 Vout NC black GND black RTN
3V+ supply white Vout
Notes:
1. IP rating is determined by the electrical connector type chosen.
2. Three-wire cable is required for ratiometric and regulated outputs; two wire cable is required for current output.
3. Three meter and five meter cables are only available with Output Transfer Function CH = Current, 4 mA to 20 mA.
Hole
(vented gage
versions only)

Honeywell Sensing and Control 7
PX2 Series Heavy Duty Pressure Transducers ISSUE 8
50052336
Figure 4. Pressure Port Type Dimensions (For reference only: mm/[in].)
F1 7/16-20 UNF 1/4 in 45º Flare Female Schrader (SAE J512) F2 7/16-20 UNF 45º Flare Male (SAE J513)
Seal: 45º cone
Mating geometry: SAE J512
Installation torque1: 17 N m [12.5 ft-lb]
Seal: 45º cone
Mating geometry: SAE J513
Installation torque1: 1/4 Turn
from finger tight
F3 7/16-20 UNF 37º Flare Male (SAE J514) G1 G1/4 ( ISO 1179-3)
Seal2,3: 37º cone
Mating Geometry: SAE J514
Installation Torque1: 16 N m [11.8 ft-lb]
Seal2,3: O-ring
Mating geometry: ISO 1179-1
Installation torque1: 50 N m [38.9 ft-lb]
G2 G1/8 (ISO 1179-3) M1 M12 X 1.5 (ISO 6149-3)
Seal2,3: O-ring
Mating geometry: ISO 1179-1
Installation torque1: 25 N m [18.4 ft-lb]
Seal2,3: O-ring
Mating geometry: ISO 6149-1
Installation torque1: 25 N m [18.4 ft-lb]
N1 1/4–18 NPT N2 1/8–27 NPT
Seal: pipe thread
Mating geometry: ANSI B1.20.1
Installation torque1: 2 to 3 Turns
from finger tight
Seal: pipe thread
Mating geometry: ANSI B1.20.1
Installation torque1: 2 to 3 Turns
from finger tight
S1 9/16–18 UNF (SAE J1926-3) S2 7/16–20 UNF (SAE J1926-3)
Seal2,3: O-ring
Mating geometry: SAE J1926-1
Installation torque2: 30 N m [22.1 ft-lb]
Seal2,3: O-ring
Mating geometry: SAE J1926-1
Installation torque2: 18 N m [12.3 ft-lb]
Notes:
1. Straight thread maximum torque is validated to 150% of installation torque.
2. Seals for pressure port type order codes S1, S2, M1, G1 and G2 are included and assembled to the sensors.
3. O-ring material is nitrile 70 durometer -30 ºC to 125 ºC [-22 ºF to 257 ºF].
22 Hex flat to flat
[0.87]
“P”
= 19,2
[0.75
]12,3
[0.49]
“P
” = 20,5
[0.81
]15,5
[0.61]

Authorized Distribution Brand：
Website：
Welcome to visit www.ameya360.com
Contact Us：
Address：
401 Building No.5, JiuGe Business Center, Lane 2301, Yishan Rd
Minhang District, Shanghai , China
Sales：
Direct [phone]
Email [email protected]
QQ 800077892
Skype ameyasales1 ameyasales2
Customer Service：
Email [email protected]
Partnership：
Tel [phone]-8333
Email [email protected]
