Hoval Top Tronic T Instruction sheet

EN
Heating controller
Top Tronic®T
Operating constructions
Subject to change without notice
4 204 764 / 00 - 10/05
Hoval Schweiz
Hoval Herzog AG
CH-8706 Feldmeilen
General-Wille-Strasse 201
Telefon 044 / 925 61 11
Telefax 044 / 923 11 39
Hoval Österreich
Hoval Gesellschaft mbH
A-4614 Marchtrenk
Hovalstrasse 11
Telefon 07243 / 550-400
Telefax 07243 / 550-17
Hoval Deutschland
Hoval (Deutschland) GmbH
D-85609 Aschheim-Dornach
Karl-Hammerschmidt Strasse 45
Telefon 089 / 92 20 97-0
Telefax 089 / 92 20 97-77

2
4 204 764 / 00 - 10/05
Overview of contents
Heating system control .......................................................................................................3-35
Operating and display elements
What is the function of the heating controller TopTronic®T? .............................................................................4
Function of the operating elements...................................................................................................................5
What to do if... ...................................................................................................................................................6
Control elements of the boiler control panel.................................................................................................. 7-9
Main settings
Changing the room temperature ................................................................................................10-11
Holiday, absent, constant reduced heating......................................................................................................12
Setting the operating mode ....................................................................................................................... 13-15
Changing the time programs..................................................................................................................... 16-18
Copying of switching times........................................................................................................................ 19-20
Heating curve (heating characteristic)....................................................................................................... 21-22
Domestic hot water settings
Setting the domestic hot water temperature....................................................................................22
Manual domestic hot water reloading..............................................................................................23
Domestic hot water economy temperature .....................................................................................................24
Further settings
Setting the time ...............................................................................................................................................26
Setting the date ...............................................................................................................................................27
Changing between summer and winter time ...................................................................................................27
Setting the language .......................................................................................................................................28
Reloading the standard time program - Deleting the own time program................................................... 29-30
Manual operating mode (in case of faults) ......................................................................................................31
Alarm messages .............................................................................................................................................32
System information
Information key for system temperatures and heating circuit information .......................................................33
Special symbols ..............................................................................................................................................34
Optional accessories.......................................................................................................................................35

3
4 204 764 / 00 - 10/05 Important addresses / System data
Important addresses
and telephone numbers
Technical data
(To be completed by the heating installer) Information for the owner of the system:
Room station available
Number of heating circuits: 1 2 3
Heating circuits Heating curve
value set
Heating circuit HC = _____________ __________
Heating circuit MC1 = ____________ __________
Heating circuit MC2 = ____________ __________
Enable time program P2, P3: yes no
Heating installer
Plumbing installer
Electrical installer
Die Raumstation RS-T Die Raumstation RS-T dient nicht nur zur Fernbe-
dienung Ihrer Heizung sondern misst auch gleich-
zeitig die Temperatur im Wohnraum.
Einstellungen (z.B. Raumtemperatur) können so-
wohl an der Raumstation RS-T als auch direkt am
Kessel Bedienfeld vorgenommen werden.

4
4 204 764 / 00 - 10/05
Heating system control
Function of the operating elements The central rotary pushbutton and the labelled keys are desi-
gned for easy and straightforward operation.
Rotary pushbutton:
Change and store
values
Basic procedure for changing settings
An example
Select the desired function
Turn the rotary pushbutton to
select or change the desired
parameter (flashing word or
number)
Press the Info key at any time
to go back to the basic display
without storing the values set
Press the rotary pushbutton to
store the value set
It is also possible to store the
value using the selected function
key
Function keys
Function keys
Dreh-Drück-Knopf:
Werte verstellen und
speichern

5
4 204 764 / 00 - 10/05 Heating system control
What to do if ...
The following information can be used as a first level support in frequently occurring situations.
Observation
It is too cold
It is too warm
From now on, equal day and night
temperatures should be maintained
continuously
This evening, the heating should
remain on for longer
A larger amount of hot water is
required
From now on, hot water but no hea-
ting is required
Suddenly, there is no heating or hot
water; it is cold.
The room temperature setpoint re-
quires frequent adjustments becau-
se it is too cold or too hot
Today, I will be absent for several
hours during the day
I am travelling for a short period of
time (e.g. 3 days)
I will be travelling for an indefinite
period of time
In summer, it is too cold or too
warm.
Remedy
Set a higher value for the room temperature with and the
rotary pushbutton (see page 16).
Set a lower value for the room temperature with and the
rotary pushbutton (see page 16 and 20).
Set the operating mode to “HEATING” with (page 20).
Set the operating mode to “PARTY” with and set
the desired time (page 19).
Press for 3 seconds and set the additional loading time
(page 29).
Set operating mode to “SUMMER” with (heating
off, hot water only) (page 20).
Check the boiler controller for alarms and consult a heating en-
gineer, if necessary.
Change the set heating curve (page 27).
Changing the heating curve is not sensible if your system is fitted with
a room sensor (or room station) and an outdoor sensor. The correct
settings for the heating curve are then provided automatically
Set the operating mode to “ABSENT TIL” with and set
the return time (see page 19).
Set the operating mode to “HOLIDAY TIL” with and set
the return time (see page 19).
Set the operating mode to “RED. HEATING” with .
When returning, set the operating mode to “AUTOMATIC”
(see page 20).
indicates that the summer disconnection is active.
If it is too cold, set the operating mode to with (see
page 20).
� � �
� � �
� � �
� � �
� � �
� � �






� � �

� � �


6
4 204 764 / 00 - 10/05
1
3
4
8
5
2
7
6
Taste Benennung Funktion
1Daytime room
temperature
Use this function key to change the desired daytime
room temperature page 8
2Reduced room
temperature
Use this function key to change the desired room tem-
perature in the reduced heating mode page 10
3DHW temperaturerUse this function key to set the desired daytime dome-
stic hot water temperature page 20
4Rotary pushbutton Use the rotary pushbutton to select or change the
desired parameters (flashing word or number).
- Clockwise turn (+): increase value
- Counter-clockwise turn (-): decrease value
- Short tap: accept and store the value selected and
displayed
- Pressing for approx. 3 seconds: go to programming
level (level selection)
5- Show the temperatures and hours of operation on
the display
- Return to the basic display without saving the va-
lues,is also possible any time with this function key.
For futher information see page 32
6The heating curve shows the flow temperature of a
heating system as a function of the autdoor tempera-
ture. Use this function key to modify the heating curve.
For further information see page 19
System information key
Heating curve set-up key
Heating system control
Control elements of the boiler control panel

7
4 204 764 / 00 - 10/05
Touche Désignation Fonction
7Operating mode
selection key
 HOLIDAY Turn off the heating system during the holidays (Frost
protection page 10
ABSENT TIL Tamporarily switch off heating page 10
 PARTY TIL Extended heating page 10
 AUTOMATIC Automatic heating according to the preset heating
times page 11
 SUMMER DHW Only DHW Heating off

HEATING
Continous heating mode page 11
 RED HEATING constant reduced heating mode page 11
STANDBY System switched off
Frost protection activated page 11
8Display The basic display shows the day of the week, date and
time of the day, as well as the current boiler tempera-
ture and room temperature (room station).
Possible readouts:
1 Active heating time 24h
2 Weekday display
3 Display of the active operating mode and the clock
programme
4 Time of the day
5 Selected operating mode
6 Date / Day / Month / Year
7 Room temperature (when activated)
2
1
3
4
6
7
5
Heating system control

8
4 204 764 / 00 - 10/05
Heating system control
Main settings
Changing the room temperature
Setting the daytime room temperature
Basic display
Tap the “Daytime room temperature” key
The daytime room temperature
setpoint flashes
Set the desired room temperature by turning the “rotary push-
button”.
- Setting range 5 - 30ºC (Factory setting 20ºC)
The new “Daytime room temperature” setpoint appears on the
display
Tap the “Daytime room temperature” key to confirm the tempe-
rature setpoint
ROOM DAY
-20.0C
ROOM DAY
-22.0C
If “MC1” is shown on the
display, you need to select
the heating circuit.
(Information on which
heating circuit to select for
your home can be found
on page 3 of these instruc-
tions).
MO. 16. AUG.'04
14:00 62.5C

9
4 204 764 / 00 - 10/05 Heating system control
MO. 16. AUG.'04
14:00 62.5C
ROOM NIGHT
-20.0C
ROOM NIGHT
-18.0C
Basic display
Tap the “Reduced room temperature” key
The night time room temperature
setpoint flashes.
Set the desired room temperature by turning the “rotary push-
button”.
- Setting range 5 - 30ºC (Factory setting 16ºC)
The new “Reduced room temperature” setpoint appears on the
display.
Tap the “Reduced room temperature” key to confirm the tempe-
rature setpoint.
If “MC1” is shown on the
display, you need to select
the heating circuit.
(Information on which
heating circuit to select for
your home can be found
on page 3 of these instruc-
tions).
Setting the reduced (night time) temperature

10
4 204 764 / 00 - 10/05
� � �
Holiday, absent, constant reduced heating
Depending on the duration of your absence and what your requirements are in regard to comfort, there
are different operating modes available for interrupting or reducing the heating. In any case you will be
able to save a lot of energy and money if the rooms are not heated or less heated during your absence.
The following table is intended as a guide for finding the best operating mode for each particular case:
Application
You go on holiday for e.g. 1
week and you know the return
date
You leave home in the mor-
ning and come back late in the
evening
You are travelling for an inde-
finite period of time and want
the living area to be at the
set reduced temperature on
return.
You are away for an indefinite
period of time during spring or
autumn and you don’t mind if
your home is cool on return
Operating mode
System is off during holidays
"HOLIDAY TIL"

Heating interrupted temporarily
"ABSENT TIL"

Continuous reduced heating
mode
"RED. HEATING"

System switched off - Frost pro-
tection activated
"STANDBY"

Function
- Heating system OFF / Calorifier
frost protected (5ºC)
- Room temperature set to mini-
mum (10ºC)
Setting range:
current date + 250 days
End of holiday = Return date
0:00 o’clock
Early return
“Press and hold” for 3 sec,
then return to “AUTOMATIC”
mode
Heating temporarily interrupted
until set time
Setting range: 0.5.....24h
Continuous reduced heating and
DHW mode around the clock
The entire heating system is
switched off and frost protected.
No DHW mode!
Heating system control
See following pages for a detailed description on how to set the operating modes.
You can return to the “AUTOMATIC” function (normal heating mode) at any time by “pressing and hol-
ding” for 3 sec

11
4 204 764 / 00 - 10/05

� � �
Heating system control
Tap the “Operating mode” key
The note “OP. MODE” is displayed for a short time
The currently active operating mode is then shown flashing on the
display. An indicator bar at the lower part of the display points to the
corresponding symbol.
Set the desired operating mode by turning the “rotary pushbutton”:
"HOLIDAY TIL” or “ABSENT TIL” or “PARTY TIL"
The selected operating mode is shown flashing on the display
Tap the “rotary pushbutton” to confirm the selected operating mode
Today’s date (“HOLIDAY TIL”) or the current time (“ABSENT TIL”,
“PARTY TIL”) is shown flashing on the display.
Turn the “rotary pushbutton” and select
- for “HOLIDAY TIL”, the date of return from holiday
- for “ABSENT TIL”, the expected return time (within max. 24h).
- for “PARTY TIL”, the time the party is expected to end.
Tap the “rotary pushbutton” to confirm the setting.
Setting the operating mode
Procedure for activating the operating modes “HOLIDAY TIL”, “ABSENT TIL” or “PARTY TIL”.
OP. MODE
AUTOMATIC
HOLIDAY TIL
HOLIDAY TIL
27.08

12
4 204 764 / 00 - 10/05
AUTOMATIK
� � �
Heating system control
Procedure for activating the operating modes “AUTOMATIC”, “SUMMER1” , “HEATING”, “RED. HEATING”
and “STANDBY”
Tap the key “Operating mode”
The note “OP. MODE” is displayed for a short time
The currently active operating mode is then shown flashing on the
display
Set the desired operating mode by turning the “rotary pushbutton”
for example “RED. HEATING”
OP. MODE
AUTOMATIC
RED. HEATING
Tap the “rotary pushbutton” to confirm the setting.
1The operating mode “Summer” can not be selected when each
heating circuit is set up separately.

13
4 204 764 / 00 - 10/05
Operating mode Function
AUTOMATIC

SUMMER

HEATING

RED. HEATING

STANDBY

Automatic control mode according to the heating times set in the 1. time
program
Factory setting:
Heating: 06:00 - 22:00
Reduced heating: 22:00 - 06:00
Domestic hot water: 05:00 - 22:00
DHW mode only
DHW is produced at the times set in the time program (for showering, etc.)
Factory setting for domestic hot water:
05:00 - 22:00
Frost protection is active
Continuous heating mode
The room temperature is not reduced during the night.
DHW is produced at the times set in the time program
Continuous reduced heating mode
The rooms are continuously heated at the “ROOM NIGHT” temperature set-
ting.
No heating mode
Heating system is switched off
There is no heating and no DHW is produced. Frost protection is active.
Heating system control
Info:
Operating mode “Summer” can not
be selected when each heating
circuit is set up separately.

... pro Tag
1 Heizzyklus!
... pro Tag
2 Heizzyklen!
... pro Tag
3 Heizzyklen!
... pro Tag
1 Heizzyklus!
... pro Tag
2 Heizzyklen!
... pro Tag
3 Heizzyklen!
Heating system control
Changing the time programs (heating times)
This function allows creating individual time programs for the heating and DHW modes. After selecting the
respective heating circuit, the factory-set standard program (P1) is loaded and can then be edited individu-
ally.
The standard heating times preset by the manufacturer are, e.g.:
Circuit Day Heating from
All heating circuits
(HC,MC-1,MC-2) Mo-Su 06.00 - 22.00
Domestic hot wa-
ter circuit (DHW) Mo-Su 05.00 - 22.00
Further standard programs can be - or could have been - set-up or enabled for programming by the
installer (P1-P3) see page 18.
A maximum of 3 heating times per day are
Table for recording individual switching times
Time program for living area (MC1)
Day Cycle 1 Cycle 2 Cycle 3
from to from to from to
Mo
Tu
We
Th
Fr
Sa
Su
Time program for living area (MC2)
Day Cycle 1 Cycle 2 Cycle 3
from to from to from to
Mo
Tu
We
Th
Fr
Sa
Su
Time program for living area (HC)
Day Cycle 1 Cycle 2 Cycle 3
from to from to from to
Mo
Tu
We
Th
Fr
Sa
Su
Times program for calorifier (DHW)
Day Cycle 1 Cycle 2 Cycle 3
from to from to from to
Mo
Tu
We
Th
Fr
Sa
Su
per day
1 heating cycle
per day
2 heating cycles
per day
heating cycles
14
4 204 764 / 00 - 10/05

15
4 204 764 / 00 - 10/05 Heating system control
 
0 2 4 6 8 10 12 14 16 18 20 22 24
06.00-22.00
MO-1-
Basic display
Press the “rotary pushbutton” for at least 3 sec.
The note “TIMEPROGRAMS” appears on the display.
Tap the “rotary pushbutton” to confirm
The letters “HC” also appear on the display
Select the heating circuit by turning the “rotary pushbutton”.
(Information on which heating circuit to select for your home can
be found on page 3 of these instructions)
Select Time program P1, P2 or P3, if required - see page 18
Tap the “rotary pushbutton” to confirm the selected heating circuit
Use the “rotary pushbutton” to select the day for which the heating time has to be
modified.
Note: The 3rd heating cycle is omitted if the 2nd heating cycle does
not contain any switching times.
Change - Exit:
Every flashing setting can be corrected using the rotary button, if required, and
accepted by tapping. Use the key to go back one step. Use the key or
wait for approx. 60 sec. to go back to the basic display.
MO. 16. AUG.'04
14:00 62.5C
TIMEPROGRAMS
TIMEPROGRAMS
HC
TIMEPROGRAMS
MC-1
e.g.
� � �

16
4 204 764 / 00 - 10/05
� � �
.......
Heating system control
If P1 is displayed, it means that further standard heating times programs are already enabled. If not, P2
and P3 can be enabled by the heating technician..
Circuit Day Heating from
All heating circuits
(HC,MC-1,MC-2)
Mo-Th
Fr
Sa-Su
06.00-08.00 16.00-22.00
06.00-08.00 13.00-22.00
07.00-23.00
Hot water circuit
(DHW)
Mo-Th
Fr
Sa-Su
05.00-08.00 15.30-22.00
05.00-08.00 12.30-22.00
06.00-23.00
Circuit Day Heating from
All heating circuits
(HC,MC-1,MC-2)
Mo-Fr
Sa-Su
07.00-18.00
reduced
Hot water circuit
(DHW)
Mo-Fr
Sa-Su
06.00-18.00
reduced
Factory setting:
Switching times program P2
Factory setting:
Switching times program P3
 
0 2 4 6 8 10 12 14 16 18 20 22 24
06.00-22.00
MO-1-
 
0 2 4 6 8 10 12 14 16 18 20 22 24
06.00-22.00
MO-1-
 
0 2 4 6 8 10 12 14 16 18 20 22 24
06.00-22.00
SU-1-
 
0 2 4 6 8 10 12 14 16 18 20 22 24
-.---.--
MO-2-
Tap the “rotary pushbutton” to confirm the day.
The currently set heating start time is shown flashing on the display
Set the desired heating start time by turning the “rotary pushbutton”.
Tap the “rotary pushbutton” to confirm the set start time.
Turn the “rotary pushbutton” to set the time setpoint for the end of the
heating mode on the week day shown
The week day is shown flashing on the display. You can now set a
second heating time (Mo -2) for this day by turning the “rotary push-
button”
or
by going directly to Tuesday to set the desired heating time.
Instead of introducing each day separately, you can also use the
“copy” function - see page 25
This function allows you to copy the switching times from any
week day to other days (Mo-Su) or to an entire week (1-7) or to
day groups like working days (1-5) or weekends (6-7).
Once you have completed all the changes, tap the operating mode
key to confirm the settings and open the basic display

17
4 204 764 / 00 - 10/05 Heating system control
COPY
DAY
Basic display
Press the “rotary pushbutton” for at least 3 seconds
The word “TIMEPROGRAMS” is shown on the display.
Tap the “rotary pushbutton” to confirm the selected operating mode.
The note “HC” is also shown on the display.
Select the heating circuit by turning the “rotary pushbutton”.
(Information on which heating circuit to select for your home can be
found on page 5 of these instructions)
Select Time program P1, P2 or P3, if required - see page 24
Tap the “rotary pushbutton” to confirm the selected heating circuit.
The heating time setpoint is shown flashing on the display
Keep turning the “rotary pushbutton”
until “COPY”, “DAY” appears flashing on the display
MO. 16. AUG.'04
14:00 62.5C
TIMEPROGRAMS
TIMEPROGRAMS
HC
TIMEPROGRAMS
MC-1
 
0 2 4 6 8 10 12 14 16 18 20 22 24
06.00-22.00
MO-1-

18
4 204 764 / 00 - 10/05
� � �
Heating system control
Tap the “rotary pushbutton” to confirm the settings
Change - Exit:
Every flashing setting can be corrected using the rotary button
and accepted by tapping. Use the key to go back one step.
Use the key or wait for approx. 60 sec. to go back to the
basic display.
Select the day from which the heating time setting is to be copied by
turning the “rotary pushbutton”.
Note: The 3rd heating cycle is omitted if the 2nd heating cycle
does not contain any switching times
Tap the “rotary pushbutton” to confirm the desired day.
Select the target day(s): Weekdays (MO...SU), whole week (1-7)
Working days only (1-5), weekend only (6-7)
Tap the “rotary pushbutton” to confirm the setting
Confirmation for correct copying of day(s).
Target range for the next copy process is shown flashing on the
display.
Select the next copy range by turning the “rotary pushbutton”.
Target range for the copy process is shown again flashing on the
display.
Use the same scheme to create any additional copies.
After completing all the changes, tap the operating mode key to con-
firm the settings and open the basic display.
COPY
FROM MO
COPY MO
TO
1-5
COPY
DAY OK
COPY MO
TO 6-7
COPY MO
TO
50

19
4 204 764 / 00 - 10/05 Heating system control
Heating curve (heating characteristic)
The slope of the heating characteristic curve generally describes the ratio between variations in the flow
temperature and variations in the outdoor temperature.
HEAT. CURVE
HC  OFF
HEAT. CURVE
HC  OFF
HEAT. CURVE
HC 1.5
Basic display
Press the “Heating curve” key
“Heating curve” display appears
“HC” flashes. In case of several heating circuits you must first
select the relevant circuit by turning the “rotary pushbutton”- see
page 3, Technical data.
Confirm
The slope of the heating characteristic curve is shown flashing on
the display
Select the desired value for the slope of the heating characteristic
curve by turning the “rotary pushbutton”.
The selected slope of the heating characteristic curve is shown
on the display
Recommended settings
Floor heating: 0,3...1,0
Radiator heating: 1,2...2,0
Convector heating: 1,5...2,0
The heating is normally preset by the installer during the commissioning of the heating system. The hea-
ting curve should only be changed in small steps and over longer periods of time.
Heating flow temperature
Outdoor temperature
Heating curve slope
MO. 16. AUG.'04
14:00 62.5C

20
4 204 764 / 00 - 10/05
Heating system control
HEAT. CURVE
MC 1.00
Tap to confirm
Turn the rotary pushbutton to set up further heating circuits, if
required
After completing all the changes, tap the operating mode key to
confirm the settings and open the basic display.
Setting the domestic hot water temperature
Basic display
Settings can be conducted at a room station, if this is available.
Tap the “Domestic hot water temperature” key.
The current DHW temperature setpoint is shown flashing on the
display.
MO. 16. AUG.'04
14:00 62.5C
DHW
DAY 60.0C
