Hoover WDXC 4751 User manual

EN

!
2
Thank-you for choosing a Hoover washing
machine. We are proud to always offer
new, innovative and technologically
advanced products, with a complete range
of home appliances to ensure true
assistance in your daily routine.
We suggest you register your product at
www.registerhoover.com to gain faster
access to supplementary services solely
reserved to our most loyal customers.
Carefully read this manual for correct and
safe appliance use and for helpful tips on
efficient maintenance.
Only use the washing machine
after carefully reading these instructions.
We recommend you always keep this
manual on hand and in good conditions for
any future owners.
Please check that the appliance is
delivered with this instruction manual,
warranty certificate, service centre address
and energy efficiency label. Also check that
plugs, curve for drain hose and liquid
detergent or bleach tray (only on some
models) are included. We recommend you
keep all these components.
Each product is identified by a unique 16-
character code, also called the “serial
number”, printed on the sticker affixed to
the appliance (porthole area) or in the
document envelope found inside the
product. This code is a sort of specific
product ID card that you will need to
register it and should you need to contact
the Hoover Customer Service Centre.
This appliance is marked according to
the European directive 2012/19/EU
on Waste Electrical and Electronic
Equipment (WEEE).
WEEE contains both polluting substances (which
can cause negative consequences for the
environment) and basic components (which can
be re-used). It is important to have WEEE
subjected to specific treatments, in order to
remove and dispose properly all pollutants, and
recover and recycle all materials. Individuals can
play an important role in ensuring that WEEE
does not become an environmental issue; it is
essential to follow some basic rules:
!WEEE should not be treated as household
waste;
!WEEE should be handed over to the relevant
collection points managed by the municipality or
by registered companies. In many countries, for
large WEEE, home collection could be present.
In many countries, when you buy a new
appliance, the old one may be returned to the
retailer who has to collect it free of charge on a
one-to-one basis, as long as the equipment is of
equivalent type and has the same functions as
the supplied equipment.
1. GENERAL SAFETY RULES
2. INSTALLATION
3. PRACTICAL TIPS
4. MAINTENANCE AND CLEANING
5. QUICK USER GUIDE
6. CONTROLS AND PROGRAMS
7. DRYING CYCLE
8. AUTOMATIC WASHING/DRYING CYCLE
9. CUSTOMER SERVICE CENTRE AND
WARRANTY
Environmental conditions
Contents

!
EN
3
1. GENERAL SAFETY
RULES
!This appliances is intended to
be used in household and
similar applications such as:
- Staff kitchen areas in shops, offices
and other working environments;
- Farm houses;
- By clients in hotels, motels and
other residential type environments;
- Bed and breakfast type environments.
A different use of this appliance
from household environment
or from typical housekeeping
functions, as commercial use by
expert or trained users, is excluded
even in the above applications. If
the appliance is used in a manner
inconsistent with this it may reduce
the life of the appliance and may
void the manufacturer’s warranty.
Any damage to the appliance or
other damage or loss arising
through use that is not consistent
with domestic or household use
(even if located in a domestic or
household environment) shall not
be accepted by the manufacturer to
the fullest extent permitted by law.
!This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.
!Children should be supervised
to ensure that they do not play
with the appliance.
!Children of less than 3 years
should be kept away unless
continuously supervised.
!If the supply cord is damaged, it
must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
!Only use the hose-sets
supplied with the appliance for
the water supply connection
(do not reuse old hose-sets).
!Water pressure must be between
0,05 MPa and 0,8 MPa.
!Make sure that a carpet do not
obstruct the base of the machine
and ventilation openings.
!The OFF condition is reached
by placing the reference mark on
the programmes control/knob in
the vertical position. Any other
different position of such control
sets the machine in ON condition
(only for models with programmes
knob).

!
4
!The final part of a washer dryer
cycle occurs without heat (cool
down cycle) to ensure that the
items are left at a temperature
that ensures that the items will
not be damaged.
!After installation, the appliance
must be positioned so that the
plug is accessible.
!The appliance must not be
installed behind a lockable
door, a sliding door or a door
with a hinge on the opposite
side to that of the washer
dryer, in such way that a full
opening of the washer dryer
door is restricted.
!The maximum load capacity of
dry clothes depends on the
model used (see control panel).
!The appliance is not to be used
if industrial chemicals have
been used for cleaning.
!Do not dry unwashed items in
the washer dryer.
!Items that have been soiled with
substances such as cooking oil,
acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes
and wax removers should be
washed in hot water with an extra
amount of detergent before being
dried in the washer dryer.
!Items such as foam rubber
(latex foam), shower caps,
waterproof textiles, rubber
backed articles and clothes or
pillows fitted with foam rubber
pads should not be dried in the
washer dryer.
!Fabric softeners, or similar
products, should be used as
specified by the fabric softener
instructions.
!Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such
as a washer dryer. The items
become warm, causing an
oxidation reaction in the oil,
Oxidation creates heat. If the
heat cannot escape, items can
become hot enough to catch
fire. Piling, stacking or storing
oil-effected items can prevent
heat from escaping and so
create a fire hazard.
!If it is unavoidable that fabrics
contain vegetable or cooking
oil or have been contaminated
WARNING:
never stop a washer dryer before
the end of the drying cycle
unless all items are quickly
removed and spread out so that
the heat is dissipated.

!
EN
5
by hair care products be
placed in a washer dryer they
should first be washed in hot
water with extra detergent -
this will reduce, but not
eliminate, the hazard.
!Remove all objects from
pockets such as lighters and
matches.
!To consult the product fiche
please refer to the manufacturer
website.
!Before cleaning or maintaining
the washing machine, unplug
the appliance and turn off the
water faucet.
!Make sure the electrical
system is grounded. Otherwise,
seek qualified professional
assistance.
!Please do not use converters,
multiple sockets or extension
cords.
!Make sure there is no water in
the drum before opening the
porthole.
!Do not pull on the power cord
or appliance to unplug the
machine.
!Do not expose the washing
machine to rain, direct sunlight
or other weather elements.
!When moving, do not lift the
washing machine by the knobs
or detergent drawer; during
transport, never rest the
porthole on the trolley. We
recommend two people lift the
washing machine.
!In the event of fault and/or
malfunction, turn off the
washing machine, close the
water faucet and do not tamper
with the appliance.
Immediately contact the
Customer Service Centre and
only use original spare parts.
Failure to observe these
instruction may jeopardise
appliance safety.
Appliance complies with
European Directives:
!2006/95/EC (LVD);
!2004/108/EC (EMC);
!2009/125/EC (ErP);
!2011/65/EU (RoHS)
and subsequent amendments.
Safety instructions
WARNING:
water may reach very high
temperatures during the
wash cycle.

!
6
2. INSTALLATION
!Cut the tube straps, being
careful not to damage the tube
and power cord.
!Unscrew the 2or 4screws (A)
on the back and remove the 2
or 4shims (B) as illustrated in
figure 1.
!Close the 2or 4holes using
the plugs included in the
instruction envelope.
!If the washing machine is built-in,
after cutting the hose straps,
unscrew the 3or 4screws (A) and
remove the 3or 4shims (B).
!In some models, 1or more
shims will fall inside the machine:
tilt the washing machine forward
to remove them. Close the holes
using the plugs found in the
envelope.
!Place the polionda sheet on
the bottom as shown in figure
2(according to the model,
consider version A, Bor C).
A
A
A
A
B
B
B
B
1
3
2
1
3
1
2
A
C
B
2
WARNING:
keep packaging materials
away from children.

!
EN
7
!Connect the water tube to the faucet, only
using the drain tube supplied with the
washing machine (fig. 3).
DO NOT OPEN THE FAUCET.
!Some models may include one or more of
the following features:
!HOT&COLD (fig. 4):
water mains connection settings with hot
and cold water for higher energy savings.
Connect the grey tube to the cold water
faucet and the red one to the hot water
faucet. The machine can be connected to
the cold water faucet only: in this case,
some programs may start a few minutes
later.
!AQUASTOP (fig. 5):
a device located on the supply tube that
stops water flow if the tube deteriorates;
in this case, a red mark will appear in the
window “A” and the tube must be
replaced. To unscrew the nut, press the
one-way lock device "B".
!AQUAPROTECT – SUPPLY TUBE WITH
GUARD (fig. 6):
Should water leak from the primary
internal tube "A", the transparent
containment sheath "B" will contain water
to permit the washing cycle to complete.
At the end of the cycle, contact the
Customer Service Centre to replace the
supply tube.
!Near the washing machine to the wall,
being careful that the tube is not bent or
crushed, and place the drain tube in the
tub or, preferably, connect it to a wall
drain at least 50 cm high with diameter
greater than the washing machine tube
(fig. 7).
3
1
4
B
A
5
B
A
6
min 50 cm
max 85 cm
+2,6 mt
max
max 100 cm
min 4 cm
7
Hydraulic connections
Setting

!
8
!Level the appliance using the feet as
illustrated in figure 8:
a. turn the nut clockwise to release the
screw;
b. rotate the foot to raise or lower it until it
adheres to the floor;
c. lock the foot, screwing in the nut, until it
adheres to the bottom of the washing
machine.
!Plug in the appliance.
A
B
C
8
The detergent draw is split into 3
compartments as illustrated in figure 9:
!compartment "1": for prewash detergent;
!compartment “ ”: for special additives,
softeners, starch fragrances, etc.;
!compartment "2": for washing detergent.
A liquid detergent cup is also included in
some models (fig. 10). To use it, place it in
compartment "2". This way, liquid
detergent will only enter the drum at the
right time. The cup can also be used for
bleach when the “Rinse” program is
selected.
9
10
11
WARNING:
contact the Customer Service Centre
should the power cord need
replacement.
Detergent drawer
WARNING:
only use liquid products; the washing
machine is set to automatically dose
additives at each cycle during the last
rinse.
WARNING:
some detergents are hard to remove.
In this case we recommend using the
specific container to be placed in the
drum (example in figure 11).

!
EN
9
3. PRACTICAL TIPS
WARNING: when sorting laundry, make
sure:
- have eliminated metallic objects such as
barrettes, pins, coins, from laundry;
- to have buttoned pillow cases, closed
zips, tied loose belts and long robe
ribbons;
- to have removed rollers from curtains;
- to have carefully read clothing washing
labels;
- to have removed any persistent stains
using specific detergents.
!When washing rugs, bedcovers or other
heavy clothing, we recommend you avoid
centrifuging.
!To wash wool, make sure the item can be
machine washed and marked by the
“Pure virgin wool” symbol with the “Does
not mat” or “Machine washable” label.
A guide environmentally friendly and
economic use of your appliance.
Maximise The Load Size
!Achieve the best use of energy, water,
detergent and time by using the
recommended maximum load size.
Save up to 50% energy by washing a full
load instead of 2 half loads.
Do you need to pre-wash?
!For heavily soiled laundry only!
SAVE detergent, time, water and
between 5 to 15% energy consumption
by NOT selecting Prewash for slight to
normally soiled laundry.
Is a hot wash required?
!Pretreat stains with stain remover or soak
dried in stains in water before washing to
reduce the necessity of a hot wash
programme.
Save up to 50% energy by using a 60°C
wash programme.
Before using a drying programme…
!SAVE energy and time by selecting a
high spin speed to reduce the water
content in laundry before using a drying
programme.
Following is a quick guide with tips and
recommendations on detergent use at the
various temperatures. In any case, always
read the instructions on the detergent for
correct use and doses.
Load tips
Helpful suggestions for the user
When washing heavily soiled whites,
we recommend using cotton
programs of 60°C or above and a
normal washing powder (heavy duty)
that contains bleaching agents that at
medium/high temperatures provide
excellent results.
For washes between 40°C and 60°C
the type of detergent used needs to be
appropriate for the type of fabric and
level of soiling.
Normal powders are suitable for “white”
or colour fast fabrics with high soiling,
while liquid detergents or “colour
protecting” powders are suitable for
coloured fabrics with light levels of
soiling.
For washing at temperatures below
40°C we recommend the use of liquid
detergents or detergents specifically
labeled as suitable for low temperature
washing.
For washing wool or silk, only use
detergents specifically formulated for
these fabrics.

!
10
4. MAINTENANCE AND
CLEANING
To clean the washing machine exterior, use
a damp cloth, avoiding abrasives, alcohol
and/or solvents. The washing machine does
not require any special care for ordinary
cleaning: clean drawer compartments and
the filter; some tips on how to move the
machine or on long periods of disuse are
provided below.
!We recommend you clean the drawer to
avoid accumulating detergent and
additive residue.
!To do this, extract the drawer using slight
force, clean it with running water and
reinsert it in its housing.
!The washing machine comes with a
special filter able to trap large residue,
such as buttons or coins, which could
clog the drain.
!Only available on certain models: pull out
the corrugated hose, remove the stopper
and drain the water into a container.
!Before unscrewing the filter, we
recommend you place an absorbent cloth
under it to keep the floor dry.
!Turn the filter counter-clockwise to the
limit stop in the vertical position.
!Remove and clean the filter; when
finished, replace it turning it clockwise.
!Repeat the previous steps in reverse
order to reassemble all parts.
!Should the washing machine be stored in
an unheated room for a long period of
time, drain all water from tubes.
!Unplug the washing machine.
!Detach the tube from the strap and lower
it, fully draining water into a bowl.
!Secure the drain tube with the strap when
finished.
Drawer cleaning
Filter cleaning
Suggestions for moves or
prolonged disuse

!
EN
11
5. QUICK USER GUIDE
This washing machine automatically adapts
the level of the water to the type and
quantity of washing. This system gives a
decrease in energy consumption and a
sensible reduction in washing times.
!Turn on the washing machine and select
the required program.
!Adjust the washing temperature if
necessary and press the required "option"
buttons.
!Press the START/PAUSE button to start
washing.
!The message "end" will appear on the
display or the corresponding led will turn
on at the end of the program.
!Turn off the washing machine.
For any type of wash, see the program
table and follow the operating sequence
as indicated.
Water pressure: min 0,05 Mpa / max 0,8 Mpa
Spin r.p.m.: See rating plate.
Power input / Power current fuse amp /
Supply voltage: See rating plate.
6. CONTROLS AND
PROGRAMS
A
B
DCEFGH
L
I
MN O P
A
Programme selector with OFF
position
B
START/PAUSE button
C
DELAY START button
D
PREWASH button
E
DRYING SELECTION button
F
SPIN SPEED button
G
TEMPERATURE SELECTION
button
H
RAPID LENGTH button
I
Digital display
L
BUTTONS indicator lights
M
DOOR LOCKED indicator light
N
SPIN SPEED indicator lights
O
TEMPERATURE SELECTION
indicator lights
P
RAPID LENGTH indicator lights
Program selection
DRYING
If you would like the drying cycle to
begin automatically after washing,
select the programme required using
the DRYING SELECTION button.
Or you can finish the wash and then
select the drying programme and
load size.
Wait until the porthole locked light
turns off: about 2 minutes after the
program ends.
Technical data

!
12
!Press the START/PAUSE button to start
the selected cycle.
!Once a programme is selected the
programme selector remains stationary on
the selected programme till cycle ends.
!Switch off the washing machine by
turning the selector to OFF.
!Press to start the selected cycle.
ADD OR REMOVE ITEMS AFTER THE
PROGRAMMES HAS STARTED (PAUSE)
!Press and hold the START/PAUSE
button for about 2 seconds (some
indicator light and the time remaining
indicator will flash, showing that the
machine has been paused).
!Wait 2 minutes until the safety device
unlocks the door.
!After you have added or removed items,
close the door and press the
START/PAUSE button (the programme
will start from where it left off).
CANCELLING THE PROGRAMME
!To cancel the programme, set the
selector to the OFF position.
!This button allows you to pre-programme
the wash cycle to delay the start of the
cycle for up to 24 hours.
!To delay the start use the following
procedure:
- Set the required programme.
- Press the button once to activate it (h00
appears on the display) and then press
it again to set a 1 hour delay (h01
appears on the display). The pre-set
delay increases by 1 hour each time the
button is pressed, until h24 appears on
the display, at which point pressing the
button again will reset the delay start to
zero.
- Confirm by pressing the START/PAUSE
button (the light on the display starts to
flash). The countdown will begin and
when it has finished the programme will
start automatically.
Opening the door
A special safety device prevents the
door from being opened immediately
after the end of the cycle.
Wait for 2 minutes after the wash
cycle has finished and the "Door
Security" light has gone out before
opening the door.
PROGRAMME selector with OFF
position
When the programme selector is turned
the display lights up to show the settings
for the programme selected.
For energy saving, at the end of the
cycle or with an inactivity period, the
display level contrast will decrease.
N.B.: To switch the machine off, turn
the programme selector to the OFF
position.
The programme selector must be
returned to the OFF position at the end
of each cycle or when starting a
subsequent wash cycle prior to the next
programme being selected and started.
START/PAUSE button
Close the door BEFORE selecting the
button START/PAUSE.
When the START/PAUSE button has
been pressed, the appliance can take
few seconds before it starts working.
DELAY START button

!
EN
13
!It is possible to cancel the delay start by
turning the programme selector to OFF.
If there is any break in the power supply
while the machine is operating, a special
memory stores the selected programme
and, when the power is restored, it
continues where it left OFF.
It allows you to do a preliminary wash at the
beginning of the cycle. The temperature does
not exceed 40°C and in any case it does not
exceed the maximum temperatures of the
selected washing program (ex. the temperature
of HAND program will be 30°C.
!Ensure that the programme selector is
not in the OFF position then press the
button to select the required drying
programme: an indicator will light to
display the drying result selected each
time you press the button.
!To cancel the selection before the start of
a drying programme, press the button
repeatedly until the indicators go out or
return the programme selector to the OFF
position.
!To cancel the cycle during the drying
phase, hold the button down for about
3 seconds until the cooling indicator
lights up.
!Given the high temperature inside the
drum, we recommend that you allow the
dryer to complete the cool down period
before returning the programme selector
to the OFF position and removing the
laundry.
!By pressing this button, it is possible to
reduce the maximum speed, and if you
wish, the spin cycle can be cancelled.
!To reactivate the spin cycle press the button
until you reach the spin speed you would
like to set.
!It is possible to modify the spin speed
without pausing the machine.
When you select a program, the light
illuminates the recommended temperature.
It is also possible to change the
temperature but not over the maximum in
order to save the fabrics.
The button becomes active when you select
the RAPID program on the knob; it allows you
to select one of three durations indicated.
The option buttons should be selected
before pressing the START/PAUSE
button.
If an option is selected that is
not compatible with the selected
programme then the option indicator
first flashes and then goes off.
PREWASH button
DRYING SELECTION button
SPIN SPEED button
To prevent damage to the fabrics, it is
not possible to increase the speed
over that which is automatically
suitable during the selection of the
program.
The machine is fitted with a special
electronic device, which prevents the
spin cycle should the load be
unbalanced.
This reduces the noise and vibration in
the machine and so prolongs the life of
your machine.
TEMPERATURE SELECTION
button
RAPID LENGTH button

!
14
The display’s indicator system allows you to
be constantly informed about the status of
the machine.
2
3
541 7 6
33
1) DOOR LOCKED INDICATOR LIGHT
!The indicator light is illuminated when the
door is fully closed.
!When START/PAUSE is pressed on
the machine with the door closed, the
indicator will flash momentarily and then
illuminate.
!A special safety device prevents the door
from being opened immediately after the
end of the cycle. Wait for 2 minutes after
the wash cycle has finished and the
DOOR LOCKED light has gone out before
opening the door. At the end of the cycle
turn the programme selector to OFF.
2) CYCLE DURATION
!When a programme is selected the
display automatically shows the cycle
duration, which can vary, depending on
the options selected.
!Once the programme has started you will
be kept informed constantly of the time
remaining to the end of the wash.
!The appliance calculates the time to the
end of the selected programme based
upon a standard loading, during the cycle,
the appliance corrects the time to that
applicable to the size and composition of
the load.
!If automatic washing/drying is selected, at
the end of the wash phase, the drying time
remaining to the end will be shown on the
display.
3) BUTTONS INDICATOR LIGHTS
!These light up when the relevant buttons
are pressed.
!If an option is selected that is not
compatible with the selected programme
then the light on the button first flashes
and then goes off.
4) SPIN SPEED indicator lights
The indicator lights show the spin speed of
the selected programme that can be
changed or omitted by the relevant button.
5) TEMPERATURE SELECTION indicator
lights
The indicator lights show the washing
temperature of the selected programme
that can be changed (where allowed) by the
relevant button.
6) RAPID LENGTH indicator lights
The indicator lights show the rapid
programmes that can be selected by the
relevant button.
Digital Display
Close the door BEFORE selecting the
START/PAUSE button.
If the door is not properly closed,
the light will continue to flash for
about 7 seconds, after which the
start command will be automatically
delete. In this case, close the door
in the proper way and press the
START/PAUSE button.

!
EN
15
7) DRYING PROGRAMME INDICATORS
The indicators display the type of the drying
programme.
Automatic drying programmes
Extra dry programme (suitable for
towels, bathrobes and bulky loads).
Iron dry programme (that leaves the
laundry ready for ironing).
Cupboard dry programme (for
items that will be put away without
ironing).
!By selecting one of these automatic
programmes, the washer dryer will
calculate the time needed for drying and
the level of moisture remaining in the
laundry, according to the load and drying
type selected.
!After pressing the START/PAUSE button,
the display will show the drying time
remaining.
Cool down phase
Activated during the final cool down
period, in the last 10/20 minutes of
each drying phase.
Useful tips
!Your washer dryer automatically ends the
cycle when it reaches the selected drying
level.
!In order to ensure the correct operation of
the appliance, it is advisable not to
interrupt the drying phase unless it is
absolutely necessary.
The appliance calculates the time to
the end of the selected programme
based upon a standard loading.
During the cycle, the appliance
corrects the time according to the size
and composition of the load.

!
16
2
1
PROGRAM
kg *
(MAX.)
TEMP.°C
DETERGENT
Recommended
Max.
2
1
ActivEco 20°C
2)
6
7
8
9
10
20°
20°
Baby 60°C
2)
4
4,5
5,5
6
6,5
60°
60°
Daily 59 Min.
2)
2
2,5
3
3
3,5
40°
60°
Rapid (14/30/44 Min.)
1)
2)
1
1
1,5
1,5
1,5
30°
30°
2
2,5
2,5
2,5
2,5
30°
30°
3
3,5
3,5
3,5
3,5
30°
40°
Cottons**
2)
6
7
8
9
10
40°
90°
( )
Delicates
2
2,5
2,5
2,5
2,5
40°
40°
Auto Clean
Rinse 2)
-
-
-
-
-
-
-
Drain & Spin
2)
-
-
-
-
-
-
-
Mixed
2)
3
3,5
4
4,5
5
40°
60°
( )
Hand & Silk
1
1
2
2
2
30°
30°
Wool
1
1
2
2
2
40°
40°
Low Heat
(drying)
3
3,5
4
4,5
5
-
-
High Heat
(drying)
5
5
5
6
6
-
-
Rapid W&D 59 Min.
1,5
1,5
1,5
1,5
1,5
30°
30°
Table of programmes

!
EN
17
Please read these notes:
* Maximum load capacity of dry clothes,
according to the model used (see control
panel).
The spin speed may also be reduced, to
match any guidelines suggested on the
fabric label, or for very delicate fabrics
cancel the spin completely this option is
available with a spin speed button. This
function can be activated with the button
SPIN SPEED.
If the label does not indicate specific
information, it is possible to use the
maximum spin expected in the program.
An over dosing of detergent can cause
excessive foaming.
If the appliance detects the presence of
excessive foam, it may exclude the spinning
phase or extend the duration of the program
and increase water consumption.
( )
Only with PREWASH option
selected (programmes with
PREWASH option available).
(Only for models with liquid
detergent compartment)
When only a limited number of
articles have stains which require
treatment with liquid bleaching
agents, preliminary removal of
stain can be carried out in the
washing machine.
Pour the bleach into the liquid
bleach container, inserted into the
compartment marked "2" in the
detergent drawer, and set the
special programme RINSE.
When this phase has terminated,
turn the programme selector on
the OFF position, add the rest of
the fabrics and proceed with a
normal wash on the most suitable
programme.
1)
Selecting the RAPID program on
the knob, it will be possible to
select with the RAPID LENGTH
button, one of the three rapid
programs available among 14 Min.,
30 Min. and 44 Min..
2)
Programmes for automatic drying.
INFORMATION FOR THE TEST
LABORATORIES (Ref. EN 50229
Standards)
Washing
Use the programme ** with the maximum
degree of soiling selected, maximum spin
speed and a temperature of 60°C.
Programme recommended also for test
with a lower temperature.
Drying
First drying with Akg (a load consist:
pillowcases and hand-towels) selecting
the cotton drying programme
( ) cupboard dry ( ).
Second drying with Bkg (a load consist:
sheets and hand towels) selecting the
cotton drying programme ( )
cupboard dry ( ).
Capacity
(washing)
(kg)
A(kg)
B(kg)
First
drying
Second
drying
6
5
1
7
5
2
8
5
3
9
6
3
10
6
4

!
18
To clean different types of fabrics and
various levels of dirt, the washing machine
has specific programs to meet every need
of washing (see table of programmes).
ActivEco 20°C
This innovative programme, allows you to wash
different fabrics and colours together, such as
cottons, synthetics and mixed fabrics at only
20°C and provides an excellent cleaning
performance. Consumption on this program is
about 40% of a conventional 40°C. cottons wash.
Baby 60°C
This program allows you to wash all baby
clothes getting a perfect clean and
sanitizing effect, setting the temperature at
60°C minimum. To optimize the result of the
sanitizing effect we recommend the use of
powder detergent.
Daily 59 Min.
This specially designed programme
maintains the high quality wash
performance whilst greatly reducing the
wash time. The programme is designed for
a reduced load (see table of programmes).
Rapid (14/30/44 Min.)
Washing cycle suggested for low loads and
slightly dirty. With this program it is
recommended to reduce the quantity of
detergent normally used, in order to avoid
unnecessary waste. Selecting the RAPID
program and acting on the button you can
choose one of three programs available.
Cottons
This program is suitable to clean normally
soiled cotton laundry and it is the most efficient
program in terms of combined energy and
water consumptions for washing cotton laundry.
Delicates
This program alternates among moments of
work during breaks and is particularly suitable
for washing delicate fabrics. The wash cycle
and rinses are carried out with a high level of
water to ensure the best performance.
Auto Clean
This program is suited to clean the drum of your
appliance. It is recommended to use this
program every 50 washing cycles, to ensure a
long service life and avoid bad odors. Make sure
to start the program exclusively without laundry in
the machine, using only powder detergent for
washing machine. When the washing cycle
finishes, open the door of the washing machine
to dry the drum.
Rinse
This program performs 3 rinses with an
intermediate spin (which can be reduced or
excluded by using the appropriate button) . It
is used for rinsing any type of fabric, for
example after a wash carried out by hand.
Drain & Spin
The program completes the drain and a
maximum spin. It is possible to delete or reduce
the spin with the SPIN SPEED button.
Mixed
The washing and rinsing are optimized in
the rhythms of rotation of the drum and to
the water levels. The gentle spin, ensures a
reduced formation of creases in the fabric.
Hand & Silk
This programme allows a delicate washing
cycle for garments specified as "Hand Wash
only" and laundry items made from Silk or
specified as "Wash as Silk" on the fabric label.
Wool
This program performs a wash cycle
dedicated to the wool fabrics that can be
washed in a washing machine, or the
articles to be washed by hand.
DRYING
The drum changes direction during the
drying cycle to prevent the laundry from
tangling and producing even more drying.
Cool air is used during the last 10/20
minutes of the drying cycle to minimize
creasing.
Programmes selection
WARNING:
Dispensers used for concentrated
powders and liquid detergents must be
removed from the drum before
commencing the tumble drying
programmes.

!
EN
19
Low Heat
Low temperature drying programme
recommended for synthetics and mixed
fibres (always refer to the laundry care label).
High Heat
High temperature drying programme
recommended for cottons and linen items
(always refer to the laundry care label).
Rapid W&D 59 Min.
When you only have a few items to wash
and dry in a hurry, this 59 minute cycle
is the ideal time saver! Suitable for a light
1,5 kg load size (e.g. 4 shirts) or slightly
dirty fabrics, this cycle will wash, rinse, spin
and dry your garments in under an hour.
We recommend that you reduce the
detergent dosage when using this
programme to avoid wastage.

!
20
7. DRYING CYCLE
!Drying guidance advice is general, but
practical experience of using the product
will help you to achieve the best drying
results.
!We recommend setting a lower drying
time than indicated, when first using the
appliance in order to establish the degree
of dryness required.
!We recommend not drying fabrics that
fray easily, such as rugs or garments with
a deep pile, in order to avoid air duct
clogging.
!We recommend that you sort the laundry
by the following methods:
- By drying care symbols, which are
displayed on the clothing labels
Suitable for tumble drying.
Tumble dry at high temperature.
Tumble dry at low temperature only.
DO NOT tumble dry.
- By size and thickness
Whenever the wash load is bigger than
the drying capacity, separate the clothes
according to thickness (e.g. towels from
thin underwear).
- By fabric type
Cottons/linen: towels, cotton jersey, bed
and table linen.
Synthetics: blouses, shirts, overalls, etc.
made of polyester or polyamide, as well
as for cotton/synthetic mixes.
!Only dry pre-spun laundry.
!The washer dryer can perform the
following types of drying:
-Low temperature drying programme
recommended for mixed fabrics
(synthetics/cotton) synthetic fabrics.
-High temperature drying programme
recommended for cotton, terry toweling,
linen, hemp fabrics, etc....
!Open the door.
!Fill with the laundry, not exceeding the
maximum drying load indicated in the
programme table. For large items (e.g.
sheets) or very absorbent items (e.g.
towels or jeans), it is a good idea to
reduce the load.
!Close the door.
If the fabric does not have a care label,
you should assume that it is not
suitable for drying.
During the drying phase the drum will
accelerate to a higher speed to
distribute the load and to optimize the
drying performance.
The correct way to dry
The appliance door is fitted with a
protective shield to prevent contact
with the glass door which can reach
high temperatures, during the drying
cycle.
It should not be necessary to remove
the shield from the machine during
the normal course of use.
