Hoover HW160M User manual

W.MACHINE/WASHER-DRYER
31000009 HW160M UK
Service Manual

IELB2038

IELB2416

IELB2423

IELB2607

31000009 HW160M UK 0214 (02/04/2002)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
2 Programs disc 03841525
8a Buffer with spring service pack 97917116
14a Drying knob 03841461
15 Cam disc 03850303
19 Button 03841517
19h Door opening button 03841487
24 Button protection 03841444
25 Dashboard plate 03930235
31 Control panel 05140917
32 Dispenser drawer front 04230960
48 R/H side frame 03940686
48a L/H side frame 03940687
49 Top rear frame 03940685
51 Work top 03410167
60 Hinge 91700102
61 Counter ring 90489572
62 Door surround 03730872
63 Door glass 91600903
65a Door catch with spring service pack 97920326
67 Glass door with frame 04230951
73a Screw 09031030
76 Cabinet assy 04230672
77 Rear panel 97911044
78 Socle 41006148
79 Rear foot 92606474
80 Front foot 92692300
94c Filter knob with gasket 06015493
97d Filt hous w/filter cartridge 91941772
99a Hose 91620000
101 Dispenser drawer 03870775
103 Rack 41005935

31000009 HW160M UK 0214 (02/04/2002)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
109 Dispenser bottom section assy 03870711
110 Dispenser top section 03870774
111 Water injector nozzle 92149327
112 Distribution connecting rod 92884212
113 Lever 97910582
114 Driving lever 92152800
114a Hose clip 92470061
116 Cam 06012915
118 Spring 92483148
131 Hose clip 92470020
131a Hose clip 92470194
132 Hose 97910517
132a Valve hose hot water 97910525
133 Hose clip 92470012
134 Solenoid valve 91213546
134a Solenoid valve warm water 92202852
138 Drain hose 92693373
138a Drain house elbow 92689587
138b Hose clamp 92895051
142 Fill hose 92250869
142a Fill hose for hot water 92250877
151 Timer 41004415
151c Drying timer 41004416
152i N.C.Push-button+resistance 41000611
152l N.C.Push-button 91201421
153 Pressure switch 28376102 0230 (24/07/2002)
153 Pressure switch 28376103 0230 (24/07/2002)
155 Indicator light 91209510
157 Wiring harness 41004860
157d 7 Way connection 97911473
157e 6 Way connecton 97911481

31000009 HW160M UK 0214 (02/04/2002)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
157f 11 Way connecton 97911499
158 Mains block 91623678
161d Drain/recycle pump complete 91941771
162 Door safety device 90489300
164 Anti jamming filter radio 91212795
178 Motor connector 27719213
202 Drum 41001240
203 Tub 97920714 0230 (24/07/2002)
203 Tub 97921118 0230 (24/07/2002)
204a Front flange 04240184
205 Drum shaft assy 41001233
215 Tub gasket 92131689
217 Seal retainer 91406201
219 Bolt 21446068
221 Nut 92424209
225a Gasket 92445626
230 Tub gasket clip 91750458
230a Tub gasket clip 90488603
232 Heater holder 97910301
242 Support spring. 92484492
242a R/H support spring 92484484
244 Washer 92430206
244a Counter weight washer 92430214
246 Bolt 92419472
246a Bolt 97911507
246b Slide 09078825
246c Clamp 97910061
248 Lower balance weight 91500344
251a Telescopic shock absorber 92484518
251c Washer 97910509
251d Nut 97915565

31000009 HW160M UK 0214 (02/04/2002)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
259 Support 92673961
271 Door gasket 91620118
272 Discharge pipe 03860469 0230 (24/07/2002)
272 Discharge pipe 41001597 0230 (24/07/2002)
273 Fill pipe 91620033
274 Pressure switch air chamber 04350200
275 5x8 hose 66655735 0230 (24/07/2002)
275 5x8 hose 66655740 0230 (24/07/2002)
276 Steam hose 97910400
277 Hose spring 90386137
278a Hose clip d44 92470137
286 Heater 91201546
287g Thermostat 92212687
287m NTC probe 92743616
290 Drum pulley 03850285
292 Drive belt 92130442
292b Bottom panel 04230945
292c Clips 92473636
330 Screw x hinge 97917587
424 R/H Balance weight 03940637
425 L/H Balance weight 03940581
432 Steam condenser 03860482
433 Gasket 03870636
434 Motor fan 04350196
440 Scroll 09077868
440a Scroll seal 09077975
441 Cover 03870603
442 Fan 09088253
446 Upper duct 03860560
447 Lower duct 03860561
448 Upper heater 04820057
450 Lower heater 04820056

31000009 HW160M UK 0214 (02/04/2002)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
456 Spring 25411602
458a Elastic ring 92470319
461d Thermostat 147/M.R. 91213512
461e Thermostat 162/M.R. 91213520
461f Thermostat 140/100 91213538
462 Hose 03320027
464a T-piece connection 09090036
465 Water injector nozzle 92683556
473 Commutator motor 91201102
479 Electronic control 91200607
483a Brush with brush holder 92126721
487 Special bolt 09183567
491c Mains cable x UK 91200201
492 Heater fixing plaque 92871359
494 Red window 91611509
500a Hose clip 06012880
526 Sleeve 91601654
530 Fan fixing nut 09062431
535 Knob handle 03841449
547 Module protection 91612044
558 Support bracket 91800570
588 Siphon 41000762
602 Shock-absorb.conn.bracket 92898790
614 Therm.press.push b. supp. 03870721
632 Control support plate 91802090
668 Pump cover 03520065
734 Timer protection 03420083
738 Door protection 03930250
751 Capacitor tube 97919666
806 Door upper hinge 41005451
807 Door lower hinge 41005452

31000009 HW160M UK 0214 (02/04/2002)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
827a Open button x door interlock 90489363
828a Cable door safety device 04320340
828b Tach.coil 91950881
829 Metallic cover 91950899
831 Thermostat hole stopper 92898394
832 Discharge pipe circlip 91408004
833 Upper counterweight support 92898915
834 Lower counterweight supp. 92898923
839 Clip 92470384
840 Drum paddle 41001234
848 Plug 92943216
1000 Ring 97910459
1007 Tie rod 92419514
1010 Duct fan seal 09077892
1015 Fan support 09090374
1019 Instruction for use 05651239
1068 Trade mark plate 41000597

31000009 HW160M UK 0214 (02/04/2002) - Modifications History -
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2011 Gias S.r.L.
NEW TUB
153 Pressure switch 28376102 0230 (24/07/2002)
153 Pressure switch 28376103 0230 (24/07/2002)
203 Tub 97920714 0230 (24/07/2002)
203 Tub 97921118 0230 (24/07/2002)
272 Discharge pipe 03860469 0230 (24/07/2002)
272 Discharge pipe 41001597 0230 (24/07/2002)
275 5x8 hose 66655735 0230 (24/07/2002)
275 5x8 hose 66655740 0230 (24/07/2002)

HW120M, HW130M, HW160M UK

WIRING DIAGRAM
