Hoshizaki DCM-700BAE User manual

MATERIAL ABBREVIATIONS
PLASTIC
ABS =Acrylonitrile-butadien-styrene
AC =Polyacetal
EVA =Ethylene vinyl acetate
PA =Polyamide = Nylon
PC =Polycarbonate
PE =Polyethylene
PES =Polyester
PETP =Polyethyleneterephthalate = Tetlon
PF =Phenol-formaldehyde
PP =Polypropyleneoride
PS =Polystyrene
PTFE =Polytetrafluoroethylene = Teflon
PUR =Polyurethane
PVC =Polyvinyl chloride
RUBBER
EPDM =EP rubber
NBR =Nitrile butadiene rubber
NR =Natural rubber
SI.R =Silicone rubber
SY.R =Synthetic rubber
STEEL
G.S =Galvanized steel
S.S =Stainless steel
AUXILIARY CODE
Ex.1 K-0 Parts are the same as in the preceding year.
"K" is the tenth in alphabetical order with "I" skipped.
So, "K" indicates "2000".
Ex.2 A-1 "A" is the first in alphabetical order.
So, "A" indicates "2001".
Ex.3 A-2 Each time a part is changed in a year, this number advances.
(Note) = Part deleted.
X = Part deleted and replaced by "O" part.
O = New part for "X" in the sameauxiliary code.
i

FASTENER ABBREVIATION LIST
ST Phillips Truss Head Machine Screw
SP Phillips Pan Head Machine Screw
SF Phillips Flat Head Machine Screw
SS Phillips Pan Head Machine Screw with Split Lock Washer
SW Phillips Pan Head Machine Screw with Split Lock Washer
and Flat Washer
T1 Phillips Truss Head Tapping Screw (Correspond to Type A)
T2 Phillips Truss Head Tapping Screw (Correspond to Type B)
T3 Phillips Truss Head Tapping Screw (Correspond to Type C)
FT Phillips Truss Head Tapping Screw (Special)
BH Hexagon Head Bolt
BC Socket Head Cap Screw
BS Hexagon Bolt with Split Washer
BW Hexagon Bolt with Split Washer and Flat Washer
BF Hexagon Flange Bolt
BR Cross-Recessed Hexagon Head Bolt
BRW Cross-Recessed Hexagon Head Bolt with Split Lock Washer
and Flat Washer
WL Split Lock Washer
WT External Tooth Washer
WF Flat Washer
WS Spring Washer
NH Hexagon Nut
NF Hexagon Flange Nut
NC Hexagon Cap Nut
NS Square Nut
NW Wing Nut
Ex. ST0308S (Phillips Truss Head Machine Screw,
3x8, made of stainless steel)
Material None: Plated Steel
Length (mm) S: Stainless Steel
Nominal Diameter (mm) B: Brass
Form of Head P: Plastic
Description
(Note) Second character is numerical except the list.
Ex. S1, S2, B3 etc.
And abbreviations and names are shown under the illustration.
ii

1

2

3

HA
MODEL : DCM-700BAE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
C-1D-1E-0F-0
BEVAPORATOR ASSY -324704A03 1111
CREFRIGERATION CIRCUIT -106805A01 1-
-106805A02 111
DWATER CIRCUIT -105365A02 1111
EMIDDLE FRONT PANEL ASSY -219681A03 1111
FBIN ASSY -104002A02 1111
GGEAR MOTOR ASSY -432467A01 1111
HGEAR MOTOR ASSY (L) -432468A01 1111
JGEAR MOTOR ASSY (R) -432469A01 1111
KSHUTTER ASSY -211245A02 1111
LCONTROL BOX ASSY -216191A02 1111
MLABEL LOCATION -220513A01 1111
1FRAME G.S 105309G02 1111
2CENTER FRAME G.S 429833G01 1111
3WASHER PVC 422916-01 3333
4DRAIN PAN S.S 319054G01 1111
5BRACKET -EVAPORATOR S.S 431738-01 1111
6EDGING CE-024 7991EC120 1111
7FRAME (UPPER) G.S 319008G03 1111
8SPOUT PC 103932G01 1111
9PACKING (A) -SPOUT EPDM 427195-01 1111
10 THUMBSCREW S.S, ABS 415949G03 18 18 18 18
11 SPOUT ABS 208807-01 1111
12 PACKING (B) -SPOUT EPDM 427196-01 1111
13 BARRIER -DRIP S.S 429825-01 1111
14 GASKET EPDM 429758-01 3333
15 COVER -BIN ABS 210023G01 1111
16 COLLAR S.S 4H0171-01 2222
17 AUGER -DISPENSING S.S 320679G01 1111
18 AGITATOR (RIGHT) S.S 321013G01 1111
19 AGITATOR (LEFT) S.S 319017G02 1111
4

HA
MODEL : DCM-700BAE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
F-1G-0G-1H-0
-324704A03 -BEVAPORATOR ASSY
-324704A02 1111
CREFRIGERATION CIRCUIT -106805A02 1111
DWATER CIRCUIT -105365A02 1111
EMIDDLE FRONT PANEL ASSY -219681A03 1111
FBIN ASSY -104002A02 1111
GGEAR MOTOR ASSY -432467A01 1111
HGEAR MOTOR ASSY (L) -432468A01 1111
JGEAR MOTOR ASSY (R) -432469A01 1111
KSHUTTER ASSY -211245A02 1111
LCONTROL BOX ASSY -216191A02 1111
MLABEL LOCATION -220513A01 1111
1FRAME G.S 105309G02 1111
2CENTER FRAME G.S 429833G01 1111
3WASHER PVC 422916-01 3333
4DRAIN PAN S.S 319054G01 1111
5BRACKET -EVAPORATOR S.S 431738-01 1111
6EDGING CE-024 7991EC120 1111
7FRAME (UPPER) G.S 319008G03 1111
8SPOUT PC 103932G01 1111
9PACKING (A) -SPOUT EPDM 427195-01 1111
10 THUMBSCREW S.S, ABS 415949G03 18 18 18 18
11 SPOUT ABS 208807-01 1111
12 PACKING (B) -SPOUT EPDM 427196-01 1111
13 BARRIER -DRIP S.S 429825-01 1111
14 GASKET EPDM 429758-01 3333
15 COVER -BIN ABS 210023G01 1111
16 COLLAR S.S 4H0171-01 2222
S.S 320679G01 11-17 AUGER -DISPENSING
S.S 339194G01 11
18 AGITATOR (RIGHT) S.S 321013G01 1111
19 AGITATOR (LEFT) S.S 319017G02 1111
5

HA
MODEL : DCM-700BAE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
C-1D-1E-0F-0
20 SEPARATOR G.S 326873-01 1111
21 BRACKET -FLOAT SWITCH LEADS G.S 427165-01 1111
22 BUSHING SR-5KN-4420472-06 1111
23 BUSHING SR-30-1420472-03 2222
24 BARRIER -LEADS G.S 446469-01 1111
25 TIE CV-150 7920-0003 3333
26 COVER -JUNCTION BOX G.S 420594-01 1111
27 GUIDE -CUP ABS 326702-01 2222
28 PANEL (LOWER) S.S 216097G01 1111
29 TRAY -DRIP ABS 105311G01 1111
30 REAR PANEL G.S 220426-01 1111
31 SIDE PANEL (LEFT) S.S 216095-03 1111
32 SIDE PANEL (RIGHT) S.S 216096-03 1111
33 STRIKE 83 435995-01 2222
34 CATCH 82 435994-01 2222
35 TOP PANEL S.S 440457G06 1---
S.S 333962G02 111
36 FRONT PANEL S.S 326874G03 1111
37 GRILLE PVC COATED
STEEL
216100G01 1111
38 "O"RING G95 7616-G095 1111
39 RING PA 431736-01 1111
40 STRAP G.S 431737-01 1111
41 GUIDE ABS 211171-01 1111
42 PACKING EPDM 320668-01 1111
43 SQUARE WASHER BRASS 433537-02 1111
44 SCREW -GROUNDING BRASS 433304-02 1111
ABS 103122-01 88-45 LOUVER (C)
ABS 103122-03 88
46 TAPPING SCREW -BLACK STEEL, 4x8 433954-01 8888
47 THUMBSCREW ABS,S.S 415949G05 5555
48 ICE CHUTE S.S 439788G02 1111
6

HA
MODEL : DCM-700BAE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
F-1G-0G-1H-0
20 SEPARATOR G.S 326873-01 1111
21 BRACKET -FLOAT SWITCH LEADS G.S 427165-01 1111
22 BUSHING SR-5KN-4420472-06 1111
23 BUSHING SR-30-1420472-03 2222
24 BARRIER -LEADS G.S 446469-01 1111
25 TIE CV-150 7920-0003 3333
26 COVER -JUNCTION BOX G.S 420594-01 1111
27 GUIDE -CUP ABS 326702-01 2222
28 PANEL (LOWER) S.S 216097G01 1111
29 TRAY -DRIP ABS 105311G01 1111
30 REAR PANEL G.S 220426-01 1111
31 SIDE PANEL (LEFT) S.S 216095-03 1111
32 SIDE PANEL (RIGHT) S.S 216096-03 1111
33 STRIKE 83 435995-01 2222
34 CATCH 82 435994-01 2222
35 TOP PANEL S.S 440457G06 ----
S.S 333962G02 1111
36 FRONT PANEL S.S 326874G03 1111
37 GRILLE PVC COATED
STEEL
216100G01 1111
38 "O"RING G95 7616-G095 1111
39 RING PA 431736-01 1111
40 STRAP G.S 431737-01 1111
41 GUIDE ABS 211171-01 1111
42 PACKING EPDM 320668-01 1111
43 SQUARE WASHER BRASS 433537-02 1111
44 SCREW -GROUNDING BRASS 433304-02 1111
45 LOUVER (C) ABS 103122-03 8888
46 TAPPING SCREW -BLACK STEEL, 4x8 433954-01 8888
47 THUMBSCREW ABS,S.S 415949G05 5555
48 ICE CHUTE S.S 439788G02 1111
7

HA
MODEL : DCM-700BAE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
C-1D-1E-0F-0
49 THUMBSCREW ABS, S.S 415949G08 4444
50 SPOUT COVER ABS 215773-01 1111
51 APRON PANEL S.S 220386-01 1111
PP 208284G01 44
-
52 AIR FILTER (C)
PP 208284G03 44
8

HA
MODEL : DCM-700BAE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
F-1G-0G-1H-0
49 THUMBSCREW ABS, S.S 415949G08 4444
50 SPOUT COVER ABS 215773-01 1111
51 APRON PANEL S.S 220386-01 1111
52 AIR FILTER (C) PP 208284G03 4444
9

HA
MODEL : DCM-700BWE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
C-1D-0E-0F-1
-324704A03 111-BEVAPORATOR ASSY
-324704A02 1
CREFRIGERATION CIRCUIT -106806A01 1111
DWATER CIRCUIT -105365A02 1111
EMIDDLE FRONT PANEL ASSY -219681A03 1111
FBIN ASSY -104002A02 1111
GGEAR MOTOR ASSY -432467A01 1111
HGEAR MOTOR ASSY (L) -432468A01 1111
JGEAR MOTOR ASSY (R) -432469A01 1111
KSHUTTER ASSY -211245A02 1111
LCONTROL BOX ASSY -216191A02 1111
MLABEL LOCATION -220513A02 1111
1FRAME G.S 105310G02 1111
2CENTER FRAME G.S 429833G01 1111
3WASHER PVC 422916-01 3333
4DRAIN PAN S.S 319054G01 1111
5BRACKET -EVAPORATOR S.S 431738-01 1111
6EDGING CE-024 7991EC120 1111
7FRAME (UPPER) G.S 319008G03 1111
8SPOUT PC 103932G01 1111
9PACKING (A) -SPOUT EPDM 427195-01 1111
10 THUMBSCREW S.S, ABS 415949G03 18 18 18 18
11 SPOUT ABS 208807-01 1111
12 PACKING (B) -SPOUT EPDM 427196-01 1111
13 BARRIER -DRIP S.S 429825-01 1111
14 GASKET EPDM 429758-01 3333
15 COVER -BIN ABS 210023G01 1111
16 COLLAR S.S 4H0171-01 2222
17 AUGER -DISPENSING S.S 320679G01 1111
18 AGITATOR (RIGHT) S.S 321013G01 1111
19 AGITATOR (LEFT) S.S 319017G02 1111
20 SEPARATOR G.S 326873-01 1111
10

HA
MODEL : DCM-700BWE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
G-0H-0
BEVAPORATOR ASSY -324704A02 11
CREFRIGERATION CIRCUIT -106806A01 11
DWATER CIRCUIT -105365A02 11
EMIDDLE FRONT PANEL ASSY -219681A03 11
FBIN ASSY -104002A02 11
GGEAR MOTOR ASSY -432467A01 11
HGEAR MOTOR ASSY (L) -432468A01 11
JGEAR MOTOR ASSY (R) -432469A01 11
KSHUTTER ASSY -211245A02 11
LCONTROL BOX ASSY -216191A02 11
MLABEL LOCATION -220513A02 11
1FRAME G.S 105310G02 11
2CENTER FRAME G.S 429833G01 11
3WASHER PVC 422916-01 33
4DRAIN PAN S.S 319054G01 11
5BRACKET -EVAPORATOR S.S 431738-01 11
6EDGING CE-024 7991EC120 11
7FRAME (UPPER) G.S 319008G03 11
8SPOUT PC 103932G01 11
9PACKING (A) -SPOUT EPDM 427195-01 11
10 THUMBSCREW S.S, ABS 415949G03 18 18
11 SPOUT ABS 208807-01 11
12 PACKING (B) -SPOUT EPDM 427196-01 11
13 BARRIER -DRIP S.S 429825-01 11
14 GASKET EPDM 429758-01 33
15 COVER -BIN ABS 210023G01 11
16 COLLAR S.S 4H0171-01 22
S.S 320679G01 - 17 AUGER -DISPENSING
S.S 339194G01 11
18 AGITATOR (RIGHT) S.S 321013G01 11
19 AGITATOR (LEFT) S.S 319017G02 11
20 SEPARATOR G.S 326873-01 11
11

HA
MODEL : DCM-700BWE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
C-1D-0E-0F-1
21 BRACKET -FLOAT SWITCH LEADS G.S 427165-01 1111
22 BUSHING SR-5KN-4420472-06 1111
23 BUSHING SR-30-1420472-03 2222
24 BARRIER -LEADS G.S 446469-01 1111
25 TIE CV-150 7920-0003 3333
26 COVER -JUNCTION BOX G.S 420594-01 1111
27 GUIDE -CUP ABS 326702-01 2222
28 PANEL (LOWER) S.S 216097G01 1111
29 TRAY -DRIP ABS 105311G01 1111
30 REAR PANEL G.S 220427-01 1111
31 SIDE PANEL (LEFT) S.S 220498-01 1111
32 SIDE PANEL (RIGHT) S.S 220499-01 1111
33 STRIKE 83 435995-01 2222
34 CATCH 82 435994-01 2222
35 TOP PANEL S.S 440457G06 1---
S.S 333962G02 111
36 FRONT PANEL S.S 326874G03 1111
37 GRILLE PVC COATED
STEEL
216100G01 1111
38 "O"RING G95 7616-G095 1111
39 RING PA 431736-01 1111
40 STRAP G.S 431737-01 1111
41 GUIDE ABS 211171-01 1111
42 PACKING EPDM 320668-01 1111
43 SQUARE WASHER BRASS 433537-02 1111
44 SCREW -GROUNDING BRASS 433304-02 1111
ABS 103122-01 44-45 LOUVER (C)
ABS 103122-03 44
46 TAPPING SCREW ( BLACK) STEEL,4x8 433954-01 4444
47 THUMBSCREW ABS,S.S 415949G05 5555
48 ICE CHUTE S.S 439788G02 1111
49 THUMBSCREW ABS, S.S 415949G08 4444
12

HA
MODEL : DCM-700BWE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
C-1D-0E-0F-1
-324704A03 111-BEVAPORATOR ASSY
-324704A02 1
CREFRIGERATION CIRCUIT -106806A01 1111
DWATER CIRCUIT -105365A02 1111
EMIDDLE FRONT PANEL ASSY -219681A03 1111
FBIN ASSY -104002A02 1111
GGEAR MOTOR ASSY -432467A01 1111
HGEAR MOTOR ASSY (L) -432468A01 1111
JGEAR MOTOR ASSY (R) -432469A01 1111
KSHUTTER ASSY -211245A02 1111
LCONTROL BOX ASSY -216191A02 1111
MLABEL LOCATION -220513A02 1111
1FRAME G.S 105310G02 1111
2CENTER FRAME G.S 429833G01 1111
3WASHER PVC 422916-01 3333
4DRAIN PAN S.S 319054G01 1111
5BRACKET -EVAPORATOR S.S 431738-01 1111
6EDGING CE-024 7991EC120 1111
7FRAME (UPPER) G.S 319008G03 1111
8SPOUT PC 103932G01 1111
9PACKING (A) -SPOUT EPDM 427195-01 1111
10 THUMBSCREW S.S, ABS 415949G03 18 18 18 18
11 SPOUT ABS 208807-01 1111
12 PACKING (B) -SPOUT EPDM 427196-01 1111
13 BARRIER -DRIP S.S 429825-01 1111
14 GASKET EPDM 429758-01 3333
15 COVER -BIN ABS 210023G01 1111
16 COLLAR S.S 4H0171-01 2222
17 AUGER -DISPENSING S.S 320679G01 1111
18 AGITATOR (RIGHT) S.S 321013G01 1111
19 AGITATOR (LEFT) S.S 319017G02 1111
20 SEPARATOR G.S 326873-01 1111
13

HA
MODEL : DCM-700BWE TITLE : A. ICE DISPENSER ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
G-0H-0
BEVAPORATOR ASSY -324704A02 11
CREFRIGERATION CIRCUIT -106806A01 11
DWATER CIRCUIT -105365A02 11
EMIDDLE FRONT PANEL ASSY -219681A03 11
FBIN ASSY -104002A02 11
GGEAR MOTOR ASSY -432467A01 11
HGEAR MOTOR ASSY (L) -432468A01 11
JGEAR MOTOR ASSY (R) -432469A01 11
KSHUTTER ASSY -211245A02 11
LCONTROL BOX ASSY -216191A02 11
MLABEL LOCATION -220513A02 11
1FRAME G.S 105310G02 11
2CENTER FRAME G.S 429833G01 11
3WASHER PVC 422916-01 33
4DRAIN PAN S.S 319054G01 11
5BRACKET -EVAPORATOR S.S 431738-01 11
6EDGING CE-024 7991EC120 11
7FRAME (UPPER) G.S 319008G03 11
8SPOUT PC 103932G01 11
9PACKING (A) -SPOUT EPDM 427195-01 11
10 THUMBSCREW S.S, ABS 415949G03 18 18
11 SPOUT ABS 208807-01 11
12 PACKING (B) -SPOUT EPDM 427196-01 11
13 BARRIER -DRIP S.S 429825-01 11
14 GASKET EPDM 429758-01 33
15 COVER -BIN ABS 210023G01 11
16 COLLAR S.S 4H0171-01 22
S.S 320679G01 - 17 AUGER -DISPENSING
S.S 339194G01 11
18 AGITATOR (RIGHT) S.S 321013G01 11
19 AGITATOR (LEFT) S.S 319017G02 11
20 SEPARATOR G.S 326873-01 11
14

15

HA
MODEL : DCM-700BAE, BWE TITLE : B. EVAPORATOR ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER
C-1D-0D-1
E-0
F-0F-1
1GEAR MOTOR MGZ2200UL-
160E
2U0077-01 111
2HOUSING -315732G02 1111
3"O"RING G90 7616G090 1111
EXTRUDING HEAD S.S 208121G02 111
-
4
EXTRUDING HEAD-95 S.S 216409G01
1
5WASHER S.S 425277-01 3333
6CUTTER S.S 315736G01 1111
S.S 211063G01 111-7AUGER
S.S 235266G01 1
-319138G01 111-8EVAPORATOR
-228206G01 1
9CORD HEATER SP4523U 3U0097-01 1111
10 SOCKET HEAD CAP SCREW S.S, M10x15 429121-02 3333
11 MECHANICAL SEAL HK9A-MN 432493-01 1111
16

HA
MODEL : DCM-700BAE, BWE TITLE : B. EVAPORATOR ASSY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQ'D NUMBER
NUMBER F-1
G-0G-1 H-0
1GEAR MOTOR MGZ2200UL-
160E
2U0077-01 11
2HOUSING -315732G02 11
3"O"RING G90 7616G090 11
4EXTRUDING HEAD-95 S.S 216409G01 11
5WASHER S.S 425277-01 33
6CUTTER S.S 315736G01 11
7AUGER S.S 235266G01 11
8EVAPORATOR -228206G01 11
9CORD HEATER SP4523U 3U0097-01 11
10 SOCKET HEAD CAP SCREW S.S, M10x15 429121-02 33
11 MECHANICAL SEAL HK9A-MN 432493-01 11
17
