Hoover HBDOS695TAMCRE80 User manual

EN

2
Thank you for choosing this product.
We are proud to offer the ideal product for
you and the best complete range of home
appliances for your daily routine.
Carefully read this manual for correct and
safe appliance use and for helpful tips on
efficient maintenance.
Only use the washing machine after
carefully reading these instructions. We
recommend you always keep this manual on
hand and in good condition for any future
owners.
Each product is identified by a unique 16-
character code, also called the “serial
number”, printed on the sticker. This can be
found inside the door opening. This code is
a unique code for your product that you will
need to register the product warranty, or if
you need to contact the Customer Service
Centre.
This appliance is marked according to
the European directive 2012/19/EU
on Waste Electrical and Electronic
Equipment (WEEE).
WEEE contains both polluting substances (which
can cause negative consequences for the
environment) and basic components (which can
be re
-
used). It is important to have WEEE
subjected to specific treatments, in order to
remove and dispose properly all pollutants, and
recover and recycle all materials. Individuals can
play an important role in ensuring that WEEE
does not become an environmental issue; it is
essential to follow some basic rules:

WEEE should not be treated as household
waste;

WEEE should be handed over to the relevant
collection points managed by the municipality or
by registered companies. In many countries, for
large WEEE, home collection could be present.
In many countries, when you buy a new
appliance, the old one may be returned to the
retailer who has to collect it free of charge on a
one
-to-
one basis, as long as the equipment is of
equivalent type and has the same functions as
the supplied equipment.
1.
GENERAL SAFETY RULES
2.
INSTALLATION
3.
DETERGENT DRAWER
4.
PRACTICAL HINTS
5.
CLEANING AND MAINTENANCE
6.
QUICK USER GUIDE
7.
CONTROLS AND PROGRAMMES
8.
DRYING CYCLE
9.
AUTOMATIC WASHING/DRYING CYCLE
10.
TROUBLESHOOTING AND WARRANTY
Contents
Environmental conditions
FOR U.K. ONLY
On receipt of your appliance please
check it carefully for damage. Any
damage found must be reported
to the
delivery driver immediately.
Alternatively
damage found must be
reported to the retailer within 2 days of
receipt.

3
EN
1. GENERAL SAFETY
RULES
This appliance is intended to
be used in household and
similar applications such as:
- Staff kitchen areas in shops, offices
and other working environments;
- Farm houses;
- By clients in hotels, motels and
other residential type environments;
- Bed and breakfast type environments.
A different use of this appliance
from household environment
or from typical housekeeping
functions, as commercial use by
expert or trained users, is excluded
even in the above applications. If
the appliance is used in a manner
inconsistent with this it may reduce
the life of the appliance and may
void the manufacturer’s warranty.
Any damage to the appliance or
other damage or loss arising
through use that is not consistent
with domestic or household use
(even if located in a domestic or
household environment) shall not
be accepted by the manufacturer to
the fullest extent permitted by law.
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.
Children should be supervised
to ensure that they do not play
with the appliance.
Children of less than 3 years
should be kept away unless
continuously supervised.

If the supply cord is damaged, it
must be replaced by a special
cord or assembly available from
the manufacturer or its service
agent.

Only use the hose-sets
supplied with the appliance for
the water supply connection
(do not reuse old hose-sets).
 Water pressure must be between
0.1 MPa and 1 MPa.

Make sure carpets or rugs do
not obstruct the base or any of
the ventilation openings.
The final part of a washer dryer
cycle occurs without heat (cool
down cycle) to ensure that the
items are left at a temperature
that ensures that the items will
not be damaged.

4

After installation, the appliance
must be positioned so that the
plug is accessible.
The appliance must not be
installed behind a lockable
door, a sliding door or a door
with a hinge on the opposite
side to that of the washer
dryer, in such way that a full
opening of the washer dryer
door is restricted.
The maximum load capacity of
dry clothes depends on the
model used (see control panel).
The appliance is not to be used
if industrial chemicals have
been used for cleaning.
Do not dry unwashed items in
the washer dryer.
 Items that have been soiled with
substances such as cooking oil,
acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes
and wax removers should be
washed in hot water with an extra
amount of detergent before being
dried in the washer dryer.
Items such as foam rubber
(latex foam), shower caps,
waterproof textiles, rubber
backed articles and clothes or
pillows fitted with foam rubber
pads should not be dried in the
washer dryer.
Fabric softeners, or similar
products, should be used as
specified by the fabric softener
instructions.
Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such
as a washer dryer. The items
become warm, causing an
oxidation reaction in the oil,
Oxidation creates heat. If the
heat cannot escape, items can
become hot enough to catch
fire. Piling, stacking or storing
oil-effected items can prevent
heat from escaping and so
create a fire hazard.
If it is unavoidable that fabrics
contain vegetable or cooking
oil or have been contaminated
by hair care products be
placed in a washer dryer they
should first be washed in hot
water with extra detergent -
this will reduce, but not
eliminate, the hazard.
 Remove all objects from pockets
such as lighters and matches.
WARNING:
never stop a washer dryer before
the end of the drying cycle
unless all items are quickly
removed and spread out so that
the heat is dissipated.

5
EN
 To consult the product technical
specification please refer to the
manufacturer website.
The technical details (supply
voltage and power input) are
indicated on the product rating
plate
Make sure that the electrical
system is earthed, complies
with all applicable law and that
the (electricity) socket is
compatible with the plug of the
appliance. Otherwise, seek
qualified professional assistance.
The use of converters, multiple
sockets or extension cords is
strongly advised against
Before cleaning or maintaining
the washing machine, unplug
the appliance and turn off the
water tap.
Do not pull on the power cord
or appliance to unplug the
machine.
Make sure there is no water in
the drum before opening the
door.
Do not expose the washing
machine to rain, direct sunlight
or other weather elements.
Protect from possible freezing.
When moving, do not lift the
washing machine by the knobs
or detergent drawer; during
transport, never rest the door on
the trolley. We recommend two
people lift the washing machine.
In the event of fault and/or
malfunction, turn off the
washing machine, close the
water tap and do not tamper
with the appliance.
Immediately contact the
Customer Service Centre and
only use original spare parts.
Failure to observe these
instruction may jeopardise
appliance safety.
WARNING:
water may reach very high
temperatures during the
wash cycle.
WARNING:
the appliance must not be
supplied through an external
switching device, such as a
timer, or connected to a circuit
that is regularly switched on
and off by a utility.
Electrical connections and
safety instructions

6
2. INSTALLATION

Remove the 2 or 4 transportation
screws (A)
on the back and
remove the 2 or 4
flat washers,
rubber bungs and plastic spacer
tubes (B) as illustrated in figure 1
.

If the washing machine is built
-
in , unscrew the 3 or
4
transportation screws (A)
and
remove the 3 or 4
flat washers,
rubber bungs and plastic spacer
tubes (B) .

During the removal of the screws
occasionally spacer tubes fall
inside the product, these can be
remove by tilting the product forward
and recovering them from the floor
or inside the base of the machine.

Cover the open transportation screw
holes with the 2 or 4
plastic caps
included in the instruction bag.
WARNING:
keep packaging materials
away from children.

7
EN

Position the template onto the
reverse of the furniture door. It
is possible to mount the hinges
and closure magnet on the right
or left-
hand side depending on
your requirements. Mark the
screw hole positions, then drill
out these positions.

Fix the hinges in place with the
4 screws provided (A).

Fix the magnet (B)
in place
using screw (C).

Mount the plate (D)
on the right
or left-
hand side, depending on
your installation requirements.
Place the plastic support
(E)
under the plate and fix it in
position with screw (F).

Snap mount cap (G)
in the
lower position.
Instructions for mounting the
furniture door

8

Mount the furniture door to the
front of the washer using the
hinges. Fix the spacers (I)
in
place with the 2 screws (J)
and
then fix the hinges with 2 screw
(H).

Slide the washer into an
opening of the size indicated in
the diagram opposite. A furniture
plinth may be run across the front
of the appliance, but its height will
be dictated by the height the
washer is set at.

The 4 adjustable feet allow the
height of the washer to be
adjusted from 820 mm to a
maximum of 840 mm. To adjust
the height, you should remove
the nuts fitted to each foot and
replace these with the 5 mm
nuts supplied. Raise the feet to
your desired height and then
fully tighten the lock nut to the
base of the washer.
We suggest mounting the
furniture door so that it opens
towards the left, which is the
same direction as the porthole
door. This will leave more
space when you are loading
washing into the appliance.

9
EN

Connect the water hose to the water
supply tap (fig. 3)
only using the hose
supplied with the appliance (do not
reuse old hose-sets).

SOME MODELS
may include one or
more of the following features:

HOT&COLD (fig. 4):
water mains connection settings with hot
and cold water for higher energy savings.
Connect the grey tube to the cold water
tap
and the red one to the hot water
tap. The machine can be connected to
the cold water tap only: in this case, some
programs may start a few minutes later.

AQUASTOP (fig. 5):
a device located on the supply tube that
stops water flow if the tube deteriorates;
in this case, a red mark will appear in the
window “A
” and the tube must be
replaced. To unscrew the nut, press the
one-way lock device "B".

AQUAPROTECT –
SUPPLY TUBE WITH
GUARD (fig. 6):
Should water leak from the primary
internal tube "A"
, the transparent
containment sheath "B
" will contain water
to permit the washing cycle to complete.
At the end of the cycle, contact the
Customer Service Centre to replace the
supply tube.
Hydraulic connections

10

The washing machine should be installed in
its final position such that the water fill hose
is not kinked or trapped. The corrugated
drain hose should be inserted into suitable
drain pipe of between 50 cm and 85 cm
height above the floor using the curved drain
hose support. If an under sink connection is
used the drain hose must be routed above
the sink overfill opening to prevent back
siphoning. Care must be taken to avoid
kinking or trapping the drain hose (fig. 7) .

Level the appliance using the feet as
illustrated in figure 8:
a.
turn the nut clockwise to release the
screw;
b.
rotate the foot to raise or lower it until it
touches to the floor;
c.
lock the foot, screwing in the nut, until it
tightens against to the bottom of the
washing machine.

Plug in the appliance.
*
ACCESSORY SOLD SEPARATELY
WARNING:
contact the Customer Service Centre
should the power cord need
replacement.
Installation faults are not covered by
the manufacturers warranty.
Setting

11
EN
3. DETERGENT DRAWER
The detergent draw is split into 3
compartments as illustrated in figure 9:
compartment "1": for prewash detergent;
compartment “ ”: for special additives,
softeners, starch fragrances, etc.;
compartment "2": for washing
detergent.
WARNING:
some detergents are not designed for
use in the dispenser drawer but are
supplied with their own dispenser that
is placed in the drum directly.
WARNING:
only use liquid products; the washing
machine is set to automatically dose
additives at each cycle during the last
rinse.

12
4. PRACTICAL HINTS
When sorting laundry, make sure:
- have eliminated metallic objects such as
hair clips, pins, coins, from laundry;
- to have buttoned pillow cases, closed zips,
tied loose belts and long robe ribbons;
- to have removed rollers, hooks or clips
from curtains;
- to have carefully read clothing washing
labels;
- to have removed any persistent stains
using specific detergents.

When washing rugs, bedcovers or other
heavy clothing, we recommend you avoid
the spinning cycle.

To wash wool, make sure the item can be
machine washed. Check the fabric label.

Leave the appliance’s door slightly open
between washes, to prevent possible bad
smells developing inside the machine.
Tips on how to save money and not
damage the environment when using your
appliance.
Load the machine to the highest capacity
shown in the programme table for each
programme - this will allow you to SAVE
energy and water.
Noise and residual laundry moisture are
affected by spin speed: a faster spin is
associated with greater noise and lower
residual moisture in the laundry.
The most efficient programmes in terms
of combined use of water and energy are
usually the longer-lasting ones with lower
temperature.
Maximise the load size
Achieve the best use of energy, water,
detergent and time by using the
recommended maximum load size.
Save up to 50% energy by washing a full
load instead of 2 half loads.
Do you need to pre-wash?
For heavily soiled laundry only!
SAVE detergent, time, water and
between 5 to 15% energy consumption
by NOT selecting Prewash for slight to
normally soiled laundry.
Is a hot wash required?
Pretreat stains with stain remover or soak
dried in stains in water before washing to
reduce the necessity of a hot wash
programme. Save energy by using a low
temperature wash programme.
Before using a drying programme
(WASHER-DRYERS)
SAVE energy and time by selecting a
high spin speed to reduce the water
content in laundry before using a drying
programme.
Below is a short guide with tips and advice
on the use of detergent.
Only use detergents suitable for machine
washing.
Select your detergent according to the
type of fabric (cotton, delicates,
synthetics, wool, silk, etc.), the colour, the
type and level of soiling and the
programmed washing temperature.
To use the right amount of detergent,
softener or any other additives, carefully
follow the manufacturer’s instructions
every time: correctly using the
appliance with the right dose allows
you to avoid waste and to reduce the
environmental impact.
Dosing the detergent
Useful advice for saving
Load tips

13
EN
Too much detergent leads to excessive
foam, which prevents the cycle being
carried out correctly. It could also affect
the quality of the washing and rinsing.
The use of ecological detergents without
phosphates may cause the following
effects:
- cloudier rinse drain water: This effect is
tied to the suspended zeolites which do
not have negative effects on rinse
efficiency.
- white powder (zeolites) on laundry at
the end of the wash: this is normal, the
powder is not absorbed by fabric and does
not change its colour.
To remove the zeolites, select a rinse
programme. In the future consider using
slightly less detergent.
- foam in the water at last rinse: this does
not necessary indicate poor rinsing.
Consider using less detergent in future
washes.
- abundant foam: This is often due to the
anionic surfactants found in the detergents
which are hard to eliminate from laundry.
In this case, do not re-rinse to eliminate
these effects: it will not help at all.
We suggest conducting a maintenance
wash using a proprietary cleaner.
If the problem persists or if you suspect a
malfunction, immediately contact an
Authorised Customer Service Centre.
For washing wool or silk, only use
detergents specifically formulated for
these fabrics.
For washing at temperatures below
40°C
we recommend the use of liquid
detergents or detergents specifically
labeled as suitable for low temperature
washing.
For washes between 40°C and 60°C
the type of detergent used needs to be
appropriate for the type of fabric and
level of soiling. Normal powders are
suitable for “white” or colour fast fabrics
with high soiling, while liquid detergents
or “colour protecting” powders are
suitable for coloured fabrics with light
levels of soiling.
When washing heavily soiled whites,
we recommend using cotton programs
of
60°C
or above and a normal washing
powder (heavy duty) that contains
bleaching agents that at medium/high
temperatures provide excellent results.

14
5. CLEANING AND
MAINTENANCE
Looking after your appliance correctly can
extend its lifespan.
Disconnect the machine from the power
supply.
Clean the appliance’s external cabinet,
using a damp cloth and AVOIDING
ABRASIVES, ALCOHOL AND/OR
DILUENTS.
It is advisable to regularly clean the
detergent drawer to avoid the
accumulation of detergent and additive
residues.
Remove the drawer gently but firmly.
Clean the drawer under running water
and put it back into its compartment.
The appliance has a special filter that
traps larger residues that could block the
draining system, such as buttons or
coins.
We recommend checking and cleaning
the filter 5 or 6 times a year.
Disconnect the machine from the power
supply.
Ensure all the water has been emptied
from the drum.
Before unscrewing the filter, we
recommend you place an absorbent towel
under it to keep the floor dry. A small
amount of water will come out of the filter
as you remove it - this is normal.
Turn the filter counter-clockwise to the
limit stop.
Remove and clean the filter; when
finished, replace it turning it clockwise.
The filter handle will be locked when it is
not possible to turn any further and the
handle is horizontal. Smearing a small
amount of liquid soap on the filter seal will
help refitting.
Repeat the previous steps in reverse
order to reassemble all parts.
If the appliance is kept in a non-heated
room for long periods of time, all water
residues must be completely removed
from the pipes.
Disconnect the machine from the power
supply socket.
 Detach the tube from the drainage system
and clip on the rear of the machine and
lower it, fully draining water into a bowl.
Secure the drain tube with the drainage
system and clip on the rear of the
machine when finished.
Keep the door glass and gasket clean.
Suggestions for moves or
prolonged disuse
Cleaning the pump filter
Drawer cleaning
Cleaning the appliance’s exterior

15
EN
6. QUICK USER GUIDE
This washing machine automatically adjusts
the level of the water to the type and
quantity of washing. This system gives a
reduction in energy consumption and a
saving in washing times.
Turn on the washing machine and select
the required program.
Adjust the washing temperature if
necessary and press the required "option"
buttons.
Press the START/PAUSE button to start
washing.
At the end of the programme, the
message "End" will appear on the display
or, on some models, all wash stage
indicator lights will turn on.
Turn off the washing machine.
For any type of wash, see the program
table and follow the operating sequence
as indicated.
Water pressure:
min 0.1 Mpa / max 1 Mpa
Spin r.p.m.: See rating plate.
Power input / Power current fuse amp /
Supply voltage: See rating plate.
7. CONTROLS AND
PROGRAMMES
A
Programme selector with OFF
position
B
START/PAUSE button
C
DELAY START button
D
DRYING SELECTION / STEAM
FUNCTION
button
E
RAPID / STAIN LEVEL button
F
OPTIONS button
G
TEMPERATURE SELECTION
button
H
SPIN SPEED button
G+H
KEY LOCK
I
Digital display
L
DOOR LOCKED indicator light
Technical data
Wait until the DOOR LOCKED light has
gone out before opening the door.
DRYING
If you
would like the drying cycle to
begin automatically after washing,
select the programme required using
the DRYING SELECTION button.
Or you can finish the wash and then
select the drying programme and
load size.
Program selection

16
Press the START/PAUSE button to start
the selected cycle.

Once a programme is selected the
programme selector remains stationary on
the selected programme till cycle ends.

"End" will appear in the display at the
end of the program and the DOOR
LOCKED light will go off, it is now
possible to open the door.

Switch off the washing machine by
turning the selector to OFF.
Press to start the selected cycle.
PAUSING THE MACHINE
Keep the START/PAUSE button pressed
for about 2seconds (some light indicators
and the residual time display will flash,
showing that the machine is paused).
Press the START/PAUSE button again to
re-start the programme from the point it
had been paused at.
CANCELLING THE PROGRAMME
To cancel the programme, set the
selector to the OFF position.
Wait until the DOOR LOCKED light has
gone out before opening the door.
This button allows you to pre-programme
the wash cycle to delay the start of the
cycle for up to 24 hours.
DELAY START button
For safety reasons, in some wash
cycle phases, the door can be opened
only if the level of the water is below
its lower edge and if the temperature
is less than 45°C. If these conditions
are met, wait for the DOOR LOCKED
light to switch off before opening the
door.
When the START/PAUSE button has
been pressed, the appliance can take
few seconds before it starts working.
Close the door BEFORE selecting the
button START/PAUSE.
START/PAUSE button
The programme selector must be
returned to the OFF position at the end
of each cycle or when starting a
subsequent wash cycle prior to the next
programme being selected and started.
When the programme selector is turned
the display lights up to show the settings
for the programme selected.
For energy saving, at the end of the
cycle or with an inactivity period, the
display level contrast will decrease.
N.B.: To switch the machine off, turn
the programme selector to the OFF
position.
PROGRAMME selector with OFF
position
WARNING:
Don’t touch the display while inserting
the plug because the machines
calibrates
the systems during the first
seconds: touching the display, the
machine couldn’t work property. In
this case, remove the plug and repeat
the operation.

17
EN
To delay the start use the following
procedure:
- Select the required programme.
- Press the delay start button once to
activate it (h00 appears on the display)
and then press it again to set a 1 hour
delay (h01 appears on the display). The
pre-set delay increases by 1 hour each
time the button is pressed, until h24
appears on the display, at which point
pressing the button again will reset the
delay start to zero.
- Confirm by pressing the START/PAUSE
button. The delay countdown will begin
and when it has finished the programme
will start automatically.
It is possible to cancel the delay start by
turning the programme selector to OFF.
If there is a break in the power supply
whilst the machine is operating, when
the power is restored, the machine will
restart from the beginning of the phase it
was in when the power was lost.
This button allows you to choose between
two different options:
- DRYING SELECTION
For automatic washing/drying cycle:
after the selection of washing programme
according to laundry type, select a degree
of dryness by pressing this button. At the
end of the washing programme, the
selected drying cycle will start
automatically.
If a washing programme is not
compatible with automatic drying
selected, this function will not be
activated.
If you want delete the selection before
the programme starts, please press
repeatedly the button until the lights go off
or reposition the programme selector to
the OFF position.
Drying only cycle:
select via the knob the desired drying
programme in conjunction with your
fabrics, by pressing this button it is
possible to select a degree of dryness
that is different to the default one (except
for the wool drying programme).
To cancel the cycle during the drying
phase, please press the button for about
3 seconds.

"End" will appear in the display at the
end of the program and the DOOR
LOCKED light will go off, it is now
possible to open the door.
It is also possible to cancel the drying
cycle by turning the programme
selector to the OFF position. It is
necessary to wait for the cooling
phase’s end (10/20 minutes) and the
DOOR LOCKED light to go off before
opening the door.
WARNING:
After cancelling the drying programme,
the cool down phase will begin and
please wait for about 10/20 minutes
before opening the door.
If you exceed the maximum dryable
load of laundry indicated in the
programme table, the laundry may not
be dried satisfactory.
DRYING SELECTION / STEAM
FUNCTION button
The option buttons should be
selected before pressing the
START/PAUSE button. If an option is
selected that is not compatible with
the selected programme then the
option indicator light first flashes and
then goes off.

18
- STEAM FUNCTION
After the selection of "ACTIVE STEAM"
programme, select between three different
intensity of steam treatments that are
suitable for dry or wet clothes and
according to fabric type:
- Active Steam Synthetics/Mixed
(default selection) P1 appears on the
display
This programme is suitable for synthetics
and mixed clothes. In the case of wet
clothes (i.e. after washing) If relax creases
is selected after spin the dry clothes will
reach the ideal moisture level for an easy
ironing. Medium time.
- Active Steam Cotton
(only a button push) P2 appears on the
display
This programme is for cotton clothes. In
the case of wet clothes (i.e. after washing)
If relax creases is selected after spin the
dry clothes will reach the ideal moisture
level for an easy ironing. Medium time.
- Steam Refresh
(two button pushes) P3 appears on the
display
Thanks to the steam action, the cycle lets
to refresh and relax clothes’ creases after
use. This programme consists of a start
phase in which the steam in introduced
and the excess moisture is removed at
the final stage to allow prompt use. This
cycle is suitable for dry clothes.
The function is suitable for max up to 1,5 kg
load.
This button allows you to choose between
two different options, depending on the
selected programme:
- RAPID
The button becomes active when
you select the RAPID CARE (14'/30'/44')
programme on the knob and allows you to
select one of three durations indicated.
- STAIN LEVEL button
Once the programme has been selected
the wash time set for that programme will
be automatically shown.
This option allows you to choose between
3 levels of wash intensity modifying the
length of the programme, depending on
how much the fabrics are soiled (can
only be used on some programmes as
shown in the table of programmes).
This button allows you to choose between
three different options, depending on the
selected programme:
- PREWASHING

This option allows you to make a prewash
and it is particularly useful for heavily
soiled loads (can be used only on some
programmes as shown in the table of
programmes).
We recommend you use only 20% of the
recommended quantities shown on the
detergent pack.
- AQUAPLUS

This option (available only in some
programmes) allows you to wash the
load in a much larger quantity of water
and this, together with the new combined
action of the drum rotation cycles, where
water is filled and emptied, will give you
garments which have been cleaned and
rinsed to perfection so that the detergent
dissolves completely, ensuring an
efficient cleaning action.
This function is for the people with
delicate and sensitive skin.
OPTIONS button
RAPID / STAIN LEVEL button

19
EN
This function can be used for children’s
items and for washing of very dirty items,
for which you are required to use a lot of
detergent, or for washing of Towels
whose fibres have the tendency to hold
the detergent.
- HYGIENE +
Activated when you set 60°C of
temperature. This option allows deep
cleaning of your clothes by maintaining the
same temperature for the whole wash.
This button allows you to change the
temperature of the wash cycles.
It is not possible to raise the temperature
over the maximum allowed for the
programme, in order to protect the
fabrics.
If you want carry out a cold wash all the
indicators must be off.
By pressing this button, it is possible to
reduce the maximum speed, and if you
wish, the spin cycle can be cancelled.
If the label does not indicate specific
information, it is possible to use the
maximum spin expected in the program.
To reactivate the spin cycle press the
button until you reach the spin speed you
would like to set.
It is possible to modify the spin speed
without pausing the machine.
Pressing simultaneously the buttons
TEMPERATURE SELECTION and SPIN
SPEED for about 3 seconds, the
machine allows you to lock the keys. In
this way, you can avoid making
accidental or unwanted changes if a
button on the display is pressed
accidently during a cycle.
The key lock can be simply cancelled by
pressing the two buttons simultaneously
again or turning off the appliance.
The display’s indicator system allows you to
be constantly informed about the status of
the machine.
1) DOOR LOCKED INDICATOR LIGHT
The indicator light is illuminated when the
door is fully closed.
Digital Display
KEY LOCK
The machine is fitted with a special
electronic device, which prevents the
spin cycle should the load be
unbalanced. This reduces the noise
and vibration in the machine and so
prolongs the life of your machine.
An over dosing of detergent can
cause excessive foaming. If the
appliance detects the presence of
excessive foam, it may exclude the
spinning phase or extend the duration
of the program and increase water
consumption.
To prevent damage to the fabrics, it is
not possible to increase the speed
over the maximum allowed for the
programme.
SPIN SPEED button
TEMPERATURE SELECTION
button

20
When START/PAUSE is pressed on the
machine with the door closed, the
indicator will flash momentarily and then
illuminate.
Wait until the DOOR LOCKED light has
gone out before opening the door.
2) SPIN SPEED
This shows the spin speed of the selected
programme that can be changed or omitted
by the relevant button.
3) WASH TEMPERATURE INDICATOR
LIGHTS
The indicator lights show the washing
temperature of the selected programme that
can be changed (where allowed) by the
relevant button. If you want carry out a cold
wash all the indicators must be off.
4) CYCLE DURATION
When a programme is selected the
display automatically shows the cycle
duration, which can vary, depending on
the options selected.
Once the programme has started you will
be kept informed constantly of the time
remaining to the end of the wash.
The appliance calculates the time to the
end of the selected programme based
upon a standard loading, during the cycle,
the appliance corrects the time to that
applicable to the size and composition of
the load.
5) KEY LOCK INDICATOR LIGHT
The indicator light shows that the keys are
locked.
6) STAIN LEVEL INDICATOR LIGHT
The indicator light shows the selection of
the relevant option.
7) Kg MODE (function active only on
certain programmes)
During the first minutes of the cycle, the
"Kg MODE" indicator remain on while the
intelligent sensor will weigh the laundry
and adjust the cycle time, water and
electricity consumption accordingly.
Through every wash phase "Kg MODE"
allows to monitor information on the wash
load in the drum and in the first minutes
of the wash it:
- adjusts the amount of water required;
- determines the length of the wash cycle;
- controls rinsing according to the type of
fabric selected to be washed it;
- adjusts the rhythm of drum rotation for
the type of fabric being washed;
- recognizes the presence of lather,
increasing, if necessary, the amount of
water during rinsing;
- adjusts the spin speed according to the
load, thus avoiding any imbalance.
8) DRYING SELECTION INDICATOR LIGHTS
The indicators display the degrees of
dryness that can be selected by the
relevant button:
Automatic drying programmes
EXTRA DRY
(suitable for towels, bathrobes and
bulky loads).
IRON DRY
(that leaves the laundry ready for
ironing).
If the door is not properly closed,
the light will continue to flash
for
about 7 seconds
, after which the
start command
will be automatically
delete. In this case, close
the door
in the proper way and press the
START/PAUSE button.
Close the door BEFORE selecting the
START/PAUSE button.
