Hotronix MAXX User manual

OPERATOR’S MANUAL
THE MAXX® PRESS
DIGITAL CLAM
Available models: MAXX
®
Clam
11" x 15", 16" x 16", 16" x 20" (shown)

SERVICE HOTLINE: [phone]
HOTRONIX®
THE MAXX®PRESS Safety Instructions
When using your heat press, basic precautions should always be
followed, including the following:
1. Read all instructions.
2. Use heat press only for its intended use.
3. To reduce the risk of electric shock, do not immerse the heat press in water or other liquids.
4. Never pull cord to disconnect from outlet, instead grasp plug and pull to disconnect.
5. Do not allow cord to touch hot surfaces, allow heat press to cool completely before storing.
6. Do not operate heat press with a damaged cord or if the equipment has been dropped or damaged. To
reduce the risk of electric shock, do not disassemble or attempt to repair the heat press. Take it to a
qualified service person for examination and repair. Incorrect assembly or repair could increase the
risk of fire, electric shock, or injury to persons when the equipment is used. Power supply cord must be
disconnected before cleaning or servicing press.
7. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
8. Close supervision is necessary for any heat press being used by or near children. Do not leave equipment
unattended while connected.
9. To avoid burns, do not touch hot metal parts or the heated platen during use.
10. To reduce the likelihood of circuit overload, do not operate other high voltage equipment on the same circuit.
11. If an extension cord is necessary, then a 20-amperage rated cord should be used. Cords rated for less
amperage may overheat. Care should be taken to arrange the cord so that it cannot be pulled or tripped
over.
12. Keep hands clear of the upper heat press platen during lock down as the pressure may cause injury.
13. Heat press should be placed on a sturdy, suitable stand at least 36"L x 24"W x 29"H.
14. Work area must be kept clean, tidy and free of obstructions.
Product Warranty Registration
Log onto www.Hotronix.com/registration
You must provide the Hotronix®heat press serial number and model information.

3WWW.HOTRONIX.COM
Table Of Contents
Safety Instructions 2
Machine View 4
Control Panel Guide 5
Operating Instructions 6–8
Connecting the System 6
Start Up/Shut Down 6
Adjusting Temperature 7
Adjusting Time 7
Adjusting Pressure 8
Printing/Pressing 8
Electrical Schematic 9
Parts Location Guide 10
Replacement Parts List 11
Contact 12

SERVICE HOTLINE: [phone]
HOTRONIX®
THE MAXX®PRESS Machine View
LED Display
Lower Platen
ON/OFF Switch
Over-the-Center
Pressure
Adjustment Knob
Lift Handle
Upper Platen
Circuit
Breaker
Power
Supply
Located on the back of the press
Platen
Release
Located under the press

5WWW.HOTRONIX.COM
Digital Display
Temperature
Indicator
Set Indicator
Time Indicator
Mode Select
Decrease Increase
Control Panel Guide

SERVICE HOTLINE: [phone]
HOTRONIX®
THE MAXX®PRESS
Connecting the System
Connect the power cord into a properly grounded electrical
outlet with a sufficient amperage rating.
Voltage
120 volt requires a full 20-amp grounded circuit.
240 volt requires a full 10-amp grounded circuit.
Extension Cords should be as short as possible and not
less than 12 gauge. Heavy duty cords are recommended.
Circuits with less than 15 amps or that have other high
demand equipment or heat presses plugged in should not
be used.
Note: If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or a similarly qualified person in
order to avoid hazard. Use SJT type rated 300 V cord for replacement.
CAUTION
Failure to follow these instructions will cause:
1. Erratic controller functions.
2. Inaccurate displays and slow heat up.
3. The circuit breaker to disengage.
Operating Instructions
Start Up/Shut Down
Locate the lift handle and position the heat platen in the
UP position.
Locate the Power ON/OFF Switch on the side of the press,
then turn the Power Switch ON.

7WWW.HOTRONIX.COM
Adjusting Temperature
Press the Mode Select button in the center of the Control Panel.
The (SET) and (TEMP) lights located next to the display
will illuminate.
Press the (+) or (-) button to raise or lower the
temperature setting.
The temperature can be set from 205°F (96°C) to 430°F (220°C).
The LED Display will show changes as you make them.
Note: The temperature indicator will only display temperatures
200°F (93°C) and up.
Adjusting Time
Once you have adjusted the temperature, press the Mode
Select button again to advance to Time Mode.
The (SET) and (TIME) lights will illuminate.
Adjust the time in the same manner you adjusted
the temperature.
Select the desired time and push the Mode Select button
again to exit.
All lights will be off and the press will return to PRINT mode.

SERVICE HOTLINE: [phone]
HOTRONIX®
THE MAXX®PRESS
Adjusting Pressure
Over-the-Center
Pressure
Adjustment
Knob
The MAXX®Clam Press features a patented,
over-the-center pressure adjustment located
in the center of the heat platen.
Turn the knob clockwise to increase pressure and
counterclockwise to decrease pressure.
Remember to allow for the thickness of your garment when
adjusting the pressure.
WARNING: Structural damage caused by excessive
pressure is not covered under the limited warranty!
Operating Instructions
Printing/Pressing
Once your equipment has reached the designated temperature:
• Position the garment and design
• Lower and lock the heat platen into the PRESS position to
begin the automatic timing process
• The timer will automatically count down and audibly signal
you to lift the heat platen into the UP position when the
print cycle is complete

9WWW.HOTRONIX.COM
Electrical Schematic
- 1800 W for 16 x 20, 10A CBs
- 1800 W for 15 x 15, 10A CBs
- 1000 W for 11 x 15, 10A CBs
240V
- 1800 W for 16 x 20, 20A CBs
- 1800 W for 15 x 15, 20A CBs
- 1000 W for 11 x 15, 10A CBs
120V
- 1800 W for 16 x 20, 20A CBs
- 1800 W for 15 x 15, 20A CBs
- 1000 W for 11 x 15, 10A CBs
230V
US 120V/240V Versions
CE 230 V Version

SERVICE HOTLINE: [phone]
HOTRONIX®
THE MAXX®PRESS Parts Location Guide

11WWW.HOTRONIX.COM
Replacement Parts List
ITEM # PART # DESCRIPTION QTY
1 4-1172-B Control Housing, MAXX 1
3 1-2018 Controller Overlay, MAXX 1
4 1-2105 Grommet, 9/32" ID 3/8" OD 2
5 3-1011-235 Screw, Sheet Metal #6 x 1/2" 6
6 2-1006-50 Nut, #6-32 Hex with Lockwasher 9
7 3-1011-130 Screw, Pan Phillips #4-40 x 1" 2
8 1-1759 Power Inlet 1
9 1-2087 Power Switch 1
10 3-1011-19 Screw, Machine #6-32 x 1/2" 7
11 3-1011-25 Screw, Machine #6-32 x 1/4" 5
12 1-1353 Conduit Fitting, 1/2" Topaz Straight Twist-On 1
13 Kit 3-6946 Controller Kit, MAXX 1
14 2-1006-51 Nut, #4-40 with Tooth Washer 8
15 2-1661 Controller Bracket, STX MAXX 1
16 1-1059 TRIAC 1
17 3-1011-22 Screw, Machine #4-40 x 3/8" 6
18 1-1290 Terminal Block, 5 Contact High Voltage 1
20 1-1211 Proximity Switch 1
21 1-1331 Circuit Breaker 20A (STX XF XRF) 1
23 KIT 3-6904 Handle Assembly MAXX 1
27 1-2094 Steel Pin 1/2" D x 6.45" 2
28 1-1048-3 Washer, 1/2" Nylon 10
29 1-1107-1 Hub Cap 1/2" 8
30 1-2093 Steel Pin, 1/2" x 5.375" 2
31 1-1042-1 All Thread Pin 1
32 1-2096 PVC Spacer 1/2 I.D. x 5" 1
33 1-1540 Foam Grip, Black 1
34 2-1006-2 JCN - NUT 2
35 1-1219 Proximity Magnet 1
36 1-2085-1 Magnet Bracket (MAXX) 1
37 3-1011-232 Shipping Bolt (Thumb Screw), 1/4"-20 x 1/2" 1
38 KIT 3-6901 Base, MAXX 16x20, 15x15, 11x15 2
46 3-1011-252 Screw, Pan Phillips #6-32 x 3/4" 1
47 3-1011-182 Acorn Nut 10-32 4
48 3-1011-164 Screw, Button Socket Head #10-32 x 1/2" 4
49 1-1256 Rubber Foot 5
50 1-2332 Quick Release Clamp, Manual Presses 1
51 2-1006-20 Nut, Hex Nylok 5/16"-18 3
52 1-1939 Ball Stud 10mm 4
54 KIT 3-6951 Pressure Link MAXX 2
56 KIT 3-6903-1 Adjustment Arm Kit, MAXX 1
60 3-1011-215 Soc HD Cap Screw 1/4-20 x 3/8 " 2
61 2-1006-7 Nut, Hex 1/4"-20 Nylok 2
62 3-1011-106 Screw, Button Socket Head 1/4"-20 X 3/4" 2
63 3-1011-55 Screw, Shoulder 3/8" x 1-1/4" w/ 5/16"-18 Thread 1
64 3-6956 Bridle Links MAXX 2
ITEM # PART # DESCRIPTION QTY
65 1-2091 Pin, 1/2" x 3" w/ 1/4-20 Threads 1
66 1-2098 PVC Spacer 1/2 " I.D.x 2.48 2
67 1-2092 Pin, 1/2" x 3-5/8" w/ 5/16"-18 Threads 1
68 1-2114 Steel Spacer 2
69 2-1006-46 Washer, 5/16" SS 2
72 1-2243 Gas Spring 16x20 & 16x16 2
73 3-1199-1 Lower Platen 11 x 15 1
73 3-1086 Lower Platen 15 x 15 1
73 2-1029 Lower Platen, 16x20 1
74 1-1875 Silicone Pad 11 x 15 Gray 1
74 1-1473 Silicone Pad 15 x 15 Gray 1
74 1-1011 Silicone Pad 16 x 20 Gray 1
75 3-1336 Adapter Plate 1
76 1-2215 Quick Release Pin 1
77 2-1006-25 Washer, Flat 1/4" SAE 4
78 2-1006-44 Washer, Split Lock 1/4" 4
79 3-1011-191 Screw, Socket Head Cap 1/4"-20 x 1" 4
80 3-1199 Heat Platen 11 x 15 1
80 3-1320 Heat Platen 15 x 15 1
80 2-1002-3 Heat Platen 16 x 20 1800W Milled 1
81 1-2258 Insulation 11 x 15 1
81 1-2257 Insulation 15 x 15 1
81 1-1020 Insulation 16 x 20 1
82 3-1331-B Heat Platen Cover 11 x 15 MAXX 1
82 3-1337-B Heat Platen Cover 15 x 15 MAXX 1
82 3-1332-B Heat Platen Cover 16 x 20 MAXX 1
84 2-1081 Adjustment Spindle 1
87 1-1012 Adjustment Knob 1
88 3-1011-238 Bolt, Hex Head 5/16-18 x 3-1/2" 1
89 1-2076 Thermostat Disc 1
90 1-1272-1 Temperature Probe 1
91 3-1011-87 Screw, SS Phillips #8-32 X 1/4" 1
92 3-1011-98 Screw, SS Sheet Metal #4 X 1/4" 2
94 3-1011-217 Screw, Flat Head Phillips #10-24 x 7/16" 4
95 1-1063 Washer, Plastic Finishing 4
96 1-1048-2 Conduit, STX & MAXX 11x15, 12" 1
96 1-1048-2 Conduit, STX & MAXX 20/16/15, 12" 1
97 1-1940 Conduit Fitting, 1/2" Elbow 1
200 2-1671 120V Locking Power Cord 1
201 1-2186 220V Power Cord 1
202 2-1672 230V European Locking Power Cord 1
203 1-1279 Lower Platen Spacer 1
204 KIT 3-6924 Platen Lift Kit 1
205 1-2367 Quick Change Keyway (Old Style) 1
206 3-1011-127 Screw, Machine #8-32 x 3/8" Black Oxide 2
207 1-1068 Heater Wire (Not Shown) 1

SERVICE HOTLINE: [phone]
HOTRONIX®
THE MAXX®PRESS CONTACT US
STAHLS’ Hotronix®
One Industrial Park
Carmichaels, PA 15320
U.S.A.
Technical Support
800.727.8520
Speak with a representative
24 hours a day,
7 days a week,
365 days a year.
Customer Service
800.727.8520
Monday – Friday
8am – 5pm EST
Replacement Parts
800.727.8520
8am – 7pm EST
Web
Hotronix.com
This document includes multiple trademarks and describes equipment covered by many
patents that are owned by GroupeSTAHL and/or its subsidiaries. GroupeSTAHL enforces
its rights to protect these intellectual properties.
©
2018
