Hoover Dynamic Next WDMT413AI2 User manual

EN

!
2

!
EN
3
Thank-you for choosing a Hoover washing
machine. We are proud to always offer
new, innovative and technologically
advanced products, with a complete range
of home appliances to ensure true
assistance in your daily routine.
We suggest you register your product at
www.registerhoover.com to gain faster
access to supplementary services solely
reserved to our most loyal customers.
Carefully read this manual for correct and
safe appliance use and for helpful tips on
efficient maintenance.
Only use the washing machine
after carefully reading these instructions.
We recommend you always keep this
manual on hand and in good conditions for
any future owners.
Please check that the appliance is
delivered with this instruction manual,
warranty certificate, service centre address
and energy efficiency label. Also check that
plugs, curve for drain hose and liquid
detergent or bleach tray (only on some
models) are included. We recommend you
keep all these components.
Each product is identified by a unique 16-
character code, also called the “serial
number”, printed on the sticker affixed to
the appliance (porthole area) or in the
document envelope found inside the
product. This code is a sort of specific
product ID card that you will need to
register it and should you need to contact
the Hoover Customer Service Centre.
This appliance is marked according to
the European directive 2012/19/EU
on Waste Electrical and Electronic
Equipment (WEEE).
WEEE contains both polluting substances (which
can cause negative consequences for the
environment) and basic components (which can
be re-used). It is important to have WEEE
subjected to specific treatments, in order to
remove and dispose properly all pollutants, and
recover and recycle all materials. Individuals can
play an important role in ensuring that WEEE
does not become an environmental issue; it is
essential to follow some basic rules:
!WEEE should not be treated as household
waste;
!WEEE should be handed over to the relevant
collection points managed by the municipality or
by registered companies. In many countries, for
large WEEE, home collection could be present.
In many countries, when you buy a new
appliance, the old one may be returned to the
retailer who has to collect it free of charge on a
one-to-one basis, as long as the equipment is of
equivalent type and has the same functions as
the supplied equipment.
1. GENERAL SAFETY RULES
2. INSTALLATION
3. PRACTICAL TIPS
4. MAINTENANCE AND CLEANING
5. QUICK USER GUIDE
6. CONTROLS AND PROGRAMS
7. DRYING CYCLE
8. AUTOMATIC WASHING/DRYING CYCLE
9. CUSTOMER SERVICE CENTRE AND
WARRANTY
Environmental conditions
Contents

!
4
1. GENERAL SAFETY
RULES
!This appliances is intended to be
used in household and similar
applications such as:
- Staff kitchen areas in shops, offices
and other working environments;
- Farm houses;
- By clients in hotels, motels and
other residential type environments;
- Bed and breakfast type environments.
A different use of this appliance
from household environment or
from typical housekeeping
functions, as commercial use by
expert or trained users, is
excluded even in the above
applications. If the appliance is
used in a manner inconsistent with
this it may reduce the life of the
appliance and may void the
manufacturer’s warranty. Any
damage to the appliance or other
damage or loss arising through
use that is not consistent with
domestic or household use (even if
located in a domestic or household
environment) shall not be
accepted by the manufacturer to
the fullest extent permitted by law.
!This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance in a
safe way and understand the
hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
!Children should be supervised to
ensure that they do not play with
the appliance.
!Children of less than 3 years
should be kept away unless
continuously supervised.
!If the supply cord is damaged, it
must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order to
avoid a hazard.
!Only use the hose-sets supplied
with the appliance for the water
supply connection (do not reuse
old hose-sets).
!Water pressure must be between
0,05 MPa and 0,8 MPa.
!Make sure that a carpet do not
obstruct the base of the machine
and ventilation openings.
! The OFF condition is reached by
placing the reference mark on the
programmes control/knob in the
vertical position. Any other different
position of such control sets the
machine in ON condition (only for
models with programmes knob).
!The final part of a washer dryer
cycle occurs without heat (cool
down cycle) to ensure that the
items are left at a temperature
that ensures that the items will not
be damaged.

!
EN
5
!After installation, the appliance
must be positioned so that the
plug is accessible.
!The appliance must not be
installed behind a lockable door, a
sliding door or a door with a hinge
on the opposite side to that of the
washer dryer, in such way that a
full opening of the washer dryer
door is restricted.
!The maximum load capacity of
dry clothes depends on the model
used (see control panel).
!The appliance is not to be used if
industrial chemicals have been
used for cleaning.
!Do not dry unwashed items in the
washer dryer.
!Items that have been soiled with
substances such as cooking oil,
acetone, alcohol, petrol,
kerosene, spot removers,
turpentine, waxes and wax
removers should be washed in
hot water with an extra amount of
detergent before being dried in
the washer dryer.
!Items such as foam rubber (latex
foam), shower caps, waterproof
textiles, rubber backed articles
and clothes or pillows fitted with
foam rubber pads should not be
dried in the washer dryer.
!Fabric softeners, or similar
products, should be used as
specified by the fabric softener
instructions.
!Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such as
a washer dryer. The items
become warm, causing an
oxidation reaction in the oil,
Oxidation creates heat. If the heat
cannot escape, items can become
hot enough to catch fire. Piling,
stacking or storing oil-effected
items can prevent heat from
escaping and so create a fire
hazard.
!If it is unavoidable that fabrics
contain vegetable or cooking oil or
have been contaminated by hair
care products be placed in a
washer dryer they should first be
washed in hot water with extra
detergent - this will reduce, but
not eliminate, the hazard.
!Remove all objects from pockets
such as lighters and matches.
!To consult the product fiche please
refer to the manufacturer website.
!Before cleaning or maintaining the
washing machine, unplug the
appliance and turn off the water
faucet.
WARNING:
never stop a washer dryer before
the end of the drying cycle
unless all items are quickly
removed and spread out so that
the heat is dissipated.
Safety instructions

!
6
!Make sure the electrical system is
grounded. Otherwise, seek qualified
professional assistance.
!Please do not use converters,
multiple sockets or extension
cords.
!Make sure there is no water in the
drum before opening the porthole.
!Do not pull on the power cord or
appliance to unplug the machine.
!Do not expose the washing
machine to rain, direct sunlight or
other weather elements.
!When moving, do not lift the
washing machine by the knobs or
detergent drawer; during transport,
never rest the porthole on the
trolley. We recommend two people
lift the washing machine.
!In the event of fault and/or
malfunction, turn off the washing
machine, close the water faucet
and do not tamper with the
appliance.
Immediately contact the Customer
Service Centre and only use
original spare parts. Failure to
observe these instruction may
jeopardise appliance safety.
Appliance complies with
European Directives:
!2006/95/EC (LVD);
!2004/108/EC (EMC);
!2009/125/EC (ErP);
!2011/65/EU (RoHS)
and subsequent amendments.
WARNING:
water may reach very high
temperatures during the wash
cycle.

!
EN
7
2. INSTALLATION
!Cut the tube straps, being careful
not to damage the tube and
power cord.
!Unscrew the 2or 4screws (A) on
the back and remove the 2or 4
shims (B) as illustrated in figure
1.
!Close the 2or 4holes using the
plugs included in the instruction
envelope.
!If the washing machine is built-in,
after cutting the hose straps,
unscrew the 3or 4screws (A)
and remove the 3or 4shims (B).
!In some models, 1or more
shims will fall inside the machine:
tilt the washing machine forward
to remove them. Close the holes
using the plugs found in the
envelope.
!Place the polionda sheet on the
bottom as shown in figure 2
(according to the model, consider
version A, Bor C).
A
A
A
A
B
B
B
B
1
3
2
1
3
1
2
A
C
B
2
WARNING:
keep packaging materials away
from children.

!
8
!Connect the water tube to the faucet, only
using the drain tube supplied with the
washing machine (fig. 3).
DO NOT OPEN THE FAUCET.
!Some models may include one or more of
the following features:
!HOT&COLD (fig. 4):
water mains connection settings with hot
and cold water for higher energy savings.
Connect the grey tube to the cold water
faucet and the red one to the hot water
faucet. The machine can be connected to
the cold water faucet only: in this case,
some programs may start a few minutes
later.
!AQUASTOP (fig. 5):
a device located on the supply tube that
stops water flow if the tube deteriorates;
in this case, a red mark will appear in the
window “A” and the tube must be
replaced. To unscrew the nut, press the
one-way lock device "B".
!AQUAPROTECT – SUPPLY TUBE WITH
GUARD (fig. 6):
Should water leak from the primary
internal tube "A", the transparent
containment sheath "B" will contain water
to permit the washing cycle to complete.
At the end of the cycle, contact the
Customer Service Centre to replace the
supply tube.
!Near the washing machine to the wall,
being careful that the tube is not bent or
crushed, and place the drain tube in the
tub or, preferably, connect it to a wall
drain at least 50 cm high with diameter
greater than the washing machine tube
(fig. 7).
3
1
4
B
A
5
B
A
6
min 50 cm
max 85 cm
+2,6 mt
max
max 100 cm
min 4 cm
7
Hydraulic connections
Setting

!
EN
9
!Level the appliance using the feet as
illustrated in figure 8:
a. turn the nut clockwise to release the
screw;
b. rotate the foot to raise or lower it until it
adheres to the floor;
c. lock the foot, screwing in the nut, until it
adheres to the bottom of the washing
machine.
!Plug in the appliance.
A
B
C
8
The detergent draw is split into 3
compartments as illustrated in figure 9:
!compartment "1": for prewash detergent;
!compartment “ ”: for special additives,
softeners, starch fragrances, etc.;
!compartment "2": for washing detergent.
A liquid detergent cup is also included in
some models (fig. 10). To use it, place it in
compartment "2". This way, liquid
detergent will only enter the drum at the
right time. The cup can also be used for
bleach when the “Rinse” program is
selected.
9
10
11
WARNING:
contact the Customer Service Centre
should the power cord need
replacement.
Detergent drawer
WARNING:
only use liquid products; the washing
machine is set to automatically dose
additives at each cycle during the last
rinse.
WARNING:
some detergents are hard to remove.
In this case we recommend using the
specific container to be placed in the
drum (example in figure 11).

!
10
3. PRACTICAL TIPS
WARNING: when sorting laundry, make
sure:
- have eliminated metallic objects such as
barrettes, pins, coins, from laundry;
- to have buttoned pillow cases, closed
zips, tied loose belts and long robe
ribbons;
- to have removed rollers from curtains;
- to have carefully read clothing washing
labels;
- to have removed any persistent stains
using specific detergents.
!When washing rugs, bedcovers or other
heavy clothing, we recommend you avoid
centrifuging.
!To wash wool, make sure the item can be
machine washed and marked by the
“Pure virgin wool” symbol with the “Does
not mat” or “Machine washable” label.
A guide environmentally friendly and
economic use of your appliance.
Maximise The Load Size
!Achieve the best use of energy, water,
detergent and time by using the
recommended maximum load size.
Save up to 50% energy by washing a full
load instead of 2 half loads.
Do you need to pre-wash?
!For heavily soiled laundry only!
SAVE detergent, time, water and
between 5 to 15% energy consumption
by NOT selecting Prewash for slight to
normally soiled laundry.
Is a hot wash required?
!Pretreat stains with stain remover or soak
dried in stains in water before washing to
reduce the necessity of a hot wash
programme.
Save up to 50% energy by using a 60°C
wash programme.
Before using a drying programme…
!SAVE energy and time by selecting a
high spin speed to reduce the water
content in laundry before using a drying
programme.
Following is a quick guide with tips and
recommendations on detergent use at the
various temperatures. In any case, always
read the instructions on the detergent for
correct use and doses.
Load tips
Helpful suggestions for the user
When washing heavily soiled whites,
we recommend using cotton
programs of 60°C or above and a
normal washing powder (heavy duty)
that contains bleaching agents that at
medium/high temperatures provide
excellent results.
For washes between 40°C and 60°C
the type of detergent used needs to be
appropriate for the type of fabric and
level of soiling.
Normal powders are suitable for “white”
or colour fast fabrics with high soiling,
while liquid detergents or “colour
protecting” powders are suitable for
coloured fabrics with light levels of
soiling.
For washing at temperatures below
40°C we recommend the use of liquid
detergents or detergents specifically
labeled as suitable for low temperature
washing.
For washing wool or silk, only use
detergents specifically formulated for
these fabrics.

!
EN
11
4. MAINTENANCE AND
CLEANING
To clean the washing machine exterior, use
a damp cloth, avoiding abrasives, alcohol
and/or solvents. The washing machine does
not require any special care for ordinary
cleaning: clean drawer compartments and
the filter; some tips on how to move the
machine or on long periods of disuse are
provided below.
!We recommend you clean the drawer to
avoid accumulating detergent and
additive residue.
!To do this, extract the drawer using slight
force, clean it with running water and
reinsert it in its housing.
!The washing machine comes with a
special filter able to trap large residue,
such as buttons or coins, which could
clog the drain.
!Only available on certain models: pull out
the corrugated hose, remove the stopper
and drain the water into a container.
!Before unscrewing the filter, we
recommend you place an absorbent cloth
under it to keep the floor dry.
!Turn the filter counter-clockwise to the
limit stop in the vertical position.
!Remove and clean the filter; when
finished, replace it turning it clockwise.
!Repeat the previous steps in reverse
order to reassemble all parts.
!Should the washing machine be stored in
an unheated room for a long period of
time, drain all water from tubes.
!Unplug the washing machine.
!Detach the tube from the strap and lower
it, fully draining water into a bowl.
!Secure the drain tube with the strap when
finished.
Drawer cleaning
Filter cleaning
Suggestions for moves or
prolonged disuse

!
12
5. QUICK USER GUIDE
This washing machine automatically adapts
the level of the water to the type and
quantity of washing. This system gives a
decrease in energy consumption and a
sensible reduction in washing times.
!Turn on the washing machine and select
the required program.
!Adjust the washing temperature if
necessary and press the required "option"
buttons.
!Press the START/PAUSE button to start
washing.
!The message "end" will appear on the
display or the corresponding led will turn
on at the end of the program.
!Turn off the washing machine.
For any type of wash, see the program
table and follow the operating sequence
as indicated.
Water pressure: min 0,05 Mpa / max 0,8 Mpa
Spin r.p.m.: See rating plate.
Power input / Power current fuse amp /
Supply voltage: See rating plate.
6. CONTROLS AND
PROGRAMS
}
A
B
HGILMNE
C
OPF
D
Q
A
Touch Control (with ON/OFF
button)
B
START/PAUSE button
C
SPIN SPEED button
D
TEMPERATURE SELECTION
button
E
DELAY START button
F
WASH TIME button
G
PREWASH button
H
HYGIENE PLUS button
I
EXTRA RINSE button
L
DRYING SELECTION button
M
FAVOURITES button
N
NIGHT & DAY button
O
Digital display
P
DOOR LOCKED indicator light
Q
DRYING PROGRAMME
SELECTION button
E+N
KEY LOCK
Program selection
DRYING
If you would like the drying cycle to
begin automatically after washing,
select the programme required using
the DRYING SELECTION button.
Or you can finish the wash and then
select the drying programme and
load size.
Wait until the porthole locked light
turns off: about 2 minutes after the
program ends.
Technical data

!
EN
13
1) ON/OFF button
Press for at least 1 second the ON/OFF
button to turn on the appliance.
Switching on, the related indicator will light
on, as well as the "X Red Light", waiting
for the selection of a washing programme.
If a programme is not selected within 30
seconds, the appliance will automatically
turn off.
Waiting for the selection of the programme
the display is off.
2) PROGRAMME SELECTION button
Turning on the appliance is also possible by
pushing for at least one second the button
of a selected programme (the display will
light up, showing the parameters of the
selected cycle).
To set another programme, press the
related button (the corresponding indicator
light will light up).
To switch off the appliance, press the
ON/OFF button (for at least 3 seconds).
3) BUTTON SELECTION indicators
They light up at the touch of the related
button.
4) "X Red Light"
It lights up at the pressing of any button of
the Touch Control, with a diffused lighting
fading to the edges.
It gradually turns off within 5 minutes since
the last touch of a button, in order to save
energy.
WARNING:
Don’t touch the display (and the Touch
Control) while inserting the plug because
the machines calibrates the systems
during the first seconds: touching the
display, the machine couldn’t work
property. In this case, remove the plug
and repeat the operation.
Opening the door
A special safety device prevents the
door from being opened immediately
after the end of the cycle.
Wait for 2 minutes after the wash
cycle has finished and the "Door
Security" light has gone out before
opening the door.
Touch Control

!
14
!Press to start the selected cycle.
ADD OR REMOVE ITEMS AFTER THE
PROGRAMMES HAS STARTED (PAUSE)
!Press and hold the START/PAUSE
button for about 2 seconds (some
indicator light and the time remaining
indicator will flash, showing that the
machine has been paused).
!Wait 2 minutes until the safety device
unlocks the door.
!After you have added or removed items,
close the door and press the
START/PAUSE button (the programme
will start from where it left off).
CANCELLING THE PROGRAMME
!To cancel the programme, press the
ON/OFF button (for at least 3 seconds).
!By pressing this button, it is possible to
reduce the maximum speed, and if you
wish, the spin cycle can be cancelled.
spin speed cancelled.
!To reactivate the spin cycle press the button
until you reach the spin speed you would
like to set.
!It is possible to modify the spin speed
without pausing the machine.
!This button allows you to change the
temperature of the wash cycles.
cold wash.
!It is not possible to raise the temperature
over the maximum allowed for every
programme, in order to save the fabrics.
!This button allows you to pre-programme
the wash cycle to delay the start of the
cycle for up to 24 hours.
START/PAUSE button
Close the door BEFORE selecting the
button START/PAUSE.
When the START/PAUSE button has
been pressed, the appliance can take
few seconds before it starts working.
The option buttons should be selected
before pressing the START/PAUSE
button.
If an option is selected that is
not compatible with the selected
programme then the option indicator
first flashes and then goes off.
SPIN SPEED button
To prevent damage to the fabrics, it is
not possible to increase the speed
over that which is automatically
suitable during the selection of the
program.
The machine is fitted with a special
electronic device, which prevents the
spin cycle should the load be
unbalanced.
This reduces the noise and vibration in
the machine and so prolongs the life of
your machine.
TEMPERATURE SELECTION button
DELAY START button

!
EN
15
!To delay the start use the following
procedure:
- Set the required programme.
- Press the button once to activate it (h00
appears on the display) and then press
it again to set a 1 hour delay (h01
appears on the display). The pre-set
delay increases by 1 hour each time the
button is pressed, until h24 appears on
the display, at which point pressing the
button again will reset the delay start to
zero.
- Confirm by pressing the START/PAUSE
button (the light on the display starts to
flash). The countdown will begin and
when it has finished the programme will
start automatically.
!It is possible to cancel the delay start by
pressing the ON/OFF button (for at least
3 seconds).
If there is any break in the power supply
while the machine is operating, a special
memory stores the selected programme
and, when the power is restored, it
continues where it left OFF
!By selecting this button there is a choice
of 3 levels of wash intensity, depending
on how much the fabrics are soiled (can
be used only on some programmes as
shown in the table of programmes).
!Once the programme has been selected
the indicator light will automatically show
the wash time set for that programme.
!Selecting a different wash time the
relevant indicator will light up.
!This option allows you to make a prewash
and it is particularly useful for heavily
soiled loads (can be used only on
some programmes as shown in the
table of programmes).
!We recommend you use only 20% of the
recommended quantities shown on the
detergent pack.
With this option it is possible to hygienize
the clothes, the washing programme
reach a temperature of 60°C.
!This button allows you to add rinses at
the end of the washing cycle. The
maximum number of extra rinses is
related to the programme selected.
!This function has been studied for the
people with delicate and sensitive skin,
for which also a least residue of detergent
can cause irritations or allergies.
!It advises to also use this function for the
children items and in case of washings of
very dirty items, for which it is due to use
a lot of detergent, or in the washing of
toweling items whose fibres mostly have
the tendency to hold the detergent.
!This button allow to select the required
degree (or time) of drying programme: an
indicator light will light to display the
drying result selected each time you
press the button.
!To cancel the selection before the start of
a drying programme, press the button
repeatedly until the indicators go out.
!To cancel the cycle during the drying
phase, press and hold the button for at
least 3 seconds.
Given the high temperature inside the
drum, the machine will execute a cool
down phase before to unlock the door,
so the laundry can't be removed until
the end of this phase.
WASH TIME button
PREWASH button
HYGIENE PLUS button
EXTRA RINSE button
DRYING SELECTION button

!
16
This function allows you to save the settings
of your two favourite personalised
programmes, including the temperature,
spin speed and soil level, so you can recall
them quickly.
How to memorize a programme for the
first time:
1)
Select the programme and the
options you want.
2)
Press the FAVOURITES button,
choosing either M1 or M2. You should
choose M1 if this is the first
programme you have saved.
3)
Keep your finger on the
FAVOURITES button for about 3
seconds to save the combination in
the chosen position.
Memorize a new programme when M1 &
M2 already have programmes saved:
1)
Set the programme and the options
you want.
2)
Press the FAVOURITES button for
about 3 seconds to save the
combination in the position M1. The
pre-existing saved programme in M1
will move in the position M2.
Start a program that is already
memorized
!Press briefly the FAVOURITES button
(once for M1, twice for M2) and press the
START/PAUSE button.
!Once you recall a memorized program,
you can still change its options and
settings, pressing the corresponding
keys. In this case, the added options
won’t be memorized.
!This option reduces the intermediate spin
speed to 400 rpm, where applicable,
increase the water level during rinsing
and keep the laundry immersed in water
after the final rinse, in order to spread the
fiber perfectly.
!During the phase in which the water is
held in the tub, the relevant indicator light
blink to show that the machine is at a
standstill.
!Deselect the option to end the cycle with
a spin dry (which may be reduced or
cancelled using the appropriate button)
and emptying phase.
!Thanks to electronic control, the water in
the intermediate phases is emptied
silently, making this option very useful for
washing at night.
This button allows you to select one of three
drying programmes available. By pressing
this button, one indicator light will go on to
show the selected drying programme.
!Pressing simultaneously the buttons
NIGHT & DAY and DELAY START for
about 3 seconds, the machine allows
you to lock the keys.
In this way, you can avoid making
accidental or unwanted changes if a
button on the display is pressed
accidently during a cycle.
!The key lock can be simply cancelled by
pressing the two buttons simultaneously
again or by pressing the ON/OFF button
(for at least 3 seconds).
FAVOURITES button
If you accidently select a memorized
program, simply turn the program
knob to select another one.
NIGHT & DAY button
DRYING PROGRAMME SELECTION
button
KEY LOCK

!
EN
17
The display’s indicator system allows you to
be constantly informed about the status of
the machine.
2
13 14
1615 10 12 5
7 7 7 7 7
8 9 411
3
16
1) DOOR LOCKED INDICATOR LIGHT
!The indicator light is illuminated when the
door is fully closed.
!When START/PAUSE is pressed on
the machine with the door closed, the
indicator will flash momentarily and then
illuminate.
!A special safety device prevents the door
from being opened immediately after the
end of the cycle. Wait for 2 minutes after
the wash cycle has finished and the
DOOR LOCKED light has gone out
before opening the door. At the end of the
cycle press the ON/OFF button (for at
least 3 seconds).
2) SPIN SPEED
This show the spin speed of the selected
programme that can be changed or omitted
by the relevant button.
spin speed cancelled.
3) WASH TEMPERATURE
This show the washing temperature of the
selected programme that can be changed
(where allowed) by the relevant button.
cold wash.
4) CYCLE DURATION
!When a programme is selected the
display automatically shows the cycle
duration, which can vary, depending on
the options selected.
!Once the programme has started you will
be kept informed constantly of the time
remaining to the end of the wash.
!The appliance calculates the time to the
end of the selected programme based
upon a standard loading, during the cycle,
the appliance corrects the time to that
applicable to the size and composition of
the load.
!If automatic washing/drying is selected, at
the end of the wash phase, the drying time
remaining to the end will be shown on the
display.
5) WASH TIME
!Once the programme has been selected,
the indicator light will automatically show
the wash time set for that programme.
!Selecting a different wash time the
relevant indicator will light up.
Digital Display
Close the door BEFORE selecting the
START/PAUSE button.
If the door is not properly closed,
the light will continue to flash for
about 7 seconds, after which the
start command will be automatically
delete. In this case, close the door
in the proper way and press the
START/PAUSE button.

!
18
6) EXTRA RINSES
The indicator lights show the extra rinses
selected by the relevant button.
7) OPTIONS
The indicator lights show the options that
can be selected by the relevant buttons.
8) Wi-Fi (some models only)
!In the models with the Wi-Fi option, the
icon indicates that the Wi-Fi system is
working.
!For all other information in the Wi-Fi
system, there is a specific manual inside
the machine.
9) DELAY START
This flashes when delay start has been set.
10) Kg MODE (function active only on
Cotton and Synthetics programmes)
!For the programmes where the "Kg
MODE" function is active, the appliance
in the first minutes it calculates the real
laundry loaded, updating the levels on the
display in real time.
Every levels shown on the display is the
20% of the maximum loading capacity.
When a programme is selected the
maximum capacity suggested is shown
on the display.
!Through every wash phase "Kg MODE"
allows to monitor information on the wash
load in the drum and in the first minutes
of the wash it:
- adjusts the amount of water required;
- determines the length of the wash cycle;
- controls rinsing according to the type of
fabric selected to be washed it;
- adjusts the rhythm of drum rotation for
the type of fabric being washed;
- recognizes the presence of lather,
increasing, if necessary, the amount of
water during rinsing;
- adjusts the spin speed according to the
load, thus avoiding any imbalance.
11) FAVOURITES
The indicator light show that the memory
function is working.
12) KEY LOCK
The indicator light show that the keys are
locked.
13) TAP CLOSED
Indicates that the machine is unable to load
the water: it is suggested to turn off the
machine, check that the tap is open and the
water pressure is not particularly low.
14) FILTER BLOCKED
Indicates that the machine is not able to
drain the water: it is suggested to turn off
the machine, check that the filter is not
clogged or that the drain hose is not kinked
or crushed.
15) STANDARD COTTON PROGRAMMES
LIGHTS (see table of programmes)
The lights will light up when you select the
most efficient program in terms of water and
energy consumption, to wash cotton
garments with a normal grade of soil.
16) DRYING SELECTION INDICATORS
The indicators display the type of the drying
programme.
Automatic drying programmes
Extra dry programme (suitable for
towels, bathrobes and bulky loads).
Iron dry programme (that leaves the
laundry ready for ironing).
Cupboard dry programme (for
items that will be put away without
ironing).

!
EN
19
!By selecting one of these automatic
programmes, the washer dryer will
calculate the time needed for drying and
the level of moisture remaining in the
laundry, according to the load and drying
type selected.
!After pressing the START/PAUSE button,
the display will show the drying time
remaining.
Timed drying programmes
They may be used to select timed
drying programmes.
Cool down phase
Activated during the final cool down
period, in the last 10/20 minutes of
each drying phase.
Useful tips
!The 30 minute drying programme is
recommended for small loads (less than 1
kg) or only slightly damp loads.
!Your washer dryer automatically ends the
cycle when it reaches the selected drying
level.
!In order to ensure the correct operation of
the appliance, it is advisable not to
interrupt the drying phase unless it is
absolutely necessary.
The appliance calculates the time to
the end of the selected programme
based upon a standard loading.
During the cycle, the appliance
corrects the time according to the size
and composition of the load.

!
20
2
1
PROGRAM
kg *
(MAX.)
TEMP.°C
DETERGENT
Recommended
Max.
2
1
All In One 20°C
2)
5,5
6
6,5
7
8
20°
20°
All Baby 60°C
2)
5,5
6
6,5
7
8
60°
60°
All In One 59 Min.
2)
8
9
10
11
13
40°
40°
Wool & Silk
2
2
2
2
2,5
30°
30°
Rinse
2)
-
-
-
-
-
-
-
Delicates
2,5
2,5
2,5
2,5
3
40°
40°
Low Heat
(drying)
4
4,5
5
5,5
6,5
-
-
High Heat
(drying)
5
6
6
7
8
-
-
Rapid W&D 59 Min.
1,5
1,5
1,5
1,5
1,5
30°
30°
Mixed
1)
2)
4
4,5
5
5,5
6,5
40°
60°
( )
Cottons**
1)
2)
8
9
10
11
13
40°
90°
( )
Rapid 30 Min.
2)
2,5
2,5
2,5
2,5
3
30°
30°
Drain & Spin
2)
-
-
-
-
-
-
-
Table of programmes
